PixelDiT & PixelDiT2

Pixel-space diffusion transformers for image generation

NVIDIA · University of Rochester

Papers and Resources

Work	Publication	Resources
PixelDiT2: Representation-Grounded Pixel Diffusion Transformers	NeurIPS 2026
PixelDiT: Pixel Diffusion Transformers for Image Generation	CVPR 2026 Oral

News

• 2026/09 — PixelDiT2 is accepted to NeurIPS 2026.
• 2026/06 — PixelDiT is a CVPR 2026 Best Paper Finalist.
• 2026/06 — Added post-modulation for PiT blocks to improve training stability.
• 2026/04 — PixelDiT training and inference code, and pretrained models, are released.
• 2026/02 — PixelDiT is accepted to CVPR 2026 Oral.
• 2025/11 — The PixelDiT paper is released.

Models and results

Note: Our models are resumed every 4 hours, using the timestamp as the random seed each time. As a result, the final training outcome may have a slight gap compared to a continuous run without intermediate resumes.

Class-to-image · ImageNet

Results use 50,000 samples. PixelDiT2 uses Heun with 50 steps; PixelDiT uses FlowDPMSolver with 100 steps. The class-to-image guide lists all checkpoints and the corresponding sampling commands.

Text-to-image · PixelDiT-T2I

See the text-to-image guide for training and inference.

ComfyUI. PixelDiT-T2I is also available in ComfyUI. The Comfy-Org/PixelDiT repository provides repackaged weights (bf16 and mxfp8) and a ready-to-use text-to-image workflow. The repository also hosts PiD.

Quick start

Install the requirements for the model family you want to use, in separate Python environments:

PixelDiT2 uses Python 3.10 and pinned PyTorch/CUDA dependencies. The PixelDiT file retains the original dependency specification; requirements.txt remains its compatibility entrypoint. C2I evaluation also differs: PixelDiT2 uses the LTH14 torch-fidelity fork with JiT statistics, while PixelDiT uses ADM in a separate evaluation environment. See the guides for details.

For class-to-image generation, both model families use c2i/main.py. Choose a matching checkpoint and configuration in the model list, then follow the shared inference or training workflow.

Repository Structure

├── pixdit_core/      # Shared model definitions
│   ├── pixeldit2_c2i.py   # PixelDiT2  (single-path patch DiT + grounding)
│   ├── grounding.py       # PixelDiT2  frozen DINOv3 encoder and projection P_g
│   ├── pixeldit_c2i.py    # PixelDiT   (dual-level: patch DiT + pixel PiT)
│   └── pixeldit_t2i.py    # PixelDiT   text-to-image
├── tools/            # Checkpoint download, evaluation and GFLOPs computation
├── c2i/              # Class-to-image (PixelDiT and PixelDiT2)
└── t2i/              # Text-to-image

# PixelDiT2 (ImageNet 256x256 and 512x512)
python tools/compute_flops.py --config c2i/configs/pixeldit2_h16_in256.yaml
python tools/compute_flops.py --config c2i/configs/pixeldit2_h16_in512.yaml --height 512 --width 512

# PixelDiT C2I (ImageNet 256x256, default resolution)
python tools/compute_flops.py --config c2i/configs/pix256_xl.yaml

# PixelDiT T2I at 1024x1024
python tools/compute_flops.py --config t2i/configs/PixelDiT_1024px_pixel_diffusion_stage3.yaml --height 1024 --width 1024

Acknowledgements

We would like to thank the authors of PixNerd and SANA for sharing their code. We also thank the SANA team for sharing their text-to-image training data.

Citation

If you find this work useful, please cite:

@inproceedings{yu2026pixeldit2,
      title={PixelDiT2: Representation-Grounded Pixel Diffusion Transformers},
      author={Yongsheng Yu and Wei Xiong and Yichen Sheng and Shiqiu Liu and Jiebo Luo},
      booktitle={Conference on Neural Information Processing Systems (NeurIPS)},
      year={2026},
}

@inproceedings{yu2026pixeldit,
      title={PixelDiT: Pixel Diffusion Transformers for Image Generation},
      author={Yongsheng Yu and Wei Xiong and Weili Nie and Yichen Sheng and Shiqiu Liu and Jiebo Luo},
      booktitle={Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)},
      year={2026},
}
