Handwritten Formula to LaTeX Converter

This repository contains a vision-language pipeline for converting handwritten mathematical formulas into LaTeX. The project was developed as a technical assignment solution and includes training code, evaluation code, command-line inference, and a Streamlit demo application.

The final successful solution is based on Qwen/Qwen2-VL-2B-Instruct fine-tuned with LoRA on linxy/LaTeX_OCR.

The full technical report for the assignment is available in TECHNICAL_REPORT.md.

Overview

The project solves handwritten formula recognition as an image-to-text task. An input image containing a handwritten mathematical formula is processed by a vision-language model and converted into LaTeX. In addition to the training and evaluation pipeline, the repository includes a Streamlit application for interactive inference and visual rendering of the generated formula.

The final best-performing setup uses Qwen/Qwen2-VL-2B-Instruct fine-tuned on linxy/LaTeX_OCR. The resulting model significantly outperformed zero-shot and one-shot baselines and also outperformed the combined-dataset SFT variant.

Final results on linxy/LaTeX_OCR:test:

Published checkpoints:

• qwen2vl-latex-ocr
• qwen2vl-latex-ocr-combined

Repository Structure

.
|-- Dockerfile
|-- docker-compose.yml
|-- README.md
|-- TECHNICAL_REPORT.md
|-- requirements.txt
|-- configs/
|   `-- train_config.qwen2vl_2b.yaml
|-- src/
|   |-- data_utils.py
|   |-- evaluate.py
|   |-- inference.py
|   |-- metrics.py
|   |-- model_utils.py
|   `-- train.py
|-- app/
|   `-- streamlit_app.py
|-- scripts/
|   `-- upload_to_hub.py
`-- demo/
    |-- streamlit_demo.mp4
    |-- streamlit_input_photo.jpg
    |-- streamlit_prediction_text.tex
    `-- streamlit_rendered_output.png

Build and Run

Local setup

git clone https://github.com/dmitryz1024/Multimodal_Reasoning_for_STEM.git
cd Multimodal_Reasoning_for_STEM
python3 -m venv venv
source venv/bin/activate
python -m pip install --upgrade pip
pip install torch torchvision --index-url https://download.pytorch.org/whl/cu128
pip install -r requirements.txt

If Hugging Face authentication is required:

huggingface-cli login

Training

Best single-dataset run:

python -m src.train --config configs/train_config.qwen2vl_2b.yaml --run_name qwen2vl_latex_only

Combined run:

python -m src.train --config configs/train_config.qwen2vl_2b.yaml --use_secondary --run_name qwen2vl_combined

Evaluation

python -m src.evaluate --model_name "Qwen/Qwen2-VL-2B-Instruct" --checkpoint_latex_ocr ./checkpoints/qwen2vl_latex_only/final --checkpoint_combined ./checkpoints/qwen2vl_combined/final --dataset "linxy/LaTeX_OCR" --subset "human_handwrite" --eval_mode all --output evaluation_results_qwen2vl_all.json

Command-line inference

python -m src.inference path/to/image.png

With a fine-tuned checkpoint:

python -m src.inference path/to/image.png --checkpoint ./checkpoints/qwen2vl_latex_only/final

Streamlit demo

streamlit run app/streamlit_app.py

Docker

Build image:

docker build -t latex-ocr .

Run the app:

docker compose up latex-ocr

Run training:

docker compose run --rm train

Demo Assets

The repository includes demo artifacts generated with the final model:

• input photo
• predicted LaTeX
• rendered output
• video walkthrough

Preview:

Notes

• The default inference model is Qwen/Qwen2-VL-2B-Instruct.
• The main technical discussion, failed SmolVLM attempts, hyperparameters, and final conclusions are documented in TECHNICAL_REPORT.md.
