Shoal Subtitles

Part of Shoal, a family of Jellyfin plugins that work together: Shoal Ingest files new media into your libraries, Shoal Subtitles finds, checks and synchronises subtitles, and Shoal AI gives both optional AI help. Each works on its own; installed together, they help each other.

A Jellyfin plugin that finds subtitles for videos that are missing them, checks every candidate against what is actually said in the audio, and fixes the timing, so the subtitles you get are the right ones and in sync.

Status: alpha. Checking and fixing existing subtitles, finding missing ones, as a last resort generating them from a full transcript, and comparing doubtful subtitles line by line with a full transcript work with the built-in speech-to-text, a local service, or a paid service within your monthly limit. The design is in docs/DESIGN.md.

Installing

From the Shoal plugin repository (recommended): in Dashboard → Plugins → Repositories, add https://raw.githubusercontent.com/chrisgrulau/jellyfin-shoal/main/manifest.json, install Shoal Subtitles from the catalogue and restart Jellyfin. Jellyfin installs updates from a repository automatically (daily, and at start-up) unless you switch that off for the plugin under My Plugins.

By hand: download jellyfin-plugin-subtitles.zip from the releases, check it against SHA256SUMS (and, if you like, its build provenance with gh attestation verify jellyfin-plugin-subtitles.zip --repo chrisgrulau/jellyfin-subtitles), and put Jellyfin.Plugin.Subtitles.dll in <jellyfin data>/plugins/Subtitles_<version>/, then restart Jellyfin.

Nothing is checked, changed or downloaded until you have saved the settings page once. For speech-to-text, either allow the built-in one on the plugin page (it downloads about 90 MB the first time), or point Local service address at an OpenAI-compatible service (for example a faster-whisper server); then press Test.

What it does

For each video missing subtitles (or holding suspect ones):

find candidates → score them → check the best against the audio → synchronise → verify → file (or ask you)

1. Find candidates: first through Jellyfin's own subtitle providers (for example the OpenSubtitles plugin, using your account), then SubDL (with a free API key). Text subtitles already inside the video can be checked too (optional). As a last resort (off by default), a subtitle is generated from a full transcript of the video (see Generated subtitles). Planned, not yet built: image tracks read with OCR.
2. Score them without spending anything: release name, source and edition, frame rate, running time, uploader signals, machine-translation flags, language check.
3. Check against the audio: short, dialogue-heavy snippets are transcribed and matched against the subtitle text.
4. Synchronise: fixes a constant offset or a gradual drift (a frame-rate difference), using the video's own speech/silence pattern first (free) and speech-to-text when needed. Separate offsets around cuts are planned.
5. File it, or hold it for your review. When an existing file is changed, its original is kept in the plugin's data folder, so Undo brings it back.

Speech-to-text

Three uses, each switched on or off separately and each with its own provider and model:

Providers:

When a service fails: a call that fails for a passing reason (no connection, a timeout, a server error, a short rate limit) is tried again up to 5 times, about 2, 4, 8 and 16 seconds apart; a refused key, a rejected request or a used-up allowance isn't. If it still fails, a check falls back to a free service on the server: the local service, then the built-in one (only if allowed and already downloaded); never to a paid service (If the chosen service fails, fall back to a free local one, on by default). A failing local service falls back to built-in and a failing built-in one to the local service. The result says so and offers Rerun with … the service you chose, when that service can be used. If nothing is left and the free line-start stage couldn't decide on its own, no verdict is recorded: the result reads "Couldn't check yet" and it is checked again on the next run. A built-in program that can't start, or keeps crashing, has its files checked against their checksums and is downloaded again if they're damaged. Every failure is listed under Advanced → Recent speech errors; only a problem that keeps happening (5 failures in a day, half the calls failing, or failures on 3 runs in a row; cleared after 3 successes in a row) shows as a banner and in Jellyfin's Activity log.

How it works today

A daily task (Scheduled Tasks → Shoal → Check and sync subtitles, or Check now on the plugin page) checks the text subtitle files beside your films and episodes. Each one's timing is compared with the audio, first for free by matching where lines start against where speech starts, then, if that isn't clear-cut, by transcribing a few minutes with a free local speech-to-text service and matching the words. Corrections (a shift, and a frame-rate change if the subtitle was made for a PAL release) are applied or held for your review, and every change can be undone from the plugin page. With many results, tick the ones to act on (or select every result matching the filter) and apply, decline, undo or check them again together; Apply all waiting for review… does the first for the whole filter after confirming the count. The work runs in the background with the same safety as each row's own buttons, and files changed since are skipped and listed.

A second daily task (Find missing subtitles, or Find missing now) searches your subtitle providers, such as the OpenSubtitles plugin, for films and episodes that have no subtitle in your languages. The best candidates are downloaded one at a time and checked against the audio the same way; one is added only if it clearly fits, with its timing corrected. Existing subtitle files are never replaced, downloads are capped per day, and Undo removes an added subtitle.

A third daily task (Generate missing subtitles and check whole files, off until you switch on Generate subtitles when none can be found, Check whole file for doubtful subtitles or Fix subtitles made for a different cut, or pick a subtitle with Check whole file or Try fixing timing by section) makes subtitles from a full transcript for videos the search found nothing for, compares doubtful subtitles with a full transcript, and fixes subtitles made for a different cut section by section; see below.

New videos don't wait for the night: a few minutes after films or episodes are added (10 by default, counted from the last one, so a whole season is handled together), their subtitles are checked and missing ones searched for, within the same limits (Handle new videos soon after they're added, on by default). A subtitle file that appears beside a video is checked the same way. Generating subtitles stays nightly.

All three tasks work on every film and show library unless you untick some under Libraries on the settings page (for example anime or children's libraries). The subtitle languages are those under Subtitle languages; left empty, each library uses its own subtitle download languages from Jellyfin's library settings (then the server's preferred metadata language, then English), and the page shows what is in effect for each library.

Languages

Every language works the same way, as long as the subtitle is in the language that is spoken:

• Each language is looked after for the videos whose audio is in it. A video is searched for (and generated for) in a language when one of its audio tracks is tagged with that language; an audio track with no language tag is taken to be in the library's first subtitle language. Checks listen to the audio track in the subtitle's language, and speech-to-text is told that language.
• A subtitle in another language than the audio (French subtitles for an English film, say) is never lined up by its words: speech-to-text would be listening for the wrong language and nothing could match. Its timing is left as it is, and its result says Not the audio's language. An experimental setting (Advanced → Check the timing of subtitles in another language than the audio, off by default) checks such a subtitle by when speech starts alone, which works in any language; any correction it finds waits for your review. Searching for subtitles in another language than the audio (translation) is planned.
• Checking a download's text: a subtitle whose letters are in the wrong alphabet (Cyrillic offered as English, Latin offered as Greek) is turned down in any language; English, French, Spanish, German, Italian, Portuguese, Dutch, Swedish, Danish, Norwegian, Polish, Finnish and Turkish are also recognised by their common words (Swedish, Danish and Norwegian aren't told apart from each other).
• Clean-up recognises speaker labels in any alphabet (JOSÉ:, ДИМА:), the full-width brackets of Chinese and Japanese sound descriptions (（笑）), and credit lines in the languages subtitles are most often shared in.
• Chinese, Japanese and Thai, written without spaces, are lined up with speech character by character; generated Chinese and Japanese lines are shorter (16 characters) and shown for longer. The whole-file check, which compares words, skips them.
• The whole-file check reads numbers said in words ("twenty-five") only in English; in other languages only a number heard in the place of another counts. Negations are counted in English, French, Spanish, Italian, Portuguese, German, Dutch, Swedish, Danish, Norwegian and Polish, and not at all in other languages.
• The results can be shown per language, and the summary line counts subtitles still missing per language.

Generated subtitles

When the search found nothing that fits a video in one of your languages, and Generate subtitles when none can be found is on, the whole video is transcribed and a subtitle is made from what was said.

• Which videos: those whose result is "Nothing fitting found" (the search ran, the providers answered, nothing fitted), in a language of the Subtitle languages setting that is also the language of the video's audio. The audio track's language tag decides; a track without one is taken to be in your first subtitle language. Subtitles are never generated in another language than the one spoken (translation is planned).
• The file: <video name>.<language>.generated.srt beside the video, for example Film (2020).en.generated.srt. Jellyfin reads the language from the name and takes the word generated as the track's title, so players list it as generated - English - SRT (the exact wording depends on the client). Nothing is added to the subtitle text itself.
• Lines: at most two lines of 42 characters, each shown for 1 to 7 seconds, split at pauses and sentence ends, and lengthened into silence where possible so they can be read (about 20 characters a second at most).
• Machine-made: names, quiet or overlapping speech and songs may be wrong. The results list shows Generated, with the service and model that made it and how many lines it has.
• Found later: a generated subtitle doesn't count as having one, so the daily search keeps looking (every 30 days per video, as for any video nothing fitted). When it adds a real subtitle, the generated one is removed (a copy is kept in the plugin's originals folder) and its result shows Replaced by a found subtitle. The timing check leaves generated subtitles alone: they are speech-to-text already.
• Undo removes a generated subtitle, and it isn't generated again on its own (Generate again in the results asks for it). Deleting the file by hand has the same effect. Jellyfin's own "Download missing subtitles" task does count a generated file as a subtitle, so it stops looking for that video; this plugin's search doesn't.
• No speech: a video where almost nothing is said (fewer than about 20 words an hour: music, silence, sound effects) gets no subtitle; its result says No speech to transcribe, and it isn't transcribed again unless you change the Full transcript service or model.
• Which service, and what it costs: the Full transcript row under speech-to-text, separate from the other two uses. By default the built-in one, which is free but slow on a CPU (roughly as long as the video, sometimes longer); a local service with a GPU is free and much faster. A paid service (Deepgram, OpenAI) is charged for every minute of the video (a two-hour film is 120 minutes: about USD 0.52 on Deepgram Nova-3, USD 0.72 on OpenAI Whisper at the prices shipped with this version); the whole video's cost is reserved against your monthly limit before it starts, and a video that doesn't fit in what's left of the limit waits.
• Pace: at most Videos transcribed per night (20 by default, 0 to 200), the ones waiting longest first, and no new video is started after Stop starting new videos after (4 hours by default, 0 to 24; 0 means no limit; a video already being transcribed finishes). The log's summary line says when the time ran out and how many are left for the next night. The task runs at 05:00, an hour after the search; it can be run from the plugin page (Run full transcripts now) or Scheduled Tasks.

Whole-file check

A subtitle that looks doubtful can be compared, line by line, with a full transcript of its video. Off by default: Check whole file for doubtful subtitles.

• Which subtitles: only doubtful ones: the timing check was unclear, or settled by only a few matching words, or the AI wording audit flagged lines; and any you pick with Check whole file in the results (even with the switch off). Never generated subtitles (they are the transcript), translations matched by meaning, or subtitles in a language other than the audio's (or not among your subtitle languages); Check whole file says so when you pick one.
• What it finds: lines heard but missing from the subtitle (at least 4 different words over a second with no line shown; chants, laughter and a run of sung or broadcast lines are left alone); lines of 8 or more words with nothing heard around them while the lines either side were heard; lines where a number or negation ("not", "never" …) is added, dropped or changed among words that otherwise match, or where a character's name is heard in the place of another the subtitle uses; and lines that leave out most of what is said. Case, punctuation, contractions ("don't" / "do not"), numbers in digits or words ("25" / "twenty-five") and times ("6:00" / "6 a.m.") don't count as differences, and the subtitle's timing may be off by up to 3 seconds (a correction waiting for review is allowed for). If too little of the subtitle is heard, or too many lines have nothing heard, the transcript is taken to be at fault and nothing is flagged. The rules were tuned on real films and episodes so that good subtitles get about two findings an hour, many of them real faults such as digits split by text recognition ("Level 1 4").
• Confidence: words the speech-to-text wasn't sure of don't flag anything: below 0.90 for Deepgram, 0.80 for the Whisper-based services (the built-in, local and OpenAI). With Tune confidence thresholds automatically (off by default), each service and model learns a stricter threshold from subtitles already known to be good; it never goes below those starting points. With the AI plugin, lines whose wording differs can also be confirmed by it (within the run's AI checks); lines it doesn't confirm are left out.
• Review: nothing is changed on its own. The result lists each line with its time, what was heard and a suggested fix, with its own Apply (or Add line / Remove line), Decline and Edit (which opens the editor at that line with the fix filled in, saved only when you save). Apply on the result takes every suggested fix at once but leaves lines with nothing heard for you to remove one by one. Undo brings the original back. Show Differs from what is said (whole file) to list them; they also go to the Activity log.
• Cost and pace: it uses the Full transcript service, the same as generated subtitles, and a paid one is charged for the whole video (reserved before it starts). Transcripts are kept (compressed, at most 200 MB, the least recently used going first), so checking again, or generating from the same video, costs nothing more. At most Subtitle files checked whole per night (5 by default, 0 to 200; files you picked go first and count too), within the same Stop starting new videos after hours as generating. Picked files are checked on the next run (05:00, or Run full transcripts now).

Subtitles made for a different cut

Some subtitles were made for another version of the video: a scene added or cut, a recap or cold open, ad breaks trimmed differently, sometimes a different frame rate as well. They start in time and then jump or drift part-way, so no single shift fixes them, and the timing check leaves them unclear. Off by default: Fix subtitles made for a different cut.

• Which subtitles: those whose timing check was unclear, or settled by speech-to-text with only partial agreement; and any such subtitle you pick with Try fixing timing by section in the results (even with the switch off). Not subtitles for another language or matched by meaning, generated ones, or ones the search added.
• How: the subtitle is lined up with a full transcript of its video, word runs that occur once in each marking where they agree. Where the timing holds steady for a stretch and then jumps, the stretches become sections, each moved by its own amount (with one frame-rate correction for the whole file). A jump is always placed between two lines. If too few words match, or they don't agree for long stretches (another episode, another language, notes rather than dialogue), the subtitle is left alone and the result says why.
• Review: nothing is changed on its own. The result reads, for example, "Made for a different cut: timing jumps at 12:40 (+3.2 s) and 31:05 (−41.0 s)", with each section in the nerd stats. Apply moves each section; Decline leaves the file as it is; Undo brings the original back. Lines covering a part the video doesn't have are listed for you to remove (Remove line, or decline to keep them); they are never moved into the wrong place. Where the video has a part the subtitle doesn't, it simply has no lines.
• Cost and pace: it uses the Full transcript service and the transcripts the whole-file check and generated subtitles keep, so a video is transcribed only once. With a transcript already kept, Try fixing timing by section answers at once; otherwise it waits for the next run. At most Subtitle files checked whole or fixed by section per night (5 by default, shared with the whole-file check), within the same Stop starting new videos after hours.
• Tested on real videos: on subtitles cut in 312 ways (scenes removed or added, both, with a frame-rate change, a block before the start), the sections were right every time and their timing within a few hundredths of a second; good subtitles were left as one timing (the only jumps found in them were real, at act breaks), and subtitles for another episode were always left alone.

Safety

• Reversible and idempotent: the original subtitle is always kept; every change is recorded with where it came from, how it was scored and synchronised, and what it cost. Re-running skips work already done.
• Timing fixes are applied automatically by default; changes to the wording are never applied without your review unless you choose otherwise.
• Clean-up follows the same rules. Removing subtitle-site adverts and credit lines is automatic by default (they are never dialogue; this can be switched to review). Empty lines are always removed. Merging a line repeated back to back and removing sound descriptions (off by default) change the wording, so they follow the wording setting. Shortening overlaps and lengthening lines too brief to read follow the timing setting. ASS signs, karaoke and effects keep their timing unless you ask otherwise.
• Budgets and limits: monthly spending limit for paid services, in your own currency (5 a month by default; 0 means no paid services at all, and "no limit" is an explicit choice). Providers' charges (usually in US dollars) are converted with the European Central Bank's daily rates, with an optional percentage for taxes or card fees.
  • Every paid call is priced from the providers' published prices (shipped with the plugin), reserved against the month's limit before it is made, and recorded afterwards, so runs stop at the limit.
  • A call whose cost can't be worked out isn't made.
  • The settings page shows this month's spending.
  • One budget page with Shoal AI: when Shoal AI is installed (and "Allow Subtitles to use this budget for paid speech-to-text" is ticked there, the default), the currency, monthly limit and a limit for Deepgram and for OpenAI are set on Shoal AI's page, and paid calls are counted there. This page then shows "Spending limits are set in Shoal AI" with this month's figures and a link, and hides its own spending settings (they are kept, and apply again without Shoal AI). API keys stay here. What was spent here earlier in the month is counted there once.
  • Provider limits are handled respectfully: no hammering an API that has said stop.

Settings

Dashboard → Plugins → Subtitles. The results come first: each row shows the video as "Series S01E05" (the episode title beneath) or "Title (Year)", the outcome, the changes as small icons with counts (⏱ timing shift, ↔ line timing tidied, 🔈 sound descriptions removed, ✂ lines removed, 💬 wording changed, ➕ lines to add, 🔤 text that didn't decode cleanly, ⏳ queued; hover for words, dashed when waiting for review), one sentence about what happened and when. ▸ opens the row's details: the files, what changed, lines to review and the numbers behind it ("Nerd stats"). The list shows 15 at a time (Show more), filtered and searched on the server; on a phone the rows become cards.

The settings are grouped in sections that open and close (General, Finding and checking, Clean-up, Speech-to-text, Spending limit). Basic settings cover the key decisions in plain language; an Advanced settings section holds finer controls (costs, how much is checked per run, clean-up details, AI checks) with warnings where a change could make results worse. "Let agreement between sources settle disagreements" is shown there as coming later; it has no effect yet.

Requirements

• Jellyfin 12.1 or newer (the plugin targets .NET 10).
• For OpenSubtitles results: Jellyfin's OpenSubtitles plugin, signed in to your account.
• For SubDL results: a free API key from subdl.com, entered on the plugin page.
• Write access to your media folders for Jellyfin's account: corrections are written beside the video, and found subtitles are added there. Folders it can't write (a read-only mount, NAS permissions) are shown as "Can't write here" and tried again after 30 days, without downloading or checking anything.
• Jellyfin's ffmpeg (it comes with the official packages and images; a system ffmpeg found on the PATH works too).

Roadmap

1. First release: candidate sources, scoring, audio check and synchronisation (built-in, local or cloud speech-to-text), subtitle clean-up, reversible changes, review screen, budgets.
2. With the AI plugin installed: lines matched by meaning when the wording differs from what is said (done); wording audit of checked subtitles and, a few per night, the existing library (done); subtitle editor with audio playback (done).
3. Full transcription: last-resort subtitles (done), whole-file check of doubtful subtitles (done), automatic confidence calibration (done, off by default), timing fixed by section for subtitles made for a different cut (done, off by default).
4. More languages (done: any language the audio is in); later, subtitles in a different language from the audio (translation; timing by speech starts is there as an experiment, see Languages).

What it stores and sends

Stored in the plugin's data folder (<jellyfin data>/plugins/Jellyfin.Plugin.Subtitles/): keys.json (owner-only), results.json (a result per subtitle: paths, video names, what was changed; kept while the file exists), originals/ (the original of every file it changed, for Undo), spend.json and rates.json (spending), downloads.json (the day's download count), transcripts/ (full transcripts, compressed, at most 200 MB) and calibration.json (counts per speech-to-text model for tuning confidence), speech-errors.jsonl (the last 500 speech-to-text failures of the last 30 days: time, service, kind and a short message with keys removed) and speech-calls.json (calls per service per hour and per run, for telling a lasting problem from a passing one). The built-in speech-to-text lives in <jellyfin data>/shoal-subtitles/.

Sent:

Needs write access to your media folders: corrections are written beside the video.

Upgrading and uninstalling

Upgrades keep settings, results and originals. Before uninstalling, use Restore all originals… (under the results on the plugin page) to reverse everything the plugin did, or Undo on single changes: once the plugin is gone, its originals are no longer linked to their files. Restore all puts back the original of every file it changed and removes every subtitle it added or generated; files changed since by you or another program are left alone and listed. Then untick Enabled, save, and uninstall. Left behind: the plugin's data folder (keys, results, originals) and <jellyfin data>/shoal-subtitles/ (the built-in speech-to-text). Jellyfin's own "Download missing subtitles" task uses the same OpenSubtitles allowance, so you may want only one of them searching.

Building

The shared source (jellyfin-plugin-common) is a git submodule, so clone with --recurse-submodules, or fetch it in an existing clone; the build fails without external/common:

git submodule update --init --recursive
dotnet build -c Release

Any .NET 10 SDK builds it (global.json sets the floor, so Linux distribution packages work), and package versions are locked in packages.lock.json. The Jellyfin packages are pinned to the server version in build.yaml's targetAbi; bump them together.

The output Jellyfin.Plugin.Subtitles.dll goes in <jellyfin data>/plugins/Subtitles_<version>/.

Security

This repository is public. No secrets are committed. API keys you enter are stored in their own file, keys.json in the plugin's data folder, readable only by Jellyfin's account (never in the plugin configuration, and never shown again or logged). See SECURITY.md.

Licence

GPL-3.0, in line with Jellyfin's official plugins (the server itself is GPL-2.0).
