A new open-source project has been released, building upon this project.

X-One-Pipeline This project now just provide sample based on Y1-IMETA cause we only have this brand robotic arm. Other brand robotic arm also support, you can find it at src.robot.controller, same as this project, and to realize a new robot, just make a config like config/x-one.yml, and a ${robot}.py at src/robot/robot, add it into src/robot/robot/init.py, then you can use your robot in the new project.

Recent updates (2026-07)

This branch adds XPolicyLab deployment support, Xspark data conversion, teleop IPC improvements, and several protocol / naming fixes.

XPolicyLab integration

Upstream: XPolicyLab

End-to-end workflow

control_your_robot collect
        ↓
tools/transform2xspark.py          # raw HDF5 → xspark v1.0 layout
        ↓
tools/write_xpolicy_instruction.py # ensure instruction + metadata (if not set during transform)
        ↓
copy/symlink into XPolicyLab tree   # data/{bench}/{task}/{env_cfg}/data/episode_*.hdf5
        ↓
XPolicyLab policy/<POLICY>/process_data.sh + train.sh
        ↓
offline replay eval (ReplayRobot) or real-robot deploy (real_env_client)

Step 1 — Collect raw data

python example/collect/collect.py
# or teleop:
python example/teleop/master_slave_arm_teleop_fs.py

Raw layout: save/{task_name}/*.hdf5 with flat groups such as left_arm/, cam_head/.

Step 2 — Convert to xspark v1.0

python tools/transform2xspark.py save/test_robot \
  --save-dir ./data \
  --task-name stack_bowls \
  --skip-video

Output layout:

data/stack_bowls/
├── data/episode_0000000.hdf5
├── preview_video/                 # optional
└── config.json

Step 3 — Ensure language instruction (optional during convert)

transform2xspark.py only writes instruction / instructions when it finds text from:

• --instruction
• sidecar JSON (0.json, info.json)
• task_info/{task_name}.json or task_instructions/{task_name}.json

If none are found, the episode is still converted and instruction keys are omitted so you can add them later:

python tools/write_xpolicy_instruction.py data/stack_bowls/data \
  --task-name stack_bowls \
  --verify

Step 4 — Place data for XPolicyLab training

# Example target inside an XPolicyLab workspace
mkdir -p ../XPolicyLab/data/RoboDojo/stack_bowls/piper_x/data
cp data/stack_bowls/data/episode_*.hdf5 ../XPolicyLab/data/RoboDojo/stack_bowls/piper_x/data/

Then follow the target policy README, e.g.:

cd ../XPolicyLab/policy/Pi_05
bash install.sh
bash process_data.sh RoboDojo stack_bowls piper_x joint
bash train.sh RoboDojo stack_bowls piper_x joint 0 0

Step 5 — Offline evaluation (HDF5 replay)

Use my_robot/replay_robot.py with example/deploy/replay_robot.yml (copy and edit for your task). Point hdf5_paths to the data/ subdirectory and set hdf5_format: xspark. The replay client reads the top-level instruction dataset and sends it to the policy server as obs["instruction"].

Step 6 — Real-robot deployment

Split-machine flow (see XPolicyLab policy README):

# policy machine
bash setup_eval_policy_server.sh ...

# robot machine — uses example/deploy/real_env_client.py via task_env shim
bash setup_eval_env_client.sh ...

Protocol: WebSocket via client_server.ws.WsModelClient (not legacy robodojo_ws).

xspark v1.0 episode schema (XPolicyLab-compatible)

Each episode_{index:07d}.hdf5 contains:

Repo helpers:

• example/deploy/real_env_client.py: real-robot environment client
• my_robot/replay_robot.py + example/deploy/replay_robot.yml: offline HDF5 replay
• example/deploy/robot_client_server/: lightweight model client/server helpers
• task_env/real_env_client.py: import shim for XPolicyLab robodojo
• src/robot/utils/base/xpolicy_hdf5.py: metadata read/write/validate helpers

Xspark data pipeline

• X_spark_format_pipeline in src/robot/utils/base/data_transform_pipeline.py
• tools/transform2xspark.py: batch-convert raw collect HDF5 to xspark layout
• tools/write_xpolicy_instruction.py: add/update instruction, instructions, data_format_version, additional_info/frequency
• Supports legacy qpos → eef and slave_*_arm → left_arm / right_arm renaming
• Use --skip-video or XSPARK_SKIP_PREVIEW=1 for faster batch conversion

python tools/transform2xspark.py save/test_robot --save-dir ./data --skip-video
python tools/write_xpolicy_instruction.py data/xspark/data --task-name xspark --verify

Teleop performance

• example/teleop/master_slave_arm_teleop_fs.py now uses MsgpackSharedDict instead of multiprocessing.Manager().dict() for master → slave → collector IPC, avoiding slow JSON-like proxy serialization on every control tick.
• Graceful process shutdown avoids corrupting HDF5 on episode finish.
• Dependency: msgpack>=1.0.5 (see pyproject.toml / requirements.txt).

Fixes and refactors

• Unified end-effector field naming: qpos → eef across controllers, robots, and scripts.
• XPolicyLab ws protocol update: robodojo_ws → ws in deploy client.
• Agent-oriented repo guide: agent.md.

WECHAT

if the wechat group overdue, you could add my wechat to join in.

Piper new sdk pyAgxArm support!

We now support the new Piper SDK--pyAgxArm, which is more efficient and easier to use. You can refer to src/robot/controller/PiperAgx_controller.py for details. In this new sdk, we support reset robotic-arm while in teleop mode, cause we enable gravity-compensation by MIT control. But be careful when you reset the robot, make sure the robot is in a safe position to avoid any damage. We also provide a simple teleop script example/teleop/master_slave_arm_teleop_fs.py to show how to use the new sdk to control the robot, you can have a try. Also a robot demo agilex_piperAgx_dual_base.py provided in my_robot.

Robot Node support!

Now you can you example/collect/collect_node.py to easily collect robot data paradell, this pipeline will decorate Robot class with an node. Just have a try.

visualize data by rerun!

refer to scripts/visual_hdf5_rerun.sh to visual your data, support type:

1. control_your_robot raw data
2. act / rdt hdf5 data

Data collect pipeline now can choose to save the data into the format you want!

You can try it by switch to the branch--newest to have a try.
A function added at CollectAny called _add_data_transform_pipeline(), add we provide two choice under utils/data_transofrm_pipeline.py:

1. image_rgb_encode_pipeline
   this will encode every egb image in your data, then save it, it will cost lower memory for data saving by using jepg.
2. general_hdf5_rdt_format_pipeline
   this will save the data into rdt_hdf5 format without instruction.

RoboTwin depoly pipeline support!

Now we already support RoboTwin pipeline! You can refer to under step for your Sim2Real experiment!

1. link RoboTwin policy to control_your_robot policy

# example
ln -s path/to/RoboTwin/polciy/pi0 path/to/control_your_robot/policy/

2. modify deploy.sh By using RoboTwin pipeline, you should set --robotwin first, then extra info should be set like:

# pi0 eval.sh
python script/eval_policy.py --config policy/$policy_name/deploy_policy.yml \
    --overrides \
    --task_name ${task_name} \
    --task_config ${task_config} \
    --train_config_name ${train_config_name} \
    --model_name ${model_name} \
    --ckpt_setting ${model_name} \
    --seed ${seed} \
    --policy_name ${policy_name}

# your deploy.sh
python example/deploy/deploy.py \
    --base_model_name "openpi"\
    --base_model_class "None"\
    --base_model_path "None"\
    --base_task_name "test"\
    --base_robot_name "test_robot"\
    --base_robot_class "TestRobot"\
    --robotwin \
    --overrides \
    --task_name ${task_name} \
    --task_config ${task_config} \
    --train_config_name ${train_config_name} \
    --model_name ${model_name} \
    --ckpt_setting ${model_name} \
    --seed ${seed} \
    --policy_name ${policy_name}

By RoboTwin pipeline, some of the base_ index may not make effect, here use None instead. Also some of the RoboTwin setting not take effect, you could ignore it.

Other deploy info you could refer to RoboTwin Document, like some of the model should modify deploy_policy.yml.

Control Your Robot!

This project aims to provide a comprehensive and ready-to-use pipeline for embodied intelligence research, covering everything from robotic arm control, data collection, to Vision-Language-Action (VLA) model training and deployment.

Quick Start!

Since this project includes several test examples, such as robotic arm tests, visual simulation, and full robot simulation, it is possible to quickly understand the overall framework without requiring any physical hardware.
Because no hardware is needed, you can install the environment simply by running:

 pip install -r requirements.txt
 # or
 GIT_LFS_SKIP_SMUDGE=1 uv sync
GIT_LFS_SKIP_SMUDGE=1 uv pip install -e .

This project provides special debug levels: "DEBUG", "INFO", and "ERROR". To fully observe the data flow, set it to "DEBUG":

export INFO_LEVEL="DEBUG"

Alternatively, you can set it in the main function:

import os
os.environ["INFO_LEVEL"] = "DEBUG" # DEBUG , INFO, ERROR

1. Data Collection Tests

To collect your robot data, just change the robot class in this file.

# Node collect
python exaexample/collect/collect_node.py
# Single-threaded (may have accumulated delays due to function execution)
python example/collect/collect.py

2. Model Deployment Tests

To deploy the model on your robot, you just need to setup a model class in src/robot/policy/test_policy/inference_model.py like under src/robot/policy/. Then setup your robot in scripts/deploy.sh.

# General deployment script
bash deploy.sh
# Offline data replay consistency test
# you should generate data at least 3 data first by running: python example/collect/collect.py
bash eval_offline.sh

3. Remote Deployment and Data Transfer

Just change the robot / model class in the file, and correctly set the input/output transform.

# Start the server first, simulating the inference side (allows multiple connections, listens on a port)
python scripts/server.py
# On the client side, collect data and execute commands (example only executes 10 times)
python scripts/client.py

4. Interesting Scripts

# Collect keypoints and perform trajectory replay
python scripts/collect_moving_ckpt.py
# SAPIEN simulation, see planner/README.md for details

5. Debug Scripts

# Because controller and sensor packages have __init__.py, execute with -m
python -m src.robot.controller.TestArm_controller
python -m src.robot.sensor.TestVision_sensor
python -m my_robot.test_robot

6. Data Conversion Scripts

# After running python example/collect/collect.py and obtaining trajectories
python scripts/convert2rdt_hdf5.py save/test_robot/ save/rdt/

# TO openpi dataset(lerobot2.1)
python scripts/convert2act_hdf5.py save/test_robot/ save/openpi_hdf5/
# you should copy an instruction from task_instructions/ to save/openpi_hdf5/
python scripts/convert2openpi.py --raw_dir save/openpi_hdf5/ --repo_id my_repo_id

7. upload data Important!!!

sensor.vision_sensor already set encode_rgb=True by DEFAULT, you do not need to use encode and decode.

# In the original dataset, image files occupy a large amount of storage space, which is unfavorable for data transmission. Therefore, a compression and decompression script is provided. It performs JPEG processing on the images to enable faster transfer. The script is configured by default for a dual-arm, three-view setup, but it can be adjusted according to specific needs.
# compress. will make a new floder: path/to/floder/_zip/
python scripts/upload_zip.py path/to/floder --encode

# decompress.
python scripts/upload_zip.py path/to/floder

8. telop by joint/eef

# We provide two general architectures for teleoperation-based data collection. The first one is relatively simple, where the teleoperation control frequency is aligned with the data collection frequency. The second one is slightly more complex, allowing the teleoperation frequency to far exceed the data recording frequency. Both architectures have been validated through real-world robot experiments.
# same freq
python example/teleop/master_slave_arm_teleop.py
# diff freq (300Hz control / 60Hz collect; msgpack IPC)
python example/teleop/master_slave_arm_teleop_fs.py

9. Xspark + XPolicyLab data prep

python tools/transform2xspark.py save/test_robot --save-dir ./data --skip-video
python tools/write_xpolicy_instruction.py data/xspark/data --task-name xspark --verify

See XPolicyLab integration above for the full training / offline eval / deploy flow.

On real robot!

1. Implement Your Robot Configuration

Required:
__init__(self): Initialize all controllers and sensors
set_up(self): Execute the set_up parameters for each controller and sensor

Optional:
is_start(self): Check if the robot arm is currently moving
reset(self): Reset the robot arm to its initial position

2. Some Additional Functions

replay(self, hdf5_path, key_banned, is_collect, episode_id):
    Replay previously collected trajectories.
    Note: key_banned must be set. If you are replaying based on joints, ban 'eef'; otherwise, ban the other key.
    is_collect and episode_id are linked: they indicate that the replayed trajectory data is being collected and saved under the given episode_id.
    If episode_id is not set, you might overwrite the originally collected trajectories.

show_pic(self, data_path, pic_name):
    Replay video from a specified camera.
    Can be used directly and will automatically decode compressed images in the raw data.

🤖 Supported Devices

🎛️ Controllers

✅ Implemented

🚧 Planned Support

📡 Sensors

✅ Implemented

🚧 Planned Support For new sensor support requests, please open an issue, or submit a PR with your sensor configuration!
