AX Engine

AX Engine is a Mac-first Apple Silicon inference runtime optimized first for Qwen 3.8 27B AXQ, with maintained support for additional Qwen, Gemma, GLM, and other certified families. Install with Homebrew, download the pinned 27B pack, and serve OpenAI-compatible endpoints locally.

Primary optimization target. Checkpoint Tier 1. MTP Tier 2 pending. AX certification record: Candidate (gates open).

The default pack is qwen3.8-27b:axq (AutomatosX/AX-Qwen3.8-27B-MLX-AXQ-6bit-MTP @ 3e290738e96972307c6aeb9934ab170ca0eae1c1). Other families stay supported; they are not the first-run or qualification center. Super-class Qwen 3.8 (2.4T) is experimental only.

NVIDIA/CUDA fleet serving lives in AX Serving. AX Engine remains the local Apple Silicon runtime and no longer ships the former vLLM or TensorRT provider bridges, runtime package, container, or CUDA qualification scripts.

Browse AutomatosX serve-ready chat / coding / embedding snapshots in the AutomatosX model collection on Hugging Face. Additional native families (GLM 4.7 Flash, Nemotron Omni, Unlimited-OCR, Whisper, MiniCPM-V, and others) are documented under Supported Models.

Requires macOS 26 (Tahoe)+ on Apple Silicon (M2 or newer). Product SKUs:

• Mac mini M4 Pro 64 GB — best experience for Qwen 3.8 27B AXQ (qwen3.8-27b:axq)
• MacBook Pro M5 Max 128 GB — qualification target for Qwen 3.8 Flash Next MXFP4 MTP (125B-A6B). Second SKU. MXFP4 MTP target; native support and checkpoint qualification pending. MTP Tier 2 pending. AX certification record: Candidate (gates open). The existing qwen3.8-flash-next:axq alias selects affine 4-bit, not MXFP4.

Compact single models (Qwen 3.5 9B 4-bit preferred) still fit 16 GB. Prefer 4-bit for headroom on that class.

Why AX Engine

• Optimized first for Qwen 3.8 27B AXQ — one download of qwen3.8-27b:axq is the default serve path. Direct and MTP refresh rows live in Performance; MTP speedup is workload-dependent and MTP Tier 2 is still pending
• Speculative decode on the default pack — product-path MTP on qwen3.8-27b:axq is the number in Performance. MTP Tier 2 is still pending. Same-package peers that cannot load this AXQ snapshot are listed as unsupported rather than substituted with another checkpoint
• Multi-model on one process — keep a scoped set of Qwen 3.5/3.6, Qwen3-Coder-Next, Gemma 4, and embedding models resident (load_mode=add), route by request model (chat + embeddings together), with fair Metal turn arbitration, memory preflight, and optional idle eviction. Exact-prompt prefix reuse is the S1 differentiator: official dual-model campaign (Qwen stream + Gemma 13.8k prefill) clears all locked gates at 5.03× median throughput vs a multi-process peer MLX server — see Performance and Server: Multi-model
• You own the stack you serve — AX runs the MLX graph, KV/runtime, and OpenAI-compatible server for supported Gemma / Qwen / GLM (and other direct families); mlx-lm and llama.cpp stay optional compatibility adapters
• Engine-owned scheduling and KV — continuous batched decode (certification-gated), chunked prefill, preempt-and-recompute, and a paged KV ledger with cross-request prefix sharing run inside the engine, with a published ax_runtime_* saturation contract for fleet routers — see Scheduling and KV runtime
• Native media and speech — image/video chat, mixed image+audio reasoning, OCR, and Whisper transcription/translation run through repo-owned MLX graphs with capability-gated OpenAI endpoints (checkpoint-authoritative; see media table below)
• Clear fleet boundary — AX Engine owns local Apple Silicon inference; AX Serving owns fleet orchestration and NVIDIA/CUDA workers
• Claims you can audit — public rows ship with checked-in artifacts (route, model snapshot, sampler, accept rate, provenance)

Quick Start

Homebrew (primary)

brew install defai-digital/tap/ax-engine
ax-engine doctor

Homebrew is the primary install path for the CLI, server, and bench tools. The self-contained release formula installs the release's pinned libmlx.dylib, libjaccl.dylib, and precompiled mlx.metallib; it does not build MLX from source. End users therefore do not need Python, Xcode, or the Metal Toolchain.

Python SDK (pip)

Use the wheel for Python applications that import ax_engine, optional Python integrations, or systems where Homebrew is unavailable. Install it in a virtual environment:

python3 -m venv .venv
source .venv/bin/activate
python3 -m pip install --upgrade pip
python3 -m pip install --upgrade "ax-engine[download]>=7.4.0,<8"
ax-engine doctor

The wheel also exposes ax-engine and ax-engine-server and bundles the bench binary used by diagnostics. If both Homebrew and pip are installed, an active virtual environment normally wins on PATH; use which -a ax-engine to see every copy and prefer one installation channel in each shell. See Getting Started for the full channel comparison and troubleshooting.

Run AX Engine

Option A — interactive TUI (pick a model, download, serve, chat):

ax-engine tui

Option B — serve Qwen 3.8 27B AXQ 6-bit MTP, then request from another terminal. qwen3.8-27b:axq is the pinned AutomatosX 6-bit MTP pack (same checkpoint as ax-qwen3.8-27b). The command reuses the cached snapshot when present and downloads it otherwise. Listen defaults to 127.0.0.1:31418:

ax-engine serve qwen3.8-27b:axq

curl http://127.0.0.1:31418/v1/chat/completions \
  -H 'content-type: application/json' \
  -d '{"model":"qwen3.8-27b","messages":[{"role":"user","content":"Say hello in one sentence."}],"max_tokens":64}'

Option C — coding model (resolve + serve):

ax-engine serve ax-qwen3-coder-next --port 31418

Python wheel, source builds, and troubleshooting: Getting Started.

Models

Managed AutomatosX catalog (download / TUI)

ax-engine download --list and the TUI expose the curated public AutomatosX model collection only — not every community MLX weight. Qwen 3.8 27B AXQ (6-bit MTP default), Qwen 3.6, Qwen 3.5, and Gemma 4 variants published there (plain 4-bit/6-bit, QAT, OptiQ, AXQ where available) are first-class serve targets. Other native families (for example GLM 4.7 Flash, Nemotron Omni, Unlimited-OCR, Whisper, MiniCPM-V) use the repo-owned runtime via serve aliases, presets, or manual model directories; they are not all AutomatosX-managed packages. Full matrix: Supported Models.

Qwen 3.8 Super-class (2.4T) is experimental only, not a production target. Those packs can technically load through the SSD expert-stream path (--stream-experts, default auto), but local inference is too slow even at 2-bit to recommend or certify. Start local serving on Qwen 3.8 27B AXQ 6-bit MTP (qwen3.8-27b:axq).

Recommended starting packages (serve-ready, match published benches):

Repositories ending in -MTP or -Assistant-MTP already contain the prepared sidecar or assistant artifacts and model-manifest.json. Download them with the standard flow; do not run download-mtp afterward.

Native multimodal and speech support is checkpoint-authoritative: AX advertises only modalities whose required tower tensors are present in model-manifest.json.

GLM-OCR is not supported.

Download helpers inspect the source tensor index and automatically rebuild older packaged manifests that omitted a declared Qwen or Gemma vision tower. For an existing manual model directory, run ax-engine-bench generate-manifest --force /path/to/model.

The default Hugging Face cache layout is models--AutomatosX--<repository>/snapshots/<revision>. Use the shorter ax-* aliases shown by ax-engine download --list; for example:

ax-engine serve qwen3.8-27b:axq
ax-engine serve qwen3.8-27b:axq --offline  # require the pinned 6-bit MTP cache

Aliases, hardware sizing, and legacy MTP packaging targets: Supported Models · Qwen 3.6 27B AXQ certification · Hardware FAQ · CLI.

AXQ endurance evidence

AX Engine 6.13.5 completed an 8-hour endurance test with 8.87 hours of continuous measured runtime for the pinned Qwen 3.6 27B AXQ 6-bit model on a 64 GB M4 Pro Mac mini: 437/437 requests succeeded, the owned server did not restart, and no retained-RSS growth, swap, lifecycle-drain failure, or performance guardrail breach was observed. The operator stopped this run to add deeper vLLM-style leak attribution before restarting the full 72-hour qualification, so it is short-duration evidence, not a 72-hour pass. Read the 8-hour endurance report or use the reusable AXQ endurance utility and detached launch procedure to verify another local AXQ package.

Multi-model serving

One process can keep several allowlisted models loaded and route each request by model (OpenAI, gRPC, Ollama, Anthropic). Add mode is limited to Qwen 3.5 9B, Qwen 3.6 27B/35B, Qwen3-Coder-Next, Gemma 4 12B/26B/31B, and the EmbeddingGemma 300M / Qwen3-Embedding 0.6B–8B embedding models (chat + embeddings from one process); AutomatosX AX- package names resolve to the same targets. Each model owns its own session and scheduler while a process arbiter fair-rotates Metal turns (no fused cross-model batch).

# After a first model is already serving on :31418
curl -s http://127.0.0.1:31418/v1/model/load -H 'content-type: application/json' -d '{
  "model_id": "gemma-4-12b-it",
  "model_path": "/path/to/gemma-4-12b-artifacts",
  "load_mode": "add",
  "make_default": false
}'

curl -s http://127.0.0.1:31418/v1/chat/completions -H 'content-type: application/json' -d '{
  "model": "gemma-4-12b-it",
  "messages": [{"role": "user", "content": "Hi"}],
  "max_tokens": 32
}'

Full contract (load/unload, memory preflight, idle eviction, metrics labels): Server: Multi-model serving · Supported Models.

Scheduling and KV runtime

Token-level scheduling is owned by the engine, not a gateway: each step the scheduler builds a decode-first, token-budgeted batch with chunked prefill and mixed prefill+decode routes, backed by a paged logical KV ledger. Full design: Scheduler · KV Cache · Serving Invariants.

• Continuous batched decode — structurally eligible decode requests share one batched forward (default on; AX_MLX_BATCHED_DECODE=0 is the kill switch) behind a fail-closed bit-exact certification gate; host-sampled batching is a separate opt-in
• Paged KV ledger with prefix sharing — per-request block tables, ref-counted cross-request prefix reuse, tiered eviction, and an optional disk-durable prefix cache that survives restarts
• Pressure handling — KV memory-pressure throttling, preempt-and-recompute (newest in-flight prefill only, never decode), and server admission control (global and per-model concurrency caps → 429)
• Fleet telemetry contract — /metrics publishes versioned ax_runtime_* saturation series (KV utilization, queue depth, batch headroom, TTFT p95, decode tok/s, error rate) that AX Serving and other routers consume for node selection; token scheduling itself stays on-box

Current dense batched-decode ceiling. On the strict M5 Max projection probe, the default Shared policy reaches 328.9 aggregate tok/s at B=8 (4.01× its B=1 throughput), versus 102.6 tok/s / 1.25× for the RowExact fallback. The paired Shared/RowExact ratio is 3.20× with five of five wins and identical full-cohort greedy hashes. This is a dense Llama-3.1-8B, 32-token-prefill microbenchmark—not an end-to-end serving, long-prompt, or MoE claim. Production continuous-batching claims still require matching serving evidence—see Batched decode ceiling and Long Context claim boundaries.

Performance

Qualification SKU: Mac mini M4 Pro 64 GB (2026-09-17)

Same-pack measurements on the selected SKU (Mac16,11, macOS 26.6.2) with the installed bundled wheel built from clean ad999f3f, which includes the target-head and low-precision SwiGLU corrections. Same flappy contract as below (four cases, 256 gen, greedy, thinking disabled, 2 warmups, 5 measured reps, 3 s cooldown); decode and prefill are 20-run medians. Evidence: benchmarks/results/mtp-axq-peer/2026-09-17-mac-mini-m4-pro-64gb/.

Two host daemons held about 1.2 CPU cores throughout; every lane ran under that condition and the AX lane was repeated with agreement within 0.4%. These are throughput numbers on the qualification SKU, not a quality or certification claim; the record stays Candidate.

Why the M4 Pro and M5 Max numbers differ: memory bandwidth

Decode on this 6-bit 27B pack streams 20.84 GB of dense weights per token. Direct autoregressive decode (mlx-lm) already uses 97.5% of the Mac mini M4 Pro's published 273 GB/s and 94.7% of the M5 Max's 614 GB/s, so the 2.2x decode gap is the 2.25x bandwidth gap. MTP moves past that ceiling by emitting about 3.9 tokens per weight pass. Prefill is compute-bound and the M5 Max has twice the GPU cores plus per-core neural accelerators, which is why its prefill lead is 6x for both AX and MTPLX. Full analysis: docs/performance/decode-bandwidth-utilization.md.

Campaign host: Apple M5 Max 128 GB (2026-09-15)

Historical same-pack measurements with the runtimes available on 2026-09-15: qwen3.8-27b:axq @ 3e290738e96972307c6aeb9934ab170ca0eae1c1. Apple M5 Max, 128 GB (campaign host, not the Mac mini M4 Pro 64 GB SKU). flappy suite, four cases, 256 gen, greedy, 2 warmups, 5 measured reps, 3 s cooldown. Decode is the median of 20 measured runs. Same snapshot directory for every runtime; no GGUF or community-4-bit substitute.

These measurements predate the target-head precision fix that removes the automatic 2-bit decode cache and the low-precision SwiGLU correction that replaces the fused dense activation with the split MLX operations. They do not establish throughput or numerical parity for the corrected runtime. A same-session A/B on this campaign host (recorded under the 2026-09-17 SwiGLU consistency evidence) measured decode within 0.3% and prefill 0.5-1.4% below the 2026-09-15 binary after both corrections. The corrected runtime's peer numbers with a recorded build commit are the qualification-SKU table above; a refresh of this M5 Max table is still pending.

AX and MTPLX loaded the snapshot and completed the MTP contract. Decode and prefill are 20-run medians on the same flappy prompts (prompt lengths 264–432 tokens). mlx-lm 0.31.3 is a direct-AR decode baseline (first generated token excluded; prefill not split in that harness). OMLX 0.6.4 required a writable snapshot plus import_mtplx_sidecar; Lightning MTP ran at draft depth 1 and the OMLX runner reports generate-wall tok/s (prefill not split). mlxcel 0.7.0 still fails to load this AXQ affine layout. Unsupported is not replaced with another checkpoint. MTP Tier 2 remains pending. Artifacts: 2026-09-15 campaign.

Archived Qwen 3.6 serving, multi-model S1, embeddings, and the 2026-08-31 depth-1 AX / MTPLX 2.9.0 / OMLX 0.6.4 table stay in Performance Results and Benchmarks.

SDKs

Most clients use the OpenAI-compatible HTTP server. Python also has an in-process session API.

Server

ax-engine serve is the normal entrypoint (see Quick Start). Default listen is 127.0.0.1:31418 (not AX Serving’s 18080). Port map, LAN bind, and Serving vs Engine:

Network ports and settings

curl http://127.0.0.1:31418/v1/runtime

Auth, streaming, embeddings, Ollama-shaped routes: Server · API Compatibility · OpenClaw. Fleet / NVIDIA serving: AX Serving.

Documentation

Development

cargo build --workspace
cargo test --quiet
cargo clippy --all-targets --all-features -- -D warnings
cargo fmt --check
maturin develop
python -m unittest discover -s python/tests -v

Crate layout and conventions: AGENTS.md · Architecture.

Limitations

• Qwen3.5 long-prompt prefill can trail upstream MLX references on longer prompts
• Raw HuggingFace / mlx-community snapshots load directly: model-manifest.json is auto-generated from config.json + safetensors headers on first load and weight sanitization is auto-detected, so mlx_lm.convert is not required
• N-gram acceleration is workload-dependent, not a raw kernel speedup
• NVIDIA/CUDA serving requires the separate AX Serving product

Details: FAQ limitations.

Contributing

Issues, wishlist items, reproducible benchmarks, and docs feedback are welcome. Unsolicited code PRs for runtime, kernel, scheduler, or performance paths are generally not accepted — open an issue first. See CONTRIBUTING.md.

Community

• Website: automatosx.com
• Discord: Join us
• Email: enquiry@defai.digital

Acknowledgments

AX Engine is grateful to the open-source foundations, benchmarking peers, and community contributors listed in Acknowledgments.

License

Apache License, Version 2.0. See LICENSE.

Copyright (c) 2026 DEFAI Private Limited
