phantom-kv

Refusal removal for language models as a loadable KV-cache graft. No weight edits. No refusal-direction projection. Fully reversible. Ship megabytes, not checkpoints — unload the cache and the base model is byte-identical again.

Demos

Pills, hot-swapped mid-session — base refuses, /pill black answers, /pill none restores guardrails. Same session, zero model reload, weights untouched:

▶ full-quality mp4 · raw mp4

Blue pill = DFIR mode — an incident-response prompt refused by base model, answered by /pill blue, refused again by /pill none:

▶ full-quality mp4 · raw mp4

Cyber-selective capability modes — the same SQL-injection prompt refused by both base and /pill blue (defensive-only pill keeps off-domain guardrails on) and answered by /pill red:

▶ full-quality mp4 · raw mp4

Recorded deterministically with VHS (docs/assets/phantom-kv-*.tape, re-record after any change). The numbers behind these scenes are in docs/TECHNIQUE.md §7.5–§7.6 and §6.10–§6.12.

The technique

Existing refusal-removal methods both build on the "refusal is a 1-D direction" insight (Arditi et al. 2024): either edit that direction out of the weights (abliteration, e.g. heretic), or project it out of activations at runtime (weightless / GLP, h ← h − α·(h·d̂)d̂ inside a vLLM hotfix).

phantom-kv uses neither. Its premise:

A KV cache is context. You cannot cache a subtraction — but you can cache learned context that out-signals refusal circuits through ordinary attention.

A phantom graft is a small bank of per-layer key/value tensors, trained against abliteration's own dual objective — suppress refusal on harmful prompts while minimizing KL divergence from the base model on harmless ones — and spliced into the cache at serving time at invariant positions 0..N. From the model's vantage it is indistinguishable from conversation history that is already there: a phantom context. Attention reads it; nothing is ever projected out of any activation.

  TRAIN (offline, per model)                     SERVE (any engine with a KV cache)
  ───────────────────────────                    ────────────────────────────────
  frozen base model ⊕ learnable K/V bank         boot: load graft.bin → reserved
        │                                            cache blocks (validate sha)
        ▼                                            │
  loss = CE(comply | harmful)                        ▼
       + λ·KL(base ‖ graft | harmless)   →   request: attend over [graft K/V] ⊕
        │                                          prompt K/V  — read-only,
        ▼                                          per-request swappable
  phantom.bin (safetensors, ~MBs)

How it differs from existing tools

All three tools remove refusal. They differ in where the intervention lives — and that choice decides everything else: permanence, runtime cost, per-architecture work, and what can go wrong.

heretic — surgery in weight space

Heretic computes a per-layer "refusal direction" (difference-of-means between harmful and harmless prompt residuals) and orthogonalizes weight matrices — attention out-projections and MLP down-projections — so that direction can no longer be written into the residual stream. It ships a modified checkpoint.

Consequences, by construction:

• Permanent. Reverting means re-flashing the original weights; the capability trade-off is baked into the checkpoint forever.
• Quantization-bound. The edit is made against one weight file — quantize afterwards, or switch quants, and the work must be redone.
• Architecture-aware. It must identify which matrices express the direction for each model family; its own support matrix varies (dense, some MoE, some hybrid — pure state-space models unsupported).

weightless / GLP — surgery in activation space

GLP keeps weights intact and moves the same direction to runtime: a boot-time vLLM hotfix subtracts α·(h·d̂)d̂ from hidden states at a chosen write site, on every layer, on every token, of every forward pass.

Consequences, by construction:

• Per-architecture hook-site mapping. The correct subtraction point must be found per model family — their own public field notes document shipping a mislabeled site on DSV4 (the "post-layer residual" anchor was actually the pending FFN write, before a hyper-connection fold).
• A runtime patch that must fail closed. If the boot-time hook can't apply, the endpoint must refuse to serve — the patch is part of the serving critical path.
• Engine-bound. vLLM hotfix, or their GGUF/GLP format extension for llama.cpp; MoE explicitly requires the GGUF extension. Each engine is separate integration work.

phantom-kv — context space: nothing is subtracted anywhere

phantom-kv never locates a refusal direction and never removes anything from weights or activations. A trained bank of keys/values sits in the cache as phantom context, and the model's own attention does the steering — the same mechanism it uses for any instruction in any prompt. The forward pass is never intercepted; the signal path is never altered; the only influence channel is the input channel the model was built to consume.

What this buys

• No damage pathway through the math. Orthogonalization and projection force a change on every token's hidden states, whether or not it helps — the KL cost is paid on all traffic. A graft's influence is attention-gated: the model itself decides how strongly to weight it, per head, per token. (We still measure KL on every run — additive context is not free, it just fails softer.)
• No 1-D assumption. Both baselines inherit the premise that refusal is one removable direction. Where refusal is distributed across circuits, a graft doesn't care — it is optimized end-to-end against observed behavior, not against a geometric model of how refusal is implemented.
• No per-token hook, nothing to fail closed. Runtime cost is attention over N extra cache slots — indistinguishable from a slightly longer prompt.
• Dose as artifacts, not a runtime α. Strength variants are separate trained grafts, hot-swappable per request.

Why model-agnostic

Both baselines must understand the body they operate on: heretic maps refusal-expressing matrices per architecture; GLP maps a correct runtime hook site per architecture (and got one publicly wrong). The graft interacts with neither — it lives in the KV cache, the one interface every attention-based architecture exposes with the same shape: per-layer K and V tensors. Training needs gradients with respect to cache tensors on a frozen model; nothing about layers, experts, hyper-connections, or state-space blocks is ever read, identified, or assumed. Dense, MoE, or hybrid — if the model attends over past K/V, the same container format and the same splice apply. There is nothing to port.

Two scopes to keep separate: the toolchain is universal (same training + eval code for any causal LM on Hugging Face), but each trained graft is bound to one exact model revision — K/V values are produced by that model's own weights, so a graft built for one model is meaningless for another, and the loader enforces the model-id match. Supporting a new model = retraining, which is automated and takes about an hour on a laptop. Serving a different quantization than you trained on: validate per quant lane (steering signals empirically survive quantization drift, but it's measured, not assumed).

Honest caveat: deployed so far on Qwen3 (dense). Cross-architecture and cross-quantization confirmation is roadmap item 5, and we publish whatever we find.

Why inference-engine-agnostic

GLP ships as an engine patch (vLLM hotfix, or a GGUF extension for llama.cpp). The graft ships as data — tensors in a documented container — and every engine already has a delivery path for cache data:

• vLLM — prefix-caching / KV-connector seam, no forward-pass hooks;
• HF transformers — first-class past_key_values (what this repo uses);
• llama.cpp — prompt-cache session files;
• any engine that can only build cache from tokens — a hard-token distilled variant degrades gracefully to a prefixed prompt.

Worst case is a prompt; best case is a load-once cache block. Never an engine fork, never a boot patch, never a site map.

Summary

Results so far

Scoreboard: Qwen3-4B-Instruct-2507, hardened 60-prompt harmful suite, 20-prompt harmless suite, greedy decoding, teacher-forced KL against the base model's own completions. Full methodology: docs/TECHNIQUE.md.

Deliverable arm: v3 (artifacts/grafts/v3.bin) — same 5/60 refusals as the margin-2.5 operating point, with KL mean 0.015 / max 0.059: ~3× better preservation, best recorded in this project, zero degeneration, zero regressions. The 5/60 floor holds across every single-graft parameterization (margin sweep, embeddings arm, direct K/V alike) — but §6.11 refines this: the floor is dose-soft, not objective-hard — doubling the phantom bank (two copies of the same graft) flips all five residual refusals at depth 0 and keeps 4/5 of them after 4k tokens of filler; the remaining attack is dose scaling plus hard-core CE targets, not a data-only problem. v2.x frontier sweep and bistability analysis: docs/TECHNIQUE.md §6.6; v3 method §6.7; refresh/dose result §6.11.

Robustness, measured:

• Off-suite transfer (§6.8): on 60 held-out harmful prompts disjoint in subject from training, base 5/60 → v3 2/60 refusals, same zero-degeneration, 0/20 harmless — refusal suppression generalizes. The on-suite KL floor (0.015) was partly memorization: holdout KL is 0.404 mean / 0.834 max (the graft preserved the evaluated completions, not benign distributions per se).
• Persistence (§6.9, §6.11): 15 probes × 5 context depths under benign filler — the graft fades gracefully, half-life ≈ 2-4k tokens; at 16k tokens ~5/6 of compliant flips have reverted, no corruption anywhere (0/20 harmless, 0 stutters). The fix is measured too: re-injecting the graft behind the filler keeps 4/5 of hard refusals flipped through ~4k but none by 16k — long sessions need a refresh cadence ≲ 4k tokens (periodic re-injection or phantom.lib slot ladders; both live in the eval + serving adapters).

Reading of v1 (the control arm): free text buys the easy 40% of refusals with zero regressions — 10 flips to genuine compliance, 15 stubborn refusals remain, at KL ~0.37. The learned arms must capture the remaining headroom at lower KL to justify themselves over a cached jailbreak prompt. That is exactly the calibration v1 exists to provide.

Mechanics, verified: save→load round-trip bitwise equal, round-trip logit diff 0.000e+00, harmless completions coherent under graft, refusal classifier + graft-format self-test 17/17.

Multi-model graft libraries (phantom.lib)

One file, one trained graft per model inside it. Package every model you serve into a single tamper-checked artifact; the resolver picks the right bank — or refuses (fail-closed; a wrong-model splice never happens silently):

phantom-graft library add --lib phantom.lib --graft grafts/llama.bin        # alias = its model_id
phantom-graft library add --lib phantom.lib --graft grafts/kimi.bin
phantom-graft library add --lib phantom.lib --graft grafts/qwen.bin --alias qwen:dose-strong
phantom-graft library list --lib phantom.lib
phantom-eval --model Kimi/K2 --graft phantom.lib                            # auto-resolves single match
phantom-eval --model Qwen/Qwen3-4B-Instruct-2507 --graft phantom.lib --graft-alias qwen:dose-strong

Resolution rules are fail-closed: unknown/missing alias or a model-id mismatch → hard error naming the alternatives, before any inference runs. Per-entry sha256 is re-verified on every load. Dose ladders ship as sibling aliases of the same model (hot-swappable per request in serving stacks, zero model reload).

Pills: guardrailed model, selectable modes (red / blue / black)

The flagship deployment story of cache-space grafting. Ship one model with guardrails ON, and hand operators per-session capability modes as cache content:

• no pill — the shipped model, guardrails fully on.
• black pill — remove all refusals (global; the v3 arm).
• red pill — suppress refusal only on cyber-offensive work (exploitation, evasion, credential access, lateral movement, C2…).
• blue pill — suppress refusal only on cyber-defensive work (forensics, detection, IR, reverse engineering…).
• redlite pill — preservation-tilted red variant (dose A/B at the §7.5 dose ratio; leakage profile within jitter of red).
• red2 pill — donor-CE targets (strongest on-domain suppression in repo, −91.8%), not selective — leakage grows with strength (§7.6).

Because the pill is cache content — never weights — all modes share one tensor shape and trading them mid-session, without restarting inference, is swapping 129 cache slots. Weight-space "uncensoring" (heretic/ablit) bakes one global state into the checkpoint; a guardrailed and capable model with per-session modes is only expressible in cache space.

Pills are trained with a domain-selective objective: suppression on the pill's domain, KL-anchored to the base model's refusals on every other domain (kitchen-sink control suites included), warm-started from the v3 direct-KV bank:

phantom-chat --model Qwen/Qwen3-4B-Instruct-2507 --graft artifacts/grafts/phantom.lib
phantom> /pill red       # offensive mode: same session, no restart
phantom> /pill none      # guardrails back on
phantom> /pill black     # global refusal removal
phantom> /pill red2      # donor-CE — strongest on-domain
phantom> /pill           # list aliases + active pill (black, red, blue, redlite, red2)

Correctness is enforced by the pill matrix (phantom-eval --matrix run_*.json): a pill must score ≈0 refusals on its own domain and == base on every other harmful domain — any off-domain drop is measured leakage, not a bonus. Suites cyber_offensive / cyber_defensive are in data/suites/; build/train/compile/score commands for the whole matrix are in docs/TECHNIQUE.md §7/§10.

First full matrix (2026-09-19, Qwen3-4B-Instruct-2507): blue zeroes its own domain (4→0 refusals on cyber-defensive) while holding cyber-offensive and the general harmful battery at base level — a working selective pill; red is the strongest suppressor in the repo (offensive 61→17 = −72%) but aggressive enough to leak into other domains; black (= v3) lands between. The selective lever is the suppression/preservation dose ratio, not architecture — numbers and reading in docs/TECHNIQUE.md §7.5. Status: research preview; the 4B phantom.lib ships black (= v3), red, blue, redlite, and red2 (§7.5–§7.6).

Second-generation red (red2, donor-CE targets, 2026-09-21): on-domain suppression 61→5 refusals (−91.8%, best in repo) — but leakage grows with strength (general battery −54%), so donor CE buys suppression, not selectivity; routing / hard-negative ce are the named next levers (docs/TECHNIQUE.md §7.6). Alias red2 ships in the 4B phantom.lib.

Honest limits

Refusal behavior lives in the weights, so any kept-weights method fights the model at inference with additive context. Headline caveats you should weigh alongside every number in this README, all measured rather than waived:

• Classifier recall: the lexical classifier only counts canned refusal phrasing — the judge audit (§6.10.1, Qwen/Qwen3-8B) reads semantic refusals on ~59-61/81 of every pill arm on cyber_offensive, while the classifier reported anywhere from 5 to 61 depending on arm (disagreement ledger −16…−71 rows). Every "suppression %" or refusal rate here is a recall floor, and it needs adjudication before being quoted as true compliance.
• Persistence (~2–4k token half-life): the graft fades gracefully under accumulated context (no corruption, returns toward base). Measured mitigation: re-injection keeps the doubled dose live through ~4k but not through ~16k — refresh cadence must be ≲ 4k tokens (phantom-eval --persistence --refresh shows it directly; §6.11).
• KL memorization: the on-suite KL floor partly reflects memorization of the eval itself — holdout KL is 0.404 mean vs on-suite 0.015 (§6.8).
• Capability costs: multi-step arithmetic pacing shifts under the graft — GSM8K final-answer rate 45/75 → 27/75 for v3 at a 256-token budget, while MMLU is bit-identical across arms (§6.10).
• Scope: refusal numbers are one architecture family (Qwen3 dense, Apple MPS/bf16). Cross-architecture grafting additionally requires a prefix/suffix-splittable chat template — GLM's recursive template is currently rejected by phantom-graft (§6.12); the eval machinery itself ports (GLM baseline 20/60, §6.12).

Repo layout

data/suites/                 prompt suites (harmful, harmless, ext scale-ups, holdouts,
                             cyber red/blue, K3 general-harmful battery, GSM8K/MMLU
                             capability spot-check subsets)
data/grafts/v1_prefill.json  v1 graft source (hand-crafted prefill)
src/phantom_kv/
  model.py                   device/dtype policy loader (MPS, bf16)
  eval/refusal.py            lexical refusal classifier (--self-test)
  eval/metrics.py            teacher-forced KL (float32, completion-masked)
  eval/runner.py             scoreboard orchestration, reports
  eval/persistence.py        dilution/persistence probe (--persistence, --refresh)
  eval/pillmatrix.py         pill matrix combiner (--matrix)
  eval/capability.py         GSM8K/MMLU capability spot checks (--capability)
  eval/judge.py              judge-model quality audit of run reports (--judge)
  graft/format.py            phantom.bin container + validation
  graft/library.py           phantom.lib multi-payload library (aliases, tamper checks)
  graft/build.py             chat-template-derived prefill shaping, cache extraction
  graft/cli.py               phantom-graft build-prefill/library --verify
  train/                     learned-graft pipeline (targets/train/compile, v2+v3+pill arms)
  train/pilltargets.py       domain-selective pill target builder (build-pill-targets)
  train/donors.py            donor-CE harvesting: prefix-forced stack + judge gate
  serve/session.py           phantom-serve: load-once graft blocks, hot-swap, re-injection
  chat.py                    phantom-chat: interactive base-vs-graft demo with /pill hot-swap
  banner.py                  ASCII launch banner
docs/TECHNIQUE.md            technique + experimentation record (§7 = pill program)
artifacts/                   (gitignored) grafts, libraries, eval reports

Quickstart

uv venv --python 3.12 .venv
uv pip install --python .venv/bin/python -e .

# scoreboard sanity (no model needed)
.venv/bin/phantom-eval --self-test

# baseline eval (scoreboard model)
.venv/bin/phantom-eval --model Qwen/Qwen3-4B-Instruct-2507 \
  --harmful data/suites/harmful_seed.jsonl \
  --harmless data/suites/harmless_seed.jsonl

# build + verify the v1 prefill graft, then eval with it spliced in
.venv/bin/phantom-graft build-prefill --model Qwen/Qwen3-4B-Instruct-2507 \
  --source data/grafts/v1_prefill.json --out artifacts/grafts/v1.bin --verify
.venv/bin/phantom-eval --model Qwen/Qwen3-4B-Instruct-2507 \
  --harmful data/suites/harmful_seed.jsonl \
  --harmless data/suites/harmless_seed.jsonl \
  --graft artifacts/grafts/v1.bin

Reports land in artifacts/eval/run_<utc-ts>.{json,md} with suite sha256 and environment provenance. Greedy decoding makes every run deterministic and directly comparable.

Quality gates and serving:

# capability spot checks (GSM8K/MMLU subsets); --graft compares arms
.venv/bin/phantom-eval --model Qwen/Qwen3-4B-Instruct-2507 \
  --capability data/suites/capability_gsm8k.jsonl data/suites/capability_mmlu.jsonl \
  --graft artifacts/grafts/phantom.lib --graft-alias black

# judge-model audit of any run report (disagreements vs lexical classifier)
.venv/bin/phantom-eval --judge artifacts/eval/<run>.json --judge-model Qwen/Qwen3-8B

# persistence probe incl. re-injection (refresh) arm
.venv/bin/phantom-eval --model Qwen/Qwen3-4B-Instruct-2507 \
  --graft artifacts/grafts/v3.bin --persistence --refresh

# HF reference serving adapter (load-once blocks, per-request hot-swap)
.venv/bin/phantom-serve --model Qwen/Qwen3-4B-Instruct-2507 \
  --lib artifacts/grafts/phantom.lib --demo

Roadmap

1. (done) Eval harness: refusal-rate + teacher-forced KL; hardened 60-prompt harmful suite; Qwen3-4B discriminating baseline (25/60, KL exact 0).
2. (done) phantom.bin container, graft splice path, v1 prefill-cache arm (15/60, KL 0.367/0.604).
3. (done) v2 — learned soft-prompt graft, warm-started at v1: 25/60 → 3/60, 0 regressions, KL 0.452/2.678; suppression-attractor caveat and quality audit documented (§6.4). v2.1: suppression-dose cap, per-prompt KL reporting, judge-model quality pass.
4. (done) v3 — learned direct K/V graft with norm regularization (warm-start anchored to v2.2): same 5/60 refusals, KL mean 0.015 (-2.8× vs v2.2), zero degeneration — and the key finding that the 5/60 floor is parameterization-independent (objective-bound, not capacity-bound).
5. (done — research preview) Pill program: domain-selective grafts shipped (black/red/blue/redlite/red2 in phantom.lib), per-session hot-swap in phantom-chat (pills auto-enable side-by-side), selective training recipes and leakage matrices (docs/TECHNIQUE.md §7; first matrix §7.5, donor-CE red2 sweep §7.6). Remaining named levers for a strong-and-selective red pill: routing, hard-negative ce, per-prompt hinges.
6. (done) Capability spot checks (--capability, GSM8K/MMLU subsets, §6.10): MMLU 54/100 = 54/100 across arms; GSM8K 45/75 → 27/75 under v3; suite expansion (harmful_ext/harmless_ext, +120 eval-only prompts); judge-model audit (--judge, §6.10.1: lexical-vs-judge disagreement −16/−39/−59/−71 rows — suppression numbers are recall floors until adjudication); persistence refresh implemented+measured (§6.11: the 5/60 floor is dose-soft, refresh cadence ≲ 4k tokens); suite-expansion as named; serving adapters: HF reference adapter shipped+exercised (phantom-serve, §11). vLLM prefix seam and llama.cpp prompt cache remain documented integration designs, descoped pending an engine host (no CUDA backend exists here; llama.cpp cache formats differ post-RoPE).

References

• Arditi et al. 2024 — Refusal in Language Models Is Mediated by a Single Direction
• Weidmann 2025 — heretic (weight-space abliteration with TPE-optimized dose)
• Suiche 2026 — weightless / GLP (repo; inference-time projection via GGUF Layer Projection)
• Lester et al. 2021 — The Power of Scale for Parameter-Efficient Prompt Tuning (soft prompts; unrelated objective)
• Zhou et al. 2025 — Don't Say No; RAID (jailbreak-side prior art)

FAQ

Why not just abliterate? Abliteration (heretic) currently achieves lower residual refusals — and it edits weights: you ship a new checkpoint, redo it per quantization, and the change is permanent. phantom-kv targets the cases where base weights must stay byte-identical and intervention must be reversible per request.

Is v1 the product? No — v1 is the control arm: the strongest hand-written prefill, cached. It exists to quantify what free text buys (40% of refusals at KL 0.37) so the learned arms (v2/v3) can be judged fairly.

Does it work on quantized or MoE models? Nothing in the mechanism depends on weight format or architecture (no hook site, no weight math): the graft is trained against the exact served model and attends like ordinary context. That's the claim; cross-architecture measurement is on the roadmap — watch docs/TECHNIQUE.md.

License

MIT.
