Wall-X

Building General-Purpose Robots Based on Embodied Foundation Model

We are building embodied foundation models to capture and compress the world's most valuable data: continuous, high-fidelity physical interaction.

By creating a direct feedback loop between model decisions and the body's lived experience, we enable generalizable intelligence that understands not just how the world works, but how to act effectively within it.

Repository

This repository provides the training and inference code for the WALL series open-source embodied foundation models. It includes LeRobot data preparation, model configuration, flow-matching and FAST action branches, public serving and evaluation utilities, and exported CUDA operator sources that compile during package installation.

News

• [June 2026] Wall-X 1.1.0 updates the open-source training and inference stack for Wall-OSS-0.5, including the public serving/evaluation runtime, DMuon training support, and install-time CUDA operator builds.
• [May 2026] We introduce WALL-WM: Carving World Action Modeling at the Event Joints, a World Action Model that couples future-video imagination with action prediction at semantic event boundaries.
• [May 2026] We introduce Wall-OSS-0.5: A Deployment-Ready VLA with Gradient-Bridged Pretraining, an open-source model for directly deployable real-robot manipulation and downstream adaptation.
• [Sept 2025] We introduce WALL-OSS: Igniting VLMs toward the Embodied Space, an end-to-end embodied foundation model that leverages large-scale multimodal pretraining to achieve embodiment-aware vision-language understanding, language-action association, and robust manipulation capability.

Models

• WALL-OSS-0.5: https://huggingface.co/x-square-robot/wall-oss-0.5
• WALL-OSS-FLOW-0.1: https://huggingface.co/x-square-robot/wall-oss-flow-0.1
• WALL-OSS-FLOW: https://huggingface.co/x-square-robot/wall-oss-flow
• WALL-OSS-FAST: https://huggingface.co/x-square-robot/wall-oss-fast

Environment Setup

Create and activate a conda environment:

conda create --name wallx python=3.10
conda activate wallx

Install requirements:

pip install -r requirements.txt
export FLASH_ATTN_CUDA_ARCHS=$(python -c 'import torch; print(f"{torch.cuda.get_device_capability()[0]}{torch.cuda.get_device_capability()[1]}")')
MAX_JOBS=4 pip install flash-attn==2.8.3 --no-build-isolation

Install DMuon, which is used by the default training configs:

pip install "dmuon @ git+https://github.com/X-Square-Robot/dmuon.git"

Install LeRobot:

git clone https://github.com/huggingface/lerobot.git
cd lerobot
pip install --no-deps -e .

Use --no-deps for LeRobot so it does not override the Wall-X dependency versions installed from requirements.txt.

Install Wall-X:

MAX_JOBS=8 pip install --no-build-isolation -e .

Public helper scripts live under scripts/; the examples below use the repository-root form, such as python scripts/fake_inference.py.

The exported CUDA operator sources are included in wall_x/model/core/ops/csrc/. setup.py builds them with PyTorch CUDAExtension when Wall-X is installed. ninja is included in requirements.txt for parallel builds, and MAX_JOBS controls compile parallelism. --no-build-isolation is required so the build can use the torch package already installed in the active environment.

Training

Finetune on LeRobot Datasets

Before training, see workspace/README.md for configuration details, including:

• Training script configuration
• GPU setup
• Model and data paths
• Robot DOF configuration
• Training hyperparameters

Download the pretrained checkpoint, copy workspace/example/lerobot/qwen2_5_lerobot_template.yml, replace the placeholder paths, and launch training with:

python -m wall_x.trainer.fsdp_trainer.train_fsdp --config <path/to/config.yml>

For Wall-OSS-0.5 fine-tuning, normalization, LIBERO evaluation, and open-loop WebSocket evaluation instructions, see workspace/README.md.

Inference

Basic Action Inference

For a minimal end-to-end example, run:

python scripts/fake_inference.py --checkpoint-path <path/to/checkpoint>

This script demonstrates how to:

• Load the Wall-OSS model with Qwen2_5_VLMoEForAction.from_pretrained()
• Prepare proprioceptive inputs, attention masks, and dataset specs
• Run inference in validate mode at bfloat16
• Validate output shape and check numerical stability

Simulator Evaluation

Convenience launchers for closed-loop simulator evaluation live under scripts/. LIBERO simulator setup is optional and documented with the helper scripts; see scripts/README.md.

bash scripts/run_libero.sh <path/to/checkpoint>

WebSocket Serving

Start a Wall-X WebSocket server with:

bash scripts/run_serving.sh \
  --checkpoint-path <path/to/checkpoint> \
  --train-config-path <path/to/config.yml> \
  --port 32195

The wrapper has no built-in checkpoint path. It returns raw model action chunks by default, which is suitable for open-loop evaluation. Pass --serialize-actions for clients that expect robot-serialized actions.

Open-Loop WebSocket Evaluation

To compare predictions from a running Wall-X WebSocket server against LeRobot ground truth, run:

python scripts/draw_openloop_plot.py \
  --uri ws://127.0.0.1:32195 \
  --dataset-root <path/to/lerobot_dataset> \
  --train-config <path/to/config.yml> \
  --episode-indices 0,1,2

Join Our Community

Scan the QR code on WeChat to join the discussion group.

Cite Us

If you find WALL-OSS models useful, please cite:

@article{zhai2025igniting,
  title   = {Igniting VLMs Toward the Embodied Space},
  author  = {Zhai, Andy and Liu, Brae and Fang, Bruno and Cai, Chalse and Ma, Ellie and Yin, Ethan and Wang, Hao and Zhou, Hugo and Wang, James and Shi, Lights and Liang, Lucy and Wang, Make and Wang, Qian and Gan, Roy and Yu, Ryan and Li, Shalfun and Liu, Starrick and Chen, Sylas and Chen, Vincent and Xu, Zach},
  journal = {arXiv preprint arXiv:2509.11766},
  year    = {2025}
}
