anime-rag

**Author: Martin Larrea (martin76ec)

Multimodal (Agentic) RAG over the Manga109-s manga dataset. Individual NLP course project.

• Code: https://github.com/martin76ec/manga-multi-modal-rag
• Embeddings: https://huggingface.co/datasets/martin76ec/Manga109-s-indexes
• Demo video: https://www.youtube.com/watch?v=bUYKq-7YVvg

Project Overview

Topic

Multimodal Agentic RAG.

[!Note] This project is not built with LangChain and Ragas. The chosen available model (gemma4) was not good enough at output formatting, tool calling and consistently failed. LangChain was replaced with a simpler custom MRKL.

Problem and Data

Manga dialogue in Manga109-s is Japanese-only, and panels carry visual information the transcribed text often doesn't describe. Goal: let someone who doesn't read Japanese ask a question in English and get an answer grounded in cited panels, using both artwork and dialogue.

Data: Manga109-s, 87 licensed manga volumes with page images and per-panel annotations. Fully indexed: 87 books, 82,124 panels.

Data preparation

One real panel end to end (DollGun_079_00011f25, book DollGun, page 79):

1. Crop. The book's XML annotation gives a frame bounding box [1084, 756, 1294, 1104] (x0, y0, x1, y1) on the raw page image (data/raw/images/DollGun/079.jpg). panels.py crops that box out and attaches the dialogue text box and character boxes whose coordinates fall inside it, producing one crop file (data/raw/crops/DollGun/DollGun_079_00011f25.jpg) with its dialogue and character name attached.

2. Translate. The attached dialogue is Japanese: くッ・・・撃ち尽くしたのかよッ!!?. translate.py runs it through NLLB-200 (beam search 4, repetition penalty 1.3) for display: "Shit, did you just shoot him?". The same model runs the other direction at query time, since the CLIP model and the dialogue are both Japanese-native: the English query "someone holding a gun" becomes "銃を握っている人" before embedding.

3. Embed. embedder.py runs the Japanese CLIP model on the crop image and on its Japanese dialogue text separately, giving two 512-dim vectors in the same space:

   • image_emb[:8] = [-0.0304, -0.0483, 0.0192, 0.0039, -0.0503, -0.0297, -0.0106, -0.0303]
   • text_emb[:8] = [-0.0473, 0.0111, -0.0193, -0.0085, -0.0190, -0.0422, -0.0416, 0.0035]

   Both get written to the index (one row per panel, 82,124 rows at full scale) alongside the metadata above. Panels whose dialogue is empty or under 3 word characters (e.g. "……") skip the text embedding and fall back to image-only scoring (see "What didn't work" below for why).

Baseline vs. proposed solution

Example input/output

Baseline retrieval (uv run anime-rag search "someone holding a gun" --top-k 1):

• input (English): someone holding a gun
• translated query (Japanese, what actually gets embedded): 銃を握っている人
• output:

  #0 [0.478] HanzaiKousyouninMinegishiEitarou p.010 (HanzaiKousyouninMinegishiEitarou_010_0001e8c4)
      img=0.295 text=0.753  chars: 晶海
      text (ja): あれは・・・・ / 拳銃のにおいです・・・
      text (en): That's the smell of a gun.
      crop:  data/raw/crops/HanzaiKousyouninMinegishiEitarou/HanzaiKousyouninMinegishiEitarou_010_0001e8c4.jpg
      page:  data/raw/images/HanzaiKousyouninMinegishiEitarou/010.jpg


Agent (uv run anime-rag agent "What happens when a police officer shows up at someone's house?" --top-k 2 --max-steps 3), real transcript:

input: What happens when a police officer shows up at someone's house?

--- step 0 ---
Thought: I need to search for a scene where a police officer arrives at a
person's house to see what happens next.
Action: search_manga
Action Input: a police officer showing up at someone's house

Observation (2 panels):
#0 HanzaiKousyouninMinegishiEitarou p.096: "That's when the police can
   tell the killer from the hostage."
#1 TennenSenshiG p.051: "Excuse me, I'm a police officer. I'd like to
   ask you a few questions."

--- step 1 ---
Thought: The search results provide two different contexts. [...] I have
enough information to answer based on the direct interaction in
TennenSenshiG.
Final Answer: In TennenSenshiG p.051, a police officer arrives and says
they would like to ask some questions.

Comparison methodology and results

This project meassure hit-rate/MRR for retrieval, and faithfulness/relevancy for the agent. There are two judges:

1. Custom ChatLLM (replacement for langchain and ragas as mentioned before), text-only.
2. Jev (from Typesafe) model, which looks at the actual cited panel images directly instead of trusting the agent's own description. Running both for real on the same answers showed why that distinction matters: ChatLLM reliably gives a flat 5/5 regardless of answer quality, while Jev gives differentiated, lower scores and correctly rates a declined answer as low relevancy.

The cases to test are a set of questions spanning difficulty tiers, mined for real across ~15 different books (not hand-picked from 1-2), each with a recorded verification method (metadata, literal text match, visual inspection, or Jev):

• very_simple/simple (10): exact or near-exact literal match (a character name, a term that appears verbatim in the matching dialogue)
• moderate (7): semantic queries worded differently from the matching dialogue, verified against what the dialogue actually says
• hard (2): genuinely visual, confirmed by viewing the crop image since the dialogue alone doesn't give the answer away
• complex/very_complex (4, agent-only): multi-hop and adversarial questions a single retrieval can't answer

Modality (query: "police officer", at 2-book scale):

Isolating either modality changes the ranking. Text carried more signal here:

The default wins outright on both metrics, more convincingly than the earlier 4 case version of this sweep suggested.

HyDE:

A real negative result: the generated hypothetical dialogue was stylistically plausible ("ドールガン" -> "撃てッ！", i.e. "Fire!") but generic, not close to the actual specific indexed dialogue. Most of this project's queries are literal names or terms, which HyDE's generated paraphrase works against rather than for. Not adopted.

Baseline vs. agent:

The agent's real advantage is saying "I don't know" instead of confidently returning a wrong top-1, and chaining queries for questions that need more than one search. That costs more (next section), so it's a trade-off, not a strict upgrade.

Agent LLM comparison (same question, same top_k=2, max_steps=3, real runs):

Genuinely better-calibrated reasoning, but at roughly 10x the token cost and with dependency/format problems that have no clean fix inside this project's current stack. Not a drop-in upgrade, so the shipped agent stays on Gemma-4.

IRCoT ablation (does letting each round's query be the agent's own reasoning step, vs. always re-searching the literal original question, actually help?), same multi-hop question, top_k=3, max_steps=4, one real run each:

Neither hit the groundtruth panels. In this one run, forcing the fixed query produced a cleaner decline rather than a worse, over reaching answer. One run isn't enough to conclude IRCoT's reformulation hurts in general, and the same config produced different ChatLLM scores across separate runs in this eval pass (5/5 earlier in the single-config sweep above, 2/5 here), which is itself worth flagging: this evaluation has real run-to-run variance from the LLM call, not just from the hyperparameter being changed. Kept IRCoT on by default (it's still the only thing that found the right panel unprompted for the simpler "police officer" case elsewhere in this doc), but this result is a real counterexample to assuming more reformulation always helps, not swept away.

Cost Comparison

Local resources:

Conclusions

What worked:

• Blending image and text embeddings changes outcomes versus either alone, verified by hand.
• The translation bridge makes the system usable without Japanese, fully local, no API key.
• The agent's vision is able to describe image details like "a Glock handgun" the dialogue never mentioned.
• The agent consistently abstained instead of hallucinating a plausible wrong answer.
• The custom ChatLLM scored two different answers a flat 5/5. An independent image judge (Jev) scored the same two 0.54-0.68, and correctly penalized the honest "I don't know" one for low relevancy.

Improvement Opportunities:

• CLIP collapsed very short dialogue into a generic embedding; fixed with a minimum text filter.
• NLLB dropped key words translating stuttering dialogue; fixed with beam search and repetition controls.
• The HF provider occasionally returned malformed output: once a fake empty tool call, twice different repetition loop patterns.
• The LangChain/LangGraph attempt failed outright for this model, a real negative result.
• Muse shows an upgrade with real reasoning quality gain, but is 10x expensive than gemma4.
• Tried HyDE: hit-rate/MRR collapsed from 0.94/0.84 to 0.11/0.11. Generated dialogue was plausible sounding but generic, which hurts on a corpus where most queries are literal terms. Not adopted.
• The agent still misses retrieval the plain baseline nails: a "dog barking outdoors" question the direct search answers correctly in one shot wasn't found by the agent in 3 rounds, a concrete instance of the recall gap below.

Limits:

• scripts/eval.py now has 18 retrieval and 5 agent cases, each with a recorded verification method, but it's still development selected, not a random or exhaustive sample.
• Recall, not precision, is the main failure mode: evidence missing from the index simply can't be found, and even when it's present the agent doesn't always reformulate its way to it.
• Character name translation is unreliable.
• Agent eval has real run-to-run variance: the same question with the same configuration of hyper params produced different ChatLLM judge scores (5/5 vs 2/5) across two separate runs in this eval pass, since each run calls the hosted LLM fresh. Single runs here are illustrative, not statistically stable.

AI-generated content declaration

Built with extensive assistance from Claude as an engineering collaborator: architecture, implementation, debugging failures, and part of this documentation. Design decisions and acceptance of each change were mine; the AI did the hands-on work under that direction, and its claims were verified against real run output.

---

Setup

uv sync
hf auth login

Manga109-s is a gated dataset. Request access on the dataset page first.

Usage

uv run anime-rag ask

License note

Manga109-s is distributed under its own license (non-commercial-friendly but not open), which caps how much of any one book's pages may be published and forbids redistributing the dataset itself. See the dataset page for details.
