Gorai

The robotics platform for the AI era.

Pronounced "go-ray" (like "sting-ray")

Why Gorai?

A robot is a distributed system — so build it like one. Even a "single" robot is already a network of MCUs, SBCs, sensors, and sometimes a base station. Gorai stops pretending otherwise: every sensor and actuator is a service on a NATS mesh — discovered at runtime, addressed by name, never wired by hand. The discipline that built reliable cloud systems — service discovery, location transparency, health checks, fan-out, replay — is exactly what a real robot needs.

Capabilities, not wiring. Sensors are resources you read; actuators are tools you call. Any agent on the mesh can perceive the world and change it — the capability model MCP gives AI agents, delivered natively over NATS with no MCP server in the path. We call it NCP, the NATS Capability Protocol.

One robot can be many machines. Because capabilities are addressed by name and not by location, a single logical robot can span a rover, a drone, a sensor mast, and a compute box — composed at runtime, degrading gracefully as platforms join and leave. This is the Composite Robot, and it's the whole point.

Autonomy without replay is folklore. Action logs, state streams, and replay are first-class platform concerns — not add-ons. AI execution is welcome but never trusted: safety is enforced at the capability node, not the agent. Agent-compatible, not agent-dependent — deterministic state machines and rule-based planners drive the same capabilities.

Build robots like software. Run them like systems. Opinionated, pragmatic, operational. If you already think in APIs, distributed systems, and deployments, you'll be productive in days, not months.

Read the north star: VISION.md.

---

Full documentation lives at gorai-docs. Strategy, architecture, specifications, hardware analysis, a 20-chapter book, and implementation guides — all indexed for both humans and AI agents. Point your AI agent at that repo and it will navigate 100+ documents via CLAUDE.md and INDEX.md automatically.

---

What gorai Is (and Isn't)

There are two different binaries in a Gorai project, and it's important not to confuse them:

1. Your robot binary — the program that runs on the Pi and does the robot stuff. This is your own Go module: a main.go that blank-imports the components you want and calls gorai.Run(). Its embedded NATS server, the mesh, and every component compile into this one static binary. It is fully self-contained and needs nothing from the gorai tool at runtime — you copy it to the robot and run it.

2. The gorai CLI — a developer and operator tool you run at your workstation. It never runs on the robot in production. Think of it as kubectl + a build wrapper + a package helper, rolled into one command.

So yes — you could just go build . your robot project and scp the result to the Pi. The gorai CLI earns its place by doing the things around that binary that a plain go build does not:

The first three are conveniences over the Go toolchain. The mesh commands are the part you genuinely cannot replicate with go build — they observe and debug a running system, which is what you reach for once a robot (or several) is live.

The rest of this README covers how to install the CLI, define a robot, and build it.

---

Build a robot in under an hour. Write JSON, get a binary, deploy to a Linux host (Raspberry Pi/Orange Pi/etc).

# 1. Install the CLI (a dev/operator tool — not the robot itself)
go install github.com/emergingrobotics/gorai/cmd/gorai@latest

# 2. Create a robot project from the template
git clone https://github.com/emergingrobotics/gorai-robot-template.git my-robot
cd my-robot

# 3. Edit robot.json, then validate and run
gorai validate robot.json
gorai run robot.json

# 4. Build for deployment
gorai build robot.json -o robot --target linux/arm64
scp robot pi@raspberrypi:~ && ssh pi@raspberrypi ./robot

No containers. No K8s. No external services — just a single binary on a Raspberry Pi 5 or Orange Pi 5. That's the simple case, not the ceiling: point several binaries at a shared NATS bus (or a leaf node) and the mesh ties multiple platforms into one logical robot — same code, no rewrite.

---

Hardware Powered by Gorai

Gorai targets prosumer-accessible field robots across marine, surface, underwater, and land domains — autonomous submersibles, autonomous surface vessels, and land robots. An autonomous submersible, for example, runs gorai run on a Linux host (Raspberry Pi/Orange Pi/etc) inside a pressure housing.

---

Component Ecosystem

Gorai uses the Caddy model for component packaging: your robot project is a standard Go module, and the import list in main.go is the component manifest. Each component self-registers via init() calling registry.RegisterComponent(). There is no custom package manager -- Go modules handles everything.

How It Works

A robot's main.go declares which components to include via blank imports:

package main

import (
    gorai "github.com/emergingrobotics/gorai/pkg/gorai"

    // Remote proxy components from GoRAI core
    _ "github.com/emergingrobotics/gorai/components/motor/remote"
    _ "github.com/emergingrobotics/gorai/components/camera/remote"

    // Third-party component from the ecosystem
    _ "github.com/someone/gorai-component-lidar/rplidar"

    // Custom component in this repo
    _ "my-robot/components/ballast"
)

func main() {
    gorai.Run()
}

The Go import list replaces package.json, requirements.txt, or any custom manifest. What you import is what gets compiled into the binary.

Workflow

gorai component search lidar          # Find components in the ecosystem
gorai component add sensor/rplidar    # go get + add blank import to main.go
gorai build robot.json                # Single binary with everything included

Custom Components

Custom components are ordinary Go packages in your project's repo. Write a package with an init() function that calls registry.RegisterComponent(), add a blank import in main.go, and it compiles into the binary alongside everything else.

Sharing Components

Sharing a component means publishing a Go module. Extract the package into its own repo, push to GitHub, and anyone can gorai component add it. No registry servers, no package approval process -- standard Go module hosting.

Why This Matters

This is a key advantage of choosing Go as the platform language. The single-binary story extends all the way to the component ecosystem: no runtime dependency resolution, no DLL hell, no version conflicts at deploy time. Every dependency is resolved at build time by the Go toolchain, and the result is one static binary you copy to the robot.

Non-Go components (Python vision pipelines, C++ SLAM) run as external services communicating via NATS. They do not compile into the binary. This is Phase 2 complexity.

For the full design, see docs/package-dev-approach.md.

---

Who Is Gorai For?

Use Gorai if you:

• Want real autonomy (not educational toys, not simulations)
• Need approachable software (productive in days, not months)
• Value modern tooling (AI-assisted coding, simple deployment)
• Are building prosumer robots (marine monitoring, land vehicles, research platforms)
• Are a software-first team adding physical embodiment to AI/ML or scaling from one robot to fleets
• Care more about behavior, coordination, and operations than low-level kinematics or middleware internals

Use ROS 2 if you:

• Work in enterprise/research robotics (warehouse automation, autonomous vehicles)
• Need the full ROS ecosystem (thousands of packages, simulation, SLAM libraries)
• Are in academia where ROS 2 is the standard
• Need deep hardware or control-architecture experimentation (ROS 2 is the right platform)

We're not replacing ROS 2 — we're targeting a different market. Think "ROS 2 for prosumers," with an AI-first design for the next wave of autonomous systems.

---

The Future Robot Market (and Why Gorai Addresses It)

Robotics is shifting because decision-making is moving up the stack: autonomy is no longer only hand-authored logic. Perception, planning, and task selection are increasingly learned, probabilistic, or agentic. That shift—physical AI—changes what a platform must provide.

What the future market is:

• Physical AI — systems where behavior, autonomy, and coordination are more complex than motor control or kinematics
• Software-first teams — engineers and AI/ML practitioners who need to ship robots and fleets without becoming robotics-infrastructure experts
• Autonomy as a spectrum — from scripted behaviors and state machines to learned perception and agentic planners, all needing the same operational surface

Why Gorai is built for it:

• AI-first by design — we treat AI-driven execution as a first-class assumption: capability surfaces for tools, governance and safety at runtime, and auditability/replay as baseline, not add-ons
• Start simple, scale without rewriting — one binary today; same contracts and RDL when you add ML services, multi-robot coordination, or fleet operations
• Clarity over maximal flexibility — we optimize for teams whose hardest problems are autonomy, orchestration, deployment, and safety—not low-level robotics research

We are not trying to serve every robot. We are building the default platform for teams that ask: "How do we safely decide what the robot should do next—and scale that across systems?"

For the full strategic context, see Gorai Overarching Strategy in the gorai-docs repository.

---

Prerequisites

You need Go 1.25+ to build gorai. That's it.

macOS:

brew install go

Ubuntu/Debian:

sudo apt update && sudo apt install -y golang-go

Or download from https://go.dev/dl/ for the latest version.

NATS is embedded in the gorai binary -- no external message broker to install.

NATS CLI (optional, for debugging)

The NATS CLI lets you subscribe to messages and debug your robot:

macOS:

brew install nats-io/nats-tools/nats

Linux:

go install github.com/nats-io/natscli/nats@latest

---

Quick Start

1. Install the Gorai CLI

go install github.com/emergingrobotics/gorai/cmd/gorai@latest

2. Create a robot project from the template

# Clone the template (or click "Use this template" on GitHub)
git clone https://github.com/emergingrobotics/gorai-robot-template.git my-robot
cd my-robot

# Update the module path to your own
go mod edit -module github.com/yourorg/my-robot

3. Edit robot.json

The template includes a skeleton robot.json. Add components as needed:

{
  "version": "2",
  "robot": {"name": "my-robot", "description": "My first robot!"},
  "nats": {"embedded": true, "url": "nats://localhost:4222"},
  "dashboard": {"enabled": true, "listen": ":10101"},
  "components": []
}

4. Validate and run

make validate   # Check configuration
make run        # Run in development mode

The embedded NATS server starts automatically -- no separate process needed.

5. Build and deploy

# Build for Raspberry Pi
make build TARGET=linux/arm64

# Deploy
make deploy DEPLOY_HOST=pi@raspberrypi

Using an External NATS Server

For multi-robot deployments or shared brokers, point at an external NATS server:

{
  "nats": {
    "url": "nats://nats-server.local:4222",
    "external": true
  }
}

When external is true or the URL points to a non-local address, gorai connects to the external server instead of starting its own.

---

Hardware Platforms

Not supported: Pi 3, Pi Zero

See Hardware Requirements in the gorai-docs repository for details.

Hardware Access Patterns

Gorai supports two patterns for accessing hardware. Both produce components with identical interfaces — application code doesn't know or care which is used.

Co-processor (RP2040 via GSP/2): An RP2040 microcontroller handles real-time hardware I/O (PWM, motor control, encoders). The RPi communicates with it over USB serial using the Gorai Serial Protocol v2. Best for timing-critical control, isolating hardware from Linux scheduler jitter, and reliability-critical applications (e.g., an autonomous submersible — motor control must not glitch underwater).

Native RPi hardware (GPIO/I2C/SPI): Direct access to Raspberry Pi GPIO pins, I2C buses, and SPI buses from Go code. Best for simple sensors, I2C devices, prototyping, and cost-sensitive builds where an RP2040 is unnecessary.

Both patterns can be used simultaneously — e.g., RP2040 handling motors while the Pi reads I2C sensors directly.

---

CLI Commands

Core Commands

Component Management

Mesh Commands (Service Discovery)

---

Core Components

The core repo provides component interfaces, remote proxies (for multi-robot mesh access), and fakes (for testing). Hardware-specific implementations live in external Go modules.

Interfaces (in core)

arm, base, camera, gripper, input, link, motor, power, pwm, sensor, servo, space, stepper, thruster, valve

Remote Proxies (in core)

camera/remote, gpio/remote, input/remote, motor/remote, pwm/remote, sensor/encoder/remote

Fakes (in core, for testing)

camera/fake, motor/fake, pwm/fake, servo/fake

External Components (separate Go modules)

Hardware-specific implementations are installed with gorai component add:

• gorai-picarx - SunFounder PiCar-X robot kit
• gorai-driver-hcsr04 - HC-SR04 ultrasonic distance sensor
• More in the component registry

---

Architecture

Gorai uses a message-based architecture where all components communicate via an embedded NATS server:

┌──────────────────────────────────────────────────────┐
│                  Your Robot Binary                    │
│                                                      │
│  ┌─────────┐ ┌─────────┐ ┌─────────┐                │
│  │  GPS    │ │ Motor   │ │ Sensor  │    ...          │
│  │Component│ │Component│ │Component│                 │
│  └────┬────┘ └────┬────┘ └────┬────┘                 │
│       │           │           │                      │
│       └───────────┴─────┬─────┘                      │
│                         │                            │
│                   ┌─────▼─────┐                      │
│                   │  Message  │                      │
│                   │   Router  │                      │
│                   └─────┬─────┘                      │
│                         │ NATS Protocol              │
│                   ┌─────▼─────┐                      │
│                   │ Embedded  │                      │
│                   │   NATS    │  (JetStream enabled) │
│                   └───────────┘                      │
└──────────────────────────────────────────────────────┘

Key principles:

• Single binary with embedded NATS -- no external services required
• Each component runs in its own goroutine
• Internal control uses Go channels
• Inter-component communication uses NATS only
• No shared memory between components
• Message-based architecture enables remote debugging
• External NATS supported for multi-robot or shared broker deployments

---

Examples

---

Service Discovery (Mesh)

Gorai includes a built-in service mesh for runtime discovery across independent processes. This enables:

• Cross-binary discovery — Modules that aren't compiled together can find each other
• Channel registry — Discover available NATS subjects and their schemas
• Health monitoring — Automatic TTL-based expiry for stale services
• Schema documentation — JSON Schema definitions for message types

Architecture

┌─────────────────────────────────────────────────────────────────────────┐
│                         NATS JetStream KV                                │
│  ┌─────────────────────────────────────────────────────────────────┐    │
│  │  gorai-services (TTL: 30s)     → Active service registrations   │    │
│  │  gorai-channels (persistent)   → Channel/subject descriptors    │    │
│  │  gorai-schemas  (persistent)   → Message schemas (JSON Schema)  │    │
│  └─────────────────────────────────────────────────────────────────┘    │
└─────────────────────────────────────────────────────────────────────────┘

Quick Example

// Register a service
client, _ := mesh.NewClient(natsConn)
reg, _ := client.Register(ctx, mesh.ServiceDescriptor{
    Name:    "motor-controller",
    Type:    mesh.TypeComponent,
    Subtype: "motor",
    RobotID: "robot-alpha",
})
defer reg.Deregister()

// Discover other services
motors, _ := client.FindServices(ctx, mesh.Query{Subtype: "motor"})

CLI Discovery

# List all running services
gorai mesh services

# Watch for changes in real-time
gorai mesh watch

# List available channels
gorai mesh channels robot-alpha

See the mesh service discovery specification in the gorai-docs repository for complete documentation.

---

Dynamic Discovery

Gorai supports hybrid static/dynamic configuration. Define structure in RDL, discover hardware at runtime.

The Problem

Traditional approach requires declaring every device in config:

{
  "components": [
    {"name": "motor1", "type": "motor/pwm", "config": {"pin": 18}},
    {"name": "motor2", "type": "motor/pwm", "config": {"pin": 19}}
  ]
}

What if you don't know what devices will be connected? What if devices are hot-plugged?

The Solution

Define discovery rules instead of individual devices:

{
  "gateways": [
    {
      "name": "usb-gateway",
      "type": "gateway/gsp",
      "config": {
        "discovery": {"enabled": true, "patterns": ["/dev/ttyACM*"]}
      }
    }
  ],

  "discovery": {
    "enabled": true,
    "auto_adopt": true,
    "rules": [
      {"match": {"capability": "PWM"}, "adopt_as": {"type": "motor"}},
      {"match": {"capability": "IMU"}, "adopt_as": {"type": "sensor", "subtype": "imu"}}
    ]
  },

  "services": [
    {
      "name": "patrol",
      "type": "behavior/patrol",
      "depends_on": ["@discovered:motor/*", "@discovered:sensor/imu/*"]
    }
  ]
}

What happens:

1. Gateway discovers Pico on USB with PWM+IMU capabilities
2. Auto-adopts as motor and IMU sensor (via rules)
3. Patrol service's @discovered: dependencies resolve
4. Robot starts patrolling with discovered hardware

See the dynamic discovery specification in the gorai-docs repository for complete documentation.

---

Why Gorai?

Cloud-Native Patterns

Language Strategy

• Go core — NATS orchestration, configuration, web dashboard
• Python services — Vision (OpenCV), ML inference (PyTorch) — future
• C++ services — SLAM (Cartographer), point cloud processing — future

NATS has clients for 40+ languages. Use the best tool for each job.

---

Project Status

Version: 0.1.0 (Early Development)

Current Phase: Single Binary Deployment

The current focus is a zero-dependency, single-binary deployment model:

• Single Go binary with embedded NATS server
• No external services required -- everything in one process
• No containers, no K8s
• Runs directly on Raspberry Pi with systemd
• JetStream enabled by default for event sourcing and mesh discovery

Component Ecosystem (Caddy Model)

GoRAI uses the Caddy model for component distribution. Each hardware driver is a standalone Go module. A user's robot project has a main.go that imports the GoRAI core plus blank imports for each component needed. go build produces a single binary with exactly those components compiled in. See REQUIREMENTS.md for details.

Future Roadmap

• Non-Go services — Python/C++ services (vision, SLAM) communicate via NATS as external processes, not compiled-in components
• Fleet management — Multi-robot coordination (future phase)
• ROS 2 bridge — Interop with ROS 2 ecosystems (future phase)

---

Documentation

All documentation has moved to the gorai-docs repository, including:

• Getting Started — Hardware requirements, Robot Definition Language (RDL) configuration
• Architecture & Design — Strategy, vision analysis, design comparisons, mesh service discovery, dynamic discovery
• For AI Assistants / LLMs — CLAUDE.md (in this repo), gorai-docs INDEX.md
• Future State — Roadmap, component ecosystem plans

---

Contributing

Gorai is built with Claude Code. We believe AI-assisted development is the future — the project is organized for both humans and AI to reason about effectively.

For Humans

• See CLAUDE.md for contributor guidelines
• See the gorai-docs repository for code organization and package locations

For AI Assistants

• See the LLM Design Guide in the gorai-docs repository — everything needed to design new components and services without reading the entire codebase

---

License

Apache 2.0
