Moatless Tree Search

Code for paper SWE-Search: Enhancing Software Agents with Monte Carlo Tree Search and Iterative Refinement

Note: The original development code can be found at github.com/a-antoniades/swe-search. It is only intended for reproducing the results in the paper. This is a clean refactor with a modular design, which will be maintained and extended.

Installation

Install the package:

pip install moatless-tree-search

Environment Setup

Before running the evaluation, you'll need:

1. At least one LLM provider API key (e.g., OpenAI, Anthropic, etc.)
2. A Voyage AI API key from voyageai.com to use the pre-embedded vector stores for SWE-Bench instances.
3. (Optional) Access to a testbed environment - see moatless-testbeds for setup instructions

You can configure these settings by either:

1. Create a .env file in the project root (copy from .env.example):

   cp .env.example .env
   # Edit .env with your values


2. Or export the variables directly:

   # Directory for storing vector index store files
   export INDEX_STORE_DIR="/tmp/index_store"

   # Directory for storing clonedrepositories
   export REPO_DIR="/tmp/repos"

   # Required: At least one LLM provider API key
   export OPENAI_API_KEY="<your-key>"
   export ANTHROPIC_API_KEY="<your-key>"
   export HUGGINGFACE_API_KEY="<your-key>"
   export DEEPSEEK_API_KEY="<your-key>"

   # ...or Base URL for custom LLM API service (optional)
   export CUSTOM_LLM_API_BASE="<your-base-url>"
   export CUSTOM_LLM_API_KEY="<your-key>"

   # Required: API Key for Voyage Embeddings
   export VOYAGE_API_KEY="<your-key>"

   # Optional: Configuration for testbed environment (https://github.com/aorwall/moatless-testbeds)
   export TESTBED_API_KEY="<your-key>"
   export TESTBED_BASE_URL="<your-base-url>"


Streamlit

To launch the Streamlit app, run:

# Launch with direct file loading
moatless-streamlit path/to/trajectory.json

# Launch interactive UI (file can be selected in browser)
moatless-streamlit

The following badges are used to indicate the status of a node:

Evaluation

To run the evaluation script:

moatless-evaluate \
    --model "gpt-4o-mini" \
    --repo_base_dir /tmp/repos \
    --eval_dir "./evaluations" \
    --eval_name mts \
    --temp 0.7 \
    --num_workers 1 \
    --use_testbed \
    --feedback \
    --max_iterations 100 \
    --max_expansions 5

You can optionally set the --instance_ids to evaluate on a specific instance or a list of instances.

Use --use_testbed if you got access to a testbed environment. Otherwise, tests will not be run.

Development

Install with Poetry:

poetry install --with dev

Apple Silicon

To install the dependencies on Apple Silicon (Mac M1/M2/M3 etc.), you need the following workaround to get the graphviz package working:

brew install graphviz
export CFLAGS="-I $(brew --prefix graphviz)/include"
export LDFLAGS="-L $(brew --prefix graphviz)/lib"
poetry install --with dev

Examples

Example: Basic Flow

Basic setup similar to the moatless-tools agent.

from moatless.agent.code_agent import CodingAgent
from moatless.agent.code_prompts import SIMPLE_CODE_PROMPT
from moatless.benchmark.swebench import create_repository
from moatless.benchmark.utils import get_moatless_instance
from moatless.completion import CompletionModel
from moatless.file_context import FileContext
from moatless.index import CodeIndex
from moatless.search_tree import SearchTree
from moatless.actions import FindClass, FindFunction, FindCodeSnippet, SemanticSearch, ViewCode, StringReplace, CreateFile, AppendString, RunTests, Finish, Reject

index_store_dir = "/tmp/index_store"
repo_base_dir = "/tmp/repos"
persist_path = "trajectory.json"

instance = get_moatless_instance("django__django-16379")

completion_model = CompletionModel(model="gpt-4o", temperature=0.0)

repository = create_repository(instance)

code_index = CodeIndex.from_index_name(
    instance["instance_id"], index_store_dir=index_store_dir, file_repo=repository
)

actions = [
    FindClass(code_index=code_index, repository=repository),
    FindFunction(code_index=code_index, repository=repository),
    FindCodeSnippet(code_index=code_index, repository=repository),
    SemanticSearch(code_index=code_index, repository=repository),
    ViewCode(repository=repository),
    StringReplace(repository=repository, code_index=code_index),
    CreateFile(repository=repository, code_index=code_index),
    AppendString(repository=repository, code_index=code_index),
    RunTests(repository=repository, code_index=code_index),
    Finish(),
    Reject()
]

file_context = FileContext(repo=repository)
agent = CodingAgent(actions=actions, completion=completion_model, system_prompt=SIMPLE_CODE_PROMPT)

search_tree = SearchTree.create(
    message=instance["problem_statement"],
    agent=agent,
    file_context=file_context,
    max_expansions=1,
    max_iterations=50
)

node = search_tree.run_search()
print(node.observation.message)

Example: MCTS Flow

How to setup the evaluation flow with MCTS and testbeds.

from moatless.agent.code_agent import CodingAgent
from moatless.benchmark.swebench import create_repository
from moatless.benchmark.utils import get_moatless_instance
from moatless.completion import CompletionModel
from moatless.discriminator import AgentDiscriminator
from moatless.feedback import FeedbackGenerator
from moatless.file_context import FileContext
from moatless.index import CodeIndex
from moatless.search_tree import SearchTree
from moatless.selector import BestFirstSelector
from moatless.actions import FindClass, FindFunction, FindCodeSnippet, SemanticSearch, ViewCode, Finish, Reject, RunTests, StringReplace, CreateFile
from moatless.value_function.base import ValueFunction
from testbeds.sdk import TestbedSDK
from moatless.runtime.testbed import TestbedEnvironment

index_store_dir = "/tmp/index_store"
repo_base_dir = "/tmp/repos"
persist_path = "trajectory.json"

instance = get_moatless_instance("django__django-16379")

completion_model = CompletionModel(model="gpt-4o-mini", temperature=0.7)

repository = create_repository(instance, repo_base_dir=repo_base_dir)

code_index = CodeIndex.from_index_name(
    instance["instance_id"], index_store_dir=index_store_dir, file_repo=repository
)

file_context = FileContext(repo=repository)

selector = BestFirstSelector()

value_function = ValueFunction(completion=completion_model)

discriminator = AgentDiscriminator(
    completion=completion_model,
    n_agents=5,
    n_rounds=3,
)

feedback = FeedbackGenerator()

runtime = TestbedEnvironment(
    testbed_sdk=TestbedSDK(),
    repository=repository,
    instance=instance
)

actions = [
    FindClass(code_index=code_index, repository=repository),
    FindFunction(code_index=code_index, repository=repository),
    FindCodeSnippet(code_index=code_index, repository=repository),
    SemanticSearch(code_index=code_index, repository=repository),
    ViewCode(repository=repository),
    StringReplace(repository=repository, code_index=code_index),
    CreateFile(repository=repository, code_index=code_index),
    RunTests(repository=repository, code_index=code_index),
    Finish(),
    Reject()
]

agent = CodingAgent(actions=actions, completion=completion_model)

search_tree = SearchTree.create(
    message=instance["problem_statement"],
    agent=agent,
    file_context=file_context,
    selector=selector,
    value_function=value_function,
    discriminator=discriminator,
    feedback_generator=feedback,
    max_iterations=100,
    max_expansions=3,
    max_depth=25,
    persist_path=persist_path,
)

node = search_tree.run_search()
print(node.observation.message)

Citation

@misc{antoniades2024swesearchenhancingsoftwareagents,
      title={SWE-Search: Enhancing Software Agents with Monte Carlo Tree Search and Iterative Refinement},
      author={Antonis Antoniades and Albert Örwall and Kexun Zhang and Yuxi Xie and Anirudh Goyal and William Wang},
      year={2024},
      eprint={2410.20285},
      archivePrefix={arXiv},
      primaryClass={cs.AI},
      url={https://arxiv.org/abs/2410.20285},
}
