REPA-E: Unlocking VAE for End-to-End Tuning of Latent Diffusion Transformers

Xingjian Leng^1*   ·   Jaskirat Singh^1*   ·   Yunzhong Hou¹   ·   Zhenchang Xing²  ·   Saining Xie³  ·   Liang Zheng¹ 

¹ Australian National University   ²Data61-CSIRO   ³New York University  
_{^*Project Leads}

🌐 Project Page   🤗 Models   📃 Paper  

Overview

We address a fundamental question: Can latent diffusion models and their VAE tokenizer be trained end-to-end? While training both components jointly with standard diffusion loss is observed to be ineffective — often degrading final performance — we show that this limitation can be overcome using a simple representation-alignment (REPA) loss. Our proposed method, REPA-E, enables stable and effective joint training of both the VAE and the diffusion model.

REPA-E significantly accelerates training — achieving over 17× speedup compared to REPA and 45× over the vanilla training recipe. Interestingly, end-to-end tuning also improves the VAE itself: the resulting E2E-VAE provides better latent structure and serves as a drop-in replacement for existing VAEs (e.g., SD-VAE), improving convergence and generation quality across diverse LDM architectures. Our method achieves state-of-the-art FID scores on ImageNet 256×256: 1.12 with CFG and 1.69 without CFG.

News

📅 [Oct 2025] 🚨 Released REPA-E for T2I 🚨 — a family of End-to-End Tuned VAEs:

• Family of end-to-end tuned VAEs:
  • T2I VAEs: FLUX-VAE, SD-3.5-VAE, Qwen-Image-VAE
  • ImageNet VAEs: SD-VAE, IN-VAE, VA-VAE
• End-to-end training generalizes to T2I: E2E-VAEs achieve better T2I generation quality across multiple resolutions (256×256, 512×512) compared to their standard VAE counterparts, without requiring additional representation alignment losses
• SOTA results on ImageNet 256×256: FID 1.12 with CFG and 1.69 without CFG. The generated npz files can be found here
• All models available as Hugging Face-compatible AutoencoderKL checkpoints — load directly with diffusers API, no custom wrapper needed

📅 [Jun 2025] REPA-E accepted at ICCV 2025!

📅 [Apr 2025] Paper, code, and pretrained models available on GitHub and Hugging Face.

🆕 Model Releases: Hugging Face Compatible VAEs

We are excited to release the family of End-to-End tuned VAEs as Hugging Face AutoencoderKL compatible checkpoints, ready to use with diffusers out of the box. This release includes both our text-to-image VAEs and ImageNet-trained VAEs.

Note: Please refer to our T2I codebase training codebase to reproduce the text-to-image experiments with end-to-end VAEs.

⚡️ Quickstart

from diffusers import AutoencoderKL

# Load end-to-end tuned VAE (ImageNet VAE example)
vae = AutoencoderKL.from_pretrained("REPA-E/e2e-vavae-hf").to("cuda")

# Or load a text-to-image VAE
vae = AutoencoderKL.from_pretrained("REPA-E/e2e-flux-vae").to("cuda")

# Use in your pipeline with vae.encode(...) / vae.decode(...)

🧩 Complete Example

Full workflow for encoding and decoding images:

from io import BytesIO
import requests
from diffusers import AutoencoderKLQwenImage
import numpy as np
import torch
from PIL import Image

response = requests.get("https://raw.githubusercontent.com/End2End-Diffusion/fuse-dit/main/assets/example.png")
device = "cuda"

image = torch.from_numpy(
    np.array(
        Image.open(BytesIO(response.content))
    )
).permute(2, 0, 1).unsqueeze(0).to(torch.float32) / 127.5 - 1
image = image.to(device)

vae = AutoencoderKLQwenImage.from_pretrained("REPA-E/e2e-qwenimage-vae").to(device)

# Add frame dimension (required for QwenImage VAE)
image_ = image.unsqueeze(2)

with torch.no_grad():
    latents = vae.encode(image_).latent_dist.sample()
    reconstructed = vae.decode(latents).sample

# Remove frame dimension
latents = latents.squeeze(2)
reconstructed = reconstructed.squeeze(2)

Getting Started

1. Environment Setup

To set up our environment, please run:

git clone https://github.com/REPA-E/REPA-E.git
cd REPA-E
conda env create -f environment.yml -y
conda activate repa-e

2. Prepare the training data

Download and extract the training split of the ImageNet-1K dataset. Once it's ready, run the following command to preprocess the dataset:

python preprocessing.py --imagenet-path /PATH/TO/IMAGENET_TRAIN

Replace /PATH/TO/IMAGENET_TRAIN with the actual path to the extracted training images.

3. Train the REPA-E model

To train the REPA-E model, you first need to download the following pre-trained VAE checkpoints:

• 🤗 SD-VAE (f8d4): Derived from the Stability AI SD-VAE, originally trained on Open Images and fine-tuned on a subset of LAION-2B.
• 🤗 IN-VAE (f16d32): Trained from scratch on ImageNet-1K using the latent-diffusion codebase with our custom architecture.
• 🤗 VA-VAE (f16d32): Taken from LightningDiT, this VAE is a visual tokenizer aligned with vision foundation models during reconstruction training. It is also trained on ImageNet-1K for high-quality tokenization in high-dimensional latent spaces.

Recommended directory structure:

pretrained/
├── invae/
├── sdvae/
└── vavae/

Once you've downloaded the VAE checkpoint, you can launch REPA-E training with:

accelerate launch train_repae.py \
    --max-train-steps=400000 \
    --report-to="wandb" \
    --allow-tf32 \
    --mixed-precision="fp16" \
    --seed=0 \
    --data-dir="data" \
    --output-dir="exps" \
    --batch-size=256 \
    --path-type="linear" \
    --prediction="v" \
    --weighting="uniform" \
    --model="SiT-XL/2" \
    --checkpointing-steps=50000 \
    --loss-cfg-path="configs/l1_lpips_kl_gan.yaml" \
    --vae="f8d4" \
    --vae-ckpt="pretrained/sdvae/sdvae-f8d4.pt" \
    --disc-pretrained-ckpt="pretrained/sdvae/sdvae-f8d4-discriminator-ckpt.pt" \
    --enc-type="dinov2-vit-b" \
    --proj-coeff=0.5 \
    --encoder-depth=8 \
    --vae-align-proj-coeff=1.5 \
    --bn-momentum=0.1 \
    --exp-name="sit-xl-dinov2-b-enc8-repae-sdvae-0.5-1.5-400k"

Click to expand for configuration options

Then this script will automatically create the folder in exps to save logs and checkpoints. You can adjust the following options:

• --output-dir: Directory to save checkpoints and logs
• --exp-name: Experiment name (a subfolder will be created under output-dir)
• --vae: Choose between [f8d4, f16d32]
• --vae-ckpt: Path to a provided or custom VAE checkpoint
• --disc-pretrained-ckpt: Path to a provided or custom VAE discriminator checkpoint
• --models: Choose from [SiT-B/2, SiT-L/2, SiT-XL/2, SiT-B/1, SiT-L/1, SiT-XL/1]. The number indicates the patch size. Select a model compatible with your VAE architecture.
• --enc-type: [dinov2-vit-b, dinov2-vit-l, dinov2-vit-g, dinov1-vit-b, mocov3-vit-b, mocov3-vit-l, clip-vit-L, jepa-vit-h, mae-vit-l]
• --encoder-depth: Any integer from 1 up to the full depth of the selected encoder
• --proj-coeff: REPA-E projection coefficient for SiT alignment (float > 0)
• --vae-align-proj-coeff: REPA-E projection coefficient for VAE alignment (float > 0)
• --bn-momentum: Batchnorm layer momentum (float)

4. Use REPA-E Tuned VAE (E2E-VAE) for Accelerated Training and Better Generation

This section shows how to use the REPA-E fine-tuned VAE (E2E-VAE) in latent diffusion training. E2E-VAE acts as a drop-in replacement for the original VAE, enabling significantly accelerated generation performance. You can either download a pre-trained VAE or extract it from a REPA-E checkpoint.

Step 1: Obtain the fine-tuned VAE from REPA-E checkpoints:

• Option 1: Download pre-trained REPA-E VAEs directly from Hugging Face:

  • 🤗 E2E-SDVAE
  • 🤗 E2E-INVAE
  • 🤗 E2E-VAVAE

  Recommended directory structure:

  pretrained/
  ├── e2e-sdvae/
  ├── e2e-invae/
  └── e2e-vavae/


• Option 2: Extract the VAE from a full REPA-E checkpoint manually:

  python save_vae_weights.py \
      --repae-ckpt pretrained/sit-repae-vavae/checkpoints/0400000.pt \
      --vae-name e2e-vavae \
      --save-dir exps


Step 2: Cache latents to enable fast training:

accelerate launch --num_machines=1 --num_processes=8 cache_latents.py \
    --vae-arch="f16d32" \
    --vae-ckpt-path="pretrained/e2e-vavae/e2e-vavae-400k.pt" \
    --vae-latents-name="e2e-vavae" \
    --pproc-batch-size=128

Step 3: Train the SiT generation model using the cached latents:

accelerate launch train_ldm_only.py \
    --max-train-steps=4000000 \
    --report-to="wandb" \
    --allow-tf32 \
    --mixed-precision="fp16" \
    --seed=0 \
    --data-dir="data" \
    --batch-size=256 \
    --path-type="linear" \
    --prediction="v" \
    --weighting="uniform" \
    --model="SiT-XL/1" \
    --checkpointing-steps=50000 \
    --vae="f16d32" \
    --vae-ckpt="pretrained/e2e-vavae/e2e-vavae-400k.pt" \
    --vae-latents-name="e2e-vavae" \
    --learning-rate=1e-4 \
    --enc-type="dinov2-vit-b" \
    --proj-coeff=0.5 \
    --encoder-depth=8 \
    --output-dir="exps" \
    --exp-name="sit-xl-1-dinov2-b-enc8-ldm-only-e2e-vavae-0.5-4m"

For details on the available training options and argument descriptions, refer to Section 3.

5. Generate samples and run evaluation

You can generate samples and save them as .npz files using the following script. Simply set the --exp-path and --train-steps corresponding to your trained model (REPA-E or Traditional LDM Training).

torchrun --nnodes=1 --nproc_per_node=8 generate.py \
    --num-fid-samples 50000 \
    --path-type linear \
    --mode sde \
    --num-steps 250 \
    --cfg-scale 1.0 \
    --guidance-high 1.0 \
    --guidance-low 0.0 \
    --exp-path pretrained/sit-ldm-e2e-vavae \
    --train-steps 4000000 \

Click to expand for sampling options

You can adjust the following options for sampling:

• --path-type linear: Noise schedule type, choose from [linear, cosine]
• --mode: Sampling mode, [ode, sde]
• --num-steps: Number of denoising steps
• --cfg-scale: Guidance scale (float ≥ 1), setting it to 1 disables classifier-free guidance (CFG)
• --guidance-high: Upper guidance interval (float in [0, 1])
• --guidance-low: Lower guidance interval (float in [0, 1], must be < --guidance-high)
• --exp-path: Path to the experiment directory
• --train-steps: Training step of the checkpoint to evaluate
• --label-sampling: Class label sampling strategy, [equal, random] (default: equal)

You can then use the ADM evaluation suite to compute image generation quality metrics, including gFID, sFID, Inception Score (IS), Precision, and Recall.

Quantitative Results

Tables below report generation performance using gFID on 50k samples, with and without classifier-free guidance (CFG). We compare models trained end-to-end with REPA-E and models using a frozen REPA-E fine-tuned VAE (E2E-VAE). Lower is better. All linked checkpoints below are hosted on our 🤗 Hugging Face Hub. To reproduce these results, download the respective checkpoints to the pretrained folder and run the evaluation script as detailed in Section 5.

A. End-to-End Training (REPA-E)

* The "Tokenizer" column refers to the initial VAE used for joint REPA-E training. The final (jointly optimized) VAE is bundled within the generation model checkpoint.

Click to expand for CFG parameters

• a: --cfg-scale=2.2, --guidance-low=0.0, --guidance-high=0.65
• b: --cfg-scale=1.8, --guidance-low=0.0, --guidance-high=0.825
• c: --cfg-scale=1.9, --guidance-low=0.0, --guidance-high=0.825

---

B. Traditional Latent Diffusion Model Training (Frozen VAE)

In this setup, the VAE is kept frozen and only the generator is trained. Models using our E2E-VAE (fine-tuned via REPA-E) consistently outperform baselines such as SD-VAE and VA-VAE, achieving state-of-the-art performance when incorporating the REPA alignment objective.

Note: The results for the last three rows (REPA, LightningDiT, and E2E-VAE) are obtained using the class-balanced sampling protocol (50 images per class).

Click to expand for CFG parameters

• †: --cfg-scale=2.4, --guidance-low=0.0, --guidance-high=0.73

Acknowledgement

This codebase builds upon several excellent open-source projects, including:

• 1d-tokenizer
• edm2
• LightningDiT
• REPA
• Taming-Transformers

We sincerely thank the authors for making their work publicly available.

📚 Citation

If you find our work useful, please consider citing:

@article{leng2025repae,
  title={REPA-E: Unlocking VAE for End-to-End Tuning with Latent Diffusion Transformers},
  author={Xingjian Leng and Jaskirat Singh and Yunzhong Hou and Zhenchang Xing and Saining Xie and Liang Zheng},
  year={2025},
  journal={arXiv preprint arXiv:2504.10483},
}

@misc{repaet2i2025,
    title={Family of End-to-End Tuned VAEs for Supercharging T2I Diffusion Transformers},
    author={Leng, Xingjian and Singh, Jaskirat and Murdock, Ryan and Smith, Ethan and Li, Rebecca and Hou, Yunzhong and Xing, Zhenchang and Xie, Saining and Zheng, Liang},
    howpublished={\url{https://end2end-diffusion.github.io/repa-e-t2i/}},
    year={2025}
}
