LantErn: Latent Visual Reasoning

⚠️ Active development. Both papers are published, but this codebase is still being extended with new features. APIs and training pipelines may change without notice.

---

Updates

April 2026 — LantErn accepted at the ICLR 2026 Workshop: Multimodal Intelligence 🇧🇷 🎉🎉

---

Papers

This codebase covers two works:

1. LantErn: Latent Visual Reasoning in Vision-Language Models

Introduces Latent Visual Reasoning (LVR) tokens — compressed visual embeddings interleaved with text during reasoning. Extends Qwen2.5-VL with SFT and GRPO training to emit non-verbalized visual representations.

2. What's Holding Back Latent Visual Reasoning?

Follow-up work using the Tetris synthetic analogy benchmark to diagnose what prevents LVR from working. Isolates representation failure from interface/routing failure via controlled experiments.

Models on HuggingFace: AGViveiros/lantern-models

---

Overview

LantErn extends Qwen2.5-VL to produce interleaved text and Latent Visual Reasoning (LVR) tokens. Instead of always describing what it sees in words, the model can emit compressed visual embeddings (<|lvr_start|>...<|lvr_end|>) during its reasoning chain.

Special tokens:

• <|lvr_start|> — begins a latent reasoning block
• <|lvr_sep|> — placeholder replaced by compressed visual embeddings during training
• <|lvr_end|> — ends a latent reasoning block

Training loss: γ · CE_loss(text tokens) + MSE_loss(latent positions)

---

Installation

git clone https://github.com/GuilhermeViveiros/LantErn.git
cd LantErn
pip install -r requirements.txt
pip install -e .
export PYTHONPATH=/path/to/LantErn:$PYTHONPATH

---

Training

SFT — VisCoT (3B)

sbatch scripts/finetune_lantern_sft_3b.sh

SFT — VisCoT (7B)

sbatch scripts/finetune_lantern_sft_7b.sh

SFT — Tetris (LVR model)

sbatch scripts/finetune_tetris_sft_3b.sh

SFT — Tetris (NTP baseline, no LVR)

sbatch scripts/finetune_tetris_ntp_3b.sh

GRPO (RL fine-tuning from SFT checkpoint)

sbatch scripts/finetune_lantern_rl_3b.sh

Key hyperparameters (see src/params.py for all defaults):

Add --dummy True to any training command to run on the first 1000 samples for quick testing.

---

Evaluation

VisCoT / BLINK / V* (combined)

python -m evals.viscot_blink_vstar_eval \
    --model_ref /path/to/checkpoint \
    --benchmarks viscot blink vstar \
    --output_dir results/

Latent Retrieval (R@k, MRR)

python -m evals.latent_retrieval_eval \
    --model_ref /path/to/checkpoint \
    --output_dir results/latent_retrieval

OOD Generalization (Tetris held-out shapes)

python -m evals.generalization \
    --checkpoints_dir /path/to/checkpoints \
    --held_out_path /path/to/analogy_data/held_out/held_out.json \
    --eval_path /path/to/analogy_data/eval.json \
    --n_samples 200 --batch_size 8

---

Tetris Synthetic Benchmark

The Tetris benchmark (synthetic/Tetris/) is a controlled analogy task used in Paper 2. The model is given a visual analogy over Tetris pieces and must identify the correct transformation applied to a query shape.

Generate the dataset:

# Training + eval split
python -m synthetic.Tetris.create_dataset \
    --output_dir /path/to/analogy_data

# Held-out shapes (for generalization eval)
python -m synthetic.Tetris.create_dataset \
    --output_dir /path/to/analogy_data \
    --held_out

---

Data Format (SFT)

{
  "question": "...",
  "img_path": "/path/to/image.jpg",
  "bboxs": [[x1, y1, x2, y2], ...],
  "reasoning_traces": {
    "pre_visual_text_think": "...",
    "post_visual_latent_reasoning": ["...", "..."],
    "text_think": "...",
    "answer": "..."
  }
}

len(bboxs) must equal len(post_visual_latent_reasoning).

---

Project Structure

LantErn/
├── src/
│   ├── models/             # load_model(), patched Qwen2.5-VL forward
│   ├── train/              # train_sft.py, train_grpo.py
│   ├── trainer/            # LantErnSFTrainer, LantErnGRPOTrainer
│   ├── lantern_generate/   # Custom token-by-token generation loop
│   ├── datasets/           # SFT dataset loaders (viscot, tetris, monet)
│   ├── rl/                 # GRPO reward functions
│   └── params.py           # All config dataclasses
├── evals/
│   ├── viscot_blink_vstar_eval.py   # Main eval (VisCoT, BLINK, V*)
│   ├── latent_retrieval_eval.py     # Retrieval metrics (R@k, MRR)
│   └── generalization.py            # OOD generalization on Tetris
├── synthetic/Tetris/       # Tetris analogy dataset generator
├── scripts/                # SLURM training scripts + DeepSpeed configs
└── experiments/            # Analysis notebooks and notes

---

Citation

If you use this work, please cite:

@article{lantern2025,
  title={LantErn: Latent Visual Reasoning in Vision-Language Models},
  author={Viveiros, Guilherme and others},
  journal={arXiv preprint arXiv:2603.25629},
  year={2025}
}

Paper 2 citation coming soon.
