Animator

Type an idea, get a narrated hand-drawn whiteboard explainer video.

python -m animator --prompt "How do planes fly?" -o plane.mp4

One command writes the script, draws each scene, records the narration, and animates every icon while its sentence is being spoken. A 4–5 scene video takes about a minute.

Examples

All three were generated from a single prompt each, with no editing afterwards.

Click a preview to open the full video with sound.

How it works

"How do planes fly?"
   │
   ├─ 1. Storyboard   Gemini writes scenes made of beats: one sentence + one icon each
   ├─ 2. Images       Gemini draws each scene as a 16:9 whiteboard frame
   ├─ 3. Narration    Gemini TTS speaks each scene; the pauses mark where each beat starts and ends
   ├─ 4. Regions      Gemini finds each icon in the image and assigns it to its beat
   └─ 5. Animation    The local engine draws each icon during its beat → MP4

Steps 2–4 run for all scenes in parallel. Step 5 runs locally on CPU: it writes text stroke by stroke, traces outlines from their real endpoints, fills shapes with brush strokes, and draws branching line art one path at a time. A small bundled CRAFT model tells text apart from shapes. No GPU is needed.

Setup

You need Python 3.10+ and FFmpeg.

# 1. FFmpeg
brew install ffmpeg                # macOS
sudo apt install ffmpeg            # Ubuntu / Debian
# Windows: https://ffmpeg.org/download.html, then add its bin folder to PATH

# 2. Python dependencies
python -m venv .venv
source .venv/bin/activate          # Windows: .venv\Scripts\Activate.ps1
pip install -r requirements.txt

# 3. API key (only for --prompt and --detect-regions)
cp env.example .env                # then paste your key into .env

Get a key at Google AI Studio. The .env file is loaded automatically and is git-ignored.

Usage

From a prompt

python -m animator --prompt "How photosynthesis works" -o photosynthesis.mp4

From your own images

No API key is needed for these.

# fixed length, silent
python -m animator scene.png --duration 8 -o scene.mp4

# paced to your narration
python -m animator scene.png --audio scene.wav -o scene.mp4

# several scenes joined in order
python -m animator a.png b.png --audio a.wav b.wav -o lecture.mp4

To control the drawing order, pass a region plan with --regions plan.json. To have Gemini work out the order from the image and narration text instead, use --detect-regions --narration "...". Add --save-regions to keep the detected plan so you can edit it and render again.

Images work best as ink on white: clean marker drawings with a few flat colours. Photos, gradients and dark backgrounds don't animate well.

From Python

from animator import Scene, SnippetRegionPlan, render_video

plan = SnippetRegionPlan.model_validate_json(open("a.regions.json").read())
render_video([Scene("a.png", audio="a.wav", region_plan=plan)], "out.mp4", quality="high")

Customise the style

Every prompt sent to Gemini is a plain text file in animator/prompts/:

Edit them and run again. No code changes are needed.

Project layout

animator/
  prompts/      every prompt, as editable .txt files
  gemini/       storyboard → images → narration → regions → pipeline
  engine.py     drawing engine (ordering, stroke tracing, fills)
  render.py     scenes → MP4 via FFmpeg
  cli.py        command line
  api/          HTTP API for the web app (python -m animator.api)
frontend/       React web app (Supabase sign-in, studio)
examples/       sample videos

Troubleshooting

• ffmpeg not found: install FFmpeg (see Setup) and open a new terminal. The pip package called ffmpeg is not the same thing.
• needs GEMINI_API_KEY: put the key in .env, or export GEMINI_API_KEY=....
• 429 / rate-limit warnings: these calls are retried automatically with backoff. On the free tier, use fewer scenes with --scenes 3.
• A caption appears before it is spoken: run with --save-storyboard and check scene_XX.regions.json. Each region's beat decides when it draws.
