Hybrid KAG | A chat agent that answers from your own data, grounded in both a vector store (Milvus) and a knowledge graph (Neo4j), with citations for every claim, real eval gates, guardrails, and cost controls — not just a RAG demo.
Details and verification notes live in Real retrieval, routing and answering and Production readiness; see the Roadmap to track work.
The chat pipeline has a stub mode that needs no database, no API key and no background service — this is also what .env.example and CI default to. Use this to see the UI and API shape before installing anything else:
git clone <this repo> && cd rivet_kag
cp .env.example .env # defaults: USE_STUBS=true, no API key -- nothing below needs it
make install # uv sync + npm install
make dev # API http://localhost:8000 (docs at /docs), UI http://localhost:5173
Open the UI and ask anything, or hit the API directly:
curl -X POST http://localhost:8000/api/chat \
-H 'Content-Type: application/json' \
-d '{"session_id": "demo", "message": "What is the expense policy?"}'
You'll get back a real {answer, citations[], trace[]} shape with canned citations and a canned answer — no Milvus, Neo4j, Postgres, Redis, Kafka, or LLM credentials needed; make test runs the same way. This is genuinely how far you can get with zero infrastructure, not a watered-down demo of a different code path — swapping in real retrieval and a real LLM later (see Use real retrieval and LLMs) exercises the exact same routes.
See Scope vs. a full agent platform for how this maps onto a fuller production agent architecture (multi-agent orchestration, MCP tools, VLMs) and what plugging those in would look like.
flowchart LR
UI[React UI] --> GW[API Gateway<br/>Kafka + Redis]
GW --> API[FastAPI]
API --> G[Guardrails + PII]
G --> P[Request parser<br/>intent + sources]
P --> R{Router}
R --> M[(Milvus<br/>vector search)]
R --> N[(Neo4j<br/>Cypher)]
M --> C[Merge context]
N --> C
C --> A[DeepAgents<br/>agentic RAG]
A --> O[Structured response<br/>answer + citations]
O --> UI
API -.-> PG[(PostgreSQL<br/>users, jobs, history)]
API -.-> LF[Langfuse<br/>traces]
U[File upload] --> LI[LlamaIndex ingestion] --> M
LI --> N
AgentAnswer: answer, citations used, confidence)In the UI:
API-only (no UI for these yet — use /docs, curl, or the utils/ CLI):
/api/auth/register, /login, /me) — the UI doesn't have a login screen; chat/upload work logged-out tooGET /api/actions, POST /api/actions/{id}/apply/reject) — entirely API-only today, including listing; there's no Data Management UI for this yetPOST /api/files: Excel, CSV, Markdown, PDF, via LlamaIndex) and the utils/ bulk-upload CLIsrc/pipeline/pricing.py) — visible in ChatResponse.trace[]/total_cost_usd, not rendered in the UImake eval, make judge, make deepeval, make gates, make alerts) — see Production readinessUnderlying design (not user-facing, but worth knowing about):
| Layer | Choice |
|---|---|
| Frontend | React + TypeScript (Vite) |
| Backend | FastAPI |
| Gateway / async | Kafka, Redis (cache + sessions) |
| LLM orchestration | LangChain, DeepAgents |
| Ingestion | LlamaIndex |
| Vector DB | Milvus |
| Graph DB | Neo4j |
| Relational DB | PostgreSQL |
| Guardrails | Middleware on input |
| Observability | Langfuse |
| Evals | DeepEval |
| Packaging | uv (Python), npm (frontend) |
This project implements the data/retrieval and LLOps layers of a production agent stack in full (real vector+graph RAG, evals, tracing, guardrails, cost/latency controls — see Production readiness); a few layers a fuller platform would have are deliberately out of scope here. One-liners on each, and how it currently works / how you'd wire it in if needed:
src/pipeline/answering/agent.py into a LangGraph graph with separate planner/
research/action nodes and route between them instead of one agent loop.src/pipeline/answering/tools.py's tools are bound today./api/chat responses — auth is stateless JWT, so there's no
session state to store. To add: if you need server-side sessions, add a Redis-backed session
store keyed by JWT jti, separate from the existing response-cache keys in
src/clients/redis.py.llm_provider-style branch in src/pipeline/answering/agent.py's _build_model, plus an
ingestion path for image chunks alongside the existing md/csv/xlsx/pdf loaders.Everything in Run it in 5 minutes used stubs. This section swaps in real Milvus/Neo4j retrieval and a real LLM — same routes, same UI, just backed by real infrastructure instead of canned responses. Two ways to get there: Homebrew services (this project's default for routine local dev) or Docker (see Docker below) if you'd rather not install four services directly.
You need uv (installs Python 3.12 itself), Node 18+, and Neo4j, PostgreSQL, Redis and Kafka installed locally — all via Homebrew, all run as background services. Milvus runs embedded (Milvus Lite) from a local file, so there is nothing to install for it.
brew install neo4j postgresql@16 redis kafka # once; neo4j and kafka need a JDK, Homebrew pulls one in
neo4j-admin dbms set-initial-password rivet-dev-password # once, before Neo4j's first start
createuser -s rivet && createdb -O rivet rivet # once, creates the app's Postgres role + database
make platform # start neo4j, postgres, redis and kafka as background services
make install # uv sync + npm install
make ingest # load source_data/ into Milvus and Neo4j
make dev # API http://localhost:8000 (docs at /docs) and UI http://localhost:5173
Connection settings live in .env (copy .env.example); the defaults match the commands above. Postgres tables are created automatically on startup (Base.metadata.create_all, not a migration tool — see src/db/models.py). make test lint runs the checks; the test suite never touches any of these services — see Platform.
After the one-time setup above, make up is a single command for routine local dev: it starts the four brew services if they aren't already running, polls their ports until each actually accepts a connection (not just until brew services start returns — Postgres/Neo4j/Kafka can take a few seconds to come up from cold), then runs make dev. This stays the default for day-to-day development (faster rebuilds, no container overhead) — see CLAUDE.md's "Stack and why" for the original reasoning; Docker is available as an alternative, not a replacement.
docker-compose.yml packages the whole stack — API, UI, Neo4j, Postgres, Redis, Kafka — for anyone who'd rather not install four services directly (a quick demo on a machine without Homebrew, for instance). Milvus still runs embedded even here: there's no Milvus server image, so the api container just gets the repo's ./data directory bind-mounted, same data/milvus.db file either way.
cp .env.example .env # optional: only needed to set ANTHROPIC_API_KEY/etc for a real LLM
make docker-up # builds and starts everything: API :8000, UI :5173
make docker-ingest # once, after the containers are healthy: loads source_data/
make docker-down stops everything; make docker-logs tails all container logs. The api container talks to the other containers by their compose service name (postgres, redis, kafka, neo4j), not localhost — see docker-compose.yml's environment: block. USE_STUBS=false by default here (all four services are already up), so real retrieval runs out of the box; make docker-ingest just needs to run once first, or vector/graph retrieval comes back empty rather than erroring. An LLM_PROVIDER=ollama setup needs Ollama running on the host, not in this compose file — OLLAMA_HOST defaults to http://host.docker.internal:11434 to reach it.
Verified live: built both images, brought up all six containers (Neo4j/Postgres/Redis/Kafka all pass their healthchecks), and confirmed /api/chat end to end — real vector retrieval against the bind-mounted Milvus Lite file (the same data a Homebrew-based make ingest had already loaded), /api/data/overview showing real Milvus/Neo4j data through the frontend's nginx /api proxy, and the answerer/Kafka-publish stages degrading gracefully exactly as they do outside Docker (no Ollama running on the host in that test, and Kafka's topic auto-create racing the first publish — both logged and swallowed, the request still returned 200). The Anthropic/OpenAI LLM-backed happy path itself is unverified here for the same reason as everywhere else in this README (no funded key available).
API: POST /api/chat with {"session_id": "...", "message": "..."} returns {answer, citations[], trace[]}. /api/data/* feeds the Data Management tab. POST /api/files ingests an uploaded file (see Uploading files). /api/auth/register, /login and /me handle JWT auth (see Platform).
source_data/ holds a synthetic company dataset: vector_data/ (Markdown + CSV for Milvus) and graph_data/ (node/relationship CSVs for Neo4j). See source_data/README.md for what is in it. Open source_data/index.html in a browser to explore it.
make ingest # embed and load source_data/ into both (first run downloads a ~130 MB embedding model)
Milvus Lite keeps its data in data/milvus.db. The API and the upload CLI open it one operation at a time, so you can run make ingest while make dev is running.
utils/ also handles manual uploads: uv run python -m utils.upload --help. For example vector files my_notes.md report.xlsx manual.pdf, vector text "..." --source note, graph node Employee id=E13 name="Ada", graph rel MEMBER_OF Employee:E13 Team:TM1. Everything stored is visible in the Data Management tab of the UI.
POST /api/files (multipart, field name file) accepts .md, .csv, .xlsx/.xls, .pdf and .txt, chunks it with LlamaIndex readers, embeds the chunks and upserts them into Milvus — the same collection make ingest and the Data Management tab use:
curl -F "[email protected]" http://localhost:8000/api/files
# {"filename":"notes.md","doc_type":"md","chunks_upserted":3}
Markdown is split one chunk per ## heading; CSV and Excel one chunk per row (via LlamaIndex's PagedCSVReader / PandasExcelReader); PDF one chunk per page (via PDFReader). Unsupported types get a 400, and a file with no extractable text gets a 422.
By default (USE_STUBS=true) the chat pipeline uses canned retrievers so it works with no databases running. Set USE_STUBS=false in .env (with make neo4j and make ingest already done) to switch /api/chat to real retrieval:
src/pipeline/retrieval/milvus.py) — embeds the question and runs a cosine ANN search over the ingested chunks, returning the top 4 as citations with their similarity score.src/pipeline/retrieval/neo4j.py) — a lightweight, keyword-based Cypher generator: it strips stopwords from the question, builds a query that matches nodes whose name/title/id contains one of the remaining keywords, and returns each match's direct relationships as a citation (e.g. Priya Nair (Employee) -[:LEADS]-> Data Platform (Team)). This isn't an LLM-based NL-to-Cypher translator — see the router below for that — but the query really is built from the question and executed against Neo4j, not fixed.Independently, set ANTHROPIC_API_KEY in .env to switch on two LLM-backed stages — neither needs the databases running, so both work with USE_STUBS=true too:
src/pipeline/parsing/router.py, LangChain + Claude) — classifies the question's intent and decides which retriever(s) to query, instead of always querying both. Uses with_structured_output against a small RouterDecision schema (intent, sources), so the model's choice is validated, not parsed out of free text. Anthropic-only; not affected by LLM_PROVIDER.src/pipeline/answering/agent.py, DeepAgents) — synthesizes the final answer from the merged citations, constrained to a Pydantic AgentAnswer schema (answer, citation_ids — which context items it actually used, confidence). The system prompt instructs it to answer only from the given context and say so plainly when the context doesn't cover the question, rather than guess. Its model backend is picked by LLM_PROVIDER (anthropic default, openai, or ollama for a local server) — see Model router below.Both stages fail the same way: if the call fails (bad key, timeout, malformed output) it's caught and logged, and the stage falls back to something safe — the router falls back to querying both sources, the answerer falls back to showing the retrieved citations without synthesis. A bad LLM response degrades the answer, it never 500s the request; verified live against a real, deliberately invalid key for both stages.
LLM_PROVIDER in .env picks the answerer's model backend — anthropic (default, needs ANTHROPIC_API_KEY), openai (needs OPENAI_API_KEY), or ollama (a local server at OLLAMA_HOST, default http://localhost:11434, no key). src/pipeline/answering/agent.py's _build_model maps the provider to ChatAnthropic/ChatOpenAI/ChatOllama; src/pipeline/factory.py's _answerer_has_credentials decides, per provider, whether the real DeepAgentAnswerer or StubAnswerer is used (Ollama always counts as "has credentials" — it's a local service, not a keyed API, the same reasoning as the always-real PII masker). The request parser/router stays Anthropic-only; switching LLM_PROVIDER only changes the answerer. Only the Anthropic path has been exercised against a live endpoint (a deliberately invalid key, real 401) — OpenAI and Ollama are untested beyond mocked unit tests and offline construction.
PII masking (src/guardrails/pii.py) is always on, independent of any API key — it's regex-based (email, phone, card and SSN-shaped strings get replaced with a [REDACTED_...] placeholder) and runs before the message reaches the router or the answerer, so masking never depends on having an LLM available. Input guardrails (src/guardrails/input.py) block a short list of prompt-injection phrasings before the pipeline runs at all.
evals/check_retrieval.py is a 30-question accuracy check against the live databases (unlike the mocked unit tests, it proves the retrievers find the right thing in the sample data). Run it with make eval after make ingest:
$ make eval
[PASS] What is the meal expense limit while travelling?
expected top source 'expense_policy.md', got 'expense_policy.md — Limits'
...
30/30 correct (100%)
evals/judge.py (make judge) goes further: it runs the actual pipeline end to end — real retrieval, real router, real DeepAgents answer — and has Claude grade each answer against a reference (see LLM-as-a-judge). Needs ANTHROPIC_API_KEY and costs real money to run (one answering call plus one judging call per question). Its request shape has been checked against the live API with the only key available in this environment — valid but out of credit — and gets a real 400 billing error, not a malformed-request error, but it hasn't been run end to end with a funded key yet. evals/deepeval_suite.py (make deepeval) is the fuller version — see LLM-as-a-judge — verified the same way.
Both scripts are hand-rolled precursors to the "DeepEval, 25 golden questions" Phase 4 item — same idea, smaller and framework-free.
The answerer can be given write capability — but only ever to propose a change, never to make one. This is an opt-in per request (ChatRequest.allow_actions, default false); when set, DeepAgentAnswerer binds two extra tools (src/pipeline/answering/tools.py) and a short addendum is appended to its system prompt explaining the propose-only contract. With allow_actions left at its default, these tools aren't bound at all — not just unused, structurally unavailable to that agent instance (tests/test_agent.py::test_deep_agent_answerer_binds_action_tools_only_when_enabled).
Why propose-then-apply, not direct writes. The answerer is driven by free-text chat input from anyone who can reach /api/chat — no audit trail, no undo, and prompt-injection-shaped input is exactly what it's designed to answer from. Giving it direct write access to Milvus/Neo4j would mean a bad or adversarial prompt causes a real, silent data change. A full LangGraph interrupt_on + checkpointer pause-mid-execution flow would close this more completely but is a much larger addition than this project's scope calls for (see Development philosophy); instead, every write is split into two steps that can never be collapsed into one:
src/pipeline/actions.py's propose_vector_chunk_update/propose_graph_property_update, called only via the two agent tools) — reads the current value (so there's an old_value to diff against), validates the target exists, and inserts a DataEditProposal row (Postgres: session_id, kind, target, old_value, new_value, reason, status="pending"). This step never touches Milvus or Neo4j — it's pure read-plus-audit-insert. The question's session_id and the collected proposal ids reach the tool only via contextvars (current_session_id, proposed_ids) set around the agent call in DeepAgentAnswerer.answer, never as a model-suppliable argument, so the agent can't forge whose session a proposal belongs to. The answer returned to the chat UI says a change is pending review and lists its id (ChatResponse.proposed_action_ids); it does not say the change has happened.POST /api/actions/{id}/apply / /reject, src/api/routes/actions.py) — a separate, human-initiated HTTP call with no agent involvement. Only apply_proposal ever writes to Milvus (client.upsert) or Neo4j (SET n[$prop] = $value); it re-checks the proposal is still pending (so it can't be applied or rejected twice) and records decided_at. A failure at apply time (target deleted since the proposal was made) marks the row rejected with an error, rather than raising.Scoping. Graph property updates are restricted to ALLOWED_GRAPH_LABELS (Employee, Team, Project, Tool, Document — the labels that actually exist in source_data/graph_data/*.csv), checked before the label is interpolated into the Cypher string (labels can't be parameterized). Vector chunk updates re-embed the new text (src/ingestion/embeddings.py) and preserve the chunk's other fields (source, doc_type, heading, chunk_index) rather than overwriting them.
GET /api/actions (optional ?status=pending|applied|rejected) lists proposals — entirely API-only today, there's no Data Management UI tab for this yet. Verified live end to end against real Postgres, Milvus and Neo4j, and against a local Ollama model actually choosing to call the propose tool from a natural-language request and the subsequent apply call performing the real Milvus write.
Phase 3. No stub/real split here — unlike the LLM pipeline stages, there's no meaningful "fake Postgres"; these pieces are real whenever the app runs, and are each written to degrade gracefully rather than need a flag.
src/auth/, POST /api/auth/register, /login, GET /me) — email/password with Argon2 hashing (passlib), stateless JWTs (pyjwt, JWT_SECRET/JWT_TTL_MINUTES in .env). /api/chat and /api/files accept an optional Authorization: Bearer header — logged-in activity is attributed to the user, anonymous requests still work exactly as before. No server-side session store: a stateless JWT needs none, which is why Redis's role here is caching, not sessions, despite "Redis (cache, sessions)" in the architecture diagram.src/db/, four tables — see models.py) — users; chat_history (one row per exchange, what a signed-in user could see of their own past chats); chat_audit_log (append-only, only ever stores the PII-masked question, richer fields than chat_history: outcome, sources queried, duration); ingestion_jobs (one row per /api/files upload, including failures). Tables are created with Base.metadata.create_all on startup, not Alembic migrations — the simpler, demo-appropriate choice.src/clients/redis.py) — /api/chat caches a response by a hash of the PII-masked question (keyed to the current USE_STUBS/ANTHROPIC_API_KEY mode, so switching modes never serves a stale-mode answer), TTL RESPONSE_CACHE_TTL_SECONDS (default 300s). A cache hit skips the whole pipeline — in chat_audit_log, outcome="success_cached" with duration_ms=0 marks it.src/clients/kafka.py) — publishes a rivet.chat.completed event (session, user, citation count, sources queried, duration) after every successful, non-cached chat response. Fire-and-forget: the HTTP response doesn't wait on it.All four of these are best-effort on the request path — Postgres writes, the Redis cache, and the Kafka publish are each wrapped so a failure is logged and swallowed, never raised. A /api/chat call degrades to "no history/cache/event for this one request," it never 500s because a platform service is down; verified by pointing all three at unreachable hosts and confirming chat still returns 200. The test suite never talks to a live Postgres/Redis/Kafka at all: tests/conftest.py's db_session fixture swaps in a real, in-memory SQLite database (genuine CRUD behavior, no live Postgres needed), and Kafka publishing is autouse-mocked for every test — the first version of that mock was itself a bug fix: a module-cached AIOKafkaProducer, once started inside one pytest-asyncio test's event loop, hangs forever if a later test (its own, different event loop) reuses it. Invisible in production, where uvicorn keeps one event loop for the app's whole life; see tests/conftest.py for the full story.
Design targets for cost, quality and observability, tracked in the roadmap (Phase 4) — most of it is now implemented and live-verified, not just design: per-call and job-level cost accounting, release-gate enforcement, and an alerting check all have real code (see below for exactly what each one does and doesn't cover). What's still a design, not code: the richer trace field set, and real production alerting (a cron script stands in for Prometheus/Alertmanager/paging). The specific numeric thresholds throughout this section (latency targets, alert levels) are still starting points to retune once there's real production traffic to measure against — the mechanism for enforcing them is real, the tuning isn't.
Per-stage cost accounting and the pre-flight budget rejection are implemented (src/pipeline/pricing.py, wired into src/pipeline/parsing/router.py and src/pipeline/answering/agent.py). One inspection = one /api/chat request/response cycle. Target: ≤$0.15/inspection, split into a per-stage budget so no single stage can blow the total:
| Stage | Spend driver | Budget | Notes |
|---|---|---|---|
| PII masking | — | $0.00 | Regex/NER, no LLM call — masking is a bad place to spend tokens |
| Parse/route | small classification call | ≤$0.01 (PARSE_BUDGET_USD) | Structured output. Real cost computed from the router'sAIMessage.usage_metadata (via include_raw=True) — no pre-flight gate, the stage is cheap enough it isn't worth one |
| Retrieve (vector + graph) | — | $0.00 | Local embedding (fastembed) + rule-based Cypher generation; only infra cost, no per-token spend |
| Merge / ROI-compress | optional reranker | ≤$0.005 | See below |
| Answer synthesis | agentic RAG | ≤$0.12 (ANSWER_BUDGET_USD) | The dominant cost: real cost summed across everyAIMessage DeepAgents produces (it can round-trip the model more than once per request) |
| Total | ≤$0.15 (TOTAL_BUDGET_USD) | ChatResponse.total_cost_usd — logged as a warning if exceeded; None (not summed as $0) if any stage's model isn't in the pricing table |
PRICING in src/pipeline/pricing.py) — covers only the models this project's router/answerer can actually select (the router's Anthropic model, and src/pipeline/models.py's MODEL_CATALOG). Ollama models are priced $0 (local compute, no per-token API cost). A model not in the table returns cost_usd=None — genuinely unknown, never guessed as free.DeepAgentAnswerer._estimate_cost_usd) — before the real agent call, count input tokens via the configured model's own get_num_tokens_from_messages on the assembled prompt: for Anthropic this calls the real messages.count_tokens API (verified live — see CLAUDE.md), for OpenAI it's a local tiktoken count, for Ollama a cheap local heuristic — each backend's best available method, no branching needed. Combined with a worst-case output estimate (MAX_OUTPUT_TOKENS, the same 1024-token cap passed to the model), if the estimate exceeds ANSWER_BUDGET_USD the real LLM call is skipped entirely and the context-only fallback answer is returned (AnswerResult.budget_rejected=True, cost_usd=0.0 — no call was made, so nothing was spent). If the token count itself fails (network error, unsupported model), the budget check is skipped rather than blocking the request.usage_from_ai_message reads langchain's standardized usage_metadata (input_tokens, output_tokens, and Anthropic's input_token_details.cache_read/cache_creation) and cost_usd multiplies by the model's per-token price. This lands in StageTrace (model, input_tokens, output_tokens, cost_usd, budget_rejected) and the matching Langfuse span — see Observability and audit trail.src/pipeline/answering/agent.py's _build_system_prompt): for LLM_PROVIDER=anthropic only (OpenAI caches automatically with no API to opt into; Ollama has no concept of it), the system prompt is sent as a SystemMessage with a cache_control: {type: "ephemeral"} breakpoint on its one content block. create_deep_agent preserves a SystemMessage's content blocks and appends its own boilerplate as a further, uncached block, so the breakpoint still covers all of SYSTEM_PROMPT. Verified two ways: the actual formatted request langchain_anthropic sends was inspected directly and does carry cache_control (tests/test_agent.py::test_build_system_prompt_cache_control_reaches_the_wire_format — written after an initial version using TextContentBlock's typed extras field turned out to be silently dropped by _format_text_block, which only reads a bare top-level key); and a live call against the real endpoint (with the known out-of-credit key) got the same 400 billing error as before cache_control was added, not a different "malformed request" error, confirming the request shape itself is accepted. Tool-schema caching is not implemented — DeepAgents builds its own built-in tool list (filesystem tools, task/subagent tools) internally and doesn't expose a hook to attach cache_control to it; doing this would mean forking or monkeypatching DeepAgents' internals, out of scope here. Repeat identical requests should show non-zero cache_read_tokens in the trace once a real (non-out-of-credit) Anthropic key is available to verify the cache actually hits — unverified so far for the same reason the rest of the Anthropic happy path is (see CLAUDE.md).merge_context (src/pipeline/merge.py): dedupe by id, rank by retriever score (unscored citations sort last), then greedily fill the token budget (cheap char-based estimate, no LLM call) — always keeping at least one citation even if it alone exceeds the budget. There's no summarization step; chunks are kept verbatim or dropped.SESSION_DAILY_BUDGET_USD = $1.00, src/pipeline/pricing.py) — src/api/routes/chat.py's _session_spend_24h sums chat_audit_log.cost_usd for the request's session_id over a rolling 24h window (computed from the database's own now(), not a client-side timestamp — see the function's docstring for the real bug that taught this), and once a session is over the cap, passes max_answer_cost_usd=0.0 into Pipeline.run(). This reuses the existing per-request pre-flight-rejection path (DeepAgentAnswerer.answer's max_cost_usd param) rather than a new fallback mechanism: the request still runs retrieval and returns real citations, just with the context-only fallback answer instead of a real LLM call. Best-effort like every other platform read: if the spend can't be checked (Postgres down), it doesn't block — same as a Postgres outage degrading history/audit logging elsewhere.BATCH_JOB_BUDGET_USD = $5.00) — BatchBudget (src/pipeline/pricing.py) is a simple in-process accumulator shared across one script run; evals/judge.py, evals/deepeval_suite.py and the latency/cost measurement pass in evals/release_gates.py all call budget.check() before each question and budget.add(cost) after, so evals/release_gates.py can pass one shared tracker across its whole run (retrieval + judge + deepeval + measurement) rather than each phase getting its own $5. Exceeding the limit raises BudgetExceededError — a genuine hard stop mid-run, not a logged warning the job ignores.budget_rejected: true in the trace and a logged warning, while a normal session was unaffected); make judge and make gates both still reach the real Anthropic endpoint and fail for the same known out-of-credit reason as before these changes, confirming the budget bookkeeping doesn't change the request shape.A release (prompt change, retriever change, or model swap) ships only when every blocking gate below passes against the golden set (evals/golden_questions.json — 30 questions: 20 retrieval-only plus 10 with a reference_answer for judging, covering every sample document and a spread of the knowledge graph). Warn gates are reported, not enforced.
Implemented: evals/gates.py holds the pure threshold logic as data (unit-tested offline in tests/test_gates.py — no live service needed to test the decision logic), and evals/release_gates.py (make gates) gathers real metrics from a live run (check_retrieval.py + judge.py + deepeval_suite.py + measured latency/cost) and applies them, exiting 1 on any block. .github/workflows/release-gates.yml wires this into CI as a workflow_dispatch job — manual, not on every push, since this repo has no ANTHROPIC_API_KEY (or live Milvus/Neo4j) configured as a CI secret; wiring it into push/pull_request like ci.yml would just fail every run for a reason unrelated to the code, which would violate this project's "CI stays fully offline" rule (see CLAUDE.md). Whoever configures real credentials gets real enforcement; until then, the workflow exists and documents exactly what it needs.
| Dimension | Metric | Target | Gate | Implementation |
|---|---|---|---|---|
| Retrieval quality | top-1 hit rate | ≥90% | Blocking | evals/check_retrieval.py |
| Answer quality | LLM-judge correctness score, 1–5 (see below) | mean ≥4.2, no individual score <3 | Blocking | evals/judge.py |
| Citation | FaithfulnessMetric score, 0–1 (combines "hallucinated claims" and "uncited claims" into one number — see below) | ≥0.8 | Blocking | evals/deepeval_suite.py |
| Latency | P50 end-to-end/api/chat | ≤2.5s | Warn >2.5s, blocking >5s | measured during therelease_gates.py run |
| Latency | P95 end-to-end | ≤6s | Warn >6s, blocking >10s | measured during therelease_gates.py run |
| Cost | mean $/inspection over the golden set | ≤$0.15 | Warn >$0.15, blocking >$0.20 | ChatResponse.total_cost_usd, averaged |
| HITL | sampled human review of production answers (5% of traffic, weekly) | ≥90% rated acceptable | Below 90% blocks the next release until reviewed | not implemented — no production traffic exists to sample from; always reported as "not applicable", never blocks |
| HITL | escalation rate ("I don't know" / handoff to a human) | within 2× the 7-day baseline | Blocking if exceeded — usually signals a retrieval or routing regression | not implemented, same reason |
Golden-string matching — what evals/check_retrieval.py does — only works for retrieval: it checks "did the right source come back", not "is the final answer correct." A synthesized answer has to be judged, not string-matched; this is what feeds the Answer quality and Citation rows above.
evals/judge.py (make judge) — the simple version: runs the real pipeline against each golden question with a reference_answer, then has a Claude judge call score the answer 1–5, using a JudgeVerdict schema (score, passed, rationale) so the grade is structured, not parsed out of free text.evals/deepeval_suite.py (make deepeval, needs the eval uv group — uv sync --group eval) — the fuller version, using DeepEval's GEval (a correctness rubric vs. the reference answer, scored 0–1) and FaithfulnessMetric (are the answer's claims actually supported by the retrieved context — the concrete implementation of the Citation gate). Both run against a custom AnthropicJudgeModel (deepeval.models.DeepEvalBaseLLM wrapping ChatAnthropic) rather than DeepEval's OpenAI-shaped defaults, so the judge is Claude like judge.py's. Needs the eval dependency group specifically because deepeval registers a pytest plugin that calls load_dotenv() during pytest's plugin-loading phase — before conftest.py's own dotenv neutering can run — so it's never installed by default and pyproject.toml carries addopts = "-p no:deepeval" as defense in depth even if someone runs tests with it installed (caught live while building this — see CLAUDE.md's known gotchas).claude-sonnet-5 judging, vs. the Haiku-class default answerer), to reduce self-preference bias.api.anthropic.com and fail for the expected reason (the same known out-of-credit 400 documented throughout this README), not a malformed-request error — proving the request shape, judge wrapper and golden-set plumbing are all correct even though the happy path itself is unverified (no funded key available in this environment).Langfuse tracing is implemented and local-only (src/clients/langfuse.py, wired into Pipeline.run() in src/pipeline/orchestrator.py). _is_local() refuses any host that isn't localhost/127.0.0.1 — it will never send a trace to Langfuse Cloud, regardless of LANGFUSE_HOST. There's no bundled local Langfuse server (self-hosting it needs Postgres + ClickHouse + Redis + object storage, which doesn't fit this project's brew-services-only platform story — see CLAUDE.md's "Stack and why"); run your own self-hosted instance to see traces (https://langfuse.com/self-hosting). Without one, every span attempt fails to connect and is logged as a warning by Langfuse's own exporter — same "best-effort, never breaks the request" treatment as Postgres/Redis/Kafka (see Platform): traced_span() degrades to a no-op context manager (_NullSpan) whenever the client is absent or a call fails, verified by tests/test_tracing.py.
Per-request trace (one root span per Pipeline.run() call, as_type="chain") — implemented fields:
| Field | Description |
|---|---|
session_id | set in metadata at span start and again on every update |
input | the PII-masked question — set only after the "pii" stage, neverreq.message directly, so question_raw never reaches the trace |
output | the final answer text |
sources_queried, intent | which of vector/graph were queried, and the router's intent classification |
citations_count | |
total_cost_usd | ChatResponse.total_cost_usd — sum of the per-stage cost_usd values, None if any stage's model is unpriced |
outcome | success / guardrail_blocked / error |
Not yet implemented: total_latency_ms as a distinct rollup field (the per-stage duration_ms values are there, just not pre-summed), token counts at the request level (they're per-stage — see below), and a fallback_used outcome value (the router/answerer's own fallback is logged but not yet surfaced into this field).
Per-stage trace (one child span per timed()/timed_llm() call in the orchestrator, automatically nested under the request's root span via Langfuse's OTel context) — implemented, matching StageTrace in src/schemas/chat.py: name, detail (as metadata), duration_ms (as output), and for the LLM-backed stages (parse, answer) model, input_tokens, output_tokens, cost_usd, budget_rejected — see Cost controls for how these are computed. Not yet implemented: cache_read_tokens as its own trace field (it's used in the cost calculation but not surfaced separately), query_used/num_results/top_score for vector retrieve, keywords/num_nodes_matched for graph retrieve, and per-stage error detail — these need widening the Retriever protocol to expose more than the citations it returns today.
Audit log — append-only Postgres chat_audit_log is real (see Platform), one row per request. It only stores question_masked, never the raw question — the audit trail must not become a second place PII leaks from. Today's table: session_id, user_id, question_masked, answer, sources_queried, citations_count, outcome, duration_ms, cost_usd (ChatResponse.total_cost_usd, added alongside evals/check_alerts.py specifically to feed its "mean cost/request" condition — None whenever any stage's cost is unknown, never a guessed $0). What's still a design, not code: 90-day retention (no expiry job runs yet) and per-stage token counts. Note: this table's schema is created with Base.metadata.create_all (not a migration tool — see src/db/models.py), which only creates missing tables; an existing live Postgres from before cost_usd was added needs a manual ALTER TABLE chat_audit_log ADD COLUMN cost_usd double precision; to pick it up.
Alert conditions: implemented as a stand-in for a real alerting pipeline — evals/alerts.py (pure threshold logic, unit-tested offline in tests/test_alerts.py) + evals/check_alerts.py (make alerts, reads live chat_audit_log rows). This is a manual/cron script, not real alerting: there's no Prometheus/Alertmanager, no paging integration, and the "Page" actions below (force a cheaper model, auto-rollback) aren't automated — the script only reports which level each condition is at.
| Condition | Threshold | Action | Computable today? |
|---|---|---|---|
| Mean cost/request, 15 min rolling | >$0.15 | Warn | Yes —chat_audit_log.cost_usd |
| Mean cost/request, 15 min rolling | >$0.30 | Page + force the cheaper model / stub answerer | Yes (reported only; no auto-switch) |
| P95 latency, 5 min | >6s | Warn | Yes —chat_audit_log.duration_ms |
| P95 latency, 5 min | >15s | Page | Yes (reported only) |
| 5xx / guardrail-block rate, 10 min | >2% | Warn | Yes —chat_audit_log.outcome |
| 5xx / guardrail-block rate, 10 min | >10% | Page + auto-rollback to the previous prompt/model version | Yes (reported only; no auto-rollback) |
| Router fallback rate, 30 min | >20% | Warn — LLM router likely failing or misconfigured | No — the router's own fallback isn't recorded in chat_audit_log |
| Empty-result rate (vector or graph), 30 min | >15% | Warn — index or data problem | Yes —chat_audit_log.citations_count |
| Judge-flagged hallucination rate, daily | >5% of sampled answers | Page — quality regression | No — no scheduled judge run against production traffic exists |
| Guardrail trip rate | >3× the 7-day baseline | Warn — possible prompt-injection campaign | No — needs a stored 7-day rolling baseline this project doesn't keep |
| Prompt cache hit rate | <50% of its 7-day baseline | Warn — silent cache invalidator, seeCost controls | No, same reason |
Verified live: pointed at real traffic generated through make dev, the four computable conditions correctly read non-trivial values (P95 latency, 0% error rate, 0% empty-result rate) from live rows; cost showed "not computable" for that specific traffic because the router's own known out-of-credit-key failure poisons total_cost_usd to None on every request in this environment (see CLAUDE.md), not because the wiring is broken. Caught and fixed a real bug while verifying this: the first version compared a Python-computed UTC timestamp against chat_audit_log.created_at (TIMESTAMP WITHOUT TIME ZONE, populated by Postgres's own now()) and silently returned zero rows whenever the client and server clocks disagreed — not a hypothetical, it actually happened live (~4 hours off). Fixed by computing every window boundary with Postgres's own now() instead of a client-side timestamp.
src/ backend (FastAPI), imported as `src.*`
main.py, config.py app factory, env-based settings
api/ routes (health, chat, data, auth, files) and dependencies
pipeline/ stage interfaces (base.py), orchestrator, stubs, factory
pipeline/retrieval/ real retrievers: milvus.py (vector search), neo4j.py (Cypher generation)
pipeline/parsing/ real request parser: router.py (LangChain + Claude, structured output)
pipeline/answering/ real answerer: agent.py (DeepAgents + Claude, Pydantic-validated output)
ingestion/ LlamaIndex loaders (md/csv/xlsx/pdf), embeddings, embed+upsert pipeline
auth/ password hashing (Argon2) and JWT issuance/verification
db/ SQLAlchemy models (users, chat_history, chat_audit_log, ingestion_jobs), async engine
clients/ Milvus (Lite) session, Neo4j driver, Redis client, Kafka producer
guardrails/ input.py (prompt-injection blocklist), pii.py (regex PII masking, always on)
schemas/ Pydantic request/response models
core/ logging, error handling
observability/ placeholder for Langfuse
utils/ CLI: bulk-load source_data/ and manual uploads into Milvus and Neo4j
evals/ golden_questions.json (30), live retrieval/judge/DeepEval checks, release gates, alerting — see evals/README.md
source_data/ sample data (vector_data/, graph_data/) and an HTML viewer
tests/ pytest suite
frontend/src/ React UI (Chat, Data Management)
Each pipeline stage is a Protocol in pipeline/base.py. pipeline/factory.py selects stub or real retrievers based on USE_STUBS, and the LangChain router / DeepAgents answerer whenever ANTHROPIC_API_KEY is set. PII masking has no stub variant — it's always the real, regex-based masker.
Phase 0: Skeleton
Phase 1: Data and retrieval
utils/Phase 2: Agent and safety
Phase 3: Platform
chat_audit_log)docker-compose.yml + Dockerfiles, an alternative to the Homebrew-services path, not a replacement for it — see DockerPhase 4: Quality and polish — see Production readiness for the full design
response.usage → cost_usd) and the $0.15/inspection budget, with pre-flight count_tokens rejectionGEval, FaithfulnessMetric) — evals/deepeval_suite.py (make deepeval)evals/gates.py (pure, unit-tested) + evals/release_gates.py (make gates) + .github/workflows/release-gates.yml (workflow_dispatch, needs a real ANTHROPIC_API_KEY secret this repo doesn't have — see the workflow file). HITL thresholds are intentionally never enforced: no production traffic exists to sample from.evals/alerts.py (pure, unit-tested) + evals/check_alerts.py (make alerts), reading real chat_audit_log rows. 4 of 6 conditions are genuinely computable today; 2 aren't (see below) — this is a manual/cron script, not a real alerting pipeline (no Prometheus/Alertmanager/paging integration exists in this project).allow_actions) — see Agent actionsdocs/demo.gif, recorded against the real UI with real retrieval and a real (local Ollama) answerer, not stub modeMIT, see LICENSE.
Production-minded Hybrid KAG: Milvus + Neo4j, citations, eval gates, guardrails, and cost controls
Python
6
28 commits
updated Oct 11, 2026
Hybrid KAG | A chat agent that answers from your own data, grounded in both a vector store (Milvus) and a knowledge graph (Neo4j), with citations for every claim, real eval gates, guardrails, and cost controls — not just a RAG demo.
Details and verification notes live in Real retrieval, routing and answering and Production readiness; see the Roadmap to track work.
The chat pipeline has a stub mode that needs no database, no API key and no background service — this is also what .env.example and CI default to. Use this to see the UI and API shape before installing anything else:
git clone <this repo> && cd rivet_kag
cp .env.example .env # defaults: USE_STUBS=true, no API key -- nothing below needs it
make install # uv sync + npm install
make dev # API http://localhost:8000 (docs at /docs), UI http://localhost:5173
Open the UI and ask anything, or hit the API directly:
curl -X POST http://localhost:8000/api/chat \
-H 'Content-Type: application/json' \
-d '{"session_id": "demo", "message": "What is the expense policy?"}'
You'll get back a real {answer, citations[], trace[]} shape with canned citations and a canned answer — no Milvus, Neo4j, Postgres, Redis, Kafka, or LLM credentials needed; make test runs the same way. This is genuinely how far you can get with zero infrastructure, not a watered-down demo of a different code path — swapping in real retrieval and a real LLM later (see Use real retrieval and LLMs) exercises the exact same routes.
See Scope vs. a full agent platform for how this maps onto a fuller production agent architecture (multi-agent orchestration, MCP tools, VLMs) and what plugging those in would look like.
flowchart LR
UI[React UI] --> GW[API Gateway<br/>Kafka + Redis]
GW --> API[FastAPI]
API --> G[Guardrails + PII]
G --> P[Request parser<br/>intent + sources]
P --> R{Router}
R --> M[(Milvus<br/>vector search)]
R --> N[(Neo4j<br/>Cypher)]
M --> C[Merge context]
N --> C
C --> A[DeepAgents<br/>agentic RAG]
A --> O[Structured response<br/>answer + citations]
O --> UI
API -.-> PG[(PostgreSQL<br/>users, jobs, history)]
API -.-> LF[Langfuse<br/>traces]
U[File upload] --> LI[LlamaIndex ingestion] --> M
LI --> N
AgentAnswer: answer, citations used, confidence)In the UI:
API-only (no UI for these yet — use /docs, curl, or the utils/ CLI):
/api/auth/register, /login, /me) — the UI doesn't have a login screen; chat/upload work logged-out tooGET /api/actions, POST /api/actions/{id}/apply/reject) — entirely API-only today, including listing; there's no Data Management UI for this yetPOST /api/files: Excel, CSV, Markdown, PDF, via LlamaIndex) and the utils/ bulk-upload CLIsrc/pipeline/pricing.py) — visible in ChatResponse.trace[]/total_cost_usd, not rendered in the UImake eval, make judge, make deepeval, make gates, make alerts) — see Production readinessUnderlying design (not user-facing, but worth knowing about):
| Layer | Choice |
|---|---|
| Frontend | React + TypeScript (Vite) |
| Backend | FastAPI |
| Gateway / async | Kafka, Redis (cache + sessions) |
| LLM orchestration | LangChain, DeepAgents |
| Ingestion | LlamaIndex |
| Vector DB | Milvus |
| Graph DB | Neo4j |
| Relational DB | PostgreSQL |
| Guardrails | Middleware on input |
| Observability | Langfuse |
| Evals | DeepEval |
| Packaging | uv (Python), npm (frontend) |
This project implements the data/retrieval and LLOps layers of a production agent stack in full (real vector+graph RAG, evals, tracing, guardrails, cost/latency controls — see Production readiness); a few layers a fuller platform would have are deliberately out of scope here. One-liners on each, and how it currently works / how you'd wire it in if needed:
src/pipeline/answering/agent.py into a LangGraph graph with separate planner/
research/action nodes and route between them instead of one agent loop.src/pipeline/answering/tools.py's tools are bound today./api/chat responses — auth is stateless JWT, so there's no
session state to store. To add: if you need server-side sessions, add a Redis-backed session
store keyed by JWT jti, separate from the existing response-cache keys in
src/clients/redis.py.llm_provider-style branch in src/pipeline/answering/agent.py's _build_model, plus an
ingestion path for image chunks alongside the existing md/csv/xlsx/pdf loaders.Everything in Run it in 5 minutes used stubs. This section swaps in real Milvus/Neo4j retrieval and a real LLM — same routes, same UI, just backed by real infrastructure instead of canned responses. Two ways to get there: Homebrew services (this project's default for routine local dev) or Docker (see Docker below) if you'd rather not install four services directly.
You need uv (installs Python 3.12 itself), Node 18+, and Neo4j, PostgreSQL, Redis and Kafka installed locally — all via Homebrew, all run as background services. Milvus runs embedded (Milvus Lite) from a local file, so there is nothing to install for it.
brew install neo4j postgresql@16 redis kafka # once; neo4j and kafka need a JDK, Homebrew pulls one in
neo4j-admin dbms set-initial-password rivet-dev-password # once, before Neo4j's first start
createuser -s rivet && createdb -O rivet rivet # once, creates the app's Postgres role + database
make platform # start neo4j, postgres, redis and kafka as background services
make install # uv sync + npm install
make ingest # load source_data/ into Milvus and Neo4j
make dev # API http://localhost:8000 (docs at /docs) and UI http://localhost:5173
Connection settings live in .env (copy .env.example); the defaults match the commands above. Postgres tables are created automatically on startup (Base.metadata.create_all, not a migration tool — see src/db/models.py). make test lint runs the checks; the test suite never touches any of these services — see Platform.
After the one-time setup above, make up is a single command for routine local dev: it starts the four brew services if they aren't already running, polls their ports until each actually accepts a connection (not just until brew services start returns — Postgres/Neo4j/Kafka can take a few seconds to come up from cold), then runs make dev. This stays the default for day-to-day development (faster rebuilds, no container overhead) — see CLAUDE.md's "Stack and why" for the original reasoning; Docker is available as an alternative, not a replacement.
docker-compose.yml packages the whole stack — API, UI, Neo4j, Postgres, Redis, Kafka — for anyone who'd rather not install four services directly (a quick demo on a machine without Homebrew, for instance). Milvus still runs embedded even here: there's no Milvus server image, so the api container just gets the repo's ./data directory bind-mounted, same data/milvus.db file either way.
cp .env.example .env # optional: only needed to set ANTHROPIC_API_KEY/etc for a real LLM
make docker-up # builds and starts everything: API :8000, UI :5173
make docker-ingest # once, after the containers are healthy: loads source_data/
make docker-down stops everything; make docker-logs tails all container logs. The api container talks to the other containers by their compose service name (postgres, redis, kafka, neo4j), not localhost — see docker-compose.yml's environment: block. USE_STUBS=false by default here (all four services are already up), so real retrieval runs out of the box; make docker-ingest just needs to run once first, or vector/graph retrieval comes back empty rather than erroring. An LLM_PROVIDER=ollama setup needs Ollama running on the host, not in this compose file — OLLAMA_HOST defaults to http://host.docker.internal:11434 to reach it.
Verified live: built both images, brought up all six containers (Neo4j/Postgres/Redis/Kafka all pass their healthchecks), and confirmed /api/chat end to end — real vector retrieval against the bind-mounted Milvus Lite file (the same data a Homebrew-based make ingest had already loaded), /api/data/overview showing real Milvus/Neo4j data through the frontend's nginx /api proxy, and the answerer/Kafka-publish stages degrading gracefully exactly as they do outside Docker (no Ollama running on the host in that test, and Kafka's topic auto-create racing the first publish — both logged and swallowed, the request still returned 200). The Anthropic/OpenAI LLM-backed happy path itself is unverified here for the same reason as everywhere else in this README (no funded key available).
API: POST /api/chat with {"session_id": "...", "message": "..."} returns {answer, citations[], trace[]}. /api/data/* feeds the Data Management tab. POST /api/files ingests an uploaded file (see Uploading files). /api/auth/register, /login and /me handle JWT auth (see Platform).
source_data/ holds a synthetic company dataset: vector_data/ (Markdown + CSV for Milvus) and graph_data/ (node/relationship CSVs for Neo4j). See source_data/README.md for what is in it. Open source_data/index.html in a browser to explore it.
make ingest # embed and load source_data/ into both (first run downloads a ~130 MB embedding model)
Milvus Lite keeps its data in data/milvus.db. The API and the upload CLI open it one operation at a time, so you can run make ingest while make dev is running.
utils/ also handles manual uploads: uv run python -m utils.upload --help. For example vector files my_notes.md report.xlsx manual.pdf, vector text "..." --source note, graph node Employee id=E13 name="Ada", graph rel MEMBER_OF Employee:E13 Team:TM1. Everything stored is visible in the Data Management tab of the UI.
POST /api/files (multipart, field name file) accepts .md, .csv, .xlsx/.xls, .pdf and .txt, chunks it with LlamaIndex readers, embeds the chunks and upserts them into Milvus — the same collection make ingest and the Data Management tab use:
curl -F "[email protected]" http://localhost:8000/api/files
# {"filename":"notes.md","doc_type":"md","chunks_upserted":3}
Markdown is split one chunk per ## heading; CSV and Excel one chunk per row (via LlamaIndex's PagedCSVReader / PandasExcelReader); PDF one chunk per page (via PDFReader). Unsupported types get a 400, and a file with no extractable text gets a 422.
By default (USE_STUBS=true) the chat pipeline uses canned retrievers so it works with no databases running. Set USE_STUBS=false in .env (with make neo4j and make ingest already done) to switch /api/chat to real retrieval:
src/pipeline/retrieval/milvus.py) — embeds the question and runs a cosine ANN search over the ingested chunks, returning the top 4 as citations with their similarity score.src/pipeline/retrieval/neo4j.py) — a lightweight, keyword-based Cypher generator: it strips stopwords from the question, builds a query that matches nodes whose name/title/id contains one of the remaining keywords, and returns each match's direct relationships as a citation (e.g. Priya Nair (Employee) -[:LEADS]-> Data Platform (Team)). This isn't an LLM-based NL-to-Cypher translator — see the router below for that — but the query really is built from the question and executed against Neo4j, not fixed.Independently, set ANTHROPIC_API_KEY in .env to switch on two LLM-backed stages — neither needs the databases running, so both work with USE_STUBS=true too:
src/pipeline/parsing/router.py, LangChain + Claude) — classifies the question's intent and decides which retriever(s) to query, instead of always querying both. Uses with_structured_output against a small RouterDecision schema (intent, sources), so the model's choice is validated, not parsed out of free text. Anthropic-only; not affected by LLM_PROVIDER.src/pipeline/answering/agent.py, DeepAgents) — synthesizes the final answer from the merged citations, constrained to a Pydantic AgentAnswer schema (answer, citation_ids — which context items it actually used, confidence). The system prompt instructs it to answer only from the given context and say so plainly when the context doesn't cover the question, rather than guess. Its model backend is picked by LLM_PROVIDER (anthropic default, openai, or ollama for a local server) — see Model router below.Both stages fail the same way: if the call fails (bad key, timeout, malformed output) it's caught and logged, and the stage falls back to something safe — the router falls back to querying both sources, the answerer falls back to showing the retrieved citations without synthesis. A bad LLM response degrades the answer, it never 500s the request; verified live against a real, deliberately invalid key for both stages.
LLM_PROVIDER in .env picks the answerer's model backend — anthropic (default, needs ANTHROPIC_API_KEY), openai (needs OPENAI_API_KEY), or ollama (a local server at OLLAMA_HOST, default http://localhost:11434, no key). src/pipeline/answering/agent.py's _build_model maps the provider to ChatAnthropic/ChatOpenAI/ChatOllama; src/pipeline/factory.py's _answerer_has_credentials decides, per provider, whether the real DeepAgentAnswerer or StubAnswerer is used (Ollama always counts as "has credentials" — it's a local service, not a keyed API, the same reasoning as the always-real PII masker). The request parser/router stays Anthropic-only; switching LLM_PROVIDER only changes the answerer. Only the Anthropic path has been exercised against a live endpoint (a deliberately invalid key, real 401) — OpenAI and Ollama are untested beyond mocked unit tests and offline construction.
PII masking (src/guardrails/pii.py) is always on, independent of any API key — it's regex-based (email, phone, card and SSN-shaped strings get replaced with a [REDACTED_...] placeholder) and runs before the message reaches the router or the answerer, so masking never depends on having an LLM available. Input guardrails (src/guardrails/input.py) block a short list of prompt-injection phrasings before the pipeline runs at all.
evals/check_retrieval.py is a 30-question accuracy check against the live databases (unlike the mocked unit tests, it proves the retrievers find the right thing in the sample data). Run it with make eval after make ingest:
$ make eval
[PASS] What is the meal expense limit while travelling?
expected top source 'expense_policy.md', got 'expense_policy.md — Limits'
...
30/30 correct (100%)
evals/judge.py (make judge) goes further: it runs the actual pipeline end to end — real retrieval, real router, real DeepAgents answer — and has Claude grade each answer against a reference (see LLM-as-a-judge). Needs ANTHROPIC_API_KEY and costs real money to run (one answering call plus one judging call per question). Its request shape has been checked against the live API with the only key available in this environment — valid but out of credit — and gets a real 400 billing error, not a malformed-request error, but it hasn't been run end to end with a funded key yet. evals/deepeval_suite.py (make deepeval) is the fuller version — see LLM-as-a-judge — verified the same way.
Both scripts are hand-rolled precursors to the "DeepEval, 25 golden questions" Phase 4 item — same idea, smaller and framework-free.
The answerer can be given write capability — but only ever to propose a change, never to make one. This is an opt-in per request (ChatRequest.allow_actions, default false); when set, DeepAgentAnswerer binds two extra tools (src/pipeline/answering/tools.py) and a short addendum is appended to its system prompt explaining the propose-only contract. With allow_actions left at its default, these tools aren't bound at all — not just unused, structurally unavailable to that agent instance (tests/test_agent.py::test_deep_agent_answerer_binds_action_tools_only_when_enabled).
Why propose-then-apply, not direct writes. The answerer is driven by free-text chat input from anyone who can reach /api/chat — no audit trail, no undo, and prompt-injection-shaped input is exactly what it's designed to answer from. Giving it direct write access to Milvus/Neo4j would mean a bad or adversarial prompt causes a real, silent data change. A full LangGraph interrupt_on + checkpointer pause-mid-execution flow would close this more completely but is a much larger addition than this project's scope calls for (see Development philosophy); instead, every write is split into two steps that can never be collapsed into one:
src/pipeline/actions.py's propose_vector_chunk_update/propose_graph_property_update, called only via the two agent tools) — reads the current value (so there's an old_value to diff against), validates the target exists, and inserts a DataEditProposal row (Postgres: session_id, kind, target, old_value, new_value, reason, status="pending"). This step never touches Milvus or Neo4j — it's pure read-plus-audit-insert. The question's session_id and the collected proposal ids reach the tool only via contextvars (current_session_id, proposed_ids) set around the agent call in DeepAgentAnswerer.answer, never as a model-suppliable argument, so the agent can't forge whose session a proposal belongs to. The answer returned to the chat UI says a change is pending review and lists its id (ChatResponse.proposed_action_ids); it does not say the change has happened.POST /api/actions/{id}/apply / /reject, src/api/routes/actions.py) — a separate, human-initiated HTTP call with no agent involvement. Only apply_proposal ever writes to Milvus (client.upsert) or Neo4j (SET n[$prop] = $value); it re-checks the proposal is still pending (so it can't be applied or rejected twice) and records decided_at. A failure at apply time (target deleted since the proposal was made) marks the row rejected with an error, rather than raising.Scoping. Graph property updates are restricted to ALLOWED_GRAPH_LABELS (Employee, Team, Project, Tool, Document — the labels that actually exist in source_data/graph_data/*.csv), checked before the label is interpolated into the Cypher string (labels can't be parameterized). Vector chunk updates re-embed the new text (src/ingestion/embeddings.py) and preserve the chunk's other fields (source, doc_type, heading, chunk_index) rather than overwriting them.
GET /api/actions (optional ?status=pending|applied|rejected) lists proposals — entirely API-only today, there's no Data Management UI tab for this yet. Verified live end to end against real Postgres, Milvus and Neo4j, and against a local Ollama model actually choosing to call the propose tool from a natural-language request and the subsequent apply call performing the real Milvus write.
Phase 3. No stub/real split here — unlike the LLM pipeline stages, there's no meaningful "fake Postgres"; these pieces are real whenever the app runs, and are each written to degrade gracefully rather than need a flag.
src/auth/, POST /api/auth/register, /login, GET /me) — email/password with Argon2 hashing (passlib), stateless JWTs (pyjwt, JWT_SECRET/JWT_TTL_MINUTES in .env). /api/chat and /api/files accept an optional Authorization: Bearer header — logged-in activity is attributed to the user, anonymous requests still work exactly as before. No server-side session store: a stateless JWT needs none, which is why Redis's role here is caching, not sessions, despite "Redis (cache, sessions)" in the architecture diagram.src/db/, four tables — see models.py) — users; chat_history (one row per exchange, what a signed-in user could see of their own past chats); chat_audit_log (append-only, only ever stores the PII-masked question, richer fields than chat_history: outcome, sources queried, duration); ingestion_jobs (one row per /api/files upload, including failures). Tables are created with Base.metadata.create_all on startup, not Alembic migrations — the simpler, demo-appropriate choice.src/clients/redis.py) — /api/chat caches a response by a hash of the PII-masked question (keyed to the current USE_STUBS/ANTHROPIC_API_KEY mode, so switching modes never serves a stale-mode answer), TTL RESPONSE_CACHE_TTL_SECONDS (default 300s). A cache hit skips the whole pipeline — in chat_audit_log, outcome="success_cached" with duration_ms=0 marks it.src/clients/kafka.py) — publishes a rivet.chat.completed event (session, user, citation count, sources queried, duration) after every successful, non-cached chat response. Fire-and-forget: the HTTP response doesn't wait on it.All four of these are best-effort on the request path — Postgres writes, the Redis cache, and the Kafka publish are each wrapped so a failure is logged and swallowed, never raised. A /api/chat call degrades to "no history/cache/event for this one request," it never 500s because a platform service is down; verified by pointing all three at unreachable hosts and confirming chat still returns 200. The test suite never talks to a live Postgres/Redis/Kafka at all: tests/conftest.py's db_session fixture swaps in a real, in-memory SQLite database (genuine CRUD behavior, no live Postgres needed), and Kafka publishing is autouse-mocked for every test — the first version of that mock was itself a bug fix: a module-cached AIOKafkaProducer, once started inside one pytest-asyncio test's event loop, hangs forever if a later test (its own, different event loop) reuses it. Invisible in production, where uvicorn keeps one event loop for the app's whole life; see tests/conftest.py for the full story.
Design targets for cost, quality and observability, tracked in the roadmap (Phase 4) — most of it is now implemented and live-verified, not just design: per-call and job-level cost accounting, release-gate enforcement, and an alerting check all have real code (see below for exactly what each one does and doesn't cover). What's still a design, not code: the richer trace field set, and real production alerting (a cron script stands in for Prometheus/Alertmanager/paging). The specific numeric thresholds throughout this section (latency targets, alert levels) are still starting points to retune once there's real production traffic to measure against — the mechanism for enforcing them is real, the tuning isn't.
Per-stage cost accounting and the pre-flight budget rejection are implemented (src/pipeline/pricing.py, wired into src/pipeline/parsing/router.py and src/pipeline/answering/agent.py). One inspection = one /api/chat request/response cycle. Target: ≤$0.15/inspection, split into a per-stage budget so no single stage can blow the total:
| Stage | Spend driver | Budget | Notes |
|---|---|---|---|
| PII masking | — | $0.00 | Regex/NER, no LLM call — masking is a bad place to spend tokens |
| Parse/route | small classification call | ≤$0.01 (PARSE_BUDGET_USD) | Structured output. Real cost computed from the router'sAIMessage.usage_metadata (via include_raw=True) — no pre-flight gate, the stage is cheap enough it isn't worth one |
| Retrieve (vector + graph) | — | $0.00 | Local embedding (fastembed) + rule-based Cypher generation; only infra cost, no per-token spend |
| Merge / ROI-compress | optional reranker | ≤$0.005 | See below |
| Answer synthesis | agentic RAG | ≤$0.12 (ANSWER_BUDGET_USD) | The dominant cost: real cost summed across everyAIMessage DeepAgents produces (it can round-trip the model more than once per request) |
| Total | ≤$0.15 (TOTAL_BUDGET_USD) | ChatResponse.total_cost_usd — logged as a warning if exceeded; None (not summed as $0) if any stage's model isn't in the pricing table |
PRICING in src/pipeline/pricing.py) — covers only the models this project's router/answerer can actually select (the router's Anthropic model, and src/pipeline/models.py's MODEL_CATALOG). Ollama models are priced $0 (local compute, no per-token API cost). A model not in the table returns cost_usd=None — genuinely unknown, never guessed as free.DeepAgentAnswerer._estimate_cost_usd) — before the real agent call, count input tokens via the configured model's own get_num_tokens_from_messages on the assembled prompt: for Anthropic this calls the real messages.count_tokens API (verified live — see CLAUDE.md), for OpenAI it's a local tiktoken count, for Ollama a cheap local heuristic — each backend's best available method, no branching needed. Combined with a worst-case output estimate (MAX_OUTPUT_TOKENS, the same 1024-token cap passed to the model), if the estimate exceeds ANSWER_BUDGET_USD the real LLM call is skipped entirely and the context-only fallback answer is returned (AnswerResult.budget_rejected=True, cost_usd=0.0 — no call was made, so nothing was spent). If the token count itself fails (network error, unsupported model), the budget check is skipped rather than blocking the request.usage_from_ai_message reads langchain's standardized usage_metadata (input_tokens, output_tokens, and Anthropic's input_token_details.cache_read/cache_creation) and cost_usd multiplies by the model's per-token price. This lands in StageTrace (model, input_tokens, output_tokens, cost_usd, budget_rejected) and the matching Langfuse span — see Observability and audit trail.src/pipeline/answering/agent.py's _build_system_prompt): for LLM_PROVIDER=anthropic only (OpenAI caches automatically with no API to opt into; Ollama has no concept of it), the system prompt is sent as a SystemMessage with a cache_control: {type: "ephemeral"} breakpoint on its one content block. create_deep_agent preserves a SystemMessage's content blocks and appends its own boilerplate as a further, uncached block, so the breakpoint still covers all of SYSTEM_PROMPT. Verified two ways: the actual formatted request langchain_anthropic sends was inspected directly and does carry cache_control (tests/test_agent.py::test_build_system_prompt_cache_control_reaches_the_wire_format — written after an initial version using TextContentBlock's typed extras field turned out to be silently dropped by _format_text_block, which only reads a bare top-level key); and a live call against the real endpoint (with the known out-of-credit key) got the same 400 billing error as before cache_control was added, not a different "malformed request" error, confirming the request shape itself is accepted. Tool-schema caching is not implemented — DeepAgents builds its own built-in tool list (filesystem tools, task/subagent tools) internally and doesn't expose a hook to attach cache_control to it; doing this would mean forking or monkeypatching DeepAgents' internals, out of scope here. Repeat identical requests should show non-zero cache_read_tokens in the trace once a real (non-out-of-credit) Anthropic key is available to verify the cache actually hits — unverified so far for the same reason the rest of the Anthropic happy path is (see CLAUDE.md).merge_context (src/pipeline/merge.py): dedupe by id, rank by retriever score (unscored citations sort last), then greedily fill the token budget (cheap char-based estimate, no LLM call) — always keeping at least one citation even if it alone exceeds the budget. There's no summarization step; chunks are kept verbatim or dropped.SESSION_DAILY_BUDGET_USD = $1.00, src/pipeline/pricing.py) — src/api/routes/chat.py's _session_spend_24h sums chat_audit_log.cost_usd for the request's session_id over a rolling 24h window (computed from the database's own now(), not a client-side timestamp — see the function's docstring for the real bug that taught this), and once a session is over the cap, passes max_answer_cost_usd=0.0 into Pipeline.run(). This reuses the existing per-request pre-flight-rejection path (DeepAgentAnswerer.answer's max_cost_usd param) rather than a new fallback mechanism: the request still runs retrieval and returns real citations, just with the context-only fallback answer instead of a real LLM call. Best-effort like every other platform read: if the spend can't be checked (Postgres down), it doesn't block — same as a Postgres outage degrading history/audit logging elsewhere.BATCH_JOB_BUDGET_USD = $5.00) — BatchBudget (src/pipeline/pricing.py) is a simple in-process accumulator shared across one script run; evals/judge.py, evals/deepeval_suite.py and the latency/cost measurement pass in evals/release_gates.py all call budget.check() before each question and budget.add(cost) after, so evals/release_gates.py can pass one shared tracker across its whole run (retrieval + judge + deepeval + measurement) rather than each phase getting its own $5. Exceeding the limit raises BudgetExceededError — a genuine hard stop mid-run, not a logged warning the job ignores.budget_rejected: true in the trace and a logged warning, while a normal session was unaffected); make judge and make gates both still reach the real Anthropic endpoint and fail for the same known out-of-credit reason as before these changes, confirming the budget bookkeeping doesn't change the request shape.A release (prompt change, retriever change, or model swap) ships only when every blocking gate below passes against the golden set (evals/golden_questions.json — 30 questions: 20 retrieval-only plus 10 with a reference_answer for judging, covering every sample document and a spread of the knowledge graph). Warn gates are reported, not enforced.
Implemented: evals/gates.py holds the pure threshold logic as data (unit-tested offline in tests/test_gates.py — no live service needed to test the decision logic), and evals/release_gates.py (make gates) gathers real metrics from a live run (check_retrieval.py + judge.py + deepeval_suite.py + measured latency/cost) and applies them, exiting 1 on any block. .github/workflows/release-gates.yml wires this into CI as a workflow_dispatch job — manual, not on every push, since this repo has no ANTHROPIC_API_KEY (or live Milvus/Neo4j) configured as a CI secret; wiring it into push/pull_request like ci.yml would just fail every run for a reason unrelated to the code, which would violate this project's "CI stays fully offline" rule (see CLAUDE.md). Whoever configures real credentials gets real enforcement; until then, the workflow exists and documents exactly what it needs.
| Dimension | Metric | Target | Gate | Implementation |
|---|---|---|---|---|
| Retrieval quality | top-1 hit rate | ≥90% | Blocking | evals/check_retrieval.py |
| Answer quality | LLM-judge correctness score, 1–5 (see below) | mean ≥4.2, no individual score <3 | Blocking | evals/judge.py |
| Citation | FaithfulnessMetric score, 0–1 (combines "hallucinated claims" and "uncited claims" into one number — see below) | ≥0.8 | Blocking | evals/deepeval_suite.py |
| Latency | P50 end-to-end/api/chat | ≤2.5s | Warn >2.5s, blocking >5s | measured during therelease_gates.py run |
| Latency | P95 end-to-end | ≤6s | Warn >6s, blocking >10s | measured during therelease_gates.py run |
| Cost | mean $/inspection over the golden set | ≤$0.15 | Warn >$0.15, blocking >$0.20 | ChatResponse.total_cost_usd, averaged |
| HITL | sampled human review of production answers (5% of traffic, weekly) | ≥90% rated acceptable | Below 90% blocks the next release until reviewed | not implemented — no production traffic exists to sample from; always reported as "not applicable", never blocks |
| HITL | escalation rate ("I don't know" / handoff to a human) | within 2× the 7-day baseline | Blocking if exceeded — usually signals a retrieval or routing regression | not implemented, same reason |
Golden-string matching — what evals/check_retrieval.py does — only works for retrieval: it checks "did the right source come back", not "is the final answer correct." A synthesized answer has to be judged, not string-matched; this is what feeds the Answer quality and Citation rows above.
evals/judge.py (make judge) — the simple version: runs the real pipeline against each golden question with a reference_answer, then has a Claude judge call score the answer 1–5, using a JudgeVerdict schema (score, passed, rationale) so the grade is structured, not parsed out of free text.evals/deepeval_suite.py (make deepeval, needs the eval uv group — uv sync --group eval) — the fuller version, using DeepEval's GEval (a correctness rubric vs. the reference answer, scored 0–1) and FaithfulnessMetric (are the answer's claims actually supported by the retrieved context — the concrete implementation of the Citation gate). Both run against a custom AnthropicJudgeModel (deepeval.models.DeepEvalBaseLLM wrapping ChatAnthropic) rather than DeepEval's OpenAI-shaped defaults, so the judge is Claude like judge.py's. Needs the eval dependency group specifically because deepeval registers a pytest plugin that calls load_dotenv() during pytest's plugin-loading phase — before conftest.py's own dotenv neutering can run — so it's never installed by default and pyproject.toml carries addopts = "-p no:deepeval" as defense in depth even if someone runs tests with it installed (caught live while building this — see CLAUDE.md's known gotchas).claude-sonnet-5 judging, vs. the Haiku-class default answerer), to reduce self-preference bias.api.anthropic.com and fail for the expected reason (the same known out-of-credit 400 documented throughout this README), not a malformed-request error — proving the request shape, judge wrapper and golden-set plumbing are all correct even though the happy path itself is unverified (no funded key available in this environment).Langfuse tracing is implemented and local-only (src/clients/langfuse.py, wired into Pipeline.run() in src/pipeline/orchestrator.py). _is_local() refuses any host that isn't localhost/127.0.0.1 — it will never send a trace to Langfuse Cloud, regardless of LANGFUSE_HOST. There's no bundled local Langfuse server (self-hosting it needs Postgres + ClickHouse + Redis + object storage, which doesn't fit this project's brew-services-only platform story — see CLAUDE.md's "Stack and why"); run your own self-hosted instance to see traces (https://langfuse.com/self-hosting). Without one, every span attempt fails to connect and is logged as a warning by Langfuse's own exporter — same "best-effort, never breaks the request" treatment as Postgres/Redis/Kafka (see Platform): traced_span() degrades to a no-op context manager (_NullSpan) whenever the client is absent or a call fails, verified by tests/test_tracing.py.
Per-request trace (one root span per Pipeline.run() call, as_type="chain") — implemented fields:
| Field | Description |
|---|---|
session_id | set in metadata at span start and again on every update |
input | the PII-masked question — set only after the "pii" stage, neverreq.message directly, so question_raw never reaches the trace |
output | the final answer text |
sources_queried, intent | which of vector/graph were queried, and the router's intent classification |
citations_count | |
total_cost_usd | ChatResponse.total_cost_usd — sum of the per-stage cost_usd values, None if any stage's model is unpriced |
outcome | success / guardrail_blocked / error |
Not yet implemented: total_latency_ms as a distinct rollup field (the per-stage duration_ms values are there, just not pre-summed), token counts at the request level (they're per-stage — see below), and a fallback_used outcome value (the router/answerer's own fallback is logged but not yet surfaced into this field).
Per-stage trace (one child span per timed()/timed_llm() call in the orchestrator, automatically nested under the request's root span via Langfuse's OTel context) — implemented, matching StageTrace in src/schemas/chat.py: name, detail (as metadata), duration_ms (as output), and for the LLM-backed stages (parse, answer) model, input_tokens, output_tokens, cost_usd, budget_rejected — see Cost controls for how these are computed. Not yet implemented: cache_read_tokens as its own trace field (it's used in the cost calculation but not surfaced separately), query_used/num_results/top_score for vector retrieve, keywords/num_nodes_matched for graph retrieve, and per-stage error detail — these need widening the Retriever protocol to expose more than the citations it returns today.
Audit log — append-only Postgres chat_audit_log is real (see Platform), one row per request. It only stores question_masked, never the raw question — the audit trail must not become a second place PII leaks from. Today's table: session_id, user_id, question_masked, answer, sources_queried, citations_count, outcome, duration_ms, cost_usd (ChatResponse.total_cost_usd, added alongside evals/check_alerts.py specifically to feed its "mean cost/request" condition — None whenever any stage's cost is unknown, never a guessed $0). What's still a design, not code: 90-day retention (no expiry job runs yet) and per-stage token counts. Note: this table's schema is created with Base.metadata.create_all (not a migration tool — see src/db/models.py), which only creates missing tables; an existing live Postgres from before cost_usd was added needs a manual ALTER TABLE chat_audit_log ADD COLUMN cost_usd double precision; to pick it up.
Alert conditions: implemented as a stand-in for a real alerting pipeline — evals/alerts.py (pure threshold logic, unit-tested offline in tests/test_alerts.py) + evals/check_alerts.py (make alerts, reads live chat_audit_log rows). This is a manual/cron script, not real alerting: there's no Prometheus/Alertmanager, no paging integration, and the "Page" actions below (force a cheaper model, auto-rollback) aren't automated — the script only reports which level each condition is at.
| Condition | Threshold | Action | Computable today? |
|---|---|---|---|
| Mean cost/request, 15 min rolling | >$0.15 | Warn | Yes —chat_audit_log.cost_usd |
| Mean cost/request, 15 min rolling | >$0.30 | Page + force the cheaper model / stub answerer | Yes (reported only; no auto-switch) |
| P95 latency, 5 min | >6s | Warn | Yes —chat_audit_log.duration_ms |
| P95 latency, 5 min | >15s | Page | Yes (reported only) |
| 5xx / guardrail-block rate, 10 min | >2% | Warn | Yes —chat_audit_log.outcome |
| 5xx / guardrail-block rate, 10 min | >10% | Page + auto-rollback to the previous prompt/model version | Yes (reported only; no auto-rollback) |
| Router fallback rate, 30 min | >20% | Warn — LLM router likely failing or misconfigured | No — the router's own fallback isn't recorded in chat_audit_log |
| Empty-result rate (vector or graph), 30 min | >15% | Warn — index or data problem | Yes —chat_audit_log.citations_count |
| Judge-flagged hallucination rate, daily | >5% of sampled answers | Page — quality regression | No — no scheduled judge run against production traffic exists |
| Guardrail trip rate | >3× the 7-day baseline | Warn — possible prompt-injection campaign | No — needs a stored 7-day rolling baseline this project doesn't keep |
| Prompt cache hit rate | <50% of its 7-day baseline | Warn — silent cache invalidator, seeCost controls | No, same reason |
Verified live: pointed at real traffic generated through make dev, the four computable conditions correctly read non-trivial values (P95 latency, 0% error rate, 0% empty-result rate) from live rows; cost showed "not computable" for that specific traffic because the router's own known out-of-credit-key failure poisons total_cost_usd to None on every request in this environment (see CLAUDE.md), not because the wiring is broken. Caught and fixed a real bug while verifying this: the first version compared a Python-computed UTC timestamp against chat_audit_log.created_at (TIMESTAMP WITHOUT TIME ZONE, populated by Postgres's own now()) and silently returned zero rows whenever the client and server clocks disagreed — not a hypothetical, it actually happened live (~4 hours off). Fixed by computing every window boundary with Postgres's own now() instead of a client-side timestamp.
src/ backend (FastAPI), imported as `src.*`
main.py, config.py app factory, env-based settings
api/ routes (health, chat, data, auth, files) and dependencies
pipeline/ stage interfaces (base.py), orchestrator, stubs, factory
pipeline/retrieval/ real retrievers: milvus.py (vector search), neo4j.py (Cypher generation)
pipeline/parsing/ real request parser: router.py (LangChain + Claude, structured output)
pipeline/answering/ real answerer: agent.py (DeepAgents + Claude, Pydantic-validated output)
ingestion/ LlamaIndex loaders (md/csv/xlsx/pdf), embeddings, embed+upsert pipeline
auth/ password hashing (Argon2) and JWT issuance/verification
db/ SQLAlchemy models (users, chat_history, chat_audit_log, ingestion_jobs), async engine
clients/ Milvus (Lite) session, Neo4j driver, Redis client, Kafka producer
guardrails/ input.py (prompt-injection blocklist), pii.py (regex PII masking, always on)
schemas/ Pydantic request/response models
core/ logging, error handling
observability/ placeholder for Langfuse
utils/ CLI: bulk-load source_data/ and manual uploads into Milvus and Neo4j
evals/ golden_questions.json (30), live retrieval/judge/DeepEval checks, release gates, alerting — see evals/README.md
source_data/ sample data (vector_data/, graph_data/) and an HTML viewer
tests/ pytest suite
frontend/src/ React UI (Chat, Data Management)
Each pipeline stage is a Protocol in pipeline/base.py. pipeline/factory.py selects stub or real retrievers based on USE_STUBS, and the LangChain router / DeepAgents answerer whenever ANTHROPIC_API_KEY is set. PII masking has no stub variant — it's always the real, regex-based masker.
Phase 0: Skeleton
Phase 1: Data and retrieval
utils/Phase 2: Agent and safety
Phase 3: Platform
chat_audit_log)docker-compose.yml + Dockerfiles, an alternative to the Homebrew-services path, not a replacement for it — see DockerPhase 4: Quality and polish — see Production readiness for the full design
response.usage → cost_usd) and the $0.15/inspection budget, with pre-flight count_tokens rejectionGEval, FaithfulnessMetric) — evals/deepeval_suite.py (make deepeval)evals/gates.py (pure, unit-tested) + evals/release_gates.py (make gates) + .github/workflows/release-gates.yml (workflow_dispatch, needs a real ANTHROPIC_API_KEY secret this repo doesn't have — see the workflow file). HITL thresholds are intentionally never enforced: no production traffic exists to sample from.evals/alerts.py (pure, unit-tested) + evals/check_alerts.py (make alerts), reading real chat_audit_log rows. 4 of 6 conditions are genuinely computable today; 2 aren't (see below) — this is a manual/cron script, not a real alerting pipeline (no Prometheus/Alertmanager/paging integration exists in this project).allow_actions) — see Agent actionsdocs/demo.gif, recorded against the real UI with real retrieval and a real (local Ollama) answerer, not stub modeMIT, see LICENSE.
