Alias - AI-Powered Binary Analysis

Transform executables into readable C code using Ghidra and Gemini AI.

Built for UofTHacks 13.

Features

• Drag-and-Drop Upload: Simply drag your .exe or ELF binary onto the page
• Chrome Extension: Automatically intercepts downloaded executables for analysis
• Real-time Progress: Watch the decompilation process with live console output
• Two-Pass AI Refactoring: Gemini 3 Pro fixes logic, Gemini Flash improves readability
• Split View Comparison: See the raw vs. refactored code side-by-side
• Export: Download the clean, refactored code as a .c file

Tech Stack

• Frontend: Next.js 14, TailwindCSS, Monaco Editor, Framer Motion
• Backend: Python FastAPI
• Decompiler: PyGhidra (Ghidra's Python bindings)
• AI: Google Gemini 3 Pro + Gemini Flash (two-pass refactoring)

Quick Start

Prerequisites

• Node.js 18+
• Python 3.10+
• Java 17+ (for Ghidra)
• Ghidra 11.x installed

Environment Setup

1. Clone the repository:

git clone https://github.com/yourusername/uofthacks13.git
cd uofthacks13

2. Set up environment variables:

# Create .env file in server directory
echo "GEMINI_API_KEY=your-gemini-api-key-here" > server/.env
echo "GHIDRA_INSTALL_DIR=/path/to/ghidra" >> server/.env

Running the Backend

cd server

# Create virtual environment
python -m venv venv
source venv/bin/activate  # On Windows: .\venv\Scripts\activate

# Install dependencies
pip install -r requirements.txt

# Run the server
uvicorn main:app --reload --host 0.0.0.0 --port 8000

Running the Frontend

cd client

# Install dependencies
npm install

# Run development server
npm run dev

Visit http://localhost:3000 in your browser.

Docker Deployment

For production deployment with sandboxed binary analysis:

# Set your Gemini API key
export GEMINI_API_KEY=your-gemini-api-key-here

# Build and run with Docker Compose
docker-compose up --build

Project Structure

uofthacks13/
├── client/                    # Next.js frontend
│   ├── app/
│   │   ├── page.tsx          # Main page
│   │   ├── layout.tsx        # Root layout
│   │   └── globals.css       # Cyberpunk theme styles
│   ├── components/
│   │   ├── FileDropzone.tsx  # Drag-drop upload
│   │   ├── ProgressStepper.tsx
│   │   ├── ConsoleStream.tsx
│   │   └── CodeViewer.tsx    # Monaco split view
│   └── lib/
│       └── api.ts            # API client
├── server/                    # FastAPI backend
│   ├── main.py               # FastAPI app
│   ├── routers/
│   │   └── decompile.py      # Upload & job endpoints
│   ├── services/
│   │   ├── ghidra_service.py # PyGhidra integration
│   │   └── ai_service.py     # GPT-4o refactoring
│   └── models/
│       └── schemas.py        # Pydantic models
└── docker-compose.yml        # Production deployment

API Endpoints

Security

• Binaries are never executed, only analyzed
• Uploaded files are deleted after processing
• Docker containers run with minimal privileges
• Rate limiting on upload endpoint

How It Works

1. Upload: User uploads a PE (.exe) or ELF binary
2. Analyze: PyGhidra loads and auto-analyzes the binary
3. Decompile: Each user-written function is decompiled to pseudo-C (library functions are filtered out)
4. Refactor (Two-Pass):
   • Pass 1 (Gemini 3 Pro): Fixes control flow, reconstructs data structures, corrects logic
   • Pass 2 (Gemini Flash): Renames variables, improves readability, adds comments
5. Display: Split view shows before/after comparison

Demo Tips

For the best hackathon demo:

1. Use a small, simple binary (< 1MB)
2. Pre-upload a sample binary to show the full flow
3. Have the split view ready to show the transformation

Authors

Built at UofTHacks 13 by Leo Zhang, Sean Zhao, and Lukas Li
