PHP GPU Tensors

GPU tensors, runtime-compiled CUDA kernels and fused tensor expressions for PHP.
No Python runtime required.

Native PHP extension for GPU tensors and NVIDIA CUDA-accelerated numerical workloads. Build tensor operations and machine-learning data pipelines in PHP, move data explicitly between host and GPU, and compile custom CUDA C++ kernels at runtime with NVRTC. Optionally fuse tensor expressions into compiled plans that replay quickly, with asynchronous execution and CUDA Graph for compatible plans.

Status: beta (0.1.0-beta.4) · Linux · PHP 8.1–8.5, NTS and ZTS · NVIDIA GPU required. See Validation status for exactly what has been tested on real GPUs.

Highlights

• GPU tensors. CudaArray supports arithmetic, broadcasting, comparisons, matmul() (including batches), reductions, views and Python-style slice().
• Explicit data movement. Packed buffers, .npy import and optional pinned host memory keep transfers cheap and visible.
• Custom CUDA kernels. Compile CUDA C++ at runtime with NVRTC and launch it from PHP, synchronously or asynchronously.
• Optional kernel fusion. Capture a PHP closure once, then replay it as fused GPU kernels. In a small training workload this was about 6× faster than eager execution with identical results (see Results).
• Clear scope. A low-level GPU computing library, not a machine-learning framework: no automatic differentiation, no CPU fallback.

Contents: Quick look · Results · Install · Tensors · Slicing · Data pipelines · Custom kernels · Fusion · Streams and CUDA Graph · Training example · API and limits · Validation status · Contribute

Quick look

use Cuda\CudaArray;
use Cuda\Fusion;

$a = CudaArray::ones([4]);
$b = CudaArray::full([4], 2.0);
$c = CudaArray::full([4], 3.0);

// Eager execution (default): one GPU operation per call.
$eager = $a + $b * $c;

// Fusion (opt-in): capture once, replay as fused GPU kernels.
$plan = Fusion::compile(fn($a, $b, $c) => $a + $b * $c, inputs: [$a, $b, $c]);
$fused = $plan->run($a, $b, $c);

print_r($fused->toArray()); // [7, 7, 7, 7]

Try a full training run on the GPU, written entirely in PHP:

php -n -d extension=./cuda_build-8.3/modules/cuda.so examples/08_gpu_classifier.php \
  --epochs=200 --batch-size=256 --learning-rate=0.05 --no-save

Results

Measured on PHP 8.3 NTS with an NVIDIA GeForce MX570 A (4 GB, compute capability 8.6), driver 12.6 and CUDA runtime 12.3. The models are small, so these numbers mostly show how much per-step overhead Fusion removes; they are not peak GPU throughput and not a general-purpose GPU benchmark.

Fusion vs. eager execution on the same model and data, with identical metrics (accuracy 77.29%, ROC AUC 0.853, same confusion matrix in both modes):

Workload: a small MLP (hidden size 256) on 32,768 training and 4,096 test patches of PatchCamelyon (CC0), using 480 handcrafted features per patch (RGB mean/std over an 8×8 grid and its central 4×4), batch size 512, 20 epochs, learning rate 0.02. This is a performance demonstration, not a clinical model. The planner turned the 68 captured nodes of the training step into 11 fused kernels plus 9 native boundaries (matmul and reductions).

End-to-end training example (examples/08_gpu_classifier.php, a complete Multi-Layer Perceptron (MLP) for MNIST, Fashion-MNIST, or custom CSVs. It processes hundreds of thousands of samples per second using fused CUDA kernels, showcasing tensor operations, JIT compilation, math optimization (AdamW/SGD), and pure PHP data orchestration.

Full benchmark reports live in the benchmarks repository.

Install

Requirements

Building requires the toolkit; running requires the host driver.

From source

git clone https://github.com/lcmialichi/php-gpu-tensors.git
cd php-gpu-tensors
./compile.sh
./run-tests.sh --require-gpu
php -n -d extension=./cuda_build-8.3/modules/cuda.so examples/01_basics_cuda_array.php

The build stays in cuda_build-<PHP major.minor>/modules/cuda.so; replace 8.3 above with the PHP version used by php-config. To install the extension and its INI configuration instead, run ./compile.sh --install with permission to write to your PHP extension/INI directories. To choose another PHP ABI:

PHP_BIN=php8.3 PHPIZE=phpize8.3 PHP_CONFIG=php-config8.3 ./compile.sh
PHP_BIN=php8.3 PHP_CONFIG=php-config8.3 ./run-tests.sh --require-gpu

Build options:

• CUDA_HOME if the toolkit is not at /usr/local/cuda.
• CUDA_ARCH=sm_86 when cross-building.
• CUDA_USE_CUBLAS=no ./compile.sh to use the extension's built-in CUDA matrix kernels instead of cuBLAS (cuBLAS is used when available for compatible larger matrix products).

With PIE 🥧

The extension is published as lcmialichi/php-gpu-tensors.

pie install lcmialichi/php-gpu-tensors:0.1.0-beta.4

Use 0.1.0-beta.4 or newer for the Fusion APIs and the training example described here; older releases may not include them. PIE builds the native extension for the selected PHP installation; it does not install an NVIDIA driver or CUDA Toolkit. Those must already be available on the system, and GPU execution additionally requires a compatible NVIDIA driver and a visible GPU.

With Docker

Users with the NVIDIA Container Toolkit and a working host driver can build and test in the development image:

docker compose run --rm php_cuda_dev bash -lc './compile.sh && ./run-tests.sh --require-gpu'

Running the tests

./run-tests.sh runs CPU-side C tests and the PHP test suite. Use --cpu-only to run only the host-side C tests in build environments without a GPU; this does not validate CUDA execution. --require-gpu fails immediately when no GPU is visible, instead of treating skipped GPU tests as success.

GPU Tensors in PHP

use Cuda\CudaArray;

$input = new CudaArray([[1, 2], [3, 4]], 'float32');
$weights = CudaArray::ones([2, 2]);
$output = $input->add($weights)->multiply(2);
$column_means = $input->mean(0);

print_r($output->toArray()); // [[4, 6], [8, 10]]
echo $output->dtype();       // float32

CudaArray holds GPU storage; operations return GPU tensors. toArray() transfers to the CPU and expands all values into PHP arrays. Operations include arithmetic, broadcasting, comparisons, matmul() (including batches), shape views, and sum(), mean(), min(), max(), prod(), argMax(), and argMin() with an optional axis. PHP arithmetic operators also dispatch to tensor methods. mean() reduces all values when called without an axis, or reduces one dimension when given an axis. It returns float32 for float32 input and float64 for float64, integer, and boolean input.

Python-style slicing

CudaArray::slice() accepts a comma-separated expression, or one selector per axis. Ranges have an exclusive stop, omitted bounds default to the axis limits, and negative indices/bounds count from the end. Range bounds are clipped to the axis size; individual indices outside the axis throw InvalidArgumentException.

$batch = $tensor->slice('10:20, :');
$columns = $tensor->slice(':, 2:8:2');
$lastRows = $tensor->slice('-10:');
$row = $tensor->slice(3);       // Removes the first axis.
$oneRow = $tensor->slice('3:4'); // Keeps that axis with size 1.

// Dynamic equivalents: [start, stop] or [start, stop, step].
$batch = $tensor->slice([$start, $stop], null);
$columns = $tensor->slice(null, [2, 8, 2]);

Integers remove axes; null, ':', omitted axes and slice() with no arguments select the full extent. Steps must be positive integers no larger than INT_MAX. Zero/negative steps, ellipsis, new axes, index lists and executable expressions are not supported. Expressions are parsed as integers/ranges, never evaluated as PHP.

Data pipelines for machine learning

Use this extension to build GPU-accelerated numerical steps into PHP applications: tensor arithmetic, matrix multiplication, broadcasting, reductions such as mean(), and custom CUDA kernels. These primitives support machine-learning data preparation, inference and small training loops while the data remains in NVIDIA GPU memory.

This is a low-level GPU computing library, not a complete machine-learning framework. The training example implements backpropagation explicitly; automatic differentiation and Python interoperability are not provided.

For data already in packed row-major bytes, avoid creating individual PHP scalars. fromFile() reads raw bytes, whereas fromNpy() parses NumPy's .npy format:

use Cuda\CudaArray;
use Cuda\HostArray;

$bytes = pack('g*', 1, 2, 3, 4); // little-endian float32
$host = HostArray::fromBuffer($bytes, [2, 2]);
$gpu = $host->toGpu();
$result = CudaArray::where(
    CudaArray::fromBuffer(pack('C*', 1, 0), [2], 'bool'),
    $gpu,
    CudaArray::zeros([2, 2])
);
$cpuCopy = $result->toHost();
$raw = $cpuCopy->toBuffer();

HostArray is an alias of Cuda\ContiguousArray, a contiguous CPU tensor. Pass pinned: true to its constructor or fromBuffer() for page-locked host storage when repeated transfers justify the extra host memory. where() broadcasts its three inputs; its mask treats nonzero values as true, and its two value tensors must have the same dtype. .npy imports support C-order little-endian numeric and boolean arrays; Fortran order and big-endian data are rejected.

Custom kernels

Register the CUDA kernel's argument metadata, compile to PTX, then launch with explicit grid and block dimensions:

use Cuda\Compiler;
use Cuda\CudaArray;

$source = <<<'CUDA'
extern "C" __global__ void scale(float *data, int factor, int count)
{
    int index = blockIdx.x * blockDim.x + threadIdx.x;
    if (index < count) data[index] *= factor;
}
CUDA;

$compiler = new Compiler(source: $source);
$compiler->kernel('scale', [
    ['name' => 'data', 'type' => 'array', 'dtype' => 'float32'],
    ['name' => 'factor', 'dtype' => 'int32'],
    ['name' => 'count', 'dtype' => 'int32'],
]);
$module = $compiler->compile();
$module->initialize();

$data = CudaArray::ones([512]);
$module->launch('scale',
    args: [$data, 3, 512],
    config: ['block' => [256, 1, 1], 'grid' => [2, 1, 1]]
);
print_r(array_slice($data->toArray(), 0, 4)); // [3, 3, 3, 3]

launch() synchronizes; launchAsync() returns an operation ID for sync() or wait(). Keep tensors alive until asynchronous work finishes. See the JIT examples and asynchronous execution.

Optional kernel fusion

Eager execution remains the default. Fusion is explicitly opt-in: existing code keeps using eager execution unless capture is enabled.

flowchart LR
    A[PHP closure] --> B[Capture once<br/>metadata-only placeholders]
    B --> C[Plan]
    C --> D[Fused elementwise kernels<br/>NVRTC to PTX]
    C --> E[Native boundaries<br/>matmul and reductions]
    D --> F[Replay on a private stream]
    E --> F

Fusion::run() captures tensor operations inside a callback and returns materialized CudaArray outputs:

use Cuda\Fusion;

$result = Fusion::run(fn() => $tensorA + $tensorB * $tensorC);
$eager = Fusion::run(fn() => $tensorA + $tensorB * $tensorC, enabled: false);

For repeated execution, compile a specialized plan once:

$graph = Fusion::compile(
    fn($a, $b, $c) => $a + $b * $c,
    inputs: [$tensorA, $tensorB, $tensorC]
);
$result = $graph->run($tensorA, $tensorB, $tensorC);
$other = $graph->run($otherA, $otherB, $otherC);
print_r($graph->getStats());
print_r($graph->getPlan());
echo $graph->getSource();

What to know at a glance:

• Fused: addition, subtraction, multiplication, division, unary operations, comparisons, where(), safe astype() conversions and reshape/transpose/slice index transformations.
• Execution boundaries: reductions, matmul() (currently float32) and powers run on existing kernels; the fused kernels run in dependency order around them.
• Replay: the PHP callback is not invoked again after compilation, and input values and pointers can change between executions.
• Inspection: getStats(), getPlan() and getSource() show what the planner produced; for $a + $b * $c the plan has one fused kernel and no intermediate data buffers.

Streams, asynchronous execution and CUDA Graph

Plans containing generated kernels, matmul and reductions run on a private nonblocking stream. Reduction descriptors are kernel parameters rather than shared global state, so concurrent replays cannot overwrite each other's shapes.

$graph = Fusion::compile(
    fn($a, $b, $c) => ($a + $b * $c)->sqrt(),
    [$tensorA, $tensorB, $tensorC],
    cudaGraph: true
);
$pending = $graph->runAsync($tensorA, $tensorB, $tensorC);
$finished = $pending->isFinished(); // Query without waiting.
$result = $pending->wait();        // Synchronize and retrieve outputs.

cudaGraph: true opts into a CUDA Graph executable for compatible plans. Kernel parameters are updated for new input/output pointers before each launch. getStats()['backend'] is cuda-graph, stream or native.

Check cudaGraphCompatible and cudaGraphIncompatibility to distinguish graph support from asyncCompatible. Power boundaries report the reason in incompatibility and reject runAsync(). CUDA failures are reported rather than hidden behind fallback.

$graph->setProfiling(true); // Enable timing and reset phase totals.
$result = $graph->run($tensorA, $tensorB, $tensorC);
print_r($graph->getStats());
$graph->setProfiling(false); // Disable timing and reset phase totals.

php -n -d extension=./cuda_build-8.3/modules/cuda.so \
  examples/07_fusion_graph.php --benchmark --elements=65536 --iterations=100

Real training with Fusion

examples/08_gpu_classifier.phptrains a deep MLP classifier on real datasets (MNIST, Fashion-MNIST, or CSV) without custom CUDA source or environment switches:

• Parses and normalizes dataset files directly in PHP.
• Packed float32 batches are uploaded once with fromBuffer() and kept on the GPU, including their transpose views.
• Forward pass, numerically stable softmax cross-entropy, backward pass, and optimizer (AdamW or SGD) steps are compiled once per batch shape and replayed with new parameter tensors
• Matmul/reduction boundaries and generated elementwise kernels share a private stream, with minimal synchronization.
• Loss is transferred only on reporting epochs, outputting a colorful CLI report including macro-F1 score and confusion analysis

php -n -d extension=./cuda_build-8.3/modules/cuda.so examples/08_gpu_classifier.php \
  --dataset=mnist --epochs=40 --batch-size=128 --optimizer=adam

Defaults are MNIST, 512-256 hidden layers, 40 epochs, batch size 128, and the AdamW optimizer. Every default run trains from deterministic initial weights. Omit --no-save to save parameters after successful evaluation; --load explicitly evaluates a compatible saved model instead of training. Dataset and model files are saved to the script's origin directory and are ignored by Git. The script reports one-time uploads, compilation, training throughput, and detailed evaluation metrics. Add --profile to print per-plan timing, allocation, scratch, and synchronization counters after training, or --predict-index=Nto showcase inference on a specific sample.

API and limits

The annotated signatures are in class stubs and device function stubs; runnable examples live in examples.

Current limits:

• NVIDIA GPUs only, on Linux. GPU data has no CPU fallback.
• No automatic differentiation; backpropagation is written explicitly.
• astype() supports safe dtype conversions.
• The core API baseline is frozen at 0.1.0, and the current release is beta.
• Matmul/reduction plans support async replay, but not CUDA Graph yet; power boundaries still require synchronous execution.

Validation status

The core API has a frozen 0.1.0 baseline; eager execution remains the default and Fusion is explicitly opt-in. Build and CPU checks do not substitute for GPU runtime validation on each PHP version and thread mode.

Tested on another GPU, PHP version or CUDA version? Reports are very welcome: please open an issue with your PHP version, thread mode, GPU, driver and CUDA versions, and whether ./run-tests.sh --require-gpu passed.

Contribute

Contributions can be code, tests, documentation, runnable examples, or reports from another PHP/CUDA/GPU combination. Browse open issues, report a bug, or propose a feature. Start with the contribution guide; documentation, examples, and host-side tests are possible without an NVIDIA GPU.

For possible directions, see the roadmap. A feature does not need to be listed there to be worth discussing.

Benchmarks

The benchmark suite is maintained in the separate PHP GPU Tensors Benchmarks repository. It includes focused --matmul, --import and --fusion runs, JSON/HTML reports, and a beta.4 full-suite report covering 398 cases on PHP 8.3 NTS and an MX570 A, including Fusion replay and slicing. Earlier results include a published PHP 8.5 NTS vs ZTS comparison, as well as a full-suite benchmark report covering 368 cases across five workload groups with downloadable raw reports.

License

Licensed under the MIT License.
