Castagna Veloce: the AMD Instinct MI50 inference engine

Castagna Veloce is an inference engine built and tuned for a single GPU: the AMD Instinct MI50 (Vega 20, gfx906), with 32 GB of HBM2 per card. It runs current large models across 2 to 8 cards: the DeepSeek V4 Flash, GLM-5.3-Flash and Qwen3.8 Flash-Next mixtures of experts and the dense Qwen3.8 27B. The cards are joined by tensor parallelism over plain PCIe, and speculative decoding (MTP, DSpark) makes single-user generation fast.

It is a fork of llama.cpp. It uses the same GGUF weights and the same llama-server with its OpenAI-compatible API and Web UI. On top of that it adds gfx906 kernels, fused operations for MoE-era architectures, and multi-GPU plumbing designed for cards without matrix cores or fast interconnects.

Issues and contributions are welcome, especially from other MI50 and MI60 owners.

Models and benchmarks

pp is llama-bench prompt processing of a 2,048-token prompt. AR is plain autoregressive decoding (llama-bench, 128 tokens). The bold tg numbers are the llama-server decode rate over 20 varied prompts of 200 greedy tokens each, with the model's drafter where it helps. Speculative speed depends on the text: code, lists and translations draft far better than stories. All numbers are for a single user, measured 2026-10-05/06 on the current code. Each model guide lists the exact command and settings, and BENCHMARKS.md has the full method.

New features

Everything below was written for Castagna Veloce, and none of it is in upstream llama.cpp (checked against v0.6.0). Most of it can be switched off with an environment variable for A/B tests. The speed figures were measured on 4 cards (Qwen3.8 27B on 2) when each feature landed.

Kernels for the MI50

• i-quant MoE decode kernels for the IQ2_XXS, IQ2_XS, IQ3_XXS and IQ4_XS experts of the 2-bit models, for batches of up to 64 tokens: GLM-5.3 decoding went from 41 to 62 tok/s.
• Expert-grouped quantized MoE GEMM for prefill, i-quants included: GLM-5.3 prompt processing 682 → 960 tok/s.
• Small-batch matvecs for K-quants (q4_K, q5_K, q6_K, iq4_xs), Q8_0 (with a split-K variant), F16 and F32, for 1 to 16 tokens. They are sized for speculative-decoding verify batches.
• q2_K MoE kernel with aligned 16-byte loads for DeepSeek V4's expert down projection: 101 → 71 µs at 6 tokens.
• 64-head lightning indexer for DeepSeek V4's verify and prefill batches: a verify call went from 118 to 15 µs, and prefill rose 6%.
• Sparse attention for DeepSeek V4's compressed layers in decode and prefill: prefill +16%. At contexts up to about 2K tokens the indexer is skipped (decode 53 → 58 tok/s).
• DSV4_COMP_POOL, a new op that runs DeepSeek V4's compressor gather, pooling and norm as one kernel: decode +8%. Skipping its padding blocks gave another +7%.
• Prefill GEMM fixes: split-K F16/F32 GEMMs for few-row, long-K shapes, and grids reordered for memory channels in MoE reduction and HC mixing: DeepSeek V4 prefill 1,050 → 1,143 tok/s.

Fused operations

• Hyper-connection step in one kernel (HC post, mix, pre, RMS norm and scale), with F16 or quantized weights at 1–6 tokens: DeepSeek V4 decoding +11%, and DSpark serving 75 → 80 tok/s.
• DeepSeek V4 state-row, position-embedding and multi-matrix fusions: kernel launches per token went from 4,400 to 1,200, and decoding from 37 to 44 tok/s.
• Router and top-k in one kernel: matvec, gating, top-k and weight normalization, for DeepSeek V4.1 at one token and GLM-5.3 at 1–4 tokens.
• Gate/up + SwiGLU, matvec + residual add, broadcast gate and small-concat kernels for the verify batches. Together with the small-batch matvecs they took Qwen3.8 27B MTP from 65.6 to 69.4 tok/s.
• KDA gated-norm fusion, Q8 activations reused across weight types, and batched sibling matvecs: GLM-5.3 about +4%.

Multiple cards

• Tensor-parallel pairs: tensor parallelism inside pairs of cards, with the layers pipelined across the pairs. Qwen3.8 Flash-Next's decode profile runs this way (how it works).
• PCIe all-reduce for both layouts: pairs write straight into the peer card's memory; groups of four use kernel peer writes for decode-sized tensors and copy-engine DMA for prefill-sized ones (DMA: +2% prefill).
• Persistent hyper-connection and MoE kernels with each pair's all-reduce fused in, for the Qwen3.8 Flash-Next decode profile.
• Split output head for DeepSeek V4, with a mirrored copy for the DSpark drafter: plain decoding +3%.
• Several virtual devices per card for pipelined layer-split prefill.

Speculative decoding and serving

• DSpark for DeepSeek V4 Flash: a converter from antirez's DSpark GGUF to llama.cpp's DFlash draft format, plus the KV-cache and crash fixes that made it run. It reaches 81 tok/s, against 64 for plain decoding.
• MTP drafter graph reuse and catch-up merged into the draft step: GLM-5.3 +4–8% and +5–9%.
• Verify-shaped last prompt chunk (LLAMA_CKPT_LAST_VERIFY): one graph rebuild fewer per request, +1–2% throughput and a faster first token.
• Draft vocabulary prefix (LLAMA_MTP_DRAFT_VOCAB): the drafter scores only the first 96K token ids, split across the cards, while the target still checks every draft against the full vocabulary. This is the idea of FR-Spec applied to an MTP head.

Accuracy

• F32-accumulating vision encoders for GLM-5.3, Qwen3.8 and DeepSeek V4.1: 0.13–1.7% off a full-precision reference, against 4.7–23% before. This costs some encode time, not speed elsewhere.

Tensor-parallel pairs

Castagna Veloce can run tensor parallelism in pairs of cards. Each pair splits every matrix of its layers across its two cards, the layers are divided between the pairs, and the pairs run as a pipeline. Qwen3.8 Flash-Next's decode profile uses this layout on 4 cards, while DeepSeek V4, GLM-5.3 and DeepSeek V4.1 run as groups of four. Upstream llama.cpp's -sm tensor always puts all cards into one group.

flowchart LR
  subgraph P1["Pair 1: first half of the layers"]
    G0["GPU 0"] <-->|all-reduce| G1["GPU 1"]
  end
  subgraph P2["Pair 2: second half of the layers"]
    G2["GPU 2"] <-->|all-reduce| G3["GPU 3"]
  end
  P1 -->|activations| P2

Why pairs suit the MI50:

• Point-to-point exchanges. These cards have no fast links between them, so every tensor-parallel all-reduce crosses PCIe. Inside a pair, each card exchanges with one peer only. A group of four needs an all-to-all exchange in which every card sends to three others over shared PCIe lanes.
• Direct writes into the peer's memory. The MI50 exposes all of its VRAM over PCIe (a 32 GB BAR). Each card pushes its partial result into an inbox on the other card and raises a flag there, then waits on its own local memory. That is one PCIe crossing per value instead of a round trip through host memory. Cards without peer access fall back to staging through host memory automatically.
• The pairs overlap. Reductions are queued deep on the GPUs, so the host can submit a whole step ahead and both pairs work at the same time instead of taking turns.
• Fused into the layer. In Qwen3.8 Flash-Next's decode profile, each pair's all-reduce runs inside persistent kernels that also do the model's hyper-connection and MoE steps. Both cards add the partial results in the same order, so their copies stay bit-identical.

Choosing the layout:

Left unset with -sm tensor on 4 or more cards, it also gives pairs, so the model guides always set it. LLAMA_TP_LAYER_SPLIT=a,b,... sets the share of layers each group gets; by default it follows each group's free memory.

Philosophy

• One target: AMD Instinct MI50/MI60 (gfx906). Every kernel choice is measured on these cards. Other GPUs still build, but they are untested.
• 4 cards per model as the main target, the sweet spot for 32 GB cards and today's large MoE models at 2–4 bits; 8 cards as two 4-card groups.
• Single-user latency first: speculative decoding is the default wherever a model has a drafter.
• Preserve quality. Every new kernel or fusion has a test-backend-ops case checked against the CPU backend, and every model's perplexity is re-checked after each change. Changes meant to be exact are verified bit-identical. Changes that alter rounding say so and are judged over many prompts, not one.
• Nearly every optimization has a runtime switch, usually a GGML_CUDA_* environment variable, to turn it off for A/B tests and bug reports.
• Stay close to llama.cpp: GGUF, llama-server, the usual tools and flags.

Quickstart

1. Build

Supported setup: Ubuntu 26.04 LTS with its own ROCm 7.1 packages, which still ship gfx906 code. Kernel 7.0, HIP 7.1, LLVM/Clang 21.

sudo apt install build-essential cmake git hipcc libamdhip64-dev libhipblas-dev librocblas-dev \
  rocm-device-libs-21 rocminfo rocm-smi
git clone https://github.com/benpeterson40/castagna-veloce
cd castagna-veloce
cmake -S . -B build -DGGML_HIP=ON -DAMDGPU_TARGETS=gfx906 -DGPU_TARGETS=gfx906 \
  -DCMAKE_BUILD_TYPE=Release -DGGML_HIP_NO_VMM=ON -DGGML_HIP_GRAPHS=ON -DGGML_CUDA_FA=ON \
  -DGGML_SCHED_MAX_COPIES=8 -DLLAMA_CURL=OFF
cmake --build build -j --target llama-server llama-cli llama-bench llama-perplexity
rocminfo | grep -c gfx906   # one line per card

Your user needs access to /dev/kfd and /dev/dri/renderD*, usually through the render and video groups. Log out and back in after changing membership. If CMake picks the wrong compiler, pass -DCMAKE_HIP_COMPILER=/usr/lib/llvm-21/bin/clang++.

2. Download a model

For example GLM-5.3-Flash at 2 bits (about 109 GB, 4 cards):

pip install -U huggingface_hub   # provides the hf command
hf download unsloth/GLM-5.3-Flash-GGUF --revision 621d456e93e926e4b52f85cff5f634358c1828f9 \
  --include "UD-Q2_K_XL/*" --local-dir models/GLM-5.3-Flash-GGUF

3. Serve

HIP_VISIBLE_DEVICES=0,1,2,3 LLAMA_TP_GROUP=4 LLAMA_CKPT_LAST_VERIFY=1 \
./build/bin/llama-server \
  -m models/GLM-5.3-Flash-GGUF/UD-Q2_K_XL/GLM-5.3-Flash-UD-Q2_K_XL-00001-of-00004.gguf \
  -ngl 999 -sm tensor -fa on -c 65536 -b 4096 -ub 1024 --jinja -np 1 \
  --spec-type draft-mtp --spec-draft-n-max 1 \
  --host 0.0.0.0 --port 8080

Then, from another terminal, ask it something through the OpenAI-compatible API:

curl http://localhost:8080/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d '{"messages": [{"role": "user", "content": "Say something"}]}'

LLAMA_TP_GROUP=4 makes the 4 cards one tensor-parallel group, and --spec-type draft-mtp turns on the model's own MTP drafter. The GLM-5.3-Flash guide explains every setting.

The Web UI is at http://localhost:8080. For Open WebUI, the OpenAI SDK and similar clients, set the base URL to http://localhost:8080/v1. Each model guide has the download and serve commands for that model.

Usage notes

• GLM-5.3-Flash always reasons: its template opens <think> and has no enable_thinking switch. Set the depth per request with "chat_template_kwargs": {"reasoning_effort": "low"} (or "high"; the default is "max"), or turn reasoning off with --reasoning-budget 0.
• Images: add --mmproj with the model's projector file (see its guide). The encoder runs on the first card, and a very large photo can need over a gigabyte there, so cap images with --image-max-tokens 2048.
• DeepSeek V4.1 Flash Q2_K can fall into endless reasoning loops with thinking on. Use "chat_template_kwargs": {"enable_thinking": false}, especially for images.
• One user per server (-np 1) is the tuned configuration. The kernels for 1–6-token batches are what make speculative decoding fast.

Hardware notes

• Cards: tested on MI50 32 GB (VBIOS 113-D1631700-111). The MI60 is the same gfx906 chip and should work, but it is untested. The 16 GB MI50 needs more cards for the same models.
• Peer access: the fastest pair all-reduce writes directly into the other card's VRAM, which needs the full 32 GB BAR. Our cards have it; on cards without peer access the engine stages the exchange through host memory instead.
• PCIe slots matter for prefill. The tensor-parallel all-reduce moves several MB per layer during prefill. On our board only 3 of 8 slots are x16; a 2-card model on two x16 cards prefills about 4% faster than on an x16 + x8 pair. Decode is barely affected.
• Clocks: fixing the cards at the high performance level (echo high | sudo tee /sys/class/drm/card*/device/power_dpm_force_performance_level) avoids clock ramps between drafting and verifying. With speculative decoding we measured +0.4% on GLM-5.3 and about +5% on Flash-Next (the latter on an earlier build). The published numbers use the default auto on all cards but the first.
• Cooling: the MI50 is passively cooled and needs real front-to-back airflow.

License

Castagna Veloce is a fork of llama.cpp and keeps its MIT license. The MI50-specific changes are MIT licensed as well. Model weights are not included and keep their publishers' licenses.

Castagna Veloce is not affiliated with or endorsed by AMD. AMD, Instinct and Radeon are trademarks of Advanced Micro Devices, Inc.

Acknowledgements

• llama.cpp and ggml, the base of everything here.
• danielhanchen for the Qwen3.8 Flash-Next MTP draft head, the branch this fork started from.
• timkhronos for GLM-5.3-Flash support, ported here from an earlier revision.
• smalinin/llama.cpp for DeepSeek V4.1 support (the deepseek41 model and its vision encoder), ported here from an earlier revision.
• antirez for the DeepSeek V4 Flash GGUFs and the DSpark drafter.
• Unsloth for the GLM-5.3-Flash and Qwen3.8 GGUFs, vcruz305 for the DeepSeek V4.1 Flash GGUF, and smalinin for its vision projector.
• gufo, the Strix Halo engine whose landing page this one follows.
