Nomic Embed Multimodal for FiftyOne

Nomic Embed Multimodal is a family of vision-language models built on Qwen2.5-VL that generates high-dimensional embeddings for both images and text in a shared vector space. These models provide state-of-the-art performance for visual document understanding with efficient single-vector representations.

Available Models:

• 7B Model: nomic-ai/nomic-embed-multimodal-7b (7 billion parameters)
• 3B Model: nomic-ai/nomic-embed-multimodal-3b (3 billion parameters)

Both models produce 3584-dimensional embeddings, offering a sweet spot between model size and embedding quality for document retrieval tasks.

Installation

Note: This model requires transformers<5.0. Install in this order to avoid version conflicts:

pip install fiftyone colpali-engine torch pillow peft "transformers<5.0"

Architecture

Single-Vector Design

Nomic Embed Multimodal uses a single-vector architecture where each input (image or text) is compressed into a single high-dimensional embedding:

# Image or Text → Processor → Model → (3584,) embedding

Benefits:

• ✅ Fast retrieval: Single vector per item, efficient for large-scale search
• ✅ High quality: 3584 dimensions capture rich semantic information
• ✅ Simple: No multi-vector complexity or pooling strategies
• ✅ Normalized: Ready for cosine similarity out of the box

Model Sizes

Choose the model that fits your compute and quality requirements:

Both models use the same 3584-dimensional embedding space, so you can switch between them without recomputing your entire dataset.

How It Works

Retrieval Pipeline:

dataset.compute_embeddings(model, embeddings_field="embeddings")
└─> embed_images()
    └─> processor.process_images(imgs)
        └─> model(**inputs)
            └─> Returns (batch, 3584) normalized embeddings
                └─> Stores in FiftyOne for cosine similarity search

Classification Pipeline:

dataset.apply_model(model, label_field="predictions")
└─> _predict_all()
    └─> Get image embeddings (batch, 3584)
    └─> Get text embeddings for classes (num_classes, 3584)
    └─> processor.score() → Cosine similarity
        └─> Returns classification logits
            └─> Output processor → Classification labels

Note: This model requires the colpali-engine package which provides the BiQwen2_5 implementation.

Quick Start

Load Dataset

import fiftyone as fo
from fiftyone.utils.huggingface import load_from_hub

# Load document dataset from Hugging Face
dataset = load_from_hub(
    "Voxel51/document-haystack-10pages",
    overwrite=True,
    max_samples=250  # Optional: subset for testing
)

Register the Zoo Model

import fiftyone.zoo as foz

# Register this repository as a remote zoo model source
foz.register_zoo_model_source(
    "https://github.com/harpreetsahota204/nomic-embed-multimodal",
    overwrite=True
)

Basic Workflow

import fiftyone.zoo as foz
import fiftyone.brain as fob

# Load Nomic Embed model (7B by default)
model = foz.load_zoo_model("nomic-ai/nomic-embed-multimodal-7b")

# Or use the 3B model for faster inference
# model = foz.load_zoo_model("nomic-ai/nomic-embed-multimodal-3b")

# Compute embeddings for all documents
dataset.compute_embeddings(
    model=model,
    embeddings_field="nomic_embeddings"
)

# Check embedding dimensions
print(dataset.first()['nomic_embeddings'].shape)  # (3584,)

# Build similarity index
text_img_index = fob.compute_similarity(
    dataset,
    model="nomic-ai/nomic-embed-multimodal-7b",
    embeddings_field="nomic_embeddings",
    brain_key="nomic_sim"
)

# Query for specific content
results = text_img_index.sort_by_similarity(
    "invoice from 2024",
    k=10  # Top 10 results
)

# Launch FiftyOne App
session = fo.launch_app(results, auto=False)

Advanced Embedding Workflows

Embedding Visualization with UMAP

Create 2D visualizations of your document embeddings:

import fiftyone.brain as fob

# First compute embeddings
dataset.compute_embeddings(
    model=model,
    embeddings_field="nomic_embeddings"
)

# Create UMAP visualization
results = fob.compute_visualization(
    dataset,
    method="umap",  # Also supports "tsne", "pca"
    brain_key="nomic_viz",
    embeddings="nomic_embeddings",
    num_dims=2
)

# Explore in the App
session = fo.launch_app(dataset)

Similarity Search

Build powerful similarity search:

import fiftyone.brain as fob

results = fob.compute_similarity(
    dataset,
    backend="sklearn",
    brain_key="nomic_sim",
    embeddings="nomic_embeddings"
)

# Find similar images
sample_id = dataset.first().id
similar_samples = dataset.sort_by_similarity(
    sample_id,
    brain_key="nomic_sim",
    k=10
)

# View results
session = fo.launch_app(similar_samples)

Dataset Representativeness

Score how representative each sample is of your dataset:

import fiftyone.brain as fob

# Compute representativeness scores
fob.compute_representativeness(
    dataset,
    representativeness_field="nomic_represent",
    method="cluster-center",
    embeddings="nomic_embeddings"
)

# Find most representative samples
representative_view = dataset.sort_by("nomic_represent", reverse=True)

Duplicate Detection

Find and remove near-duplicate documents:

import fiftyone.brain as fob

# Detect duplicates using embeddings
results = fob.compute_uniqueness(
    dataset,
    embeddings="nomic_embeddings"
)

# Filter to most unique samples
unique_view = dataset.sort_by("uniqueness", reverse=True)

Zero-Shot Classification

Nomic Embed supports zero-shot classification using cosine similarity between image and text embeddings:

import fiftyone.zoo as foz

# Load model with classes for classification
model = foz.load_zoo_model(
    "nomic-ai/nomic-embed-multimodal-7b",
    classes=["invoice", "receipt", "form", "contract", "other"],
    text_prompt="This document is a"
)

# Apply model for zero-shot classification
dataset.apply_model(
    model,
    label_field="document_type_predictions"
)

# View predictions
print(dataset.first()['document_type_predictions'])
session = fo.launch_app(dataset)

Dynamic Classification with Multiple Tasks

Reuse the same model for different classification tasks:

import fiftyone.zoo as foz

# Load model once (7B for best accuracy)
model = foz.load_zoo_model("nomic-ai/nomic-embed-multimodal-7b")

# Task 1: Classify document types
model.classes = ["invoice", "receipt", "form", "contract"]
model.text_prompt = "This is a"
dataset.apply_model(model, label_field="doc_type")

# Task 2: Classify importance
model.classes = ["high_priority", "medium_priority", "low_priority"]
model.text_prompt = "The priority level is"
dataset.apply_model(model, label_field="priority")

# Task 3: Classify language
model.classes = ["english", "spanish", "french", "german", "chinese"]
model.text_prompt = "The document language is"
dataset.apply_model(model, label_field="language")

# Task 4: Classify completeness
model.classes = ["complete", "incomplete", "draft"]
model.text_prompt = "The document status is"
dataset.apply_model(model, label_field="status")

Combining Embeddings and Classification

Use the same model for both workflows:

import fiftyone as fo
import fiftyone.zoo as foz
import fiftyone.brain as fob

# Load model once (choose size based on needs)
model = foz.load_zoo_model("nomic-ai/nomic-embed-multimodal-7b")

# Step 1: Compute embeddings for similarity search
dataset.compute_embeddings(
    model=model,
    embeddings_field="nomic_embeddings"
)

# Step 2: Build similarity index
index = fob.compute_similarity(
    dataset,
    model=model,
    embeddings_field="nomic_embeddings",
    brain_key="nomic_sim"
)

# Step 3: Add zero-shot classification
model.classes = ["technical", "financial", "legal", "personal"]
model.text_prompt = "This document category is"
dataset.apply_model(model, label_field="category")

# Step 4: Add more classifications
model.classes = ["urgent", "normal", "low_priority"]
model.text_prompt = "The urgency level is"
dataset.apply_model(model, label_field="urgency")

# Explore combined results
session = fo.launch_app(dataset)

Switching Between Model Sizes

Both models use the same embedding dimension (3584), so you can compare them:

# Compute embeddings with 7B
model_7b = foz.load_zoo_model("nomic-ai/nomic-embed-multimodal-7b")
dataset.compute_embeddings(model_7b, embeddings_field="nomic_7b_embeddings")

# Compute embeddings with 3B
model_3b = foz.load_zoo_model("nomic-ai/nomic-embed-multimodal-3b")
dataset.compute_embeddings(model_3b, embeddings_field="nomic_3b_embeddings")

# Compare quality
# Both produce 3584-dim vectors, so they're directly comparable
# 7B will generally have slightly better semantic quality

Resources

• Model Hub (7B): nomic-ai/nomic-embed-multimodal-7b
• Model Hub (3B): nomic-ai/nomic-embed-multimodal-3b
• Nomic AI: nomic.ai
• ColPali Engine: colpali-engine
• FiftyOne Docs: docs.voxel51.com
• Base Architecture: Qwen2.5-VL

Citation

If you use Nomic Embed Multimodal in your research, please cite:

@misc{nomicembedmultimodal2025,
  title={Nomic Embed Multimodal: Interleaved Text, Image, and Screenshots for Visual Document Retrieval},
  author={Nomic Team},
  year={2025},
  publisher={Nomic AI},
  url={https://nomic.ai/blog/posts/nomic-embed-multimodal},
}

License

• Model: Apache 2.0
• Integration Code: Apache 2.0 (see LICENSE)
