Nand2Tetris Hardware Design

This repository contains the hardware design files for the "Hack" computer as described in the popular nand2tetris course.

The hdl folder contains all the hardware designs written in the custom HDL language that the course uses. The course has an online web IDE where you can write and test out designs written in their custom HDL at nand2tetris online IDE

But since I'd like to see this computer actually running, I also have the hardware designs written in Verilog in the verilog folder. I hope to eventually have the entire computer that we've designed here running on an FPGA

There is a Makefile in each of those module folders which should help you inspect the verilog designs.

I'm using an open-source toolchain for developing in Verilog. iverilog (Icarus Verilog) for compiling the verilog files and gtkwave for inspecting the resulting digital waveforms from the test code. So you'll need to install these as well. There's more information on these tools below

For example let's say you want to simulate one of the chips in Module 2, say the FullAdder.

Then just cd into the Module folder and type make <name_of_module>

cd verilog/Module\ 2 # There's a backslash here since the name of the folder contains whitespace
make FullAdder

Running the whole computer

• In the Module 4 folder in the verilog folder, the whole Computer comes together and you can write a program in the hack assembly language in the Module 4/prog.hack file and then do make Computer to test out the Computer running the prog.hack file.
• The Module 4 folder has a python script in the assembler folder which translate your assembly program into machine code and then the Computer uses a ROM which is filled with the machine code
• And the Computer starts running the instructions in the ROM one by one. We're storing the result of the computation at address 0 in the RAM, which we print in every clock cycle, to check if the result of the computation is correct

Lecture slides

Additionally the lectures folder contains all the lecture slides downloaded from the Coursera website. If you're someone who prefers watching lecture videos rather than reading a textbook then there's the Coursera Nand2Tetris course as well from the same authors

Future Ideas

Verilog designs can be run on an FPGA. The "Hack" computer is fairly simple and can run on any basic FPGA. The Lattice ice40 has a completely open-source toolchain "icestorm". So an ice40 FPGA is highly recommended. This workflow will also be added this repo in the future.

Learning Resources

If you'd like to learn Verilog then there are some nice free resources online:

Verilog is a HDL (Hardware Description Language), which can be used to design digital hardware

• HDLBits contains practice exercises for Verilog
• NandLand
• Asic World
• Chip Verify

Further courses

• Digital Systems Laboratory at MIT
• Digital Design and Computer Architecture at ETH-Zürich

Tools used

iverilog

iverilog compiles verilog code, and can be used for executing and simulating the code.

Source code: https://github.com/steveicarus/iverilog

Usage:

If you write your digital logic in And.v and test logic in Test.v. Then compile it like so:

iverilog -o And And.v Test.v

Run it like so:

./And

You'll see the output printed to the console, and also the Test.vcd file

gtkwave

gtkwave is for visualizing waveforms.

Source code: https://github.com/gtkwave/gtkwave

Usage:

View the waveform like so:

gtkwave Test.vcd

Other tools

I haven't checked these out yet, but I'd like to in the future

• Verilator
• BlueSpec Compiler
• Amaranth
• MyHDL, a HDL in Python!

A comparison of the HDLs

In this repo, we have implemented the Hack CPU as described in the Nand2Tetris course in both the Nand2Tetris HDL (an educational HDL, developed by the course creators) and Verilog (which is an industrial HDL)

There seem to be no for-loops in the Nand2Tetris HDL, and all operations can only be executed by chips, and there are no statements like assign or even logical operators like ~, & and | in Verilog. You have the Nand chip given to you (by god) and every other functionality follows from that, starting with Not, And and Or implemented by using Nand chip and then everything other higher order functionality follows from here

Verilog on the other hand is of course a much more expressive and powerful language in comparison.
