dithr

Before (left) and after (right) using yliluoma_2_in_place.

Buffer-first rust dithering and halftoning library.

Quantizing grayscale/RGB/RGBA buffers without dithering creates visible banding and contouring. dithr provides deterministic ordered dithering, diffusion, stochastic binary methods, palette-constrained workflows, and advanced halftoning methods over typed mutable slices.

Overview

• Buffer-first API: Works directly on mutable pixel slices with explicit width, height, and stride.
• Typed formats: Supports u8, u16, and f32 sample types across Gray, Rgb, and Rgba layouts.
• Quantization control: Uses QuantizeMode for grayscale levels, RGB levels, palette mapping, or single-color workflows.
• Broad algorithm coverage: Includes stochastic, ordered, palette-oriented ordered, diffusion, variable diffusion, and advanced halftoning families.
• Palette workflow: Includes Palette<S> and IndexedImage<S> for constrained output and indexed results.
• Optional integrations: image adapters for DynamicImage workflows and rayon parallel wrappers for selected families.

Installation

cargo add dithr

[dependencies]
dithr = "0.3.0"

cargo add dithr --features image
cargo add dithr --features rayon

Quick Start

use dithr::{gray_u8, QuantizeMode, Result};
use dithr::ordered::bayer_8x8_in_place;

fn main() -> Result<()> {
    let width = 64_usize;
    let height = 64_usize;
    let mut data = Vec::with_capacity(width * height);

    for y in 0..height {
        for x in 0..width {
            let value = ((x + y * width) * 255 / (width * height - 1)) as u8;
            data.push(value);
        }
    }

    let mut buffer = gray_u8(&mut data, width, height, width)?;
    bayer_8x8_in_place(&mut buffer, QuantizeMode::gray_bits(1)?)?;

    assert!(data.iter().all(|&v| v == 0 || v == 255));
    Ok(())
}

Core Data Model

dithr is organized around a small set of types that are shared across algorithm families.

• Buffer<'a, S, L>: Mutable typed view of image data (S = sample type, L = layout).
• BufferKind / PixelFormat: Runtime format metadata (PixelFormat is an alias of BufferKind).
• Palette<S>: Palette storage for fixed-color workflows (1 to 256 entries).
• IndexedImage<S>: Indexed output (Vec<u8> indices) paired with a typed palette.
• QuantizeMode<'a, S>: Common quantization target model used by ordered/diffusion/stochastic/dot/Riemersma families.
• Error / Result<T>: Crate-level error and result surface.

Typed Buffers, Sample Types, and Layouts

Supported runtime kinds:

• Gray8, Rgb8, Rgba8
• Gray16, Rgb16, Rgba16
• Gray32F, Rgb32F, Rgba32F

Typed buffer aliases:

• GrayBuffer8, RgbBuffer8, RgbaBuffer8
• GrayBuffer16, RgbBuffer16, RgbaBuffer16
• GrayBuffer32F, RgbBuffer32F, RgbaBuffer32F

Constructor helpers:

• Gray: gray_u8, gray_u16, gray_32f
• Rgb: rgb_u8, rgb_u16, rgb_32f
• Rgba: rgba_u8, rgba_u16, rgba_32f
• Packed variants: gray_u8_packed, rgb_u16_packed, rgba_32f_packed, etc.

Generic constructors remain available on Buffer:

• Buffer::new_typed(...)
• Buffer::new_packed_typed(...)
• Compatibility constructors with runtime kind checking:
  • Buffer::new(...)
  • Buffer::new_packed(...)

Choosing a Quantization Mode

QuantizeMode<'a, S> is the canonical quantization model:

• GrayLevels(u16)
• RgbLevels(u16)
• Palette(&Palette<S>)
• SingleColor { fg: [S; 3], levels: u16 }

Convenience constructors:

• Generic:
  • QuantizeMode::gray_levels(levels)
  • QuantizeMode::rgb_levels(levels)
  • QuantizeMode::palette(&palette)
  • QuantizeMode::single_color(fg, levels)
• u8 compatibility helpers:
  • QuantizeMode::gray_bits(bits)
  • QuantizeMode::rgb_bits(bits)
• Shared conversion helper:
  • levels_from_bits(bits)

Use GrayLevels/gray_bits when output should be grayscale levels, RgbLevels/rgb_bits for uniform per-channel color quantization, Palette for strict membership in a fixed color set, and SingleColor for foreground-scaled tonal output.

Dithering and Halftoning Method Families

Binary stochastic

Fast binary dithering with fixed or randomized threshold behavior.

• threshold_binary_in_place
• random_binary_in_place

Parallel variants (rayon feature):

• threshold_binary_in_place_par
• random_binary_in_place_par

Ordered methods

Deterministic threshold-map methods with predictable structure and straightforward benchmarking.

Bayer:

• bayer_2x2_in_place
• bayer_4x4_in_place
• bayer_8x8_in_place
• bayer_16x16_in_place

Cluster-dot:

• cluster_dot_4x4_in_place
• cluster_dot_8x8_in_place
• void_and_cluster_in_place

Custom map:

• custom_ordered_in_place
• adaptive_ordered_dither_in_place
• space_filling_curve_ordered_dither_in_place
• ranked_dither_in_place
• image_based_dither_screen_in_place
• polyomino_ordered_dither_in_place
• stochastic_clustered_dot_in_place
• am_fm_hybrid_halftoning_in_place
• clustered_am_fm_halftoning_in_place
• blue_noise_multitone_dither_in_place

Parallel variants (rayon feature):

• bayer_2x2_in_place_par
• bayer_4x4_in_place_par
• bayer_8x8_in_place_par
• bayer_16x16_in_place_par
• cluster_dot_4x4_in_place_par
• cluster_dot_8x8_in_place_par
• custom_ordered_in_place_par

Palette-oriented ordered (Yliluoma)

Ordered methods designed for fixed-palette workflows.

• yliluoma_1_in_place
• yliluoma_2_in_place
• yliluoma_3_in_place

Classic diffusion

Scanline error diffusion kernels for higher local tonal quality.

• floyd_steinberg_in_place
• false_floyd_steinberg_in_place
• jarvis_judice_ninke_in_place
• stucki_in_place
• burkes_in_place
• sierra_in_place
• two_row_sierra_in_place
• sierra_lite_in_place
• stevenson_arce_in_place
• atkinson_in_place

Extended diffusion

Additional diffusion kernels with different spread patterns.

• fan_in_place
• shiau_fan_in_place
• shiau_fan_2_in_place
• block_error_diffusion_in_place

Scope note: block_error_diffusion_in_place is grayscale-only.

Variable diffusion

Tone-dependent coefficient families.

• ostromoukhov_in_place
• zhou_fang_in_place
• hvs_optimized_error_diffusion_in_place
• gradient_based_error_diffusion_in_place
• multiscale_error_diffusion_in_place
• feature_preserving_msed_in_place
• green_noise_msed_in_place
• linear_pixel_shuffling_in_place
• tone_dependent_error_diffusion_in_place
• structure_aware_error_diffusion_in_place
• adaptive_vector_error_diffusion_in_place
• vector_error_diffusion_in_place
• semivector_error_diffusion_in_place
• hierarchical_error_diffusion_in_place
• mbvq_color_error_diffusion_in_place
• neugebauer_color_error_diffusion_in_place
• multichannel_green_noise_error_diffusion_in_place

Scope note: variable diffusion methods are grayscale-only except adaptive_vector_error_diffusion_in_place, vector_error_diffusion_in_place, semivector_error_diffusion_in_place, and hierarchical_error_diffusion_in_place, mbvq_color_error_diffusion_in_place, and neugebauer_color_error_diffusion_in_place, and multichannel_green_noise_error_diffusion_in_place, which support Rgb/Rgba with alpha preservation on Rgba.

Advanced halftoning

Specialized methods with narrower scope than the ordered/diffusion baseline.

• riemersma_in_place
• knuth_dot_diffusion_in_place
• optimized_dot_diffusion_in_place
• direct_binary_search_in_place
• clustered_dot_direct_multibit_search_in_place
• direct_pattern_control_in_place
• hierarchical_colorant_dbs_in_place
• lattice_boltzmann_in_place
• electrostatic_halftoning_in_place
• model_based_med_in_place
• least_squares_model_based_in_place

Scope notes:

• direct_binary_search_in_place, clustered_dot_direct_multibit_search_in_place, lattice_boltzmann_in_place, electrostatic_halftoning_in_place, model_based_med_in_place, and least_squares_model_based_in_place require integer grayscale buffers.
• direct_pattern_control_in_place supports integer Rgb/Rgba buffers; alpha is preserved for Rgba.
• hierarchical_colorant_dbs_in_place supports integer Rgb buffers.
• riemersma_in_place, knuth_dot_diffusion_in_place, and optimized_dot_diffusion_in_place support Gray/Rgb/Rgba layouts, with alpha preserved for Rgba paths.

Palette Workflow

dithr keeps palette workflows explicit: define a palette, dither into it, and optionally build indexed output.

use dithr::{rgb_u8, IndexedImage, Palette, Result};
use dithr::ordered::yliluoma_1_in_place;

fn main() -> Result<()> {
    let width = 32_usize;
    let height = 32_usize;
    let mut data = vec![0_u8; width * height * 3];

    for y in 0..height {
        for x in 0..width {
            let i = (y * width + x) * 3;
            data[i] = (x * 255 / (width - 1)) as u8;
            data[i + 1] = (y * 255 / (height - 1)) as u8;
            data[i + 2] = ((x + y) * 255 / (width + height - 2)) as u8;
        }
    }

    let palette = Palette::new(vec![
        [0, 0, 0],
        [255, 255, 255],
        [255, 0, 0],
        [0, 0, 255],
    ])?;

    let mut buffer = rgb_u8(&mut data, width, height, width * 3)?;
    yliluoma_1_in_place(&mut buffer, &palette)?;

    let mut indices = Vec::with_capacity(width * height);
    for px in data.chunks_exact(3) {
        indices.push(palette.nearest_rgb_index([px[0], px[1], px[2]]) as u8);
    }

    let indexed = IndexedImage::new(indices, width, height, palette)?;
    assert_eq!(indexed.len(), width * height);

    Ok(())
}

Built-in palette helpers are also exported:

• cga_palette()
• grayscale_2()
• grayscale_4()
• grayscale_16()

Optional image Integration

Enable image to adapt image crate buffers into dithr buffers.

Typed adapters:

• gray8_image_as_buffer
• rgb8_image_as_buffer
• rgba8_image_as_buffer
• gray16_image_as_buffer
• rgb16_image_as_buffer
• rgba16_image_as_buffer
• rgb32f_image_as_buffer
• rgba32f_image_as_buffer

Dynamic adapter:

• dynamic_image_as_buffer(&mut image::DynamicImage) -> Result<DynamicImageBuffer<'_>>

Dynamic variants:

• DynamicImageBuffer::Gray8
• DynamicImageBuffer::Rgb8
• DynamicImageBuffer::Rgba8
• DynamicImageBuffer::Gray16
• DynamicImageBuffer::Rgb16
• DynamicImageBuffer::Rgba16
• DynamicImageBuffer::Rgb32F
• DynamicImageBuffer::Rgba32F

DynamicImage::ImageLumaA8 and DynamicImage::ImageLumaA16 are promoted to DynamicImageBuffer::Rgba8 and DynamicImageBuffer::Rgba16 during adaptation.

Current manifest configuration enables PNG and JPEG codecs for the optional image dependency.

Optional rayon Integration

Enable rayon for parallel wrappers where available.

Parallelized families:

• Ordered: all *_in_place_par ordered wrappers
• Yliluoma: yliluoma_1_in_place_par, yliluoma_2_in_place_par, yliluoma_3_in_place_par
• Binary stochastic: threshold_binary_in_place_par, random_binary_in_place_par

Current serial-only families:

• Diffusion (classic/extended/variable)
• Advanced halftoning

Example Programs

Raw buffer workflows:

cargo run --example gray_buffer
cargo run --example rgb_buffer
cargo run --example indexed_palette

Image workflows (image feature):

cargo run --example image_bayer_png --features image -- input.png output.png
cargo run --example image_palette_png --features image -- input.png output.png

Benchmarks and Development

Bench families (criterion):

• stochastic
• ordered
• yliluoma
• diffusion
• advanced

cargo bench --no-run
cargo bench --bench stochastic
cargo bench --bench ordered
cargo bench --bench yliluoma
cargo bench --bench diffusion
cargo bench --bench advanced

Development checks:

cargo fmt --all -- --check
cargo clippy --workspace --all-targets --all-features -- -D warnings
cargo check --all-features
cargo test --workspace --all-features --lib --tests --examples
cargo test --doc --all-features

Limitations and Scope

• Core processing is in-memory and buffer-first; it does not provide general image editing workflows.
• Not every algorithm supports every format/layout/sample combination.
• am_fm_hybrid_halftoning_in_place and clustered_am_fm_halftoning_in_place are grayscale-only.
• blue_noise_multitone_dither_in_place is grayscale-only.
• Variable diffusion methods are grayscale-only except adaptive_vector_error_diffusion_in_place, vector_error_diffusion_in_place, semivector_error_diffusion_in_place, mbvq_color_error_diffusion_in_place, and neugebauer_color_error_diffusion_in_place, and multichannel_green_noise_error_diffusion_in_place for Rgb/Rgba.
• block_error_diffusion_in_place is grayscale-only.
• direct_binary_search_in_place, clustered_dot_direct_multibit_search_in_place, lattice_boltzmann_in_place, and electrostatic_halftoning_in_place are integer grayscale-only.
• Parallel wrappers are currently provided for ordered, Yliluoma, and binary stochastic families.

References

• Dither: https://en.wikipedia.org/wiki/Dither
• Ordered dithering: https://en.wikipedia.org/wiki/Ordered_dithering
• Error diffusion: https://en.wikipedia.org/wiki/Error_diffusion
• Yliluoma positional dithering: http://bisqwit.iki.fi/story/howto/dither/jy/
• Dithering eleven algorithms: https://tannerhelland.com/2012/12/28/dithering-eleven-algorithms-source-code.html
• Ostromoukhov variable-coefficient diffusion: https://www.iro.umontreal.ca/~ostrom/publications/pdf/SIGGRAPH01_varcoeffED.pdf
• Zhou-Fang threshold modulation: https://history.siggraph.org/learning/improving-mid-tone-quality-of-variable-coefficient-error-diffusion-using-threshold-modulation-by-zhou-and-fang/
• Multiscale error diffusion: https://doi.org/10.1109/83.557360, https://mcl.usc.edu/wp-content/uploads/2014/01/1997-03-A-multiscale-error-diffusion-technique-for-digital-Halftoning.pdf
• Feature-preserving multiscale error diffusion: https://ira.lib.polyu.edu.hk/bitstream/10397/1524/1/J-JEI-Feature-preserving%20multiscale%20error%20diffusion_04.pdf, https://doi.org/10.1117/1.1758728
• Green-noise multiscale error diffusion: https://pubmed.ncbi.nlm.nih.gov/20215075/, https://www.eie.polyu.edu.hk/~enyhchan/J-TIP-Green_noise_digital_halftoning_with_MED.pdf
• Multichannel green-noise error diffusion: https://doi.org/10.1109/83.841537, https://doi.org/10.1364/JOSAA.16.001575
• Adaptive vector error diffusion: https://pubmed.ncbi.nlm.nih.gov/18282985/, https://doi.org/10.1109/83.597270
• HVS-optimized error diffusion (Kolpatzik-Bouman): https://engineering.purdue.edu/~bouman/publications/pdf/jei1scan.pdf, https://engineering.purdue.edu/~bouman/publications/pub_doc.html
• Vector and semivector color error diffusion: https://pubmed.ncbi.nlm.nih.gov/18255498/, https://doi.org/10.1109/83.951540, https://users.ece.utexas.edu/~bevans/papers/2003/colorDiffusion/index.html
• MBVQ/Neugebauer color error diffusion: https://www.mdpi.com/2313-433X/6/4/23, https://doi.org/10.3390/jimaging6040023, https://patents.google.com/patent/US5991438A/en, https://patents.google.com/patent/EP0895408A2/en
• Block error diffusion: https://doi.org/10.1109/TIP.2005.859776, https://shiftleft.com/mirrors/www.hpl.hp.com/personal/Niranjan_Damera-Venkata/files/ibc.pdf
• Hierarchical error diffusion: https://pubmed.ncbi.nlm.nih.gov/19473943/, https://doi.org/10.1109/TIP.2009.2019778
• Tone-dependent error diffusion: https://pubmed.ncbi.nlm.nih.gov/15376941/, https://pubmed.ncbi.nlm.nih.gov/17283778/
• Structure-aware error diffusion: https://perso.liris.cnrs.fr/ostrom/publications/pdf/SIGGRAPH-ASIA09_saed.pdf
• Linear pixel shuffling error diffusion: https://repository.rit.edu/other/391/, https://www.imaging.org/common/uploaded%20files/pdfs/Papers/2000/PICS-0-81/1625.pdf
• Riemersma dithering: https://www.compuphase.com/riemer.htm
• Knuth dot diffusion: https://dl.acm.org/doi/10.1145/35039.35040
• Optimized dot diffusion: https://doi.org/10.1109/83.841944
• Direct binary search halftoning: https://doi.org/10.1117/12.135959
• Model-based halftoning (MED + LSMB): https://pubmed.ncbi.nlm.nih.gov/18282991/, https://doi.org/10.1117/12.135965, https://users.eecs.northwestern.edu/~pappas/papers/pappas_neuhoff_tip99.pdf
• Lattice-Boltzmann halftoning: https://www.mia.uni-saarland.de/Publications/hagenburg-isvc09.pdf
• Electrostatic halftoning: https://onlinelibrary.wiley.com/doi/10.1111/j.1467-8659.2010.01716.x
• Void-and-cluster dithering: https://docslib.org/doc/9596963/the-void-and-cluster-method-for-dither-array-generation, https://cv.ulichney.com/papers/1994-filter-design.pdf
• Adaptive ordered dither: https://doi.org/10.1006/gmip.1996.0414, https://www.sciencedirect.com/science/article/pii/S1077316996904141
• Space-filling curve ordered dither: https://doi.org/10.1016/S0097-8493(98)00043-0, https://www.sciencedirect.com/science/article/pii/S0097849398000430
• Ranked dither: https://www.mayagupta.org/publications/GuptaBowenSPIE07.pdf
• Image-based dither screens: https://graphicsinterface.org/wp-content/uploads/gi1999-22.pdf, https://doi.org/10.20380/GI1999.22
• Polyomino-based digital halftoning: https://arxiv.org/abs/0812.1647, https://doi.org/10.48550/arXiv.0812.1647
• Stochastic clustered-dot dithering: https://perso.liris.cnrs.fr/victor.ostromoukhov/publications/pdf/SPIE99_StochasticClust.pdf, https://pubmed.ncbi.nlm.nih.gov/18255440/
• AM/FM hybrid halftoning: https://engineering.purdue.edu/~bouman/publications/orig-pdf/jei8.pdf, https://doi.org/10.1117/12.643690
• Clustered AM/FM halftoning: https://doi.org/10.2352/ISSN.2169-4451.2004.20.1.art00025_2, https://dblp.org/db/conf/clrimg/clrimg2006.html
• Blue-noise multitone dithering: https://doi.org/10.1109/TIP.2008.926145, https://www.eecis.udel.edu/~arce/files/Publications/5-Multitone.pdf
• Clustered-dot direct multibit search: https://pubmed.ncbi.nlm.nih.gov/28113172/, https://doi.org/10.1109/TIP.2016.2552723, https://research.ibm.com/publications/hybrid-halftoning-using-direct-multi-bit-search-dms-screen-algorithm
• Direct pattern control halftoning: https://pubmed.ncbi.nlm.nih.gov/28613170/, https://doi.org/10.1109/TIP.2017.2713939, https://cv.ulichney.com/papers/2017-PARAWACS-IEEE.pdf
• Hierarchical colorant DBS (MBVQ-guided): https://pubmed.ncbi.nlm.nih.gov/20236895/, https://doi.org/10.1109/TIP.2010.2045690, https://pubmed.ncbi.nlm.nih.gov/28613170/

License

MIT. See LICENSE.
