GhostLock — Locked Bootloader Jailbreak

Kernel exploit for Android devices with locked bootloader. Achieves temporary root + KernelSU installation without unlocking bootloader or modifying boot image. Runtime auto-detection of kernel version with multi-device offset table.

Vulnerability

CVE-2026-43499 — Futex PI (Priority Inheritance) Use-After-Free

Affects Linux kernel 5.7 ~ 7.1. Fixed in stable 6.1.175, 6.6.140, 6.12.86. Most Android devices remain unpatched as of September 2026.

The pselect6 syscall copies fd_set data onto the kernel stack. When combined with the futex PI waiter mechanism, a freed stack frame can be reclaimed as an rt_mutex_waiter structure. The rb-tree rebalance during PI chain walk then writes controlled values to arbitrary kernel addresses.

Supported Devices

Verified Working

Offsets Extracted (pending device test)

Not Feasible

The pselect stack overlay requires the freed rt_mutex_waiter to land within the user-controllable stack_fds region (words 0–14). Where it lands is determined by compiler PGO/LTO profiles, not the kernel version. See Stack Layout.

Note on 6.1 feasibility: OPLUS 6.1 kernels are consistently infeasible due to PGO inlining do_futex. However, some non-OPLUS 6.1 kernels (vivo) retain the standard call chain and are feasible (vivo T4, X Fold3 Pro). Feasibility must be checked per-device.

Exploit Flow

Two root paths, selected automatically based on device capabilities:

Path A: UMH Root (preferred, C ashmem devices)

Requires off_ashmem_misc_fops != 0 (C ashmem with static miscdevice in BSS).

PI write (mode=4)  →  redirect miscdevice fops to fake fops
                   →  configfs r/w → pipe physrw (1-byte precise kernel r/w)
                   →  SELinux enforcing = 0 (single byte, no policycap corruption)
                   →  UMH: inject work_struct into system_unbound_wq
                   →  root script → ksud late-load → KSU installed

Available on: OnePlus 13, OPPO Pad 4 Pro, 5.10/6.1 C ashmem devices. Not available on Rust ashmem (6.12 GKI) — heap-allocated miscdevice.

Path B: Direct PI Write (fallback)

Write 1 (mode=1)  →  SELinux enforcing = 0 (8-byte write, corrupts adjacent bytes)
Write 2 (mode=2)  →  task->cred = init_cred (uid=0, all capabilities)
Root shell         →  ksud late-load → KSU → SELinux policy fix

After W1+W2, the exploit patches the SELinux policy binary's config field (|= 0xC0000000 for ANDROID_NETLINK_ROUTE + GETNEIGH) and reloads via /sys/fs/selinux/load to restore network connectivity.

Bootstrap Mode (phone standalone)

App (seccomp)  →  Write 1 → mini-adb TCP → adb shell: full exploit → root

Auto-Boot

The boot-time launcher is provided by the separate GhostLock Anchor app.

Stack Layout Feasibility

With NFDS=320, core_sys_select allocates a 256-byte stack_fds buffer on the kernel stack:

stack_fds:  0    5    10   14 | 15   20   25   29
            ├─in─┤─out─┤─ex──┤ ├res_in┤res_out┤res_ex┤
            ◄── USER CONTROLLED ──►│◄── KERNEL ZEROED ──►

The exploit places fake waiter fields (task, lock) in the fd_set input bitmaps. For 6.12 nested waiter (14 words): max feasible waiter word = 3. For 5.10/6.1 compact waiter (10 words): max feasible waiter word = 7.

The waiter position depends on the call chain depth:

kernel_phys_load

All kernel writes use the linear-map alias. The bootloader picks kernel_phys_load, which varies per SoC:

A wrong value fails silently. Read it on a rooted unit:

su -c 'grep -i "Kernel code" /proc/iomem'   # c7810000-... → 0xc7800000

Override at runtime: KPHYS=0xc7800000 /data/local/tmp/a/e

PSELECT_SHIFT

/data/local/tmp/a/e                        # Default (shift=0)
PSELECT_SHIFT=-2 /data/local/tmp/a/e       # OnePlus 13 (6.6)

KIMAGE_TEXT_BASE

5.10 kernels use 0xffffffc008000000 (VA_BITS=39, different from 6.x default 0xffffffc080000000). This is handled automatically via the kimage_text_base field in the device offset entry.

Build

make NDK_ROOT=/path/to/android-ndk

Or directly:

NDK=/path/to/android-ndk
"$NDK/toolchains/llvm/prebuilt/linux-x86_64/bin/aarch64-linux-android35-clang" \
  -O2 -Wall -Isrc/core -Isrc/devices -DTARGET_CONFIG_H=\"target.h\" \
  src/core/main.c src/core/util.c src/core/slide.c \
  src/core/fops.c src/core/pipe_physrw.c src/core/root.c \
  src/core/miniadb.c src/core/umh_root.c \
  -o ./ghostlock -fPIE -pie -pthread

Prerequisites

ksud (required for KSU installation)

GhostLock provides temporary root. KernelSU installation requires ksud which bundles kernelsu.ko for each KMI version.

Setup

adb shell mkdir -p /data/local/tmp/a
adb push ./ghostlock /data/local/tmp/a/e
adb shell chmod 755 /data/local/tmp/a/e
adb shell /data/local/tmp/a/e

Run after boot completes and ADB is ready.

Adding New Devices

Only boot.img is needed — no root, no device access required.

1. Extract kernel and kallsyms

See kallsyms tools guide for the full workflow, or:

python tools/extract_target.py --kallsyms kallsyms.txt
python tools/extract_btf.py kernel

2. Determine feasibility

Check if do_futex is PGO-inlined by searching the kernel binary for all branch instructions targeting futex_wait_requeue_pi. If __arm64_sys_futex calls it directly (bypassing do_futex), the device is likely not feasible.

3. Create device entry

Add src/devices/<name>/offsets.h with the extracted offsets and include it in src/devices/offsets.h. Use the appropriate struct offsets macro:

For 5.10/6.1 compact waiter devices, also set .kimage_text_base=0xffffffc008000000ULL.

Files

License

For authorized security research and educational purposes only.
