project-surface

The missing semantic layer for AI-readable software projects.

Ask any AI agent what your project can do, where it lives, what proves it, and what a change will affect.

_{26 seconds, silent. Click through for the MP4.}

---

The problem

Every AI coding tool re-derives the same facts about your repository on every single task. What does this project do? Which command actually runs it? Which files own this behaviour? What must not be violated? Which tests prove it works?

That derivation is expensive, non-reproducible, invisible to you, and impossible to check. Every tool does it privately, and differently.

The idea

A repository is not a folder of files. It is a graph of capabilities, contracts, workflows, evidence, dependencies and risks.

project-surface materializes that graph into one small, stable, tool-readable artifact: .project/surface.json. Claude Code, Cursor, Codex, your IDE, your CI and you all read the same verified model instead of guessing separately.

The differentiator is honesty, not intelligence. "AI reads your code" already exists. What does not exist is every claim carrying an owner, a contract, evidence, freshness, confidence and a provenance tier - where an inferred fact is labelled inferred, and a stale fact is labelled stale.

---

Install

npx project-surface init          # nothing to install; or: npm i -g project-surface

Node 20.10 or newer. No native modules, no other runtime, no account, no network - the tool never leaves your machine.

From a source checkout, git clone https://github.com/Richie11747/project-surface && cd project-surface && npm install && npm run build, then node packages/cli/dist/index.js (or npm run surface --) wherever the docs say npx project-surface.

Sixty seconds

$ npx project-surface init

Wrote .project/surface.json

  project      checkout-api
  stacks       typescript
  packages     1
  commands     3
  capabilities 9
  constraints  5
  evidence     2
  risks        1

  health 0 error, 5 warning, 10 info  - run surface doctor

Now ask it about one behaviour:

$ surface inspect checkout.create

checkout.create
  POST /checkout
  HTTP endpoint registered in src/checkout/create.ts.

  Implemented by
    src/checkout/create.ts export:createCheckout
    src/checkout/create.ts L74

  Contract
    docs/contracts/checkout.md

  Evidence
    tests/checkout/create.test.ts (unknown, linked by import-graph)

  Requires environment
    DATABASE_URL

  Check it with
    npm run test

  Trust  0.70 medium | derived | unverified
         medium confidence from 2 source(s) via the typescript adapter
         Never verified.

Note unverified. Nothing has been run yet, so nothing claims to be proven. Run the test:

$ surface verify --command test
running test  npm run test
  passed 936 ms

$ surface inspect checkout.create
  Trust  0.95 high | derived | fresh

Now change the implementation and rescan:

$ surface doctor
  warn  STALE_CLAIM [checkout.create]
      Capability "checkout.create" was verified earlier but its files have changed since.
      Run: surface verify --capability checkout.create

$ surface inspect checkout.create
  Trust  0.56 low | derived | stale
         Owner files changed since verification.

That is the whole product. A claim that was proven, and then stopped being proven, says so. It stays stale across rescans until something actually re-verifies it.

---

Give it to Claude

claude mcp add project-surface -- npx -y project-surface mcp

Then ask, in a fresh session with no prior context:

Where is checkout implemented, what tests prove it, and what changes if I add a status field?

Claude answers from structured data - owners, contract, linked tests, active constraints, and a bounded impact map - instead of grepping and guessing.

Or give it a file. surface agents --write CLAUDE.md renders the surface as agent instructions - the commands that were actually run, the rules and whether each is machine-checked, where things live and what proves it - with the provenance on every line and inferred guesses left out. The block carries a fingerprint, and surface doctor reports it as stale the moment the surface changes underneath it. A hand-written CLAUDE.md cannot do that. This repository's own CLAUDE.md is generated this way and checked in CI.

Nine tools are exposed: surface_overview, surface_find_capability, surface_why, surface_constraints, surface_health, surface_impact, surface_context, surface_diff, and surface_verify.

Eight of them are strictly read-only. See Trust and safety for the ninth, and docs/mcp.md for the full tool reference. A Claude Code plugin and a GitHub Action live in integrations/.

---

The trust model

Every claim in the document carries a provenance tier. This is the spine of the whole project.

Confidence is computed, never authored. An adapter reports how it learned something; core turns that into a number:

• Independent corroborating sources raise the score within the tier band.
• A stale verified claim is demoted to derived - execution proves what the code did at a point in time, and once the owner files change that proof no longer describes the current code.
• Passing evidence promotes a claim by exactly one tier. A green test on an inferred capability makes it derived, not verified: the test proves the code behaves, not that the thing we guessed was a capability really is one.
• declared never decays. A human owns the statement, so a stale declaration is reported as a health finding rather than quietly discounted.

Freshness is fingerprint-based, not just a TTL. Each claim stores a hash of its owner files as of verification. Change a file and the claim goes stale; rescan and it stays stale, because the anchor does not move until something re-proves it.

When inference is wrong, override it once and every tool respects it:

# .project/surface.declare.yaml
capabilities:
  - id: checkout.create
    title: Creates a checkout session
    owners: [src/checkout/create.ts]
    contracts: [docs/contracts/checkout.md]
    environment: [DATABASE_URL, STRIPE_SECRET_KEY]

constraints:
  - rule: Never call the payment provider from a request handler.
    severity: error
    check:
      kind: forbid-import
      from: [src/checkout/**]
      to: [src/payments/**, stripe, "@stripe/*"]

That last block is the difference between a rule and a hope. A CLAUDE.md says do not; an agent may comply. A constraint with a check is evaluated on every scan, and when it is broken the document says so, with the file and the import, at the severity you chose - so surface doctor exits 2 and CI fails:

$ surface doctor

  warn             CONSTRAINT_VIOLATED [constraint:no-provider-in-handlers]
      Constraint "Never call the payment provider from a request handler." is violated in 1 place(s): src/checkout/create.ts (imports src/payments/provider.ts).
      Handlers must stay idempotent; provider calls go through the job queue. Fix the listed files, or change the check in .project/surface.declare.yaml.

Five kinds exist today - forbid-import, forbid-file, require-test, forbid-env, max-owners - and a check that no adapter can evaluate is reported as unchecked, never as passed. See docs/declarations.md.

---

This repository, described by itself

The claim above is cheap to make and easy to fake, so the repository is its own first user. .project/surface.json is committed, regenerated in CI, proven with surface verify, and gated with surface doctor --strict. A claim this project makes about itself cannot go stale without the build going red.

$ surface map

  CAPABILITY                  OWNER                                         CONTRACT              EVIDENCE                                 TIER      CONFIDENCE   FRESHNESS
  adapter.sdk                 packages/adapter-sdk/src/builders.ts          docs/adapters.md      test/conformance.test.js                 declared  1.00 high    fresh
  analysis.health             packages/core/src/analysis/health.ts          spec/v1/SPEC.md       test/cli.test.js                         declared  1.00 high    fresh
  cli.verify                  packages/cli/src/commands/verify.ts           docs/cli.md           test/cli.test.js                         declared  1.00 high    fresh
  commands.run                packages/cli/src/commands/context.ts          -                     -                                        inferred  0.65 medium  unverified
  evidence.runner             packages/core/src/evidence/runner.ts          docs/cli.md           packages/core/test/safety.test.js        declared  1.00 high    fresh
  mcp.verify-tool             packages/mcp-server/src/tools/verify.ts       docs/mcp.md           test/mcp.test.js                         declared  1.00 high    fresh
  safety.redaction            packages/core/src/redact.ts                   docs/trust-model.md   packages/core/test/redact.test.js        declared  1.00 high    fresh
  trust.freshness             packages/core/src/model/freshness.ts          docs/trust-model.md   packages/core/test/freshness.test.js     declared  1.00 high    fresh
  ...

  36 capabilities - 35 fresh, 0 stale, 1 without evidence, 1 without a contract

Three things are worth noticing.

• Declared sets the granularity, evidence does the proving. Inference saw 152 exported symbols. A maintainer declared 35 capabilities - one per thing a person would actually name - each with a contract and the test suite that proves it (.project/surface.declare.yaml). The guesses were not discarded: 151 of them were folded into the declaration that owns their file, as corroboration and as an alias.
• fresh is earned, not asserted. It means the linked tests were executed and passed, and the owner files have the same fingerprint now as they had then. Edit redact.ts and safety.redaction reads stale until surface verify runs again.
• The leftover is honest. commands.run is the run export every CLI command file shares. No declaration covers all eleven files, so it stays inferred - visibly, at 0.65, with no contract - rather than being hidden.
• The rules are checked, not recited. Four of the repository's constraints carry a check, evaluated on every scan: no package other than evidence/runner.ts and git/git.ts imports node:child_process; core and the adapters import nothing that speaks HTTP; no .env or private key is committed; every capability in core has linked evidence. The last one caught a module without a test on the day it was added.

---

Commands

Every command supports --json. Exit code 2 means a check failed - error-level findings, or any warning under doctor --strict - so CI can gate on it. Full reference: docs/cli.md.

---

Language support

Evidence linking is where this differs from a filename heuristic. If a test imports the implementation, that is a fact recorded in the source and is reported as import-graph. If two files merely have similar names, that is a guess and is reported as path-proximity.

---

Trust and safety

• Local-first and read-only by default. Core makes zero network calls and never writes to your source files.
• Only one code path runs a project command - evidence/runner.ts - and it will only run a command that already exists in the surface document, from a working directory physically inside the project. The only other spawn site is git/git.ts, which invokes a fixed git binary with an argument array (no shell) for read-only queries, and refuses refs that look like options.
• Symlinks are never followed. A repository can commit a link to ~/.ssh/id_rsa; the file reader refuses anything whose real path leaves the project root.
• Adapters refuse to build command lines from suspicious names. A package.json script key containing shell metacharacters is skipped rather than turned into a run string.
• surface_verify over MCP is gated twice: the operator must set PROJECT_SURFACE_ALLOW_EXEC=1, and the command must already be in the document. There is no parameter through which a caller can supply a shell string, only an id to look up. The worst an adversarial prompt can achieve is running a command the project already declares.
• Secrets never enter the document by design; captured output is best-effort. Environment variable names are surfaced; values are never read. All captured command output passes through one redaction funnel (key assignments, bearer headers, connection strings, well-known token prefixes, private-key blocks) before it is stored - a pattern blocklist, so treat it as defense in depth, not a guarantee, and keep secrets out of test output.
• No absolute paths. The conformance suite fails any adapter that leaks a machine path, and any absolute path in captured output is replaced before storage.

---

Writing an adapter

Implement three things, and pass the conformance suite:

export const myAdapter: Adapter = {
  id: "elixir",
  version: "0.1.0",
  detect(ctx) { return ctx.exists("mix.exs"); },
  extract(ctx) { return { stack, commands, capabilities, evidence }; },
};

Adapters get read-only file access and no exec capability - they propose that mix test is the test command; only core may ever run it.

The conformance suite enforces what every consumer relies on: every claim has a source, every path is project-relative, statically discovered evidence is never reported as passed, and two runs over the same project produce byte-identical output. That last one is checked mechanically, because it is the property contributors break most often.

It runs as a command too, so an adapter does not have to live in this repository to be checked:

npx -p @project-surface/adapter-sdk surface-conform ./dist/index.js ./fixtures/elixir-app

What conforming means for a document, a generator in any language, a consumer, or an adapter is written down in spec/v1/CONFORMANCE.md, independently of this implementation.

---

What this is not

Not a multi-agent swarm, a hosted vector database, a chat UI, or an automatic code modifier. It does not require an account. It will not tell you it is AGI for your repository. How it relates to CLAUDE.md, Cursor rules, repomix, aider, Cody and Continue - including where each of them is better - is in docs/comparison.md.

It is a small, fast, inspectable artifact that is honest about what it does not know.

---

Repository layout

spec/v1/          The normative format: SPEC.md, surface.schema.json, validated examples
packages/
  core/           Schema, trust model, pipeline, analyses; the only module that runs a command
  adapter-sdk/    Adapter contract and the conformance suite
  adapters/       typescript/, python/, go/, rust/, generic/ (the fallback)
  cli/            The `surface` command (published as `project-surface`)
  mcp-server/     The MCP server behind `surface mcp`
fixtures/         Five small real projects with golden snapshots
test/             Integration suites: CLI, MCP over stdio, conformance, fixtures, spec examples
docs/             Concepts, trust model, CLI, MCP, declarations, adapters
integrations/     Claude Code plugin and GitHub Action
examples/         A full declaration file and an MCP client config
.project/         This repository's own surface: the declarations, and the generated document CI verifies

Development: npm install && npm run build && npm test. See CONTRIBUTING.md.

Documentation

• docs/concepts.md - what a surface is and why
• docs/trust-model.md - what a confidence number means
• docs/cli.md · docs/mcp.md · docs/declarations.md · docs/adapters.md · docs/comparison.md
• spec/v1/SPEC.md - the normative format, with validated examples
• spec/v1/CONFORMANCE.md - what a document, generator, consumer or adapter must satisfy · spec/VERSIONING.md - what may change within v1
• examples/ - a full declaration file and an MCP client config

Status

0.2.0 is on npm - npx project-surface init installs it. What is done, what is next and what is deliberately not claimed: ROADMAP.md. The schema is versioned as project-surface/v1 and published at a stable, versioned URL - https://richie11747.github.io/project-surface/spec/v1/surface.schema.json is its $id. A generator in any language can target it; spec/v1/CONFORMANCE.md says what that takes.

The comparative benchmark - 50 golden questions with mechanically checkable answers, asked with and without a surface - is built and reproducible (docs/benchmark.md): recordings are committed with model, commit, token usage and prompt hash, and the scorer runs offline in CI. Its current state is in bench/RESULTS.md; if that file says not recorded, no number is claimed. Shipping unmeasured numbers would violate the premise of the project.

"Works on real repositories" is measured the same way: a weekly corpus run scans fourteen pinned public projects (hono, fastify, express, zod, got, fastapi, flask, httpx, requests, gin, chi, cobra, axum, ripgrep) and commits the table - capabilities found, how much is inference, health findings, time, crashes.

License

Apache-2.0. See LICENSE.
