Desktop Overlay

A tiny, native macOS floating panel that shows live system metrics — CPU, memory, disk I/O, network throughput, thermal state, and (on Intel Macs) CPU temperature and fan speed — always on top of your other windows, so you never need to open Activity Monitor.

A lightweight, open-source alternative to iStat Menus / MenuMeters / Stats.



• 100% native. Swift + SwiftUI + AppKit. No Electron, no web view, no JavaScript, no Python, no bundled runtime, no third-party dependencies.
• Local only. Zero network connections, no database, no telemetry, no analytics. Every setting lives in UserDefaults.
• Light. ~0.3% CPU and ~45 MB RAM while idle (see Performance).
• Public APIs only — the one clearly-labelled, optional exception is the SMC sensor module for CPU °C / fan RPM (see Known limitations).

---

Requirements

The Xcode project is generated from project.yml with XcodeGen, but the generated DesktopOverlay.xcodeproj is committed, so you do not need XcodeGen to build or run.

---

Install

Download the pre-built app

Grab DesktopOverlay-x.y.zip from the latest release, unzip, and move DesktopOverlay.app to /Applications.

The build is ad-hoc signed but not notarized, so on first launch macOS will refuse to open it normally. Do this once:

• right-click the app ▸ Open ▸ Open in the dialog,

or from Terminal:

xattr -dr com.apple.quarantine /Applications/DesktopOverlay.app

After that it launches normally every time.

Build it yourself — from Xcode

open DesktopOverlay.xcodeproj

Select the DesktopOverlay scheme and press ⌘R.

Build it yourself — install script

./Scripts/install.sh

Builds Release, copies the app to /Applications, ad-hoc signs it, removes the quarantine flag, and launches it. Installing to a stable, signed location is what lets Launch at Login register correctly.

./Scripts/package.sh produces dist/DesktopOverlay-<version>.zip for a release.

On first launch:

• the overlay appears immediately, centred on the main screen (~220×140 pt);
• a gauge icon appears in the menu bar;
• nothing appears in the Dock — the app is an accessory (LSUIElement).

---

Using it

In Normal size the overlay also shows the raw figures behind the percentages (13.6 / 32 GB for RAM, the user/system split for CPU) and a one-word status for sensors (cool / warm / hot, idle / moderate / high). Compact size drops those to keep the panel small.

Every setting — position, size, opacity, corner radius, font size, selected metrics, update interval, appearance, always-on-top, click-through, launch-at-login — persists across relaunches. Multi-display is handled: if a saved position ends up off every screen, the overlay is recentred on the main display.

---

Performance

Measured on a 2019 MacBook Pro (8-core i9), overlay visible with 7 metrics at a 1-second interval:

How it stays cheap:

• One timer. A single DispatchSourceTimer on a .utility queue (200 ms leeway) drives every metric. Nothing polls faster than the chosen interval.
• Off-main sampling. Collectors run on the background queue; the UI is touched once per tick with an immutable snapshot.
• No idle rendering. Sparklines are Canvas-drawn and repaint only when a new sample arrives — there is no animation loop.
• Paused when hidden. Hiding the overlay stops collection entirely.
• Thermal backoff. At serious / critical thermal state the interval is stretched ×2 / ×4 and sparkline updates pause — the app does less work when the Mac is hot.

The samples above were stable across repeated readings (no growth). A multi-hour Instruments leak / energy run has not been done — contributions welcome.

---

Architecture

DesktopOverlay/
├── App/          DesktopOverlayApp (@main), AppDelegate (lifecycle + wiring)
├── Overlay/      OverlayPanel (borderless NSPanel), OverlayWindowController,
│                 DraggableHostingView, ResizeHandleView,
│                 OverlayView / OverlayRowView / SparklineView
├── Metrics/      MetricValue, SystemMetric (protocol), MetricsCoordinator,
│                 CPUMetric, MemoryMetric, DiskMetric, NetworkMetric,
│                 ThermalMetric, BatteryMetric, SMCTemperatureMetric, FanMetric
├── Settings/     SettingsStore (UserDefaults — single source of truth),
│                 SettingsView (General / Appearance / Metrics / Update / Guide),
│                 SettingsWindowController
├── MenuBar/      MenuBarController (NSStatusItem + NSMenu, rebuilt on open)
├── Services/     SystemMetricsService (Mach / IOKit / POSIX wrappers),
│                 SMCService (optional SMC reader), LaunchAtLoginService
└── Utilities/    RingBuffer, RateCalculator, CPUCalculator, MemoryCalculator,
                  DecayingMax, OverlayGeometry, MetricFormatter

Data flow

1. MetricsCoordinator owns one background DispatchSourceTimer.
2. Each tick samples the enabled SystemMetrics off the main thread, builds an immutable frame, and hops to the main actor once to publish it.
3. SwiftUI views observe MetricsCoordinator and SettingsStore and re-render only on change.
4. Menu, overlay level, click-through and appearance react to SettingsStore through Combine.

Testing. The pure helpers (CPUCalculator, MemoryCalculator, RateCalculator, OverlayGeometry, RingBuffer, the SMC value decoders) have no I/O and are covered by 40 unit tests in DesktopOverlayTests/:

xcodebuild -project DesktopOverlay.xcodeproj -scheme DesktopOverlay \
  -destination 'platform=macOS' test

---

Metrics & where the numbers come from

---

Adding a new metric

Example: a Swap metric.

1. Identifier — add a case to MetricID in Metrics/MetricValue.swift (shortLabel, displayName, and a spot in displayOrder).
2. Raw reader — add a function to SystemMetricsService returning the raw counters via a public API, nil on failure.
3. Metric object — create SwapMetric.swift conforming to SystemMetric. Keep the previous raw sample privately for delta values; put the pure math in a Utilities/ helper so it can be unit-tested.
4. Register — add .swap: SwapMetric() to the metrics dictionary in MetricsCoordinator.
5. Expose — add a Toggle to MetricsSettingsTab in SettingsView.swift; it appears in the menu automatically (menu = displayOrder minus GPU).
6. Display — OverlayRowView / MetricFormatter already render percent / bytes / bytesPerSecond / celsius / rpm / text. Add a shortDescription line for the Guide.

Nothing else needs to change.

---

Known limitations

Everything here is a deliberate consequence of using public APIs only.

The optional SMC sensor module

Services/SMCService.swift reads CPU temperature and fan speed from the System Management Controller. This is not a documented Apple API — the 4-character keys (TC0P, F0Ac, …) and their encodings (sp78, fpe2, flt) are community-reverse-engineered, the same way iStat Menus, TG Pro and Stats do it.

• Off by default. Enable per metric in Settings ▸ Metrics ▸ Sensors (SMC).
• No special privileges. No root, no SIP / Gatekeeper changes, no kext.
• Intel only. On Apple Silicon the classic keys are absent, so the metrics report "unavailable" and their toggles are disabled.
• May break on a future macOS. If a key stops responding the row shows — and nothing else is affected.
• Isolated. Delete SMCService.swift, SMCTemperatureMetric.swift, FanMetric.swift and the two MetricID cases, and the app is back to 100 % documented APIs.

The app makes zero network connections and stores nothing outside UserDefaults.

---

Creating a release

1. Set a real bundle identifier / Developer Team in project.yml, then xcodegen generate.
2. Product ▸ Archive (Release configuration).
3. Organizer ▸ Distribute App ▸ Direct Distribution for a Developer ID-signed .app.
4. For sharing with other Macs, notarize:

   xcrun notarytool submit DesktopOverlay.zip \
     --apple-id <id> --team-id <team> --password <app-specific-pw> --wait
   xcrun stapler staple DesktopOverlay.app


5. Package the .app or a DMG.

For personal use none of this is needed — ./Scripts/install.sh is enough.

---

Manual test checklist

Run through these after UI changes:

• Light / Dark / System appearance
• Retina and non-Retina displays
• Two or more displays; disconnect one → overlay returns to the primary screen
• Full-screen app in front → overlay stays visible, Dock / menu bar don't appear
• Drag to each screen edge; quit and relaunch → position restored
• Resize to the minimum and maximum
• Click Through on → clicks reach the app behind; off → overlay interactive again (toggle it a few times)
• Always on Top on / off changes whether other windows can cover the overlay
• Opacity, corner radius, font size, Compact / Normal all apply live
• Update interval 1 / 2 / 5 s changes the refresh rate
• Launch at Login on → appears in System Settings ▸ General ▸ Login Items
• Leave running for hours → CPU ≈ idle, memory flat, Energy = Low in Activity Monitor / Instruments

---

License

MIT — see LICENSE.
