Scion: ternary MoE quantization with trained corrections

Scion is the project behind Scion-35B-A3B, split out of bonsai2-ternary-forensics so the harness, the port decisions and the release docs can be cloned and run on their own. The dense-model forensics (Bonsai 2 27B) stayed in that repository.

The idea. Ternarise the expert banks of a pretrained MoE in place, then recover the routing damage with small trained corrections on the residual stream. No full-precision masters and no full-model QAT. The frozen body ships at 2.125 bpw (Q1_0_g128 / PQ2_0 ternary experts, Q8_0 for the rest); the corrections are rank-512 branches on the attention output and the MoE block output, plus router deltas, trained by output-KD with the deployed quantizer in the loop.

Reference release: Scion-35B-A3B

empero-ai/Qwen3.8-35B-A3B-Distill (a Qwen3.8-line distill on Qwen/Qwen3.6-35B-A3B), ternary experts, Q8_0 rest and embedded corrections: 11.34 GB / 2.61 bpw in one file, no --lora step.

Task accuracy is inside the ±2% noise band, PPL is the best of the 2-bit class, and the KLD tail is the known gap and the current work item (docs/TAIL-EXPERIMENT-PLAN.md). The full table against every community quant of the same model is in docs/QUANT-RETENTION-35B.md.

The grid shows file size (left is smaller) against quality, with the PPL and KLD axes inverted so the better end is up. Every row uses the same protocol.

Card and weights: SkyIsNotGreen/Scion-35B-A3B. A snapshot of the card is kept at docs/RELEASE-35B-MODEL-CARD.md.

What the experiments established

• routing drift compounds and is the dominant failure mode (docs/MOE-EXTENSION.md §2.1);
• rotation is not the missing lever for MoE (§2.2);
• in-place ternary QAT on its own does not recover it at local budgets (§2.3);
• corrections must live on the residual stream, not inside experts; that is the placement rule (§2.4);
• router-KD is a verified no-op, and the correction repairs the state the router reads instead (§2.4a);
• train the sidecar in the deployed format, because post-hoc ternarisation is 14 to 25 times worse (§2.4c);
• the deployable Lloyd quantizer beats one-shot absmean (§2.4d);
• attn_out ships as a standard llama.cpp LoRA, and the better moe_out placement needs the ~90-line fork extension (§2.4e).

An earlier proof on the frozen proxy allenai/OLMoE-1B-7B-0924: the uncorrected mixed GGUF measured 566.7 PPL, and 14.48 with both placements and routers (2.12 GB body, 22.2 MB adapter), with CPU and HIP builds agreeing.

Quickstart

Local and free: the OLMoE proxy. Python 3.10 or newer, torch (ROCm or CUDA wheels), transformers, datasets, numpy and pyyaml. The run sequence is in moe/README.md. The in-place ternary QAT negative control is moe/olmoe_proxy.py and the correction trainer is moe/olmoe_corrections.py.

Rental: the 35B path, one 80 GB card, about $7. Quantize the deployment body locally first (llama-quantize with the experts mapped to pq2_0 and GGML_PQ2_0_LLOYD=1), run the box stages, then merge the exported adapter into the body with moe/merge_adapter_into_body.py:

bash moe/box-run.sh setup && bash moe/box-run.sh smoke && bash moe/box-run.sh cache
bash moe/box-run.sh ref   && bash moe/box-run.sh train && bash moe/box-run.sh eval && bash moe/box-run.sh export

Every stage is resumable, and checkpoints and the teacher cache land on the volume. Port notes: moe/PORT-QWEN35.md; the architecture decision record: docs/QWEN35-PORT-DECISION.md.

Runtime. Ternary experts and embedded adapters live in sky-is-green/prism-ml-llama.cpp, branch moe-corr-runtime, which is the fork's default branch: a plain git clone gets the right tree (PQ2_0 container, ffn_moe_out virtual target, embedded adapters; about 90 lines on top of Prism ML's prism branch). The fork's master is an untouched upstream mirror and cannot load these GGUFs; if a load fails with invalid ggml type 142. should be in [0, 43), you built master, and ./verify-container-support.sh in the checkout tells you in a second.

Layout

Serving notes (measured on two RX 7900 XT cards and a 7800X3D)

• the ternary container roughly halves the CPU-expert-offload penalty compared to f16 (2.07 GiB OLMoE: 34% and 50% versus 86% and 75% for prefill and decode);
• threads should equal physical cores (-t 16 collapses generation from 95 to 35 t/s on an 8C/16T CPU);
• do not layer-split when one card fits (40% generation loss);
• -ncmoe is the VRAM-budget dial, and placement does not change the math;
• a hot-expert GPU cache gave no throughput gain, because mul_mat_id computes k experts per token regardless of the weights. It would need sparse per-token dispatch rather than a static split (serving/placement-sweep-20260927/THROUGHPUT.md).

Provenance

Split from sky-is-green/bonsai2-ternary-forensics at b01f7e2 (2026-09-27). The dense forensics, the replication ladder and their failure register stayed there; this track's register is FAILURES.md.

License and attribution

Apache-2.0; see LICENSE and NOTICE. Base model: empero-ai (Apache-2.0) and Qwen / Alibaba Cloud (Apache-2.0); container and kernels: Prism ML's llama.cpp fork (MIT) with TAARDIS conventions (MIT); engine: llama.cpp (MIT). Not affiliated with, endorsed by, or supported by Prism ML, empero-ai, or Alibaba Cloud.
