Kröhnkite

Moved to https://codeberg.org/anametologin/Krohnkite

reason

Microsoft have a lot of military contracts and can be blocked by my govs. In general, the standard good-bad/free-unfree crap that starts when politicians try to divide a loaf of sausage.

A dynamic tiling extension for KWin 6 only.

Kröhnkite is mainly inspired by dwm from suckless folks, and aims to provide rock solid stability while fully integrating into KWin.

The name of the script is from mineral Kröhnkite; it starts with K and looks cool.

Features

• DWM-like window tiling
  • Dynamically tile windows, rather than manually placing each.
  • Floating windows
• Fully integrates into KWin features, including:
  • Multi-screen
  • Activities & Virtual desktop
  • Basic window management (minimize, fullscreen, switching, etc)
• Multiple Layout Support
  • Tiling layout
  • Monocle layout
  • Desktop-friendly layouts (Spread, Stair)

Development Requirement

• Typescript (see package.json)
• go-task
• p7zip (7z)

Look at me

1. If you change the Krohnkite configuration, you will need to reboot. Do not toggle the script on and off, this will start multiple instances of it.
2. Delete unused KWin shortcuts you can use any D-Bus program which can invoke D-Bus methods. Service name -org.kde.kglobalaccel path - /component/kwin method - org.kde.kglobalaccel.Component.cleanUp. ArchLinux example:

qdbus6 org.kde.kglobalaccel /component/kwin org.kde.kglobalaccel.Component.cleanUp

3. If you have a gap or vice versa you have gray(white etc) rectangle that means that there is a program with size 1x1 that have to be filtered by title or other ways. Make sure that the following programs, if you have them, have been added to the filter:

xwaylandvideobridge,plasmashell,ksplashqml

Installation

You can install Kröhnkite in multiple ways.

Using .kwinscript package file

You can download krohnkite-x.x.x.x.kwinscript file, and install it through System Settings.

1. Download the kwinscript file
2. Open System Settings > Window Management > KWin Scripts
3. Press Import KWin script... on the top-right corner
4. Select the downloaded file

Alternatively, through command-line: get info about package:

kpackagetool6 -t KWin/Script -s krohnkite

install:

kpackagetool6 -t KWin/Script -i krohnkite-x.x.x.x.kwinscript

upgrade:

kpackagetool6 -t KWin/Script -u krohnkite-x.x.x.x.kwinscript

uninstall:

kpackagetool6 -t KWin/Script -r krohnkite

Installing from Git repository

Make sure you have go-task, npm and 7-zip packages installed. All packages after building will be in builds folder. The simplest method to automatically build and install kwinscript package would be:

 go-task install

You can also build .kwinscript package file using:

go-task package

uninstall package:

go-task uninstall

Settings

Add a class name, a resource name or a window caption to ignore or float

1. to found window's className,resourcename or caption see readme
2. you can use the name of class in square brackets: [myNamE] will float or ignore all windows with class or resource names such: 'myname1', 'Myname2', 'Notmyname555' etc...

Choose layout for screen by default

1. Open Krohnkite options:
2. Tab Rules->Screen default layout. Layout configuration has format OutputName:ActivityId:VirtualDesktopName:layoutName multi monitor example: HDMI-A-1:99a12h44-e9a6-1142-55eedaa7-3a922a15ab08::columns,DP-2:spread,DP-3:Desktop 3:tile,:threecolumn - result will be:

• set columns layout as default on monitor HDMI-A-1, only on activity with id:99a12h44-e9a6-1142-55eedaa7-3a922a15ab08, every Virtual Desktops on this activity.(if you specify activity id you have to to specify virtual desktop name or leave it blank)
• set spreadlayout layout as default on monitor DP-2, every Activities, every Virtual Desktops;
• set tilelayout layout as default on monitor DP-3, on every activity, only on virtual desktop with name Desktop 3
• set threecolumnlayout layout as default on all monitors,all activities and all Virtual Desktops not covered by the previous rules

2. How to find outputName, activityId, VirtualDesktopName, layoutName: Right after system boot run KSystemLog

• Push ignore button
• Type in filter string: krohnkite
• Right after KROHNKITE: starting the script string you will see one if you have one monitor or multiple lines: Screen(output):Screen Name,Desktop(name):Virtual Desktop Name,Activity:Activity Id,layouts: numbered layouts (the case doesn't matter,layout ending can be omitted): tilelayout, monoclelayout, columns, threecolumnlayout, spreadlayout, stairlayout, spirallayout, stackedlayout, floatinglayout, btreelayout

3. Apply -> reboot

Search a window parameters to filter, float etc.

1. Krohnkite options:
2. Options->Debug new Windows
3. Reboot
4. Run KSystemLog
5. Push Ignore button
6. Type in filter string: krohnkite
7. All created windows krohnkite working with will be there.
8. Every debug entry contains parameters except those that are false and empty.

Default Key Bindings

Tips

Setting Up for Multi-Screen

Krohnkite supports multi-screen setup, but KWin has to be configured to unlock the full potential of the script.

1. Enable Separate Screen Focus feature:

• System Settings > Window Management > Window Behavior > Multiscreen Behaviour

  OR use console commands:

   kwriteconfig6 --file ~/.config/kwinrc --group Windows --key ActiveMouseScreen false
   kwriteconfig6 --file ~/.config/kwinrc --group Windows --key SeparateScreenFocus true

2. Bind keys for global shortcut Switch to Next/Previous Screen (Recommend: Meta + , / Meta + .)
3. Bind keys for global shortcut Window to Next/Previous Screen (Recommend: Meta + < / Meta + >)

Removing Title Bars

Breeze window decoration can be configured to completely remove title bars from all windows:

1. System Setting > Application Style > Window Decorations
2. Click Configure Breeze inside the decoration preview.
3. Window-Specific Overrides tab > Add button
4. Enter the followings, and press Ok:
   • Regular expression to match: .*
   • Tick Hide window title bar

Changing Border Colors

Changing the border color makes it easier to identify current window. This is convinient if title bars are removed.

1. You can use the Oxygen decoration theme. Oxygen theme settings
2. You can install third-party decorations, see Border color conversation
3. You can add to the WM section in $HOME/.config/kdeglobals (this changes the default Breeze decoration frame colors):
   • frame=R,G,B
   • inactiveFrame=R,G,B

Setting Minimum Geometry Size

Some applications like discord and KDE settings dont tile nicely as they have a minimum size requirement. This causes the applications to overlap with other applications. To mitigate this we can set minimum size for all windows to be 0.

1. System Setting > Window Management > Window Rules
2. Click on + Add New...
3. Set Window class to be Unimportant
4. Set Window types to Normal Window
5. Click + Add Properties...
6. Add the Minimum Size Property
7. Set the fields to Force and 0 x 0
8. Apply

Prevent borders and shadows from disappearing.

When a window is marked "maximized" in Breeze theme, its borders are removed to save screen space. This behavior may not be preferable depending on your setup. This can be mitigated by disabling maximized windows using Window Rules.

1. System Setting > Window Management > Window Rules
2. Click on + Add New...
3. Set Window class to be Unimportant
4. Set Window types to Normal Window
5. Click + Add Properties...
6. Add the Maximized horizontally and Maximized vertically Properties.
7. Set the options to Force and No.
8. Apply

Useful Development Resources

• KWin Scripting Tutorial
• KWin Scripting API
• Adding configuration dialog
  • Development/Tutorials/Plasma/JavaScript/ConfigDialog
  • Development/Tutorials/Using KConfig XT
• *.ui files can be edited with Qt Designer. It's very straight-forward if you're used to UI programming.
