HWE-bench

A benchmark for evaluating coding agents on RTL/hardware bug-fixing tasks. HWE-bench curates 417 real bug-fix cases from 6 open-source hardware projects (ibex, cva6, caliptra, rocket-chip, XiangShan, OpenTitan) across Verilog, SystemVerilog, and Chisel. Each case is verified end-to-end via simulation (fail-to-pass): the included test fails on the buggy commit and passes after the fix.

Methodology, design decisions, and detailed analysis are described in the accompanying paper.

NEWS

• 2026-07-31: Launched the interactive leaderboard and updated the vendored Harbor snapshot to main@00c19fe2. Generated tasks now explicitly prohibit external access. Added reference scores for GPT-5.6 Sol max and GLM-5.2, and re-evaluated GPT-5.5 xhigh under the updated setup.

Previous updates

• 2026-04-30: Added two new reference scores to the results: GPT-5.5 xhigh at 79.4% and Claude Opus 4.7 max at 74.6%.
• 2026-04-26: Updated the reference results with three new model scores in the results: Kimi K2.6 at 66.9%, DeepSeek V4 Pro at 60.4%, and DeepSeek V4 Flash at 58.3%. Kimi K2.6 was evaluated with Kimi CLI; both DeepSeek V4 models were evaluated with Claude Code using a 1M context window and max thinking effort.

Contents

• Quick Start
• Installation
• Running an Evaluation
• Results
• Adding a New Repository
• Repository Layout
• Citation

Quick Start

Clone, install dependencies, download the benchmark data, and run Codex on the ibex subset (smallest, 35 cases):

# 1. Clone and install
git clone https://github.com/pku-liang/hwe-bench.git
cd hwe-bench
uv sync
uv tool install --editable ./deps/harbor --force

# 2. Download dataset and per-PR Docker images
hf download henryen/hwe-bench --repo-type dataset --local-dir datasets/
./scripts/pull_images.sh ibex

# 3. Generate task directories
uv run python -m hwe_bench.harness.harbor.adapter \
  --input datasets/lowRISC__ibex.jsonl \
  --output tasks/hwe-bench-ibex/

# 4. Run the agent
export CODEX_AUTH_JSON_PATH=~/.codex/auth.json
harbor run --path tasks/hwe-bench-ibex/ \
  -a codex -m openai/gpt-5.5 \
  --ak version=0.145.0 \
  --ak reasoning_effort=xhigh \
  --ak web_search=disabled \
  -k 1 -r 2 --n-concurrent 4 \
  --agent-setup-timeout-multiplier 2.0 \
  --job-name my-first-run

# 5. Extract patches and score
uv run python -m hwe_bench.harness.harbor.verify_bridge \
  --harbor-job-dir jobs/my-first-run \
  --output results/my-first-run/patches

uv run python -m hwe_bench.harness.evaluator \
  --workdir $(pwd)/results/my-first-run/eval_workdir \
  --patch_files $(pwd)/results/my-first-run/patches/patches.jsonl \
  --dataset_files $(pwd)/datasets/lowRISC__ibex.jsonl \
  --output_dir results/my-first-run/eval \
  --log_dir $(pwd)/results/my-first-run/eval_logs \
  --stop_on_error false --max_workers 4

The aggregate report lands at results/my-first-run/eval/final_report.json. For detailed agent recipes, scoring conventions, and troubleshooting notes, see docs/agents.md.

Installation

Prerequisites

• Linux (tested on Ubuntu 22.04)
• Docker 20.10+ (rootless supported and recommended)
• Python 3.12+
• uv
• huggingface_hub CLI (pip install -U huggingface_hub) for dataset download
• Disk space: roughly 200 GB for the published non-OpenTitan image set (ibex alone is ~10 GB); OpenTitan local builds require additional storage
• Network access to ghcr.io/pku-liang, HuggingFace Hub, and GitHub

Install HWE-bench

git clone https://github.com/pku-liang/hwe-bench.git
cd hwe-bench
uv sync
uv tool install --editable ./deps/harbor --force

The vendored Harbor dependency is documented in deps/README.md, including its upstream base and HWE-bench-specific patches.

Dataset

All JSONL datasets are hosted on HuggingFace:

hf download henryen/hwe-bench --repo-type dataset --local-dir datasets/

The repository-specific JSONL files are:

datasets/hwe_bench_full.jsonl contains all 417 cases for analysis and aggregate loading. Use the repository-specific files when running evaluations.

Docker Images

Per-PR Docker images are published at ghcr.io/pku-liang. Pull images for one repository at a time:

./scripts/pull_images.sh ibex --dataset datasets/lowRISC__ibex.jsonl

OpenTitan images are not distributed because the benchmark flow requires Synopsys VCS. To build OpenTitan locally, first provide a local vcs:minimal image with your own VCS installation and license environment, then follow docs/building-images.md.

The pull script retags remote images into the local hwebench/... names used by the harness and Harbor task files. The --dataset path can point anywhere; image tags are derived from the JSONL records, not from the file name.

If you prefer to rebuild other images from source, see docs/building-images.md. For a fuller description of image tags, retagging, and source builds, see docs/images.md and docs/building-images.md.

Agent Credentials

Set environment variables for the agents you plan to evaluate:

Agent-specific command templates and provider notes are documented in docs/agents.md.

Running an Evaluation

The evaluation pipeline has four steps. A full run over all 417 cases typically takes around a day of wall-clock time with 4 concurrent containers. This section gives the short path; docs/agents.md covers agent-specific flags, credentials, resume behavior, and scoring details.

1. Generate task directories

uv run python -m hwe_bench.harness.harbor.adapter \
  --input datasets/<dataset>.jsonl \
  --output tasks/hwe-bench-<repo>/

Re-run the adapter whenever per-PR Docker images are rebuilt; task test.sh files embed the image's base-commit SHA, which changes across rebuilds.

2. Run the agent

The pinned Harbor snapshot's default cleanup preserves the prebuilt per-PR images used by HWE-bench. Use --no-delete only when Harbor-built local images should also be retained after a run. Codex commands keep web_search=disabled so agents do not look up the upstream PR or patch during benchmark runs. Generated tasks allow public network access during agent installation and execution, while keeping the verifier offline. Rootless Docker does not yet support Harbor's hostname allowlist reliably on the tested host, so agent-side search restrictions remain part of each benchmark recipe.

# Codex CLI
export CODEX_AUTH_JSON_PATH=~/.codex/auth.json
harbor run --path tasks/hwe-bench-<repo>/ \
  -a codex -m openai/gpt-5.5 \
  --ak version=0.145.0 \
  --ak reasoning_effort=xhigh \
  --ak web_search=disabled \
  -k 1 -r 2 --n-concurrent 4 \
  --agent-setup-timeout-multiplier 2.0 \
  --job-name hwe-<repo>-codex

# Claude Code
harbor run --path tasks/hwe-bench-<repo>/ \
  -a claude-code -m anthropic/claude-sonnet-4-6 \
  --ak max_turns=500 --ak reasoning_effort=high \
  --ak "disallowed_tools=WebSearch,WebFetch" \
  --ae CLAUDE_CODE_OAUTH_TOKEN="$CLAUDE_CODE_OAUTH_TOKEN" \
  --ae ANTHROPIC_API_KEY= \
  --ae CLAUDE_CODE_MAX_OUTPUT_TOKENS=128000 \
  -k 1 -r 2 --n-concurrent 4 \
  --agent-setup-timeout-multiplier 2.0 \
  --job-name hwe-<repo>-claude

Recipes for Kimi Code and OpenHands SDK: see docs/agents.md.

3. Extract patches

uv run python -m hwe_bench.harness.harbor.verify_bridge \
  --harbor-job-dir jobs/<job-name> \
  --output results/<job-name>/patches

4. Score

uv run python -m hwe_bench.harness.evaluator \
  --workdir $(pwd)/results/<job-name>/eval_workdir \
  --patch_files $(pwd)/results/<job-name>/patches/patches.jsonl \
  --dataset_files $(pwd)/datasets/<dataset>.jsonl \
  --output_dir results/<job-name>/eval \
  --log_dir $(pwd)/results/<job-name>/eval_logs \
  --stop_on_error false --max_workers 4

The aggregate report is at results/<job-name>/eval/final_report.json. Per-case reports live in results/<job-name>/eval_workdir/<org>/<repo>/evals/pr-<N>/report.json. --workdir must be an absolute path (required by Docker's bind-mount).

Results

Current overall and per-repository scores, file-level precision, estimated token-equivalent cost, and scaffold filters are available on the interactive leaderboard.

Adding a New Repository

HWE-bench supports Verilog, SystemVerilog, and Chisel repositories. Adding a new repo involves running the s01–s08 collection pipeline, implementing a harness class (Docker base image plus prepare scripts), writing prompt templates for tbgen/verify/psgen, running s09–s11 to produce an eval-ready JSONL, and generating task directories via the adapter.

The construction pipeline is documented in stages: collect covers s01–s08 PR collection and scoring, harness gives the overall s09–s11 flow, and the stage-specific documents cover tbgen, verify, psgen, and repository harnesses.

Repository Layout

hwe_bench/
  collect/            # s01-s08: GitHub PR collection and filtering
  harness/
    base.py           # core types: PullRequest, Image, Instance, Config
    docker_runner.py  # image builds and f2p validation
    evaluator.py      # offline patch scoring
    reporting.py      # report aggregation
    harbor/           # Harbor adapter (JSONL → task dirs, patch extraction)
    tbgen/            # s09: test-bench generation
    verify/           # s10: verification in Docker
    psgen/            # s11: problem-statement generation
    audit/            # trajectory audit pipeline
    repos/            # per-repo harnesses
      verilog/{ibex,cva6,opentitan,caliptra}/
      chisel/{xiangshan,rocketchip}/
deps/
  harbor/             # Harbor framework (git subtree)
datasets/             # JSONL datasets (downloaded separately; not in git)
tasks/                # Harbor task dirs (generated by adapter; not in git)
jobs/                 # Harbor run outputs (not in git)
results/              # Patches and evaluation outputs (not in git)
docs/                 # Extended documentation

Citation

If you use HWE-bench in your research, please cite:

@article{cui2026hwe,
  title={HWE-Bench: Benchmarking LLM Agents on Real-World Hardware Bug Repair Tasks},
  author={Cui, Fan and Hou, Hongyuan and Luo, Zizhang and Yin, Chenyun and Liang, Yun},
  journal={arXiv preprint arXiv:2604.14709},
  year={2026}
}

License

Apache 2.0. See LICENSE.

Acknowledgments

HWE-bench builds on open-source contributions from the hardware design community. We thank the maintainers of the six benchmark subject repositories: ibex (lowRISC), cva6 (OpenHW Group), caliptra-rtl and rocket-chip (CHIPS Alliance), XiangShan (OpenXiangShan), and OpenTitan (lowRISC).

The evaluation harness is built on Harbor. The project was originally forked from Multi-SWE-bench and rewritten for hardware description languages.
