PixelProof — robust AI-generated image detection

TikTok TechJam 2026 · Problem Statement 5 — build a prototype that tells AI-generated images from authentic photographs, and keeps working after the compression, blur, resizing and noise every image picks up in circulation.

Result: Final Score 0.9362 on the organisers' benchmark composition (WildFake vs COCO, resolution-matched), measured on five generator families with zero representation in training — from a 21.7M-parameter ViT, no ensemble, no second branch.

pred is the likelihood the image is AI-generated (0 → authentic, 1 → AI-generated).

---

The task and how it is scored

From the briefing deck:

• Primary metric: ROC-AUC — threshold-free, robust to class imbalance. "Clean accuracy is the #1 way to fool yourself."
• Final Score = 0.5 · AUC(clean) + 0.5 · AUC(robust), where AUC(robust) is the mean ROC-AUC over the 14 required transform conditions.
• Cross-generator test — evaluate on generators not in training. That is the real generalisation test, and every number in this README is measured that way.
• No hard FPR/FNR bar is set by the organisers; the scored quantity is the Final Score.

The 14 required transforms (deck slide 11)

Implemented once in detector/transforms.py and used identically for training augmentation and evaluation.

---

Results

All held-out. The organiser composition is the reporting number.

The SID_Set row is the hardest of the three because it includes tampered images — real photographs with a locally edited region — which this detector is not built for: it answers "was this image generated?", not "was part of it edited?". It is reported anyway rather than dropped.

Per-generator ROC-AUC on the organiser set (all five are pixel-space diffusion; none appear in training):

ADM and DDPM are the hard cases and the reason for a deliberate data choice: pixel-space diffusion leaves no VAE fingerprint for a latent-diffusion-trained detector to key on. Adding 5,000 GenImage ADM/GLIDE images to training moved ADM's clean AUC from 0.478 — below chance — to 0.937.

Robustness — the 15-condition matrix

Operating threshold 0.51 (calibrated on withheld generators). The Final Score is threshold-free; FPR/FNR are shown for completeness.

Weakest conditions: JPEG q30 and sensor noise σ0.10 (both AUC 0.830) — heavy re-compression and additive noise are the two transforms that most directly overwrite the high-frequency evidence detectors lean on. Note the floor: even there, AUC stays well above chance. Regenerate this table for any checkpoint with bash evaluate.sh <ckpt> <tag>.

Error analysis

Authentic COCO photos the detector was surest were AI — all high-contrast, low-noise studio shots whose statistics resemble the "too clean" look of a generator.

AI images (all ADM/DDPM — 2021-era pixel diffusion) the detector was surest were real. ADM's iterative denoising leaves almost no spectral fingerprint, and the content is plausible ImageNet fauna/objects.

Full note, per-condition FPR/FNR, and the file lists: docs/ERROR_ANALYSIS.md.

---

How it works

Community Forensics ViT-S/16 @224   21,666,049 params   → logit → P(AI)

That is the whole model. The interesting work is in the two things feeding it — the preprocessing and the corpus — which is exactly what deck slide 10 predicts: "the biggest lever isn't a fancier model — it's what you train on." We took that literally, and then tested it.

• Backbone — OwensLab/commfor-model-224 (timm vit_small_patch16_224.augreg_in21k_ft_in1k). A purpose-built AI-image detector; an independent 2026 benchmark ranks it #1 of 23 open detectors.
• Crop from native pixels, never resize (SAFE, KDD 2025) — Resize(256) is a low-pass filter: it destroys the high-frequency artifact before the model ever sees it. We crop 224×224 out of the original resolution instead.
• SAFE augmentation — RandomRotation(180) + 16px patch masking, which kill the colour and semantic shortcuts a detector will otherwise learn instead of the artifact.
• Corpus built for the failure mode, not for the score — 66,502 images: SID_Set full-synthetic + 17 DRAGON generators + Community-Forensics-Small (LatDiff / GAN / PixDiff / Other, for architecture diversity) + 5,000 GenImage ADM/GLIDE. That last piece exists solely because our own error analysis showed pixel-space diffusion was where the detector was blind.
• 21.7M params — 92× under the 2B limit. Runs on a laptop CPU at ~0.3 s/image for the forward pass (measured, 14 threads; ~0.5 s end to end including decode); the bundled demo_images/ score 6/6 correct there.

What we tried that did not work (measured, not guessed)

This is the part we'd most want a judge to read. Three separate attempts to add a second branch, across two independent implementations, all failed to transfer — and the failures are what justify the simple final architecture.

The pattern: an auxiliary branch's value is bounded by what the base ViT is still missing. On a weaker base (no native-crop, no pixel-diffusion data) a frozen CLIP branch is worth ~+0.02 Final Score. On the base described above, it is worth nothing measurable — the training-side fixes had already closed the gap it was compensating for. So we shipped the model without it: same accuracy, ⅕ the parameters, one checkpoint, no separate fusion-head training pass.

Full ablation tables and the reasoning at each step: docs/EXPERIMENTS_LOG.md.

The bug we found in our own benchmark

Our first organiser-set score was 0.8131. Then a size-only probe — a "classifier" that sees nothing but the image's pixel count — scored AUC 1.000 on that set. WildFake ships fakes at fixed 256×256; COCO reals are photographic resolutions. Every fake was smaller than every real, so the set was partly measuring file headers, not detection.

We rebuilt it by centre-cropping both classes to a common native size (size-only AUC → 0.500) and re-scored. The honest number was 0.7007, and we published the correction rather than the flattering original. Every result in this README is measured on the corrected set.

---

Trade-offs (the deck asks for this explicitly)

• Robustness vs clean accuracy — training on a harder, more diverse corpus lowered seen-validation AUC (0.9866 → 0.9807) while raising held-out organiser Final Score (0.8804 → 0.9362). We optimised the number that generalises, not the one that looks best in training.
• Generalisation vs specialisation — five generator families are held fully out of training. A detector tuned on them scores higher on this benchmark and breaks on the next generator. We optimised for the break.
• Complexity vs feasibility — we had a 108M two-branch variant that scored identically (0.9362) and shipped the 21.7M single-branch one instead. The deck: "a 2-branch ensemble may win 1% but cost you the demo — ship what runs." Here it won 0.0000, so the choice was easy.
• One threshold vs the generator spread — pixel-diffusion fakes score systematically lower than latent-diffusion fakes, so no single cutoff is optimal for both (organiser FNR is 16.3% at the calibrated threshold vs 3.5% on DRAGON). The scored metric is threshold-free; detector/calibrate.py lets an operator refit per deployment.
• False positives are the expensive error — flagging a real photo as AI is worse for a platform than missing one fake. Clean FPR is 6.7% and we report it at every condition rather than only the AUC.

There is no silver bullet — modern flow/DiT generators (SD3, Flux, Firefly) are the frontier where every open detector still collapses, and they are named honestly in Limitations.

---

Rules compliance (deck slide 14)

Scope (slide 17): image-level binary detection only — no video/audio, no production deployment, no localisation. Consistent with this project.

---

Try it (2 minutes)

Fastest path — score a folder in one command. No flags, no menu, no prompts. It downloads the weights itself on first run:

pip install -r requirements-cuda.txt      # NVIDIA / CPU
python inference.py <folder_of_images>    # → predictions.json

That is the whole thing. python inference.py demo_images scores the six bundled samples and should return 6/6 correct on CPU in about ten seconds.

Or do it by hand:

1 — set up the environment (Python 3.10–3.12):

python -m venv .venv
# Windows:  .venv\Scripts\activate      Linux/macOS:  source .venv/bin/activate
pip install -r requirements-cuda.txt          # NVIDIA / CPU

2 — predict a folder of images (the required deliverable format):

python pipeline.py predict \
  --input demo_images \
  --output predictions.json \
  --checkpoint checkpoints/detector.pt \
  --device auto

Both entry points write the same two files:

// predictions.json
[{"image_path": "...", "pred": 0.9993, "label": 1}]

Matching the brief: "a confidence score for each image, indicating the likelihood that it is AIGC-generated ... a JSON file containing image_path and pred". pred is that likelihood — a float in [0, 1], not a rounded label. This matters for scoring: ROC-AUC computed over 0/1 predictions collapses into a step function and understates any model. label carries the thresholded call for consumers that want a decision rather than a score, and predictions.scores.csv repeats the probability alongside confidence for spreadsheet use.

checkpoints/detector.pt is ~87 MB and not in git (large binary). inference.py fetches it automatically from the v1.0 release; the direct link is in that release if you would rather download it by hand.

3 — the interactive demo:

pip install fastapi uvicorn python-multipart
DETECTOR_CHECKPOINT=checkpoints/detector.pt uvicorn webapp.server:app --port 8000
# open http://localhost:8000

Three views: single image (verdict + confidence band), robustness grid (that image re-scored under all 15 conditions), batch (drop a folder → sorted table + CSV, up to 200 images).

4 — a public URL for a judging session (free, no account, temporary):

powershell -ExecutionPolicy Bypass -File serve_demo.ps1

Prints a https://<...>.trycloudflare.com link; Ctrl+C stops it.

5 — check what is on screen, in the browser you already use (optional):

Load extension/ at chrome://extensions → Developer mode → Load unpacked, paste the detector URL into its popup, then click Check main image in the corner of any page (or press Alt+Shift+A, or right-click → Check the main image on this page).

It ranks candidates by visible area weighted toward the centre of the viewport, so on a social feed it reads the post rather than the sidebar thumbnails and avatars, and it rings its choice on the page so you can see what it picked before you trust the number. Video works too — there is no image URL to fetch and a canvas frame grab is blocked by cross-origin tainting, so it crops a screenshot of the tab. That path is labelled "from screen capture" in the panel, because a frame already scaled by the browser and already through the site's codec is weaker evidence than an image's original bytes — which is the same finding the detector itself is built on.

extension/README.md has the bands, the limits, and the six bugs the browser tests caught.

Verify the smoke test (synthetic data, no dataset needed):

python pipeline.py smoke --device auto

---

Reproduce the training

Three steps, all from this repo — nothing is archived elsewhere.

# 1. build the corpus (streams from HuggingFace; ~66.5k images on disk)
python scripts/build_corpus.py     # SID_Set + DRAGON-17 + CF-Small + GenImage

# 2. train (10 epochs, ~3.5 h on an RTX 3050)
python pipeline.py train --config config.yaml

# 3. score every held-out set + regenerate the tables and montages
bash evaluate.sh checkpoints/detector.pt detector

config.yaml as committed is the exact configuration that produced the shipped checkpoint — crop_from_native: true, safe_augment: true, samples_per_epoch: 24000. Step 2 reads it, trains detector/, and calibrates the threshold on withheld generators, never the test set.

Data — all public: saberzl/SID_Set (the tampered class is dropped — localised editing, out of scope), lesc-unifi/dragon (17 generators in training, 8 held out), OwensLab/CommunityForensics-Small (latent-diffusion + GAN + pixel-diffusion, with LAION/ImageNet/CelebA/COCO reals), and bitmind/GenImage_ADM + bitmind/GenImage_glide. scripts/build_eval_set.py builds the resolution-matched evaluation set.

---

Repository layout

inference.py          THE entry point: python inference.py <folder> → predictions.json
pipeline.py           ingest · train · evaluate · predict · smoke · materialize-sid-set
config.yaml           the exact training configuration behind the shipped checkpoint
detector/             model · data · transforms · training · evaluation · calibration
scripts/              corpus builders, matched-set builder, shortcut probe, stream-eval
webapp/               FastAPI demo — single · 15-condition robustness · batch
extension/            Chrome extension (MV3) — right-click → check the main image
serve_demo.ps1        one command → a public Cloudflare-tunnel URL
evaluate.sh           full 15-condition eval + FP/FN montages for a checkpoint
docs/                 error-analysis note, FP/FN montages, full experiment log
demo_images/          six labelled samples (4 AI, 2 authentic) to try it on
requirements*.txt     cuda / cpu

Env vars the scripts honour: PYTHON, TTJ_DATA, DEVICE, HF_HOME, SYCL_CACHE_DIR, DETECTOR_CHECKPOINT, DETECTOR_DEVICE.

---

Threshold calibration — the 5-way split

python -m detector.calibrate runs/<name>/best.pt \
  --genval <dir> --calval <dir> --rule minmax_fpfn --apply

Calibrating on held-out generators instead of val took recall on unseen fakes from ~25% to ~98% with no change to AUC — it fixes the operating point, not the model.

---

Limitations

• JPEG q30 and sensor noise σ0.10 are the weakest conditions (both AUC 0.830) — the two transforms that most directly erase high-frequency evidence.
• DDPM and ADM (2021 pixel-diffusion) remain the hardest families (robust AUC 0.855 / 0.870) even after adding pixel-diffusion training data.
• Modern flow / DiT generators (SD3, Flux, Firefly) — the frontier where every open detector still collapses; not in this evaluation.
• Localised edits (a real photo with one AI-generated region) are out of scope — whole-image classification only, which is why the mixed SID_Set number (0.8481) is the lowest of the three we report.
• One fixed threshold cannot be optimal across pixel-space and latent diffusion at once — the score is threshold-free and the recipe is shipped.
• The margin over a two-branch variant is not statistically meaningful. 0.9362 vs a 108M-parameter alternative at 0.9362 on a 2,000-image set is a tie; we chose the smaller model on parameter count and reproducibility, not on a claimed accuracy win.
• This is a hackathon prototype, not a production moderation system.

---

What we would improve given more time

Ranked by what we believe would actually move the number, based on where the measurements point rather than on what sounds impressive.

1. Train on pixel-space diffusion properly. Adding 5,000 GenImage ADM/GLIDE images moved ADM from 0.478 to 0.937 — the single largest gain in the project, from the smallest slice of the corpus. That curve had not flattened when we ran out of time. More pixel-diffusion families, and more of each, is the most clearly-indicated next step.
2. Attack the two weakest conditions directly. JPEG q30 and noise σ0.10 both sit at 0.830 while everything else is above 0.87. Curriculum augmentation weighted toward severe compression and additive noise targets exactly that gap instead of raising the average uniformly.
3. A second opinion for the borderline band. The model is decisive on most images; the errors concentrate near the decision line. A cheap second stage invoked only for the ~10% of images in that band would cost little average latency and is where the remaining false positives live.
4. Test-time augmentation. Averaging predictions over a few crops is a known robustness gain we measured as unhelpful on 32×32 data early on, and never re-tested after moving to native-resolution training — where the original objection no longer applies.
5. Flow and DiT generators. SD3, Flux and Firefly are the frontier where every open detector still collapses, and none appear in our evaluation. We would rather state that plainly than quietly omit it.

We would also replace the dHash contamination check described below with a proper perceptual-hash sweep, and re-run the SID_Set evaluation split by full_synthetic versus tampered so that number stops conflating two tasks.

Evaluation hygiene

The brief specifies that COCO val2017 and DALL·E Advanced must not be used in training. None of our four training sources draws from them, and we checked rather than assumed: a difference-hash comparison of all 26,361 training reals against the 1,000 COCO images in our evaluation set found no genuine duplicate. Thirteen apparent collisions all mapped to a single near-uniform eval image (pixel std 12.3) whose hash is degenerate; direct comparison put those pairs 45/255 apart in mean absolute pixel difference — different photographs.

Separately, detector/data.py:assert_not_eval_only hard-fails if a path marked eval_only_* reaches training or calibration, so the guarantee is enforced in code and not only by convention.

Team contributions

• Kireeti — evaluation harness and the resolution-shortcut discovery, corpus design and build pipeline (scripts/build_corpus.py), the native-crop + SAFE training recipe, iteration 5a/5b/6a/6b and the ablations behind them, inference.py, the web demo, and this documentation.
• Ziyang — the iteration-1 to iteration-4 line that established the Community-Forensics-Small corpus and the iter4 baseline, the shortcut probe and matched-evaluation builder this project's evaluation is descended from, the frozen CLIP-B branch tested as iteration 6b, and the webapp's original batch-scoring and robustness endpoints.

(Replace or extend these lines with the split your team agrees on — they are recorded here from the commit history, which is the only record this repository has.)

License

Code and released weights: Apache-2.0. Backbones are used under their own public licenses (OwensLab/commfor-model-224, Apache-2.0).

Training-data note, stated plainly: one of the four training sources, Community-Forensics-Small, is licensed CC-BY-NC-SA-4.0 — non-commercial, share-alike. Model weights are not a derivative work of the training data under most readings, and this is a research/hackathon artifact, but anyone considering commercial use should evaluate that themselves rather than rely on the Apache-2.0 tag alone. SID_Set, DRAGON and GenImage carry no such restriction.
