QueryAPIGate

Turn SQL queries into secure, governed REST APIs.

QueryAPIGate was previously named SQL2API. Upgrading? See Upgrading from SQL2API for what changed.

Full documentation

QueryAPIGate is a self-hosted, single Flask service that runs SQL against your databases and returns the results as JSON, NDJSON, XML, YAML, CSV, TSV or Excel. Save a query once and it becomes a versioned endpoint with typed, injection-safe parameters and run history - without writing a controller, a repository layer, pagination, auth or serialization boilerplate for it.

Write SQL. Configure the query. Apply access controls. Get an API.

$ curl 'http://127.0.0.1:5000/q/example_film_search?text=Harbor&page_size=2'
[{"film_id":48,"title":"Broken Harbor","category":"Action","rating":"PG-13"},{"film_id":44,"title":"Electric Harbor","category":"Documentary","rating":"G"}]

$ curl 'http://127.0.0.1:5000/q/example_top_films?top_n=2&category=Comedy&format=csv'
title,category,rating,rentals,rank
Electric Signal,Comedy,PG,977,1
Crimson Garden,Comedy,PG-13,631,2

_{The built-in admin UI at /ui - syntax highlighting, a schema browser and one-click query history, no separate tool to install.}

---

Why QueryAPIGate?

Organizations often have valuable SQL sitting inside reports, BI dashboards, ETL pipelines, ad-hoc analysis and application code, with no path to a REST endpoint except writing a backend service around it.

              SQL Query
                  |
                  v
          +------------------+
          |   QueryAPIGate   |
          |                  |
          | Parameters       |
          | SQL Guard        |
          | Permissions      |
          | Rate Limiting    |
          | Caching          |
          | Connection Pool  |
          | Streaming        |
          | Observability    |
          +--------+---------+
                   |
                   v
               REST API
                   |
          +--------+--------+
          v        v        v
        JSON      CSV      XLSX

If you already know SQL, you can produce a governed API without building an API application around it.

---

Key features

Multi-database support

Native drivers for MySQL, PostgreSQL, ClickHouse, SQLite, H2 and DuckDB, plus generic JDBC for anything else with a driver jar - Oracle, SQL Server, DB2, Snowflake and more. The same guard, pooling, parameter binding and output formats apply regardless of which database is behind a given connection.

Security and access control

QueryAPIGate is built to expose specific query results, not database credentials:

• API key authentication, with hashed key storage (SHA-256, never the raw secret) in api_keys.json.
• Database connection passwords encrypted at rest (QUERYAPIGATE_SECRET_KEY), decrypted only in memory at the moment a connection is opened; a literal password on disk is never returned to a client either way.
• Scoped API keys: restrict a key to a set of connections, and/or to a specific allow-list of saved queries, independent of any connection grant - individual queries in that list can also be curated for write access, without granting it anywhere else reachable through the key.
• Example APIs: queryapigate examples load installs four worked scenarios - a reporting API, dashboard data, a streaming export and a partner integration - as collections, queries and roles you can run and remove again, touching nothing of yours.
• Collections: file saved queries into named groups and grant a key a whole group - read-only, live, and every move that changes who can reach a query is audited with the keys that gained or lost access. Rename a collection without any key losing reach part-way; export one as a portable bundle and import it elsewhere.
• Named permission roles: a reusable template (connections, write access, queries, collections, rate limit, allowed IPs) copied onto a key once at creation, so a shared grant set for many keys lives in one place - editing or deleting a role afterward never affects a key already created from it.
• Read-only by default; write access (INSERT/UPDATE/DDL) is off unless explicitly enabled server-wide or granted per key, and can be narrowed further to specific write operations a key may perform.
• API key expiry (TTL) and revocation.
• Per-key rate limiting, on top of the server-wide, IP-based limit.
• IP allowlisting per key: pin a key to specific addresses or CIDR ranges.
• A row ceiling for streaming exports (QUERYAPIGATE_STREAM_MAX_ROWS), unbounded by default.
• A SQL guard that only allows single SELECT/WITH/SHOW/DESCRIBE/EXPLAIN statements through by default, with bound :name parameters rather than string-concatenated SQL.

API Consumer
     |
     | API Key
     v
  QueryAPIGate
     |
     +-- Authentication
     +-- Authorization (connections + saved queries)
     +-- SQL guard
     +-- Rate limiting
     +-- Execution
     |
     v
  Database

This lets an organization hand an external client a key that can only ever reach one named query - never arbitrary SQL and never a whole connection - while internal callers keep broader, connection-level access.

Saved, versioned queries

A saved query bundles SQL, name, description, parameters, author, version, permissions and (optionally) cache configuration into one addressable resource: GET /q/<name>. Saving again under the same name creates a new version rather than overwriting the old one, so a change to the SQL doesn't silently change what's already live; ?version=1 still runs the prior one, and each run is recorded in the query's execution history.

Bound query parameters

SELECT * FROM film WHERE film_id = :id

GET /q/film_by_id?id=7

Values are sent to the database separately from the SQL text, so they cannot be injected into it. Parameters can declare a type, default, required/optional, enum, numeric range, length and pattern - invalid input is rejected with a field-by-field 400 before it reaches the database.

Multiple response formats

JSON, NDJSON, XML, YAML, CSV, TSV and XLSX are all available per request (?format=), so the same saved query serves both application clients and reporting/export use cases.

Pagination and streaming

?page=2&page_size=50 pages results with X-Has-More telling the caller whether more exist. For full exports, ?stream=true&format=csv (or tsv/ndjson) streams the entire result straight from the database cursor rather than buffering it - verified end-to-end with 1,000,000-row results and flat server memory throughout (MySQL, PostgreSQL and ClickHouse); see Streaming exports for the measured numbers. queryapigate export <query> --out '/exports/{name}_{date}.csv' wraps the same streaming path as a CLI command for cron/systemd/Kubernetes CronJob to call directly - no server needs to be running; see Scheduled exports to a file.

Query caching

Saved queries can opt into HTTP-level caching: cache_ttl, Cache-Control, ETag, conditional requests and 304 Not Modified, plus an X-Cache: HIT/MISS header. Never applied to a query that writes.

Rate limiting

A server-wide, IP-keyed limit (QUERYAPIGATE_RATE_LIMIT) and an independent, optional per-key limit can both be in effect at once - a request has to pass both. This lets different API consumers get different budgets:

Internal dashboard  -> generous server-wide limit, no per-key limit
Partner key          -> 200/hour of its own
Trial key             -> 20/hour of its own

Observability

Structured JSON logs (QUERYAPIGATE_JSON_LOGS) tagged with a request ID, per-query execution timing, slow-query warnings (QUERYAPIGATE_SLOW_QUERY_THRESHOLD), and Prometheus metrics at /metrics covering request/query counts and latencies, connection-pool occupancy and rate-limit rejections.

OpenAPI

/openapi.json is a complete, valid OpenAPI 3.0 document (checked in CI against the official validator) with every saved query listed as its own typed endpoint; /docs serves it through Swagger UI. A key's endpoint list is filtered to what that key can actually reach, so a query-scoped external key sees only its approved queries.

Administration UI

A built-in UI at /ui covers the whole workflow: connection management, a SQL editor with syntax highlighting and schema browsing (click a table/column to insert it), query execution and preview, EXPLAIN, saved-query and version management, API key management, an audit log of administrative changes, per-query execution history, response inspection with a collapsible JSON tree for non-tabular results, a quick bar chart of any numeric result, and one-click "copy as curl" / "copy as TSV" for any result.

The UI has a collapsible sidebar (Data, Access, Observability; Ctrl+B toggles it) and a read-only Settings screen that shows every environment variable, its effective value and whether it was set or is the default (secrets are reported as configured or not, never shown), with a "Copy as .env" button. Theme, table density and the default result format are per-browser preferences.

Connect Database
       |
       v
   Write SQL
       |
       v
  Test Query
       |
       v
  Save Query
       |
       v
Configure Access
       |
       v
  Expose API

Testing and quality

Unit tests, integration tests against real MySQL, PostgreSQL, ClickHouse and H2 servers (run in CI against service containers), DuckDB integration tests that run unconditionally since it's embedded, SQL-guard fuzz testing with Hypothesis, static type checking with mypy, linting with ruff, and CI on every push. See Development below.

---

Architecture

                         +---------------------+
                         |     API Client      |
                         +----------+----------+
                                    |
                                    v
                         +---------------------+
                         |    QueryAPIGate     |
                         |                     |
                         | Authentication      |
                         | Authorization       |
                         | Rate Limiting       |
                         | SQL Guard           |
                         | Parameter Binding   |
                         +----------+----------+
                                    |
                                    v
                         +---------------------+
                         |   Query Manager     |
                         |                     |
                         | Saved Queries       |
                         | Versions            |
                         | Cache               |
                         | API Metadata        |
                         +----------+----------+
                                    |
                                    v
                         +---------------------+
                         | Database Abstraction|
                         |                     |
                         | MySQL               |
                         | PostgreSQL          |
                         | ClickHouse          |
                         | SQLite              |
                         | H2                  |
                         | DuckDB              |
                         | JDBC                |
                         +----------+----------+
                                    |
                                    v
                              Database

---

Best use cases

Internal data APIs. Expose internal data to web apps, mobile apps, internal tools and other engineering teams without building a service per query:

GET /q/film_by_id?id=7
GET /q/example_top_films?top_n=5&category=Comedy

Reporting APIs. Turn an existing analytical SQL report into a reusable endpoint that dashboards or scheduled jobs can call directly, in JSON or as a CSV/XLSX export.

Partner and external-client integrations. Give a partner an API key scoped to a curated list of saved queries, with its own rate limit and expiry, instead of database credentials:

Partner --API Key--> QueryAPIGate --queries grant--> Database

Data engineering to application engineering. Data teams write and version the SQL; application teams consume it as a normal REST endpoint, without either side depending on the other's deploy cycle.

Data export. Stream large results as CSV, TSV, XLSX, JSON or NDJSON without loading the whole result into memory first.

Rapid prototyping. Get a working, parameterized API around an existing query for a proof of concept or internal tool without standing up a backend application for it.

---

How QueryAPIGate differs

QueryAPIGate's primary abstraction is the SQL query as an API resource, not the schema as a whole - so it fits well when an API should expose one specific, curated query rather than automatically surface an entire database.

---

Philosophy

Your database already contains the data logic. The goal isn't to replace application backends; it's to remove repetitive boilerplate when the actual requirement is "expose this query safely as an API" - existing SQL, plus governance, is the API.

---

Install

pip install "queryapigate[postgres]"         # pick the drivers you need: mysql, postgres, clickhouse, h2, duckdb
# or everything:                        pip install "queryapigate[all]"

SQLite needs no extra driver. H2 and generic JDBC connections (queryapigate[h2]) also need a Java runtime; H2's own driver jar is bundled, a JDBC connection to another vendor brings its own. DuckDB (queryapigate[duckdb]) needs no external runtime either - it's a native Python extension, same as SQLite. queryapigate[encryption] adds encryption at rest for connection passwords - only needed if you set QUERYAPIGATE_SECRET_KEY. From a clone: pip install -e ".[dev]". Or use Docker - see below.

Quick start

Fastest: queryapigate examples load && queryapigate serve installs four worked example APIs (reporting, dashboard, export, partner) you can try, and queryapigate examples unload removes them again.

queryapigate examples load
queryapigate serve                            # http://127.0.0.1:5000

The examples come with a small generated examples database (films, customers and rentals), so you can also run ad-hoc SQL straight away:

curl -X POST 'http://127.0.0.1:5000/execute_sql?page_size=3' -H 'Content-Type: application/json' \
     -d '{"sql": "SELECT film_id, title, rating FROM film WHERE film_id > :min", "params": {"min": 10}, "connection_name": "examples"}'

Open http://127.0.0.1:5000/docs for the interactive API reference, or http://127.0.0.1:5000/ui for a small admin UI to manage connections and saved queries and run ad-hoc SQL without leaving the browser.

For your own databases, run queryapigate init in an empty folder: it creates db_connections.json (inactive templates for every supported database) and saved_sql/. Edit the file, set "active": true, and start the server there.

Saving a query as an endpoint

This uses the examples connection that queryapigate examples load sets up:

curl -X PATCH http://127.0.0.1:5000/save_sql_to_file -H 'Content-Type: application/json' -d '{
  "filename": "film_by_id",
  "sql_query": "SELECT * FROM film WHERE film_id = :id",
  "query_parameters": {"id": {"type": "int", "min": 1, "max": 60, "description": "Film id"}},
  "connection_name": "examples",
  "author": "me", "description": "Look up a film"
}'

curl 'http://127.0.0.1:5000/q/film_by_id?id=7&format=yaml'
curl 'http://127.0.0.1:5000/q/film_by_id?id=0'
# {"error": "Invalid parameters: id must be at least 1", "errors": {"id": "must be at least 1"}}

Rules: type (int, float, str, bool), default, required, enum, min/max, min_length/max_length, pattern and description - see the API reference.

Saving again under the same name adds version 2; DELETE /saved_sql/film_by_id?version=1 removes one version.

Add "cache_ttl": 60 to cache a response for that many seconds (X-Cache: HIT/MISS, ETag, Cache-Control) - opt-in, and never used for a query that writes. See Response caching.

Configuration

Everything is configured through environment variables (all optional):

Security and production considerations

QueryAPIGate runs whatever SQL it is given against your databases, so it ships locked down and expects you to finish the job:

• Set QUERYAPIGATE_API_KEY and serve over TLS (put it behind a reverse proxy). It's a full-access admin key; for anyone who only needs to run queries against specific connections, create a scoped key instead (POST /api_keys, admin only) - see documentation/API.md. For an external client that should only reach a curated handful of saved queries and nothing else, scope the key to those query names specifically (queries) instead of a whole connection - see Per-saved-query access.
• Connect with a database account that only has the privileges the API needs - the read-only guard is defence in depth, not a replacement for grants. (H2's driver cannot enforce read-only, so H2 relies on the guard.)
• Use bound :name parameters. The older {name} placeholders paste text into the SQL and are therefore restricted to numbers and plain text.
• Saved-query files are only read from saved_sql/; passwords are never returned by the API.
• Set QUERYAPIGATE_SECRET_KEY to encrypt connection passwords at rest instead of relying solely on the ${VAR} convention - keep the key itself outside db_connections.json and out of version control, the same as any other credential; there is no way to recover an encrypted password without it.
• Set query timeouts and result-size expectations deliberately (QUERYAPIGATE_QUERY_TIMEOUT, QUERYAPIGATE_MAX_PAGE_SIZE), enable rate limiting, and route logs and /metrics into your existing monitoring.
• Plan for backup and recovery of db_connections.json, saved_sql/ and api_keys.json (QUERYAPIGATE_HOME), and put QueryAPIGate behind your normal reverse-proxy/TLS-termination setup rather than exposing it directly.

See SECURITY.md to report a vulnerability.

Calling the API from a browser

Browsers refuse cross-origin JSON calls unless the server allows them. List the sites that may call the API:

QUERYAPIGATE_API_KEY=change-me QUERYAPIGATE_CORS_ORIGINS=https://app.example.com queryapigate serve

Preflight checks are answered automatically, and the pagination headers (X-Has-More etc.) are exposed to the page's JavaScript. CORS only tells the browser which sites may call; it is not authentication, so keep the API key. Avoid * without a key: any website a visitor opens could then reach your databases through their browser (the server logs a warning if you start that way).

Rate limiting

QUERYAPIGATE_RATE_LIMIT=60/minute gives each client address a bucket of 60 requests that refills steadily, so short bursts work but the sustained rate is capped. Over the limit, requests get 429 with a Retry-After header, and every response carries X-RateLimit-Limit and X-RateLimit-Remaining. The limit is applied before the API key check, so guessing keys is throttled too; /health and CORS preflights are never counted. State is per process: with several workers, the effective limit is multiplied by the number of workers.

An API key can also carry its own rate_limit (same grammar), checked in addition to the server-wide limit, never instead of it - a request has to pass both. See Per-key rate limiting.

Docker

Every release is published to GitHub Container Registry for linux/amd64 and linux/arm64:

docker run -p 5000:5000 -v queryapigate-data:/data -e QUERYAPIGATE_API_KEY=change-me ghcr.io/anantharajuc/queryapigate:latest

The container keeps db_connections.json and saved_sql/ in /data (create a starter with docker run --rm -v queryapigate-data:/data ghcr.io/anantharajuc/queryapigate queryapigate init). The named volume above works out of the box. To use a folder on the host instead (-v "$PWD/data:/data"), create it yourself first (mkdir data) and make sure it is writable by uid 1000, the container's user - a folder that Docker creates for you is owned by root, which the container cannot write to (or run with --user "$(id -u):$(id -g)"). It runs as a non-root user under gunicorn with one worker (the files are protected by an in-process lock) and a health check on /health. Behind a reverse proxy or load balancer, set QUERYAPIGATE_TRUST_PROXY=1. To build it yourself: docker build -t queryapigate . (add --build-arg WITH_H2=true for H2).

Try it with one command

docker-compose.yml starts QueryAPIGate in front of a PostgreSQL database seeded with sample films:

docker compose up --build
curl -H 'X-API-Key: demo-key' 'http://127.0.0.1:5000/q/films_by_rating?rating=PG&max_length=90'

Open http://127.0.0.1:5000/docs, paste demo-key into the box at the top, and both saved queries appear as endpoints. The demo listens on localhost only, mounts its configuration read-only, and reads the database password from an environment variable (${DEMO_DB_PASSWORD} in demo/data/db_connections.json). Clean up with docker compose down -v.

API overview

Full details are in documentation/API.md.

Client SDKs

/openapi.json is a complete, valid OpenAPI 3.0 document (checked in CI against the official validator), so a typed client for Java, TypeScript, Go, or any of the ~50 languages openapi-generator supports costs nothing in application code - generate it from the running server's own spec:

npx @openapitools/openapi-generator-cli generate \
  -i http://127.0.0.1:5000/openapi.json -g java -o clients/java
# or: -g typescript-fetch, -g go, -g python, ...

This is deliberately not something QueryAPIGate ships pre-generated: the spec already includes every saved query as its own typed /q/<name> endpoint (see Quick start above), so a client generated against your server reflects your saved queries, not a generic snapshot.

Development

pip install -e ".[dev]"
ruff check .
mypy queryapigate
python -m unittest discover -s tests -t .

The integration tests in tests/test_integration.py run against real MySQL, PostgreSQL, ClickHouse and H2 servers when the matching QUERYAPIGATE_IT_* variables are set, and are skipped otherwise; CI runs them against service containers. DuckDB's integration tests need no such variable - being embedded, they run unconditionally whenever the duckdb package is installed. tests/test_sql_guard_fuzz.py fuzzes the SQL guard and parameter binder with Hypothesis. See CONTRIBUTING.md for the pull request process, CHANGELOG.md for what changed, and BACKLOG.md for what's planned, in priority order.

Documentation

Full documentation covers installation, configuration, database connections (including JDBC and DuckDB), saved queries and parameters, authentication and authorization, API keys, rate limiting, caching, streaming, OpenAPI, metrics, the admin UI, security and deployment. Start at the documentation site or the documentation/ directory in this repo.

Roadmap

See BACKLOG.md for the full, prioritized list with rationale. Currently open: table-level query allow-listing (write operation-type granularity and a streaming row ceiling already shipped), and not recommended without a specific hard requirement since it needs real SQL parsing. Everything else on the list is shipped, including reusable permission roles/templates on top of per-key ACLs.

Contributing

Contributions are welcome - database drivers, security, performance, UI, documentation, testing and observability are all useful areas. Please review CONTRIBUTING.md before submitting changes.

Third-party components

The wheel bundles the H2 Database JDBC driver (MPL 2.0 / EPL 1.0). The example data is generated locally by queryapigate examples load; no third-party datasets are included.

License

QueryAPIGate is source-available, under the Functional Source License, Version 1.1, MIT Future License (FSL-1.1-MIT) © Anantha Raju C. It is not an OSI-approved open source license.

In plain terms - the LICENSE is the only authoritative text:

• You may use, copy, modify and redistribute it for any purpose that is not a Competing Use - including running it inside your own company, non-commercial education and research, and professional services you provide to someone who is themselves licensed to use it.
• You may not make it available to others in a commercial product or service that substitutes for QueryAPIGate or offers the same or substantially similar functionality (for example, selling it, or hosting it as a paid service).
• Each version becomes MIT on the second anniversary of the date it was released, and can then be used under MIT terms.
• Versions up to and including 0.6.1 were released under the MIT license. They are no longer distributed (and the repository history was reset in 0.7.0), but a copy you already obtained under MIT remains yours under those terms.

Need something the license does not cover, such as offering it as part of a hosted service? Get in touch - commercial licensing may be available. This is a summary, not legal advice.

Contact

Anantha Raju C - @anantharajuc - arcswdev@gmail.com

Project link: https://github.com/AnanthaRajuC/QueryAPIGate
