UniForge3D — Windows and 8 GB VRAM

UniForge3D generates a complete 3D asset from a handful of sparse, unposed photos of one object. It jointly models reconstruction and generation in a shared anchor-guided space, so the parts you photographed stay faithful and the parts you did not are generated.

This is a fork of xibushu/UniForge3D that runs the same checkpoints on a Windows consumer machine — one 8 GB card, 64 GB of RAM, no nvcc, no conda — and adds a small web UI. Nothing about the model, its checkpoints or its output was changed: every optimisation here is bit-exact and ships with the script that proves it.

Tested configuration: Windows 11, Python 3.11, RTX 3070 Ti (8 GB), 64 GB RAM. Every number in this README was measured on that machine and is written up, with the method, in WINDOWS_LOWVRAM.md.

What this fork changes

• Prebuilt wheels instead of source builds. Every CUDA extension — CuMesh, FlexGEMM, o_voxel, nvdiffrast, flash-attn — comes from a cp311 win_amd64 wheel. There is no nvcc, no conda and no 30-minute flash-attn build. scripts/fetch.py wheels pulls all of them: torch and torchvision from the PyTorch index, flash-attn from its prebuild releases, and the five extensions from the whl/ directory of the TRELLIS.2-stableprojectorz repository, which is where they are published.
• Staged fp16 residency for 8 GB. Denoiser weights are fp16, each stage is moved onto the card only for its own steps, and the decoders keep an explicit fp32 boundary. Peak denoiser residency falls from about 12 GB to 6.3 GB.
• Weights that arrive a stage at a time. The pipeline builds each stage's models when that stage runs, instead of loading all 25 GiB before the first case: the first stage starts about 20 s in rather than after a 102 s load, and the rest of the stack is fetched on a background thread while the GPU works. --low-ram additionally drops each stage's weights once a case is done with them, so a resident server or a long batch holds one stage rather than all of them.
• Resumable downloads. scripts/fetch.py pulls the ~30 GB of weights with parallel HTTP range requests and resumes every chunk it has to retry, because pip and huggingface_hub stalled on long transfers here.
• An optional half-precision copy of the weights. One command — convert_weights_fp16.bat, or scripts/convert_weights_fp16.py — writes fp16 copies of the eight fp32 checkpoints the pipeline halves anyway (21.45 GiB down to 11.47 GiB), verifies them tensor by tensor, and switches weights/pipeline.local.json over to them, so from then on every run uses them with no extra flags. The originals are never modified, revert_weights_fp16.bat undoes it, and scripts/check_fp16_weights.py proves the copies bit-identical to what the fp32 files produce. They also take about 15 s off each --low-ram case, which reloads the weights every time.
• The fp32 originals can be deleted afterwards. A run reads the copies, so once the check above has passed the eight .pt files are only needed for the checkpoint-faithful float32 and --no-low-vram modes; deleting them takes weights/ from 41 GiB to 19 GiB. The tools stay honest about it: the local config still points at the copies (the manifest records what each came from, and a missing original is not a mismatch), check_fp16_weights.py stops with "cannot verify" instead of reporting a pass, and convert_weights_fp16.py --revert refuses rather than leaving the fp32 config pointing at nothing. scripts/fetch.py weights brings the originals back.
• A web UI (webui.py): load 2-4 images, watch progress, inspect the GLB, download it, and optionally save the baked texture maps beside it.
• Texture maps on request. --save-textures (and the UI checkbox, ticked by default) writes the pristine 2048² maps next to the GLB: basecolor.png (RGBA) and metallic_roughness.png (G = roughness, B = metallic).
• Unchanged numerics. The two optimisations made to the model code are bit-exact, and each ships with the check script that proves it (section 5 of the notes). Nothing that affects output quality is altered.

Requirements

Install

git clone https://github.com/HardeNNN/UniForge3D-Low-VRAM
cd UniForge3D-Low-VRAM
python scripts\fetch.py wheels      # torch, torchvision, flash-attn and the 5 CUDA extension wheels -> whl/
scripts\install_windows.ps1         # venv + local wheels + pinned dependencies + web UI
python scripts\fetch.py weights     # the 17 model files -> weights/  (~30 GB)
python scripts\fetch.py extras      # dinov3 + RMBG-2.0 -> models/   (unzips on completion)
python scripts\make_local_config.py # weights/pipeline.local.json

Then, optionally, halve the fp32 checkpoints once — it saves about 10 GB of disk, and weights\pipeline.local.json prefers the copies from then on, so nothing else changes:

scripts\convert_weights_fp16.bat    # convert, verify, switch over; revert_weights_fp16.bat undoes it

Every step is resumable: re-run it after an interruption and it continues from what is already on disk. fetch.py also takes --jobs N (files at once) and --connections N (range chunks in flight). Run the download steps with Python 3.11 — every wheel here is cp311, and fetch.py wheels says so instead of assembling an environment that cannot run. Finish with scripts\check_env.py (below).

Web UI

.\.venv\Scripts\python.exe webui.py          # http://127.0.0.1:7860
.\.venv\Scripts\python.exe webui.py --low-ram # one stage of weights resident at a time

There are double-click launchers for both: start_webui.bat and start_webui_lowram.bat. They run these same commands from the repository root and pass any extra flags through, so start_webui.bat --port 8000 --open works. They need no weight flags: weights\pipeline.local.json already prefers the half-precision copies once convert_weights_fp16.bat has run.

Load 2-4 photos of one object from different angles — the views are sparse and unposed, so order does not matter. Jobs run one at a time, because that is all the card holds. Each job writes its own directory under outputs/webui/, holding a copy of the exact images it ran on, prediction.glb and — with the texture box ticked, as it is by default — the baked maps under textures/. So a result stays reproducible.

Weights load a stage at a time, so there is no long wait before the first progress line: the first stage starts as soon as its own models are in memory, and the rest of the stack is loaded while the GPU works. --low-ram keeps only the stage being run in memory, which bounds what a resident server holds at the cost of reloading the weights for every job.

--port, --host and --open are available, along with the residency flags above. The server binds to the loopback interface and has no public share link. The interactive viewer is Gradio's Babylon component, which needs WebGPU: with WebGPU disabled in the browser the viewer stays empty, and the GLB preview and download still work.

Command line

.\.venv\Scripts\python.exe infer.py --config weights\pipeline.local.json --vram-debug

Cases are directories of images under --input (default assets\, which ships case01 to case18), and --input may also be a single case directory. A case whose prediction.glb already exists is skipped, so a batch is resumable. --limit N, --overwrite, --seed N, --watch SECONDS, --save-textures, --low-ram, --prefetch and the precision flags are listed in section 3 of the notes.

--weights-dtype float16 (the default under --low-vram), float32 and auto. auto means "whatever the mode would use anyway": fp16 with the default --low-vram, and each checkpoint's published precision with --no-low-vram. Only the last of those is checkpoint-faithful, and the half-precision copies cannot provide it either, so point those runs at a config built for the originals:

.\.venv\Scripts\python.exe scripts\make_local_config.py --fp32 --out weights\pipeline.local.fp32.json
.\.venv\Scripts\python.exe infer.py --config weights\pipeline.local.fp32.json --weights-dtype float32

On the tested machine the first denoiser step starts 21 s in, and one case costs about 240 s (assets\case01, measured end to end) up to roughly four times that for the most detailed example (assets\case05).

What a run writes

outputs/case01/
  prediction.glb                     the asset, PBR textures embedded
  textures/basecolor.png             2048x2048 RGBA, written with --save-textures
  textures/metallic_roughness.png    2048x2048, G = roughness, B = metallic

--save-textures writes the maps from the pristine in-memory images, so they are the same maps that went into the GLB. The web UI always writes into outputs/webui/<job>/, with a copy of the input images under input/ so a result can be reproduced exactly.

Verification

Every claim above has a script. They run on CPU unless noted, and most take a second:

Repository layout

infer.py                 batch/CLI entry point
webui.py                 Gradio web UI
start_webui.bat          launcher: default residency
start_webui_lowram.bat   launcher: --low-ram
convert_weights_fp16.bat launcher: make and use the half-precision copies
revert_weights_fp16.bat  launcher: delete them and go back
WINDOWS_LOWVRAM.md       the measurement notes: VRAM, memory, timings, decisions
assets/                  example cases, case01 .. case18
scripts/                 installer, fetcher, config generator, verification, profiling
uniforge3d/models/store.py    stage-by-stage weight residency
uniforge3d/models/loaders.py  per-group loading and the dtype policy
uniforge3d/pipelines/         the pipeline itself

Weights and licences

Nothing is committed here but code: the install fetches the weights.

• xibushu/UniForge3D — the UniForge3D checkpoints.
• microsoft/TRELLIS.2-4B and microsoft/TRELLIS-image-large — the TRELLIS.2 decoders and base DiT.
• The ungated mirror release of the TRELLIS.2-stableprojectorz project for the two gated models, facebook/dinov3-vitl16-pretrain-lvd1689m and briaai/RMBG-2.0, so no Hugging Face token is needed.

The code in this repository is Apache-2.0, as upstream. The weights keep their own terms: the two gated models ship under Meta's DINOv3 licence and BRIA's RMBG-2.0 terms, both of which carry commercial-use conditions. Read those model cards before commercial use.

Troubleshooting

• The 3D preview is blank in the web UI. The viewer is Gradio's Babylon component and needs WebGPU. Enable it in the browser, or use the GLB download — the file is fine either way.
• Loading takes a long time on the first case. That is the 25 GiB of checkpoints being read. Staged loading starts the first stage after ~20 s and fetches the rest in the background; --low-ram trades that back for reloading each group per case (~68 s), and the half-precision copies take about 15 s off that.
• The machine pages on 16 GB of RAM. Expected: one group's load peaks at 23 GB, because the model is built in fp32 and halved afterwards. --low-ram bounds what a run retains, not that transient. A build-in-fp16 loader is designed but not written (section 5).
• CUDA out of memory. Use --low-ram, and --no-prefetch so no later stage's weights are held in host memory while the card works.
• A run with --weights-dtype float32 warns about half-precision copies. The copies hold fp16 values and cannot be raised back. Use the --fp32 config from the command-line section for checkpoint-faithful runs.
• The fetch stalls. Re-run it; every chunk resumes. --jobs 1 --connections 4 is the gentlest setting.
• A run dies with a CUDA illegal memory access, or Stage1 decoded an empty sparse structure. The access violations have a known cause: the host running out of commit, which Windows reports that way. Check how much is already committed (Get-CimInstance Win32_OperatingSystem → FreeVirtualMemory) before blaming the card — a resident web UI plus a CLI batch is ~40 GB, and the page file here is capped at 32 GB. Re-run the case; the empty structure is a rare sampling failure on the random noise.
• python infer.py with no --config starts downloading from Hugging Face. Without it, infer.py falls back to the upstream --model xibushu/UniForge3D path. Pass --config weights\pipeline.local.json, which is what the install produces and what every command above uses.

Acknowledgements

This fork stands on UniForge3D, TRELLIS.2, VGGT, CuMesh, FlexGEMM, nvdiffrast and xatlas. The Windows path follows TRELLIS.2-stableprojectorz by Igor Aherne, which is where the prebuilt wheel builds and the ungated model mirror come from.

Citation

@article{chen2026uniforge3d,
  title   = {UniForge3D: Joint 3D Reconstruction and Generation in a Shared Anchor-Guided Space},
  author  = {Chen, Wenjue and Chen, Wenyue and Zheng, Heliang and Jia, Rongfei and Liu, Yuan and Li, Meng},
  journal = {arXiv preprint arXiv:2610.15357},
  year    = {2026}
}

Licence

Apache-2.0, the same licence as upstream — see LICENSE. This is a modified copy of UniForge3D: the staged-residency changes, the Windows installer, the downloader, the diagnostic scripts and the web UI are additions, and the differences from upstream are described in WINDOWS_LOWVRAM.md.
