Kubernetes-native Software Bill of Materials (SBOM) Visualization & Governance Platform

Ingest 1000+ SPDX and CycloneDX SBOMs, scan for vulnerabilities via OSV, enforce license compliance, and apply VEX statements — all visualized in a fast Angular dashboard backed by ClickHouse analytics.

BOMHort (formerly known as SeeBOM) is the same project with a new name. Read more: Why we renamed SeeBOM to BOMHort.

Getting Started · Architecture · Roadmap · Contributing · AI Policy

---

Quick Start

Prerequisites

Option A: Full Stack via Docker Compose (Recommended)

# 1. Clone the repo
git clone https://github.com/seebom-labs/BOMHort.git && cd BOMHort

# 2. Place your SBOM files in the sboms/ directory
#    Supports SPDX 2.x JSON, SPDX 3 JSON-LD, CycloneDX JSON, and in-toto attestation envelopes (auto-detected)
#    (examples included: sboms/_example.spdx.json, sboms/_example.cdx.json)

# 3. Start everything
make dev

# Or without make:
docker compose up --build -d

This starts:

• ClickHouse on localhost:9000 (TCP) / localhost:8123 (HTTP)
• API Gateway on localhost:8080
• Ingestion Watcher (runs once, scans sboms/ for new files)
• Parsing Worker (processes queued SBOM/VEX files)
• Angular UI on localhost:8090

Open http://localhost:8090 in your browser.

Configuration (.env)

Copy .env.example to .env and adjust:

cp .env.example .env

After changing .env:

# Apply new values (keeps ClickHouse data):
docker compose up -d --force-recreate

# Or full reset (wipes ClickHouse data):
make dev-reset

Configuration Files

Two JSON config files control license governance. Edit them and restart the affected services.

Custom Theme (CSS)

The entire UI color scheme is defined via CSS Custom Properties and can be overridden without rebuilding Angular.

Local (Docker Compose): Create a CSS file and set CUSTOM_THEME in .env:

# .env
CUSTOM_THEME=./my-theme.css

/* my-theme.css */
:root {
  --accent: #e94560;
  --nav-bg: #1a1a2e;
  --nav-brand: #e94560;
  --severity-critical: #ff4444;
  --license-permissive: #22c55e;
}

docker compose up -d --force-recreate ui

Kubernetes: Enable the theme ConfigMap in Helm values:

ui:
  customTheme:
    enabled: true

Then edit the ConfigMap:

kubectl create configmap bomhort-custom-theme \
  --from-file=custom-theme.css=./my-theme.css \
  --dry-run=client -o yaml | kubectl apply -f -
kubectl rollout restart deployment bomhort-ui

See ui/src/assets/custom-theme.example.css for all available variables.

Site Configuration (Texts & Branding)

All UI text content (brand name, page title, dashboard description, disclaimer, etc.) can be customised without rebuilding Angular via a ui-config.json file.

Local (Docker Compose): Edit the default file directly or point to your own:

# Option 1: Edit the built-in default
vim ui/public/ui-config.json

# Option 2: Use a custom file via .env
UI_CONFIG=./my-ui-config.json
docker compose up -d --force-recreate ui

Example ui-config.json:

{
  "brandName": "My SBOM Platform",
  "pageTitle": "My SBOM Platform",
  "dashboard": {
    "title": "Overview",
    "subtitle": "Software Supply Chain Governance",
    "description": "<strong>Welcome</strong> to our internal SBOM governance platform.",
    "disclaimer": "Internal use only. Data sourced from OSV and GitHub."
  },
  "footer": {
    "enabled": true,
    "text": "© 2026 My Company"
  }
}

All fields are optional — any missing key falls back to the built-in BOMHort default. HTML is supported in description and disclaimer.

Kubernetes: Enable the site config in Helm values:

ui:
  siteConfig:
    enabled: true
    content:
      brandName: "My SBOM Platform"
      pageTitle: "My SBOM Platform"
      dashboard:
        title: "Overview"
        subtitle: "Software Supply Chain Governance"
        description: "<strong>Welcome</strong> to our SBOM platform."
        disclaimer: "Internal use only."

Changes take effect after a pod restart (kubectl rollout restart deployment bomhort-ui). No rebuild needed.

S3 Ingestion (Default)

Ingest SBOMs directly from S3-compatible buckets (AWS S3, MinIO, GCS). This is the default and recommended ingestion method — no volumes, PVCs, or git-sync needed.

Single bucket:

# .env
S3_BUCKET=my-org-sboms
S3_ENDPOINT=s3.amazonaws.com
S3_REGION=us-east-1

Multiple buckets (JSON array):

# .env
S3_BUCKETS='[{"name":"my-org-sboms","endpoint":"s3.amazonaws.com","region":"us-east-1"},{"name":"platform-sboms","region":"us-east-1"}]'

Private buckets with credentials:

# .env (shared credentials for all buckets)
S3_ACCESS_KEY=AKIA...
S3_SECRET_KEY=...
S3_BUCKETS='[{"name":"my-private-bucket"}]'

# Or per-bucket credentials in JSON:
S3_BUCKETS='[{"name":"my-bucket","accessKey":"AKIA...","secretKey":"..."}]'

Multi-cluster: per-bucket cluster assignment:

# .env — each bucket maps to a different cluster
CLUSTER_NAME=default
S3_BUCKETS='[
  {"name":"prod-eu-sboms", "cluster":"prod-eu", "region":"eu-west-1"},
  {"name":"prod-us-sboms", "cluster":"prod-us", "region":"us-east-1"},
  {"name":"staging-sboms", "cluster":"staging"}
]'

Buckets without a cluster field inherit the global CLUSTER_NAME. If neither is set, data is untagged (single-instance mode).

Cluster is one of three ownership dimensions — namespace (#138) and project (#57) work the same way (NAMESPACE/PROJECT defaults, per-bucket fields, ?namespace=/?project= on upload), and INGEST_PATH_LAYOUT can derive all three from the ingestion path. See the deployment guide for details.

How it works:

• The Ingestion Watcher streams ListObjects from each bucket (paginated, no full listing in memory)
• Files are classified by extension: *.spdx.json / *_spdx.json → SBOM, *.openvex.json / *.vex.json → VEX
• SHA256 hashes are computed by streaming the object (not loaded into memory)
• Jobs are enqueued in batches of 500 for efficient ClickHouse inserts
• The Parsing Worker fetches S3 objects on-demand via s3://bucket/key URIs
• Local filesystem ingestion (from SBOM_SOURCE_DIR) still works alongside S3

# After editing config files:
docker compose up -d --force-recreate api-gateway parsing-worker

See docs/DEPLOYMENT_GUIDE.md for Kubernetes deployment instructions.

Option B: Local Kubernetes (Kind)

Deploy the full stack to a local Kind cluster, including ClickHouse Operator, SBOM ingestion, and the Angular UI:

# 1. Copy secrets template and fill in your values
cp examples/kind/secrets.env.example local/secrets.env
vi local/secrets.env

# 2. Deploy
make kind-up

# UI: http://localhost:8090   API: http://localhost:8080/healthz

See examples/ for Kind and production Kubernetes deployment configs.

Option C: Local Development (Hot Reload)

Use this when you want to iterate on code quickly:

# 1. Start only ClickHouse
make ch-only

# 2. Run the migrations (first time only)
make ch-migrate

# 3. In separate terminals:

# Terminal 1: API Gateway
make api

# Terminal 2: Run Ingestion Watcher (once)
make ingest

# Terminal 3: Start Parsing Worker
make worker

# Terminal 4: Angular dev server (hot reload, proxied to API)
make ui-dev

Open http://localhost:4200 — Angular proxies /api/* to localhost:8080.

---

Architecture

sboms/*.spdx.json + *.openvex.json
       │
       ▼
┌─────────────────────────┐
│   Ingestion Watcher     │  CronJob: scans files, deduplicates by SHA256,
│   (Go binary)           │  enqueues jobs into ClickHouse queue
└────────────┬────────────┘
             │
             ▼
┌─────────────────────────┐
│   Parsing Workers (N)   │  Stateless: claims jobs, parses SPDX/VEX
│   (Go binary)           │  (supports plain SPDX + in-toto attestation
│                         │  envelopes), resolves unknown licenses via
│                         │  GitHub API (50+ well-known Go module mappings),
│                         │  batch-INSERTs resolved data into ClickHouse,
│                         │  then queries OSV for vulns and checks license
│                         │  compliance
└────────────┬────────────┘
             │
             ▼
┌─────────────────────────┐
│   CVE Refresher         │  CronJob (daily): checks all PURLs for new CVEs
│   (Go binary)           │  without re-scanning all SBOMs
└────────────┬────────────┘
             │
             ▼
┌─────────────────────────┐
│   ClickHouse            │  11 tables: sboms, sbom_packages, vulnerabilities,
│                         │  license_compliance, vex_statements, ingestion_queue,
│                         │  dashboard_stats_mv, cve_refresh_log, github_license_cache,
│                         │  github_repo_metadata
└────────────┬────────────┘
             │
             ▼
┌─────────────────────────┐
│   API Gateway           │  25 REST endpoints, stateless
│   (Go binary)           │
└────────────┬────────────┘
             │
             ▼
┌─────────────────────────┐
│   Angular UI            │  10 lazy-loaded pages, virtual scrolling,
│                         │  OnPush change detection, dark mode,
│                         │  CSS custom properties theming
└─────────────────────────┘

Parsing Pipeline

The Parsing Worker processes each SBOM in a carefully ordered pipeline:

1. Parse — Auto-detect format and decode:
   • SPDX 2.x JSON (plain documents with spdxVersion field)
   • SPDX 3 JSON-LD (detected via @context: https://spdx.org/rdf/3.x/..., parsed via protobom)
   • In-toto attestation envelopes (SPDX wrapped in predicate field, common with Syft/BuildKit)
   • CycloneDX JSON (detected via bomFormat: "CycloneDX", versions 1.0–1.7)
   • Optional: Set USE_PROTOBOM=true to delegate all parsing to protobom for maximum format coverage
2. Resolve Licenses — For packages with NOASSERTION/empty licenses, query the GitHub API using three resolution strategies:
   • Direct github.com/{owner}/{repo} extraction from PURLs
   • Well-known Go module mappings (50+ entries: golang.org/x/* → golang/*, gopkg.in/*, go.uber.org/*, k8s.io/*, dario.cat/mergo, etc.)
   • Fallback to the dedicated GitHub /repos/{owner}/{repo}/license endpoint
   • Static overrides for repos where GitHub misdetects the license (e.g., opencontainers/go-digest, shopspring/decimal)
3. Insert — Batch-INSERT SBOM metadata and packages (with resolved licenses) into ClickHouse
4. Scan Vulnerabilities — OSV batch query for all PURLs
5. Check License Compliance — Classify licenses against the policy and apply exceptions

See docs/ARCHITECTURE_PLAN.md for the full blueprint.
See docs/DEPLOYMENT_GUIDE.md for Kubernetes deployment.
See docs/RELEASE.md for building and publishing container images.
See docs/TESTING.md for writing and running tests.
See the API Reference for complete endpoint documentation.

---

Makefile Commands

---

API Endpoints

For complete API documentation with request/response examples, see the API Reference.

---

Adding Your SBOMs

1. Place .spdx.json files in the sboms/ directory (or set SBOM_SOURCE_DIR in .env)
2. Place .openvex.json or .vex.json files in the same directory
3. Re-trigger ingestion (see below)
4. The Parsing Worker will automatically process new files

The Ingestion Watcher deduplicates by SHA256 hash — it will skip files that have already been processed.

Re-triggering Ingestion

# Run the watcher again (scans for new files, exits when done):
docker compose up ingestion-watcher

# If you changed SBOM_LIMIT or SBOM_SOURCE_DIR, force-recreate:
docker compose up --force-recreate ingestion-watcher

# To re-ingest everything from scratch (wipes all data):
make dev-reset

---

License Policy

The bundled default policy is derived from the CNCF Allowed Third-Party License Policy, because it is a well-reviewed public baseline — not because BOMHort targets CNCF projects. Replace it wholesale via licensePolicy.custom:

• Permissive (allowed): Apache-2.0, MIT, MIT-0, 0BSD, BSD-2-Clause, BSD-3-Clause, ISC, PSF-2.0, Python-2.0, PostgreSQL, UPL-1.0, X11, Zlib, OpenSSL, and a few more (18 total)
• Copyleft (flagged): GPL, LGPL, AGPL, MPL-2.0, EPL, EUPL, CPAL, and others (21 total)
• Unknown: Any license not in either list is flagged for review

License Exceptions

No exceptions are enabled or downloaded by default. Configure only approvals that apply to your organization using licenseExceptions.custom (a YAML object or JSON string), or --set-file licenseExceptions.custom=./my-exceptions.json with Helm. Docker Compose uses the initially empty sboms/license-exceptions.json.

The inactive example and migration guide describe the structure and matching rules. Package exceptions stay package-scoped; project restricts them to an exact SBOM document name. There is no CNCF-specific blanket promotion. An empty configuration is authoritative and does not fall back to old approvals in the SBOM directory.

Helm changes roll out both API and workers. Re-process existing SBOMs to update stored results after changing approvals; a watcher run alone skips unchanged files.

Customising the Policy

Override the default policy via Helm values:

licensePolicy:
  custom: |
    {
      "permissive": ["Apache-2.0", "MIT"],
      "copyleft": ["GPL-3.0-only", "AGPL-3.0-only"]
    }

Or edit the ConfigMap directly:

kubectl edit configmap bomhort-license-policy -n bomhort

---

Tech Stack

---

Subprojects

The seebom-labs organization hosts additional BOMHort subprojects:

• BOMcompare — Lightweight SBOM comparison tool.
• bomhort-website — Public website and landing pages for BOMHort.

See all repositories: https://github.com/seebom-labs

---

Contributing

We welcome contributions! See the Contributing Guide for how to get started.

• 📖 Full Documentation
• 🗺️ Roadmap
• 🪜 Contributor Ladder
• 🤖 AI Usage Policy
• 🛡️ Security Policy

---

License

Apache License 2.0
