boxr 📦

A fast, lightweight, production-grade Open Container Initiative (OCI) compliant container engine, image builder, compose orchestrator, and runtime written in Rust.

Note: boxr is currently in Beta. We are actively hardening features, testing parity workloads, and welcoming community contributions and feedback!

Demo

Pull, run, and manage rootless containers — no daemon, no sudo. Recorded with boxr 0.1.43 on Linux.

boxr is designed to be rootless by default and built from scratch with custom implementations:

1. Rootless by Default: User namespaces (CLONE_NEWUSER) with uid_map and gid_map mapping the unprivileged user to container root (UID 0), capability dropping (dropping CAP_SYS_ADMIN, CAP_SYS_RAWIO, etc.), and default seccomp profiles without requiring sudo/root.
2. Copy-on-Write / OverlayFS Driver: Native OverlayFS (lowerdir, upperdir, workdir, merged) with custom fast hardlink CoW trees for instant sub-millisecond container startup and near-zero disk usage.
3. cgroups v2 Resource Controllers: Memory limits (--memory), CPU quota & period (--cpus), and task limits (--pids-limit) managed via the cgroupfs v2 hierarchy.
4. Image Export & Import (save / load): Standard multi-layer Docker/OCI tar archives (boxr save -o image.tar <image> and boxr load -i image.tar).
5. Registry Authentication & Push: boxr login, boxr logout, and boxr push using base64 encoded credentials in ~/.boxr/config.json.
6. Interactive PTY / Terminal: Raw mode terminal guards (-it), window resize (TIOCGWINSZ), and clean terminal state restoration.
7. Volume Management (boxr volume): Local named persistent volumes, host directory bind mounts (-v /host:/container:ro), volume inspection, and lifecycle management.
8. Network Management (boxr network, usernet, & pasta): Bridge networks, IPAM address allocation, embedded pure-Rust user-mode network stack (usernet) with zero external dependencies, native pasta integration, and user-space rootless port forwarding proxy.
9. Dockerfile Builder (boxr build): Multi-step build engine supporting FROM, RUN, COPY, ADD, WORKDIR, ENV, CMD, ENTRYPOINT, EXPOSE, and LABEL.
10. Compose Orchestrator (boxr compose): Parsing docker-compose.yml, topological dependency graph resolution (depends_on), multi-container deployment, teardown, and log streaming.
11. Daemon REST API (boxr daemon): Unix Domain Socket server (boxr.sock) implementing Docker Engine API endpoints (/_ping, /version, /info, /containers, /images, /networks, /volumes).
12. Container Lifecycle: Background detached mode (-d), stop, start, logs, exec, and inspect.

---

Architecture & Comprehensive Documentation

Comprehensive engineering guides, architectural diagrams, and command manuals:

• Architecture & Runtime Internals Guide: Deep dive into the trampoline, storage hierarchy, and multi-platform hypervisor bridge.
• Enterprise Runtimes & Hardening Guide: Privilege dropping, /tmp sticky 1777 permissions, POSIX /dev/shm, PID 1 init, and cgroups v2.
• Rootless Container Isolation: Kernel namespaces, single-threaded trampoline, subordinate ID mapping, and capabilities.
• Container Networking & UserNet Stack: Pure-Rust embedded TAP network stack, pasta integration, and IPAM.
• CLI Command Reference Manual: Exhaustive syntax, flags, and options for all 38+ CLI subcommands.
• Kubernetes Pods & Compose Orchestration: Podman-style pods, play kube, and Docker Compose DAGs.

boxr/
├── src/
│   ├── main.rs                 # CLI entrypoint, unshare, and single-threaded trampolines
│   ├── lib.rs                  # Library crate root and command orchestration
│   ├── cli/                    # Clap CLI arguments, options, and command definitions
│   │   ├── mod.rs              # Top-level Cli and Commands enum
│   │   ├── artifact.rs         # Artifact subcommands (add, extract, inspect, ls, pull, push, rm)
│   │   ├── container.rs        # Container flags (RunArgs, ExecArgs, LogsArgs, PsArgs, Checkpoint)
│   │   ├── image.rs            # Image flags (BuildArgs, ImagesArgs, PullArgs, Save/Load, Diff, Scp)
│   │   ├── kube.rs             # Modern Kubernetes command tree (play, down, generate, apply)
│   │   ├── machine.rs          # Virtual machine commands (inspect, set, os, reset, restart, ssh, cp)
│   │   ├── quadlet.rs          # Quadlet unit file subcommands (ls, install, print, rm)
│   │   ├── secret.rs           # Secret subcommands (create, ls, inspect, rm, exists)
│   │   ├── system.rs           # System flags (DaemonArgs, EventsArgs, ServiceArgs, Pods, Check)
│   │   └── volumes_networks.rs # VolumeSubcommands and NetworkSubcommands
│   ├── artifact/
│   │   └── mod.rs              # Content-addressable OCI artifact store with SHA-256 digests
│   ├── quadlet/
│   │   └── mod.rs              # Podman Quadlet unit file manager (.container, .kube, .volume...)
│   ├── specgen/
│   │   └── mod.rs              # Podman Specgen (SpecGenerator JSON) serializer
│   ├── oci/
│   │   ├── mod.rs              # OCI module definitions
│   │   ├── reference.rs        # Image reference parsing (e.g. library/hello-world:latest)
│   │   ├── distribution.rs     # OCI Distribution Spec / Registry v2 HTTP client & ImageDistribution trait
│   │   ├── image.rs            # OCI Image Spec: manifests, configs, layer unpacker & whiteouts
│   │   └── runtime.rs          # OCI Runtime Spec: config.json bundle generator
│   ├── security/
│   │   └── mod.rs              # Rootless user namespaces, UID/GID maps, capabilities, seccomp
│   ├── cgroups/
│   │   └── mod.rs              # cgroups v2 resource limit controllers & ResourceManager trait
│   ├── storage/
│   │   ├── mod.rs              # Local storage manager (~/.boxr/)
│   │   ├── traits.rs           # ISP storage traits (ContainerReader/Writer, ImageReader/Writer)
│   │   ├── overlay.rs          # OverlayFS & Copy-on-Write storage driver
│   │   ├── image_store.rs      # Local image index & content-addressable layer store
│   │   └── container_store.rs  # Container lifecycle & state tracking
│   ├── auth/
│   │   └── mod.rs              # Credential store, tar archiver (save/load), and registry push
│   ├── terminal/
│   │   └── mod.rs              # Raw terminal PTY guard and window size detection
│   ├── builder/
│   │   ├── mod.rs              # Builder module exports and regression contracts
│   │   ├── parser.rs           # Multi-stage Dockerfile parser & Instruction AST
│   │   ├── executor.rs         # Build stage executor and containerized step runner
│   │   ├── cache.rs            # Content-addressed build cache manager (disk_usage, prune)
│   │   └── dockerignore.rs     # .dockerignore pattern matcher and wildcard resolver
│   ├── compose/
│   │   └── mod.rs              # Compose YAML parser, dependency graph, and orchestrator
│   ├── network/
│   │   ├── mod.rs              # Bridge networks, IPAM, and NetworkReader/Writer traits
│   │   ├── pasta.rs            # Pasta user-mode tap rootless network driver
│   │   ├── usernet/            # Pure-Rust native user-mode L2/L3/L4 network stack
│   │   │   ├── mod.rs          # UserNet exports and TAP packet loop integration
│   │   │   ├── packets.rs      # Ethernet, ARP, IPv4, UDP, and TCP header serializers & checksums
│   │   │   └── engine.rs       # In-memory ARP, ICMP echo, and TCP NAT proxy engine
│   │   └── rootless.rs         # Rootless user-space TCP port forwarder proxy
│   ├── pod/
│   │   ├── mod.rs              # Podman pod lifecycle and namespace sharing (PodReader/Writer)
│   │   └── ops.rs              # Pod cloning and aggregated container logging
│   ├── kube/
│   │   └── mod.rs              # Multi-resource Kubernetes YAML (Pod, Deployment, Service, PVC)
│   ├── health/
│   │   └── mod.rs              # Container healthcheck probes (HealthProbe trait) and restart supervisor
│   ├── stats/
│   │   └── mod.rs              # Real-time resource usage collector (CPU %, RAM, PIDs)
│   ├── events/
│   │   └── mod.rs              # Real-time JSONL lifecycle events recorder (EventSink & EventFilter)
│   ├── system/
│   │   └── mod.rs              # Disk space auditing (df_with_readers) and automated pruning
│   ├── volume/
│   │   ├── mod.rs              # Named volume storage and bind mount resolver (VolumeReader/Writer)
│   │   └── ops.rs              # Volume export, import, reload, rename, and mount operations
│   ├── daemon/
│   │   ├── mod.rs              # Unix domain socket server & router dispatcher
│   │   ├── containers.rs       # Container lifecycle REST endpoints (create, inspect, wait, logs)
│   │   ├── images.rs           # Image management REST endpoints (list, create, tag, inspect)
│   │   ├── system.rs           # Daemon health and system info endpoints (_ping, version, info)
│   │   ├── prune.rs            # Resource cleanup endpoints (containers, images, volumes, networks)
│   │   └── volumes_networks.rs # Volume & network REST CRUD endpoints
│   └── runtime/
│       ├── mod.rs              # Execution runtime traits (ContainerRuntime & ProcessKiller)
│       ├── checkpoint.rs       # Container checkpoint and restore runtime engine
│       ├── traits.rs           # Container runtime engine abstractions
│       ├── kill.rs             # Process termination & signal parsing
│       ├── cp.rs               # Container-to-host and host-to-container copy engine
│       ├── diff.rs             # Container filesystem diff engine
│       ├── top.rs              # Process inspection inside container bundles
│       ├── linux.rs            # Native Linux execution (unshare, pivot_root, mounts)
│       └── darwin.rs           # macOS container execution bridge (Virtualization.framework)
└── tests/
    ├── docker_parity_test.rs   # Upstream Docker and Podman CLI parity tests
    ├── podman_parity_test.rs   # Podman parity tests
    ├── e2e_test.rs             # End-to-end container, network, and compose tests
    ├── enterprise_scenarios_test.rs # Enterprise workload and security isolation tests
    ├── integration_test.rs     # Integration test suite
    ├── issues_47_to_111_test.rs # Regression tests for issues #47 to #111
    ├── issues_113_to_162_test.rs# Regression tests for issues #113 to #162
    ├── issues_163_to_342_test.rs# Regression tests for issues #163 to #342 (180 tests)
    ├── issues_343_to_391_test.rs# Regression tests for issues #343 to #391 (49 tests)
    └── qa_*.rs                 # Edge-case, negative, and breaking test matrices

---

Quick Start

Installation

Homebrew (macOS & Linux)

# Add the official tap (central hub for all formulae)
brew tap kchaitanya863/tap

# Install boxr (installs precompiled binary + bash/zsh/fish completions)
brew install boxr

# (Optional) Run daemon as an always-on background service with autostart on login:
brew services start boxr

Debian / Ubuntu (.deb)

Download and install the native .deb package from the latest release:

# x86_64 / amd64:
curl -fsSLO https://github.com/kchaitanya863/homebrew-tap/releases/latest/download/boxr_0.1.18_amd64.deb
sudo dpkg -i boxr_*_amd64.deb

# ARM64 / aarch64:
curl -fsSLO https://github.com/kchaitanya863/homebrew-tap/releases/latest/download/boxr_0.1.18_arm64.deb
sudo dpkg -i boxr_*_arm64.deb

Fedora / RHEL / CentOS (.rpm / YUM / DNF)

Download and install the native .rpm package from the latest release:

# Install via dnf or rpm:
sudo dnf install https://github.com/kchaitanya863/homebrew-tap/releases/latest/download/boxr-0.1.18-1.x86_64.rpm

# Or via rpm directly:
sudo rpm -ivh boxr-*.rpm

Windows (Chocolatey & Winget)

Install via Chocolatey:

choco install boxr

Or extract the precompiled Windows .zip package from the latest release:

Invoke-WebRequest -Uri https://github.com/kchaitanya863/homebrew-tap/releases/latest/download/boxr-windows-x86_64.zip -OutFile boxr.zip
Expand-Archive boxr.zip -DestinationPath C:\ProgramData\boxr
[Environment]::SetEnvironmentVariable("Path", $env:Path + ";C:\ProgramData\boxr\bin", "Machine")

Automated Shell Installer (curl | sh)

# Build & install boxr binary and completions
./install.sh

# Or install from GitHub:
curl -fsSL https://raw.githubusercontent.com/kchaitanya863/boxr/main/install.sh | sh

(Optional) Docker Drop-in Alias

If you would like existing docker commands to transparently run with boxr, you can choose to configure an alias or wrapper:

• Option A (Recommended wrapper): Install a standalone wrapper binary at ~/.boxr/bin/docker:

  boxr alias --install


• Option B (Shell alias): Add an alias to your shell profile (~/.zshrc, ~/.bashrc, or ~/.config/fish/config.fish):

  # Bash / Zsh
  alias docker="boxr"

  # Fish
  alias docker "boxr"


• Option C (Windows PowerShell): Add an alias in your PowerShell profile:

  Set-Alias -Name docker -Value boxr


If you already have Docker installed side-by-side or prefer explicit names, simply invoke boxr directly without creating any alias.

Manual Build

cargo build --release

The resulting binary will be at target/release/boxr.

---

Command Reference

Containers & Execution

# Run hello-world
./target/release/boxr run hello-world

# Run with resource constraints and rootless mode
./target/release/boxr run --memory 512m --cpus 1.5 --pids-limit 100 --rm alpine /bin/echo "Resource limits enforced"

# Run with Podman-style pasta rootless network namespace isolation
./target/release/boxr run --network pasta -p 8080:80 nginx:latest

# Run with zero-dependency pure-Rust user-mode network stack (usernet)
./target/release/boxr run --network usernet -p 8080:80 nginx:latest

# Run with isolated loopback-only private network namespace
./target/release/boxr run --network none alpine ifconfig

# Run in background with port forwarding, volumes, and auto-cleanup
./target/release/boxr run -d --name web -p 8080:80 -v my-data:/data alpine /bin/sh -c "echo 'ready' > /data/status.txt; sleep 60"

# View logs (with live following, timestamps, and line tailing)
./target/release/boxr logs -f -t -n 50 web

# Send Unix signals to container process (default: SIGKILL)
./target/release/boxr kill -s SIGHUP web
./target/release/boxr kill web

# Execute command inside running container
./target/release/boxr exec web /bin/cat /data/status.txt

# Inspect container metadata
./target/release/boxr inspect web

# Inspect container filesystem diff (Added, Changed, Deleted files)
./target/release/boxr diff web

# View running container processes
./target/release/boxr top web

# Pause and unpause container
./target/release/boxr pause web
./target/release/boxr unpause web

# Rename container
./target/release/boxr rename web production-web

# Wait for container to exit and print exit code
./target/release/boxr wait production-web

# Copy files between host and container
./target/release/boxr cp web:/app/config.json ./local-config.json
./target/release/boxr cp ./updated-config.json web:/app/config.json

# Dynamically update container resource limits without restarting
./target/release/boxr update --memory 1g --cpus 2.0 --pids-limit 200 web

# Attach local terminal streams to running container
./target/release/boxr attach web

# Stop, start, and remove
./target/release/boxr stop production-web
./target/release/boxr start production-web
./target/release/boxr rm production-web

Images, Commit & Registry Auth

# Pull image
./target/release/boxr pull alpine:latest

# Build image from Dockerfile
./target/release/boxr build -t my-app:v1 .

# Commit container changes into a new image
./target/release/boxr commit -m "added custom configs" my-container new-app:v1

# Save image to tar archive
./target/release/boxr save -o my-app.tar my-app:v1

# Load image from tar archive
./target/release/boxr load -i my-app.tar

# Log in to registry
./target/release/boxr login -u myuser -p mysecret

# Push image
./target/release/boxr push my-app:v1

# Log out
./target/release/boxr logout

Volumes

# Create named volume
./target/release/boxr volume create app-db

# List volumes
./target/release/boxr volume ls

# Inspect volume
./target/release/boxr volume inspect app-db

# Remove volume
./target/release/boxr volume rm app-db

Networks

# Create custom bridge network
./target/release/boxr network create my-net --subnet 172.30.0.0/16

# List networks
./target/release/boxr network ls

# Inspect network and attached endpoints
./target/release/boxr network inspect my-net

# Connect container to network
./target/release/boxr network connect my-net my-container

# Remove network
./target/release/boxr network rm my-net

Compose

# Start multi-container application
./target/release/boxr compose -f docker-compose.yml up -d

# Check service status
./target/release/boxr compose ps

# Stream logs
./target/release/boxr compose logs

# Stop and remove containers and networks
./target/release/boxr compose down

Podman Pods & Kubernetes Workloads

# Create a multi-container pod sharing network/IPC
./target/release/boxr pod create --name web-pod -p 8080:80

# List pods
./target/release/boxr pod ps

# Inspect pod configuration
./target/release/boxr pod inspect web-pod

# Play a Kubernetes Pod YAML directly
./target/release/boxr play kube pod.yaml

# Generate a Kubernetes Pod YAML from an existing container or pod
./target/release/boxr generate kube my-container

# Run a command inside a new user namespace
./target/release/boxr unshare whoami

# Remove pod and member containers
./target/release/boxr pod rm web-pod

Daemon REST API & Background Service

# Start daemon listening on Unix domain socket (or TCP on Windows)
./target/release/boxr daemon --socket ~/.boxr/boxr.sock

# Query Docker Engine API
curl --unix-socket ~/.boxr/boxr.sock http://localhost/_ping
curl --unix-socket ~/.boxr/boxr.sock http://localhost/version
curl --unix-socket ~/.boxr/boxr.sock http://localhost/containers/json

# Manage as an always-on background service with autostart on login:
boxr service install
boxr service start
boxr service status
boxr service stop
boxr service uninstall

Stats & Events Monitoring

# Display live streaming container resource stats (CPU, Memory, PIDs)
./target/release/boxr stats

# Snapshot stats without streaming
./target/release/boxr stats --no-stream

# Stream real-time container lifecycle events (create, start, die, stop)
./target/release/boxr events

System & Disk Usage

# Show disk space used by containers, images, volumes, and build cache
./target/release/boxr system df

# Reclaim space by removing stopped containers, unused networks, and build cache
./target/release/boxr system prune

# Comprehensive prune (including all unused images and volumes)
./target/release/boxr system prune --all --volumes

Shell Completions & Docker Drop-in Alias

# Generate shell autocompletion script (bash, zsh, fish)
./target/release/boxr completion zsh > ~/.zfunc/_boxr
./target/release/boxr completion bash > /etc/bash_completion.d/boxr

# Generate shell alias command
./target/release/boxr alias

# Install Docker drop-in wrapper script in ~/.boxr/bin/docker
./target/release/boxr alias --install

---

Performance Benchmarks vs Docker

Run the automated benchmark suite:

./benchmark.sh

Benchmark Results (Apple Silicon arm64)

---

Testing

Run the full automated test suite (66 unit, integration, and E2E tests):

cargo test

Test Coverage Highlights

• OCI Image References: Positive canonical specs, custom registries/ports, tags with symbols, sha256 digest pins, and negative/malformed inputs.
• Dockerfile & Multi-Stage: Named stages (AS builder), multi-stage artifact extraction (COPY --from=), .dockerignore negation (!exception) and globbing, line continuations, and malformed instruction detection.
• Compose Orchestrator: Multi-service dependency graphs, circular dependency detection (A -> B -> A, A -> B -> C -> A), and undefined dependency validation.
• Volumes & Networking: Host bind mounts, read-only modes, collision rejection, default boxr0 bridge deletion protection, IPAM sequence allocation, and invalid port boundary checks.
• Security & Cgroups: Custom Base64 roundtrip fuzzing across all byte lengths, default seccomp critical syscall blocking, cgroups memory unit multipliers, and Unix signal matrix.
• E2E & Real Workloads: Non-existent container error handling, invalid CLI flags, live Redis server with exec ping/set/get, and full-stack compose apps.

Contributing

Contributions are welcome! Please see CONTRIBUTING.md for architectural invariants, coding conventions, development setup, and pull request guidelines.

License

This project is licensed under the MIT License.
