StableProjectorz: A free tool for making 3D and textures via StableDiffusion

StableProjectorz is a tool for texturing 3D models using StableDiffusion.
It also supports generating 3D models from 2D images.

Official page: StableProjectorz
Our Discord server: here

🛠️ Setup & Building

• Requirements: Unity 6000.
• Codebase: Located entirely in Assets/_gm.
• Build: Press Ctrl + Shift + B -> Build and Run.
• Note: Keep "Development Build" unchecked for performance.

📝 Contribution Rules

1. Nested Prefabs: Keep UI separated in Prefabs. Don't modify prefabs externally. Save your work directly inside a deepest prefab itself, to prevent merge conflicts.
2. Communication: Prefer singleton-pattern, to talk between scripts. For example MyCoolScript.instance; Avoid drag-and-drop references. Initialize Singletons in Awake().
3. Folders: keep prefabs, scenes, scripts inside subfolders of Features. Do not use separate Prefabs, Scenes, Scripts folders.
4. Memory: If you spawned a RenderTexture make sure to release it, to aviod memory leaks.
5. Variables: Use [SerializeField] private instead of public.
6. Naming: _underscoreForMemberVariables.

---

Watch the video about the codebase (as of Jan 2026) for a quick-start:

📂 1. Architecture & Patterns

• Scene Management: We use Additive Loading. Start_Scene_Global scene loads UI and manager-scenes separately to prevent merge conflicts.
• Update Loop: Update_callbacks_MGR dispatches events (Navigation, Depth, Rendering) in a strict order. Using Update() for other things.
• Workflow: Use Nested Prefabs. Avoid editing Scene files directly; edit the Prefab to keep Git diffs clean.

🧊 2. The 3D World

• Access: ModelsHandler_3D.instance is the singleton entry point for all 3D data.
• Structure:
  • Objs3D_Container: Maps every sub-mesh to a unique ID for later retrieval.
  • UDIMs_Helper: Scans UVs to detect tiles (1001, 1002, etc.).
• Importer: ModelsHandler3D_ImportHelper uses AssimpNet to load OBJ/FBX/GLB at runtime.

🎥 3. The Camera System

Managed by UserCameras_MGR. Culling Planes are fixed (0.25–1000) for float precision.

• View Camera: Renders high-res image for user to see. Also renders a viewport depth texture, for mesh-clicking, etc.
• Depth Camera: Renders black and white image to send to StableDiffusion (not an exact viewport depth).
• Content Camera: Renders the square resolution to send to StableDiffusion (e.g., 512x512).
• Normals Camera: Renders View-Space normals to send to StableDiffusion (Red=Right, Green=Up).
• Vertex-Colors Camera: Renders Colors encoded in mesh-vertexes to send to StableDiffusion.
• Multi-View Logic: We use Perspective Shift (via UI Pins) to arrange multiple cameras in one viewport.

🎨 4. Rendering Pipeline

• ProjectorCamera: Spawns at the user's viewpoint. "Shines" the AI image inside the _accumulation_uv_RT texture.
• Target: Objects_Renderer_MGR renders into _accumulation_uv_RT.
• Texture Arrays: The target is a RenderUDIMs object (Texture Array). Each slice represents one UDIM tile.
• The Loop: Clear Black → Bake Projections (respecting depth) → Dilate (Anti-Seam) → Display on Mesh.

🧠 5. AI Integration

• Pipeline: StableDiffusion_Hub → SD_Generate_PayloadMaker → SD_Generate_NetworkSender (Talks to A1111/Forge via JSON).
• Storage: GenData2D_Archive stores Information Objects, not loose files.
  • GenData2D: Remembers the Camera-params (POV), Prompts, Result Textures, and User Masks.
  • This allows "Reloading" the exact state of a generation later.

🧊 6. 3D Generation

Managed by Gen3D_MGR.

1. Handshake: Queries external WebUI (Trellis/Hunyuan) for required parameters.
2. Dynamic UI: Parses response to spawn sliders/inputs automatically (Gen3D_InputPanelBuilder_UI).
3. Generates: Submits a request to the Webui, with the inputs as JSON.
4. Import: waits for resulting GLB mesh and feeds it to ModelsHandler_3D.

🖱️ 8. Input System

• KeyMousePenInput: Static helper class.
• Abstraction: Unifies Mouse clicks and Tablet Pen pressure into a single API.
• Coords: Tracks cursor in Screen Pixels and Viewport Space (0–1).

🔌 9. Agent Bridge (control socket for external tools, e.g. MCP)

Lets an outside program read app state, capture the viewport, and fire UI actions.
Plain JSON over TCP. By redDwarf03, PR #8.

• Off by default: needs --agent-bridge in spz.config. Loopback only, and every request needs a token — generated for you on first launch, so clients read it and you configure nothing. --agent-bridge-token= pins your own.
• Code: Assets/_gm/Features/AgentBridge — self-starting, no scene or prefab. See its README.
• StaticEvents gained introspection + TryInvokeDynamic, which reports failures instead of ignoring them.
• For LLMs: spz-mcp — separate MIT server, reads the tool list from the running app.
