crud-bench

The crud-bench benchmarking tool is an open-source benchmarking tool for testing and comparing the performance of a number of different workloads on embedded, networked, and remote databases. It can be used to compare both SQL and NoSQL platforms including key-value, embedded, relational, document, and multi-model databases. Importantly crud-bench focuses on testing additional features which are not present in other benchmarking tools, but which are available in SurrealDB.

The primary purpose of crud-bench is to continually test and monitor the performance of features and functionality built in to SurrealDB, enabling developers working on features in SurrealDB to assess the impact of their changes on database queries and performance.

The crud-bench benchmarking tool is being actively developed with new features and functionality being added regularly.

Contributing

The crud-bench benchmarking tool is open-source, and we encourage additions, modifications, and improvements to the benchmark runtime, and the datastore implementations.

How does it work?

When running simple, automated tests, the crud-bench benchmarking tool will automatically start a Docker container for the datastore or database which is being benchmarked (when the datastore or database is networked). This configuration can be modified so that an optimised, remote environment can be connected to, instead of running a Docker container locally. This allows for running crud-bench against remote datastores, and distributed datastores on a local network or remotely in the cloud.

In one table, the benchmark will operate 5 main tasks:

• Create: inserting N unique records, with the specified concurrency.
• Read: read N unique records, with the specified concurrency.
• Update: update N unique records, with the specified concurrency.
• Scans: perform a number of range and table scans, with the specified concurrency.
• Delete: delete N unique records, with the specified concurrency.

With crud-bench almost all aspects of the benchmark engine are configurable:

• The number of rows or records (samples).
• The number of concurrent clients or connections.
• The number of concurrent threads (concurrent messages per client).
• Whether rows or records are modified sequentially or randomly.
• The primary id or key type for the records.
• The row or record content including support for nested objects and arrays.
• The scan specifications for range or table queries.

Benchmarks

As crud-bench is in active development, some benchmarking workloads are already implemented, while others will be implemented in future releases. The list below details which benchmarks are implemented for the supporting datastores and lists those which are planned in the future.

CRUD

• Creating single records in individual transactions
• Reading single records in individual transactions
• Updating single records in individual transactions
• Deleting single records in individual transactions
• Batch creating multiple records in a transaction
• Batch reading multiple records in a transactions
• Batch updating multiple records in a transactions
• Batch deleting multiple records in a transactions

Scans

• Full table scans, projecting all fields
• Full table scans, projecting id field
• Full table count queries
• Scans with a limit, projecting all fields
• Scans with a limit, projecting id field
• Scans with a limit, counting results
• Scans with a limit and offset, projecting all fields
• Scans with a limit and offset, projecting id field
• Scans with a limit and offset, counting results

Filters

• Full table query, using filter condition, projecting all fields
• Full table query, using filter condition, projecting id field
• Full table query, using filter condition, counting rows

Indexes

• Indexed table query, using filter condition, projecting all fields
• Indexed table query, using filter condition, projecting id field
• Indexed table query, using filter condition, counting rows
• Full-text search query, using single search term, projecting all fields
• Full-text search query, using single search term, projecting id field
• Full-text search query, using single search term, counting rows
• Full-text search query, using boolean AND search terms, projecting all fields
• Full-text search query, using boolean AND search terms, projecting id field
• Full-text search query, using boolean AND search terms, counting rows
• Full-text search query, using boolean OR search terms, projecting all fields
• Full-text search query, using boolean OR search terms, projecting id field
• Full-text search query, using boolean OR search terms, counting rows

Vector search

• Bruteforce (exact) KNN query
• HNSW KNN query, with configurable m / ef_construction / ef_search
• DiskANN KNN query, with configurable degree / l_build / alpha / l_search
• Vector index build timing, until the index serves at index speed
• Recall@k against exact ground truth, scored identically for every engine
• Parameter sweeps tracing the recall/latency curve over a single index build
• Reproducible corpora, so engines and runs are compared on identical data
• Filtered KNN at several selectivities, with recall scored per predicate
• Index size on disk and resident memory

Relationships

• Fetching or traversing 1-level, one-to-one relationships or joins
• Fetching or traversing 1-level, one-to-many relationships or joins
• Fetching or traversing 1-level, many-to-many relationships or joins
• Fetching or traversing n-level, one-to-one relationships or joins
• Fetching or traversing n-level, one-to-many relationships or joins
• Fetching or traversing n-level, many-to-many relationships or joins

Workloads

• Workload support for creating, updating, and reading records concurrently

Requirements

• Docker - required when running automated tests
• Rust - required when building crud-bench from source
• Cargo - required when building crud-bench from source

Usage

cargo run -r -- -h

Usage: crud-bench [OPTIONS] --database <DATABASE> --samples <SAMPLES>

Options:
  -n, --name <NAME>                            An optional name for the test, used as a suffix for the JSON result file name
  -d, --database <DATABASE>                    The database to benchmark [possible values: dry, map, arangodb, dragonfly, fjall, keydb, mdbx, lmdb, mariadb, mongodb, mysql, neo4j, postgres, redb, redis, rocksdb, scylladb, slatedb, sqlite, surrealdb, surrealkv, surrealmx, surrealds]
  -i, --image <IMAGE>                          Specify a custom Docker image
  -p, --privileged                             Whether to run Docker in privileged mode
  -e, --endpoint <ENDPOINT>                    Specify a custom endpoint to connect to
  -b, --blocking <BLOCKING>                    Maximum number of blocking threads (default is the number of CPU cores) [default: 12]
  -w, --workers <WORKERS>                      Number of async runtime workers (default is the number of CPU cores) [default: 12]
  -c, --clients <CLIENTS>                      Number of concurrent clients [default: 1]
  -t, --threads <THREADS>                      Number of concurrent threads per client [default: 1]
  -s, --samples <SAMPLES>                      Number of samples to be created, read, updated, and deleted
  -r, --random                                 Generate the keys in a pseudo-randomized order
      --sync                                   Whether to ensure data is synced and durable
      --operation-timeout <OPERATION_TIMEOUT>  Per-operation timeout in seconds [env: CRUD_BENCH_OPERATION_TIMEOUT=] [default: 1800]
      --persisted                              Whether to enable disk persistence for Redis-family databases
      --optimised                              Use optimised database configurations instead of defaults
      --color <COLOR>                          When to use colour in terminal output (`NO_COLOR` disables colour for `auto` and `always`) [default: auto] [possible values: auto, always, never]
  -k, --key <KEY>                              The type of the key [default: integer] [possible values: integer, string26, string90, string250, string506, uuid]
      --show-sample                            Print-out an example of a generated value
      --pid <PID>                              Collect system information for a given pid
      --store-results                          Store benchmark results in SurrealDB
      --storage-endpoint <STORAGE_ENDPOINT>    SurrealDB endpoint for storing results [env: CRUD_BENCH_STORAGE_ENDPOINT=] [default: ws://localhost:8000]
      --config <CONFIG>                        Path to the benchmark TOML (`[[scans]]`, `[[batches]]`, `[value]`) [env: CRUD_BENCH_CONFIG=] [default: config/bench.toml]
      --skip-scans                             Skip all scan benchmarks
      --skip-batches                           Skip all batch benchmarks
      --skip-indexes                           Skip index operations, but still table scan queries
      --emit-phase-markers                     Emit line-oriented phase markers (`… starting`, `Benchmark starting`) for log-based tooling (e.g. `dev.sh` perf windows). Off by default; also on when `CRUD_BENCH_EMIT_PHASE_MARKERS` is `1`, `true`, `yes`, or `on`
      --corpus-seed <CORPUS_SEED>              Seed for generated row content, overriding `seed` in the benchmark TOML. With a seed the corpus is a pure function of `(seed, sample)`, making the run reproducible and letting vector-search ground truth reconstruct the corpus instead of reading it back
      --ground-truth-cache <DIR>               Directory holding cached vector-search ground truth [env: CRUD_BENCH_GROUND_TRUTH_CACHE=] [default: .crud-bench-gt]
      --vector-warmup-seconds <SECONDS>        Seconds a vector index may be warmed before a timed leg. Warming stops on its own once latency plateaus; this is a safety cap. Raise it for large corpora [default: 30]
  -h, --help                                   Print help (see more with '--help')

For more detailed help information run the following command:

cargo run -r -- --help

Comparing result*.json files in the browser

Open compare/index.html locally (drag and drop benchmark JSON artefacts). Rows and labels match CLI/CSV ordering from src/result.rs. Nothing is uploaded; ApexCharts loads from jsDelivr (works offline only if that script is cached or vendored beside the HTML file).

Workload shape (document template, scan cases, and batch throughput tests) is defined in a single TOML file. Use --config <PATH> or the environment variable CRUD_BENCH_CONFIG (default: config/bench.toml).

Value

The [value] table in the benchmark TOML customizes the row, document, or record value used in the benchmark. It uses the same JSON-oriented template rules as before, expressed as TOML keys and nested tables.

[!NOTE] For tabular, or column-oriented databases (e.g. Postgres, MySQL, ScyllaDB), the first-level fields of the JSON structure are translated as columns, and any nested structures will be stored in a JSON column where possible.

Within the JSON structure, the following values are replaced by randomly generated data:

• Every occurrence of string:X will be replaced by a random string with X characters.
• Every occurrence of text:X will be replaced by a random string made of words of 2 to 10 characters, for a total of X characters.
• Every occurrence of string:X..Y will be replaced by a random string between X and Y characters.
• Every occurrence of text:X..Y will be replaced by a random string made of words of 2 to 10 characters, for a total between X and Y characters.
• Every int will be replaced by a random integer (i32).
• Every int:X..Y will be replaced by a random integer (i32) between X and Y.
• Every float will be replaced by a random float (f32).
• Every float:X..Y will be replaced by a random float (f32) between X and Y.
• Every uuid will be replaced by a random UUID (v4).
• Every bool will be replaced by a true or false.
• Every string_enum:A,B,C will be replaced by a string from A B or C.
• Every int_enum:A,B,C will be replaced by a i32 from A B or C.
• Every float_enum:A,B,C will be replaced by a f32 from A B or C.
• Every datetime will be replaced by a datetime (ISO 8601).
• Every vector:X will be replaced by an X-dimension vector with uniform components in [-1, 1].
• Every vector:X:LO..HI will be replaced by an X-dimension vector with uniform components in [LO, HI].
• Every vector:X:clustered:N will be replaced by an X-dimension unit vector drawn from a mixture of N clusters. Add :SIGMA (default 0.35) to widen or tighten the clusters.

{
  "text": "text:30",
  "text_range": "text:10..50",
  "bool": "bool",
  "string_enum": "enum:foo,bar",
  "datetime": "datetime",
  "float": "float",
  "float_range": "float:1..10",
  "float_enum": "float:1.1,2.2,3.3",
  "integer": "int",
  "integer_range": "int:1..5",
  "integer_enum": "int:1,2,3",
  "uuid": "uuid",
  "nested": {
    "text": "text:100",
    "array": [
      "string:10",
      "string:2..5"
    ]
  }
}

Scans

Scan workloads are defined by [[scans]] entries in the benchmark TOML (see config/bench.toml). Each table describes one logical benchmark (or multiple [[scans.runs]] variants). The JSON examples below remain valid documentation for the fields on each scan object.

[!NOTE] Not every database benchmark adapter supports scans or range queries. In such cases, the benchmark will not fail but the associated tests will indicate that the benchmark was skipped.

Unknown keys are rejected. A misplaced or misspelled key used to be dropped in silence, so a run would report a healthy-looking number for a configuration nobody had written — the same failure mode the vector-search measurement work exists to eliminate. Parsing now fails and names the offending key and the table it appeared in.

Each scan object can make use of the following values:

• id (required): Stable identifier for grouping in the CLI, result tables, CSV output, and for index create/drop when with_index is present and not skipped. Use a simple identifier (e.g. where_field_integer_eq); human-readable titles live in name / run name and may contain characters that are not valid in SurrealDB or Neo4j index names.
• name: A descriptive name for the test (use this or runs, not both).
• runs: An array of { "name", "iterations"?, "projection"?, "vector_query"? } objects that share the same scan parameters (condition, with_index, and so on). Each run becomes a separate benchmark with its own display name. Per-run iterations, projection and vector_query override the entry-level value when both are set; if a run omits one, the entry-level value applies (projection defaulting to full-record scans like a single-object entry without projection). A per-run iterations matters when one array mixes leg kinds — a bruteforce KNN leg is a full table scan costing seconds per query at 100k rows, while the graph-index legs beside it answer in under a millisecond, and no single count suits both.
• projection: The projection type of the scan:
  • "ID": only the ID is returned.
  • "FULL": the whole record is returned.
  • "COUNT": count the number of records.
• start: Skips the specified number of rows before starting to return rows.
• limit: Specifies the maximum number of rows to return.
• expect: (optional) Asserts the expected number of rows returned.
• clients / threads: (optional) Concurrency for this scan's timed legs, overriding --clients and --threads. clients is capped at the pool --clients created. Index DDL is unaffected — it always runs on a single client.

[
  {
    "id": "paging_limit_100",
    "name": "limit100",
    "projection": "FULL",
    "start": 0,
    "limit": 100,
    "expect": 100
  },
  {
    "id": "paging_start_100",
    "name": "start100",
    "projection": "ID",
    "start": 100,
    "limit": 100,
    "expect": 100
  }
]

Multiple benchmarks that share the same filter, index, and write settings can use runs instead of duplicating the object:

[
  {
    "id": "idx_x_eq_1",
    "runs": [
      { "name": "select(*) where(x = 1)", "projection": "FULL" },
      { "name": "count(*) where(x = 1)", "projection": "COUNT" }
    ],
    "iterations": 10000,
    "condition": { "sql": "x = 1", "mysql": "x = 1" },
    "with_index": { "fields": ["x"] }
  }
]

Index build time

An [I]ndex · … · build row is timed from the build call until the index serves at index speed, which for some engines is long after the build call returns. The two moments coincide for an engine whose build call does all the work, and can be minutes to hours apart for one that finishes the index in the background; only the later one means the same thing for both. At 100k rows × 768-d, HNSW M 16 / EFC 200 — one run per engine on a shared machine, so the absolute times are only indicative; the split is the point:

Timing the build call alone reported the first column. At 1M rows that made SurrealDB look ~28× faster to build than pgvector — 56 s against 25 m 29 s — while its index was still being built an hour later. So each engine's wait for its index to become queryable — pending entries drained, materialisation finished, background indexing complete — is part of the timed build, and the CPU and memory sampled for the build row cover it too.

The build call's own time is kept as a diagnostic, build_returned in the JSON and Build_returned in the CSV. It is deliberately not in the summary table: it is the figure that does not mean the same thing across engines. Result files written before this change lack index_build_timing in their metadata, and the comparison viewer flags a mix of old and new files rather than setting one definition's number beside the other's.

A search is only ever timed against an index that has finished. For SurrealDB that means waiting until INFO FOR INDEX reports ready, no pending entries, and compacting: false — ready alone arrives while a vector index is still being built from per-record pending entries, and a kNN query in that state scores the remainder by hand. A server that does not report compacting cannot say when that has finished, so crud-bench skips HNSW and DiskANN legs there, reporting -, rather than time a scan wearing the index's name. SurrealDB 3.3.0 is the first release that reports it, so both the crate embedded mode links (-e memory, -e rocksdb:…, -e surrealkv:…) and the nightly Docker image server mode uses by default are covered; releases before 3.3.0 defer the same work without reporting it, and get the skip.

The wait is bounded by --operation-timeout, like every timed operation. A build that used to fit in the 30-minute default can stop fitting once its materialisation counts — a large vector index is the usual case — and the error then says so; raise the timeout to allow for it. Readiness is polled at a tenth of the time waited so far, between 10 ms and 250 ms, so a reported build is at most max(10 ms, min(10%, 250 ms)) late: a sub-second build is not rounded up to a whole poll interval.

Vector search

Vector workloads live in config/vector.toml. Each [scans.runs.vector_query] block describes one KNN benchmark:

• field (required): the vector:<dim> column to search. The index, when the strategy needs one, is derived from this — do not also declare with_index.
• top_k (required): number of neighbours to return.
• distance: cosine (default), euclidean, inner_product, or manhattan.
• index_strategy (required): { kind = "bruteforce" }, { kind = "hnsw", m, ef_construction, ef_search }, or { kind = "diskann", degree, l_build, alpha, l_search }. All knobs are required — results without explicit parameters cannot be interpreted. The search-time knob (ef_search, l_search) also accepts a list, which is swept: see below.
• holdout: { count, seed } for the query set. Query vectors are generated from seed using the schema's own vector generator and are never inserted, so no query is its own nearest neighbour.
• filters: a list of predicates the KNN result is restricted to, one timed leg each plus an unfiltered baseline — see Filtered KNN.
• filter_index: true to index each filter column before the legs (untimed) and drop it after — see Indexed filter columns. Default false.
• tie_epsilon: relative tolerance when deciding whether a returned neighbour counts as correct (default 0.0, i.e. strict recall@k). Engines compute distances at different precisions, so rows straddling the k-th boundary can swap without any real quality difference; a small tolerance stops that reading as a recall gap.

Engine support

Engines without vector support skip these runs rather than failing, so a mixed run reports - for them rather than aborting. A leg whose strategy needs an index it cannot build is skipped the same way.

Vector data

Use vector:<dim>:clustered:<n> rather than vector:<dim> for anything whose recall you intend to read. Uniform components leave a corpus with no neighbourhood structure — under distance concentration every pair sits at roughly the same distance, so a query's true neighbours are conspicuous and any index walks straight to them. Measured over 20k 128-d rows, the nearest neighbour sits at 65% of a random pair's distance under vector:128, and at 8% under vector:128:clustered:200. Recall only tells you anything on the second.

Clusters are drawn from the corpus seed, so two seeds give two genuinely different datasets rather than one structure populated differently. Query vectors come from the same generator, so they follow the corpus distribution by construction.

Corpus size matters more than dimension. Dimension scales cost linearly without making the search harder; rows add candidates that can confuse a graph. Measured against embedded SurrealDB at 128 dimensions, neither graph index beats a linear scan below ~100k rows — at 200k, HNSW is 1.7x faster than bruteforce and DiskANN 3.4x. Treat 100k as a floor, and 1M as the size worth quoting, which also matches the scale of the standard ANN datasets.

Parameter sweeps

ef_search and l_search accept a list as well as a single value:

index_strategy = { kind = "hnsw", m = 16, ef_construction = 200, ef_search = [16, 32, 64, 128, 256] }

Each value becomes its own timed leg, all sharing a single index build, and each is reported as a separate row labelled with the value it used. A lone ef_search is one arbitrary point on a curve — the comparison worth making is the curve itself, what recall an index reaches at a given latency budget — and tracing it this way costs one index build rather than one per point.

Values must be at least top_k: a search budget narrower than k cannot return k neighbours.

Engines apply the budget differently and crud-bench hides the difference. SurrealDB carries it in the KNN operator, Redis passes EF_RUNTIME on the query rather than fixing it at FT.CREATE, and pgvector takes it from the hnsw.ef_search session GUC, which is applied to every client before each leg — a setting made only on the client that built the index would reach one session out of --clients.

Filtered KNN

Filtered workloads live in config/vector-filtered.toml. Where the unfiltered config asks how fast and how accurately an index finds the nearest neighbours, this one asks the question production asks: among the rows that match this predicate.

[scans.runs.vector_query]
field = "embedding"
top_k = 10
distance = "cosine"
index_strategy = { kind = "hnsw", m = 16, ef_construction = 200, ef_search = [16, 64, 128, 256] }
filters = [
    { name = "sel~1%", field = "number", op = "lte", value = 50 },
    { name = "sel~10%", field = "number", op = "lte", value = 500 },
    { name = "tag~33%", field = "status", op = "eq", value = "published" },
]

Each predicate becomes its own timed leg, and an unfiltered leg runs first under the same index build and the same warm index — "what does filtering cost?" is not answerable against a baseline measured somewhere else. Legs are the cross product of the search sweep and the filter list, all over a single build, since the index does not depend on the predicate.

Why this is worth measuring separately: engines answer a filtered query in structurally different ways, and the differences do not show up in latency.

Post-filtering — search the index for k, then discard the hits that do not match — is the fastest of the three and the least useful, because the k the index chose were chosen without knowing about the predicate. A latency column rewards it. Recall is what exposes it, which is why every filtered leg is scored against an answer key computed per predicate: exact top-k among the matching rows, computed in the harness from the seeded corpus.

What this actually measures

Measured on 20k rows of 128-d clustered vectors, top_k = 10, HNSW m = 16 / efc = 200 / ef_search = 64, one client — all three engines answering the identical questions against the identical answer key:

Three structurally different answers to the same question, and the latency columns rank pgvector first. It is the only one of the three that loses a third of the true neighbours at 10% selectivity, and its worst 5% of queries lose 70% of theirs — while costing no more than the unfiltered query, because it never looked at the rows it skipped. SurrealDB pays 4.6x in latency and keeps every neighbour; Redis pays nothing measurable and keeps every neighbour.

That is the entire argument for scoring filtered legs against a filter-aware answer key rather than timing them. No amount of latency measurement distinguishes the first row from the third.

The divergence is not only between engines. DiskANN on the same SurrealDB build, same corpus, same predicates, sweeping l_search:

A traversal budget that is ample unfiltered — l_search = 50 reaches exact at every budget with no predicate — finds barely half the true neighbours once a 10%-selective predicate is applied, and needs roughly 4x the budget to recover. Where SurrealDB's HNSW absorbed the same predicate by traversing harder at a fixed ef_search (4.6x latency, recall intact), DiskANN keeps its latency and loses recall instead. And at l_search = 50 the wrong answer is the faster one — 1.09 ms against 2.46 ms — so latency picks it again.

This is why the filter list expands against the search sweep rather than beside it: the search budget a filtered query needs depends on the selectivity, and any single point would have reported DiskANN as either broken or fine depending on an arbitrary choice.

It is also why the low end of each shipped ladder sits below saturation and should stay there. A ladder whose every point already reaches exact prints a flat column of 1.000 and measures nothing — the recall equivalent of reporting latency with no recall column. The starved point is what makes the effect visible, and the unfiltered leg beside it at the same budget is what identifies it as a budget/selectivity interaction rather than a defect.

The HNSW ladder, ef_search = [16, 64, 128, 256], is calibrated at the scale the config is meant for (#290). Unfiltered recall@10 at 1M × 768-d:

16 sits clearly under the knee, 64 and 128 across it, 256 near saturation. The ladder it replaced, [32, 128], was chosen on a 20k × 128-d smoke run on the guess that it was already saturated; at 1M it was not (32 reads 0.670 / 0.608). Budgets saturate at different points as a corpus grows, which is why the calibration had to happen at the target scale. Selective predicates do not follow the budget at all — at 1% pgvector's post-filter never passes 0.271 on this ladder, while Redis brute-forces the matching rows at 1.000 — so the ladder is chosen on the unfiltered and 50% columns.

The DiskANN ladder, [50, 200], is not calibrated. DiskANN runs only on SurrealDB, whose 1M arm is blocked: the index keeps materialising for over an hour after reporting ready, so there is nothing yet to calibrate against.

Note every exact leg reads 1.000 under both predicates on all three engines. That is the check that the three renderings select the same rows the harness does: if SurrealQL, ANSI SQL and the RediSearch expression disagreed with the in-process predicate by even one row, exact search could not score a perfect recall against it.

Predicate grammar

A filter is { name, field, op, value }:

• name: labels the leg in the results. Must be unique within a scan; it is not part of the ground-truth cache key, so renaming a predicate does not invalidate a computed answer key.
• field: an integer, float, string or bool column from the value template. Other column types are rejected — a datetime or decimal filter would need per-engine literal formats and collation rules, and getting either subtly wrong leaves two engines answering different questions.
• op: eq, ne, lt, lte, gt, gte, or in. The ordering operators require a numeric column; in takes a list and is the natural way to dial selectivity on a categorical column.
• value: a literal, or a list for in. Text literals are restricted to letters, digits, space and _-./+:@ — every engine here quotes strings differently, and a mis-escaped literal does not fail loudly, it silently selects a different set of rows in one engine than in another.

The predicate has to be something crud-bench can evaluate, not an opaque per-dialect string like scan.condition. That is what makes a filter-aware answer key possible at all: the harness reconstructs the seeded corpus, applies the same predicate, and computes exact top-k over the rows it admits.

Selectivity is measured, not declared

The ground-truth sweep regenerates every row anyway, so it counts matches while it is there. The share that actually matched is reported in the leg label and in the Filter column of the summary table (Filter_selectivity in CSV, filter_selectivity in JSON). Names like sel~1% are intentions; the reported figure is what the corpus did.

This also makes the sweep cheaper rather than dearer: a non-matching row is skipped before any distance is computed, so a 1%-selective predicate pays for about 1% of the arithmetic.

A predicate that matches no rows fails the run rather than reporting it. Every query would have an empty answer, recall would be undefined, and the timed leg would be measuring an engine returning nothing — a configuration mistake, not a result.

How each engine is asked

CASESENSITIVE matters: RediSearch folds case on TAG fields by default, which would admit rows the answer key excludes and produce a systematic recall error that looks like an index fault.

SurrealDB 2.x declines filtered legs and reports -. Running the unfiltered query and scoring it against a filter-aware answer key would report a recall collapse that says nothing about the engine, and a skip is distinguishable from that where a wrong number is not.

DiskANN is filtered wherever it exists, which today is SurrealDB 3.x alone — it shares the index path above with HNSW. Neither pgvector nor Redis Stack ships a DiskANN index, so there is nowhere else to apply it; pgvectorscale's diskann would be a separate adapter and is tracked in #284.

Indexed filter columns

Whether the filter column is indexed changes how an engine can answer, far more than any search parameter does. Without an index it has to test the predicate candidate by candidate as it searches; with one it can start from the rows that match. That is a property of the schema, not the engine, so it is a switch — filter_index = true on a vector_query — and config/vector-filtered.toml runs every strategy both ways, the second labelled · filter index.

Each distinct filter column is indexed after the vector index and before the first leg, so the unfiltered baseline runs against the same schema, and dropped after the last. The build is not timed: it is schema setup, not the index under test.

SurrealDB needs the declared type. Its KNN pre-filter turns an indexed predicate into an allow-list of matching records — scored exactly when few match, without touching the graph — but only trusts a b-tree index on a column that cannot hold arrays: on a schemaless table an array value fans out to one index entry per element, so the index could admit rows the predicate rejects. With an index and no declared type the plan does not change. At 1% selectivity on 50k × 768-d, the pre-filter took a filtered HNSW query from 1.1 s and recall 0.96 to 25 ms and 1.000 (#314).

--skip-indexes removes filter_index scans along with the other index builds.

Two caveats worth knowing when reading the numbers:

• pgvector runs with its defaults. Without filter_index it post-filters its HNSW scan, its documented default (hnsw.iterative_scan = off). Iterative scans are not exercised yet (#312).
• Redis mirrors filter columns on every write. They ride in the same HSET as the embedding, so the cost is marginal, but the create and update phases of a filtered config are not byte-identical in work to those of config/vector.toml.

cargo run -r -- -d surrealdb -s 100000 -c 12 -t 24 --config config/vector-filtered.toml

Concurrency

Vector legs default to clients = 1, threads = 1 in config/vector.toml, and that default is load-bearing. Once an index is warm a KNN query answers in well under a millisecond, so at the benchmark's usual concurrency the timed legs measure queueing rather than search: the same query measured 0.4 ms at one client and roughly 1500 ms at sixty-four. Raise the setting to measure throughput under load — that is a legitimate thing to want — but do not read the latency columns of such a run as search cost.

The first leg timed after an index build is also warmed with untimed queries first. Without that it absorbs the whole cost of warming the index, and not by a little: on a 50k-row HNSW the first leg measured ~295 ms per query against ~0.5 ms for the identical query in the leg that followed, and it was more accurate as well — a cold index answers differently, not just slower.

Recall

An approximate index has a free parameter — ef_search, l_search — that trades accuracy for latency, so a latency number on its own cannot tell a fast index from an inaccurate one. Every KNN run is therefore scored for recall@k, reported as mean / 5th percentile in the summary table and in full in the JSON and CSV output. The 5th percentile is shown because a mean can look healthy while a tail of queries is answered badly.

Ground truth is computed by crud-bench itself and shared by every engine, rather than taken from each engine's own bruteforce leg. Scoring an engine against itself measures whether its index agrees with its own exact path — useful for tracking regressions, but not a number that can sit beside another engine's, because a quirk shared by an engine's exact and approximate paths cancels out and divergent metric definitions leave every engine near 1.0 against itself. A useful side effect: each engine's own bruteforce leg is scored too, and should read 1.000. Anything less is a metric divergence or an engine bug.

Recall needs a reproducible corpus, so a vector config must set seed (or the run must pass --corpus-seed). Row content then becomes a pure function of the seed and the sample index, which also means the same dataset is benchmarked across engines and across runs. Without a seed the KNN runs still execute and report latency, and print why recall is unavailable.

The answer key is a pure function of its inputs — both seeds, the sample count, top_k, the metric, the field, and the value template — so it is computed once, cached under --ground-truth-cache (default .crud-bench-gt, gitignored), and reused by every subsequent engine and run.

cargo run -r -- -d surrealdb -s 100000 -c 12 -t 24 --config config/vector.toml

Databases

Dry

This benchmark does not interact with any datastore, allowing the overhead of the benchmark implementation, written in Rust, to be measured.

cargo run -r -- -d dry -s 100000 -c 12 -t 24 -r

ArangoDB

ArangoDB is a multi-model database with flexible data modeling and efficient querying.

cargo run -r -- -d arangodb -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running ArangoDB instance use the following command:

cargo run -r -- -d arangodb -e http://127.0.0.1:8529 -s 100000 -c 12 -t 24 -r

Dragonfly

Dragonfly is an in-memory, networked, datastore which is fully-compatible with Redis and Memcached APIs.

cargo run -r -- -d dragonfly -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running Dragonfly instance use the following command:

cargo run -r -- -d dragonfly -e redis://:[email protected]:6379 -s 100000 -c 12 -t 24 -r

Fjall

Fjall is a transactional, ACID-compliant, embedded, key-value datastore, written in safe Rust, and based on LSM-trees.

cargo run -r -- -d fjall -s 100000 -c 12 -t 24 -r

KeyDB

KeyDB is an in-memory, networked, datastore which is a high-performance fork of Redis, with a focus on multithreading.

cargo run -r -- -d keydb -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running KeyDB instance use the following command:

cargo run -r -- -d keydb -e redis://:[email protected]:6379 -s 100000 -c 12 -t 24 -r

LMDB

LMDB is a transactional, ACID-compliant, embedded, key-value datastore, based on B-trees.

cargo run -r -- -d lmdb -s 100000 -c 12 -t 24 -r

Map

An in-memory concurrent, associative HashMap in Rust.

cargo run -r -- -d map -s 100000 -c 12 -t 24 -r

MDBX

MDBX is a transactional, key-value, memory-mapped, B-Tree storage engine without WAL.

cargo run -r -- -d mdbx -s 100000 -c 12 -t 24 -r

MongoDB

MongoDB is a NoSQL, networked, ACID-compliant, document-oriented database, with support for unstructured data storage.

cargo run -r -- -d mongodb -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running MongoDB instance use the following command:

cargo run -r -- -d mongodb -e mongodb://root:[email protected]:27017 -s 100000 -c 12 -t 24 -r

MySQL

MySQL is a networked, relational, ACID-compliant, SQL-based database.

cargo run -r -- -d mysql -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running MySQL instance use the following command:

cargo run -r -- -d mysql -e mysql://root:[email protected]:3306/bench -s 100000 -c 12 -t 24 -r

Neo4j

Neo4j is a graph database management system for connected data.

cargo run -r -- -d neo4j -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running Neo4j instance use the following command:

cargo run -r -- -d neo4j -e '127.0.0.1:7687' -s 100000 -c 12 -t 24 -r

Postgres

Postgres is a networked, object-relational, ACID-compliant, SQL-based database.

cargo run -r -- -d postgres -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running Postgres instance use the following command:

cargo run -r -- -d postgres -e 'host=127.0.0.1 user=postgres password=postgres' -s 100000 -c 12 -t 24 -r

ReDB

ReDB is a transactional, ACID-compliant, embedded, key-value datastore, written in Rust, and based on B-trees.

cargo run -r -- -d redb -s 100000 -c 12 -t 24 -r

Redis

Redis is an in-memory, networked, datastore that can be used as a cache, message broker, or datastore.

cargo run -r -- -d redis -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to an already-running Redis instance use the following command:

cargo run -r -- -d redis -e redis://:[email protected]:6379 -s 100000 -c 12 -t 24 -r

RocksDB

RocksDB is a transactional, ACID-compliant, embedded, key-value datastore, based on LSM-trees.

cargo run -r -- -d rocksdb -s 100000 -c 12 -t 24 -r

ScyllaDB

ScyllaDB is a distributed, NoSQL, wide-column datastore, designed to be compatible with Cassandra.

cargo run -r -- -d scylladb -s 100000 -c 12 -t 24 -r

The above command starts a Docker container automatically. To connect to a already-running ScyllaDB cluster use the following command:

cargo run -r -- -d scylladb -e 127.0.0.1:9042 -s 100000 -c 12 -t 24 -r

SlateDB

SlateDB is an embedded storage engine built as a log-structured merge-tree on object storage. It provides bottomless storage capacity and high durability by leveraging object storage (S3, GCS, MinIO, and more).

cargo run -r -- -d slatedb -s 100000 -c 12 -t 24 -r

SQLite

SQLite is an embedded, relational, ACID-compliant, SQL-based database.

cargo run -r -- -d sqlite -s 100000 -c 12 -t 24 -r

SurrealDB

cargo run -r -- -d surrealdb -s 100000 -c 12 -t 24 -r

[!NOTE] The embedded engine tracks the published version closest to SurrealDB's main, prereleases included, rather than the latest stable release — crud-bench exists to monitor SurrealDB as it is developed, so it should sit where the development is. Server mode already does the same by pulling the surrealdb/surrealdb:nightly image. Embedded and server therefore benchmark different builds, and a result should say which it used.

Specify a custom endpoint using -e or --endpoint to benchmark a custom deployment:

SurrealKV

SurrealKV is a versioned, transactional, ACID-compliant, embedded key-value database implemented in Rust using an LSM (Log-Structured Merge) tree and B+tree architecture.

cargo run -r -- -d surrealkv -s 100000 -c 12 -t 24 -r

SurrealMX

SurrealKV is an embedded, in-memory, lock-free and wait-free, transactional, embedded key-value database engine implemented in Rust.

cargo run -r -- -d surrealmx -s 100000 -c 12 -t 24 -r

SurrealDB local benchmark

To run the benchmark against an already running SurrealDB instance, follow the steps below.

Start a SurrealDB server:

surreal start --allow-all -u root -p root rocksdb:/tmp/db

Then run crud-bench with the surrealdb database option:

cargo run -r -- -d surrealdb -e ws://127.0.0.1:8000 -s 100000 -c 12 -t 24 -r

SurrealDB Authentication

When benchmarking SurrealDB (including surrealdb, and surrealds), you can configure authentication credentials using environment variables.

Environment Variables

• SURREALDB_USER: Username for SurrealDB authentication (default: root)
• SURREALDB_PASS: Password for SurrealDB authentication (default: root)

These environment variables are used in two scenarios:

1. Docker Container Startup: When crud-bench automatically starts a SurrealDB Docker container (-d surrealdb with no endpoint, or with -e server:rocksdb / -e server:memory / -e server:surrealkv), it uses these credentials to configure the database server
2. Client Authentication: When connecting to SurrealDB instances (both embedded and networked), the benchmark client uses these credentials to authenticate

Usage Examples

Using default credentials (root/root):

cargo run -r -- -d surrealdb -s 100000 -c 12 -t 24 -r

Using custom credentials via environment variables:

export SURREALDB_USER=admin
export SURREALDB_PASS=secure_password
cargo run -r -- -d surrealdb -s 100000 -c 12 -t 24 -r

One-line command with custom credentials:

SURREALDB_USER=admin SURREALDB_PASS=secure_password cargo run -r -- -d surrealdb -e ws://127.0.0.1:8000 -s 100000 -c 12 -t 24 -r

Connecting to an external SurrealDB instance with custom credentials:

First, start your SurrealDB instance with custom credentials:

surreal start --allow-all -u admin -p secure_password rocksdb:/tmp/db

Then run the benchmark with matching credentials:

SURREALDB_USER=admin SURREALDB_PASS=secure_password cargo run -r -- -d surrealdb -e ws://127.0.0.1:8000 -s 100000 -c 12 -t 24 -r

Note: When using the automatically started Docker containers, the environment variables configure both the server and client credentials, ensuring they match. When connecting to external instances, ensure the environment variables match the credentials configured on your SurrealDB server.

SurrealDS - Multi-Instance Distributed Benchmark with TiKV

SurrealDS (SurrealDB Distributed System) enables benchmarking against multiple SurrealDB instances simultaneously, with the primary use case being SurrealDB with TiKV as the distributed storage backend. This is particularly useful for testing SurrealDB's performance characteristics when using TiKV's distributed, transactional key-value storage in production-like environments.

Features

• TiKV Integration: Designed specifically for benchmarking SurrealDB with TiKV distributed storage
• Multi-Instance Support: Connect to multiple SurrealDB instances using a single endpoint configuration
• Round-Robin Load Balancing: Automatically distributes client connections evenly across all configured instances
• Networked Connections Only: Designed for remote SurrealDB instances (supports ws://, wss://, http://, https://)

Prerequisites

TiKV Cluster Setup (Primary Use Case)

Before running SurrealDS benchmarks with TiKV, you need to have a TiKV cluster and multiple SurrealDB instances connected to it. Here's a typical setup:

1. Start a TiKV cluster (using TiUP or your preferred deployment method):

   # Example using TiUP for local testing
   tiup playground --mode tikv-slim


2. Start multiple SurrealDB instances connected to the TiKV cluster:

   # Terminal 1 - Start first SurrealDB instance connected to TiKV
   surreal start --allow-all -u root -p root --bind 127.0.0.1:8001 tikv://127.0.0.1:2379

   # Terminal 2 - Start second SurrealDB instance connected to the same TiKV cluster
   surreal start --allow-all -u root -p root --bind 127.0.0.1:8002 tikv://127.0.0.1:2379

   # Terminal 3 - Start third SurrealDB instance connected to the same TiKV cluster
   surreal start --allow-all -u root -p root --bind 127.0.0.1:8003 tikv://127.0.0.1:2379


Alternative: Local Testing Without TiKV

For testing the load distribution mechanism without TiKV, you can use independent local instances:

# Terminal 1 - Start first instance on port 8001
surreal start --allow-all -u root -p root --bind 127.0.0.1:8001 rocksdb:/tmp/db1

# Terminal 2 - Start second instance on port 8002
surreal start --allow-all -u root -p root --bind 127.0.0.1:8002 rocksdb:/tmp/db2

# Terminal 3 - Start third instance on port 8003
surreal start --allow-all -u root -p root --bind 127.0.0.1:8003 rocksdb:/tmp/db3

Note: When using independent storage backends (like RocksDB above), each instance maintains its own separate data. With TiKV, all instances share the same distributed storage, which is the recommended production setup.

Usage

To benchmark against multiple SurrealDB instances backed by TiKV, specify the endpoints separated by semicolons:

cargo run -r -- -d surrealds -e "ws://127.0.0.1:8001;ws://127.0.0.1:8002;ws://127.0.0.1:8003" -s 100000 -c 12 -t 24 -r

How It Works

SurrealDS uses a round-robin algorithm to distribute client connections across all configured SurrealDB endpoints:

1. When the benchmark engine starts, it parses the endpoint configuration string
2. For each concurrent client creation, the engine selects the next endpoint in sequence
3. Connections cycle through endpoints evenly (client 0 → endpoint 0, client 1 → endpoint 1, etc.)
4. This ensures balanced load distribution across all SurrealDB instances

When using TiKV as the storage backend, all SurrealDB instances read from and write to the same distributed TiKV cluster, allowing you to benchmark:

• How SurrealDB performs with distributed storage
• Load distribution across multiple SurrealDB query/compute nodes
• TiKV's performance under distributed workloads
• Network overhead and coordination costs

Example with 3 endpoints and 6 concurrent clients:

• Client 0 → ws://127.0.0.1:8001 (SurrealDB instance 1 → TiKV cluster)
• Client 1 → ws://127.0.0.1:8002 (SurrealDB instance 2 → TiKV cluster)
• Client 2 → ws://127.0.0.1:8003 (SurrealDB instance 3 → TiKV cluster)
• Client 3 → ws://127.0.0.1:8001 (wraps around)
• Client 4 → ws://127.0.0.1:8002
• Client 5 → ws://127.0.0.1:8003

Configuration

The endpoint string must:

• Contain one or more SurrealDB endpoints separated by semicolons (;)
• Use remote connection protocols only: ws://, wss://, http://, or https://
• Point to instances that accept the same root credentials (default: root/root)

Note: You can customize authentication credentials using the SURREALDB_USER and SURREALDB_PASS environment variables. See the SurrealDB Authentication section for details.

Valid endpoint configurations:

# Local TiKV testing with three SurrealDB instances
-e "ws://127.0.0.1:8001;ws://127.0.0.1:8002;ws://127.0.0.1:8003"

# Production TiKV cluster with remote SurrealDB nodes
-e "ws://surreal-node1.example.com:8000;ws://surreal-node2.example.com:8000;ws://surreal-node3.example.com:8000"

# Single instance (still works, but no load distribution)
-e "ws://127.0.0.1:8000"

Use Cases

SurrealDS is ideal for:

• TiKV Performance Benchmarking: Evaluate SurrealDB's performance when using TiKV as the distributed storage backend
• Distributed Storage Testing: Assess how SurrealDB handles distributed transactional workloads across a TiKV cluster
• Load Balancing Evaluation: Test load distribution across multiple SurrealDB compute nodes sharing the same TiKV storage
• Scalability Assessment: Compare single-node vs. multi-node SurrealDB performance with TiKV
• Production Deployment Simulation: Benchmark configurations that mirror real-world distributed SurrealDB+TiKV deployments
• High Availability Testing: Evaluate performance characteristics of redundant SurrealDB instances backed by TiKV
